Garage Tek GT1005A Operating instructions

SHOWN WITH OPENED DOORS
INSTALLATION / OWNER'S MANUAL GT1005A WALL CABINET
516-621-4300 WWW.GARAGETEK.COM
PAGE 1OF 4 REV AUG 2021
GT1005A, WALL CABINET PRODUCT INFORMATION
RATINGS:
MAXIMUM WEIGHT CAPACITY: 100LBS, PER SHELF
MAXIMUM WEIGHT CAPACITY: 20LBS, CABINET BOTTOM
CAUTION: NOT INTENDED FOR STORAGE OF FLAMMABLE OR CAUSTIC CHEMICALS.
WARRANTY
GarageTek, INC. WARRANTS TO THE ORIGINAL PURCHASER ONLY THAT THE ENCLOSED PRODUCT IS FREE FROM MATERIAL
AND WORKMANSHIP DEFECTS UNDER NORMAL, HOUSEHOLD USE FOR TEN (10) YEARS FROM DATE OF PURCHASE. DEFECTIVE
PRODUCT OR PARTS WILL BE REPAIRED OR REPLACED AT HE OPTION OF GarageTek WITHOUT CHARGE TO THE ORIGINAL
PURCHASER.
THIS LIMITED WARRANTY DOES NOT APPLY TO DAMAGE RESULTING FROM ACCIDENT, NEGLECT, MISUSE, COMMERICAL USE,
ALTERATION NOT IN ACCORDANCE WITH THESE INSTUCTIONS OR REPAIRS MADE OR ATTEMPTED BY UNAUTHORIZED PERSONS.
THIS MANUFACTURE'S LIABILITY HEREUNDER IS LIMITED SOLELY TO THE REPAIR AND REPLACEMENT OF THE DEFECTIVE PRODUCT
OR PART AND THE MANUFACTURER SHALL IN NO EVENT TO LIABLE FOR ANY INCIDENT OR CONSEQUENTIAL DAMAGES WHICH
MAY RESULT FROM ANY DEFCT IN MATERIAL OR WORKMANSHIP OR FROM THE BREACH OR EXPRESS OR IMPLIED WARRANTY.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OR CONSEQUENTIAL DAMAGES, OR LIMITATION OF HOW LONG
AN IMPLIED WARRANTY LASTS, SO THE ABOVE INFORMATION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.
INSTALLED BY: ______________________________________________________________________PHONE______________________________

B
A
C
D
E
F
G
J
N
H
K
P
ASSEMBLED CABINET
STEP 1D
A
STEP 1A
STEP 1B
B
A
CURVED
EDGE
STEP 1C
E
B
I
A: BASE/ TOP X2
B: SIDE PANEL X6
C: SHELF X2
D: CAP X8
E: HINGE X 4
F: POST (NOT SUPPLIED) X4
G: HANDLE SET X2
H: SCREW, 1 1/2" LONG X2
I: SHELF HOLDER STRIP X8
J: BIN FOR DOOR X1
K: SCREW, 7/8" LONG X2
L: -----------
M: ----------
N: PANEL BRACKET (NOT SUPPLIED)
GT100 ORDERED FROM DEMO
O: SCREW#8X1 PPHSMS
(NOT SUPPLIED) P/N 12-0-81-0
FROM WEBSON
P: GarageTek ADHESIVE LABEL
STEP 1: ASSEMBLE PANELS TO BASE/TOP
ORIENTATE BASE/TOP (A) WITH SHORT POSTS FACING UPWARD AND THE SIDE HAVING THE CURVED EDGE FACING A.
FRONT.
PRESS PANEL (B), QTY 4, ONTO THE BASE. THE SMOOTH SRFACE OF THESE PANELS FACE OUTWARD. B.
ASSEMBLE THE HINGES (E), QTY 4, ONTO THE REMAINING PANELS QTY 2, AS SHOWN. C.
ASSEMBLE THESE (2) HINGED DOORS TO THE BASE. PRESS/ SNAP THE BASE/TOP (A) ONTO THE PANELS TOPS. D.
REMEMBER TO ORIENTATE THE TOP AS THE BASE ORIENTATED IN STEP 1A.
PAGE 2 OF 4 REV AUG 2021
PACKAGE CONTENT

FRONT
OF CABINET
STEP 2B
D
F
A
DETAIL A
STEP 2C
F
D
35 1/4"
F
1/2"
STEP 2 AND 3
ARE CRITICAL TO HAVING THE CABINET HANG ON THE TEKPANEL WALL WITH HEAVY LOADS.
PVC
1/2" PIPE
SCHEDULE 40
X4
STEP 2A
2. ASSEMBLE POSTS:
A. LOCALLY PURCHASED 10FT LENGTHS OF PVC 1/2" PIPE, SCHEDULE 40. CUT INTO LENGTHS OF 35 1/4" TO MAKE
THE POST (F). X4
B. THE POSTS (F) TO BE INSTALLED IN THE FOUR LOCATIONS SHOWN.
C. SLIDE EACH POSTFROM THE TOP HOLES THROUGH THE CABINET PAST THE BOTTOM HOLES.
LOCATE THE POST INSIDE THE HOLE OF EACH BOTTOM CAP (D) AND PUSH THE CAP (D) UP INTO THE BOTTOM
HOLE OF THE CABINET. AT THE TOP, LOCATE EACH POST TO THE INSIDE THE HOLE OF EACH TOP CAP (D) AND
PUSH THE CAP (D) INTO THE TOP CABINET HOLE.
3. SECURE POSTS AND INSTALL BRACKET
A. WITH THE CABINET ON A SOLID SURFACE, PRESS DOWN ON THE CABINET TOP AND DRIVE SCREW (O) X6 INTO THE
POSITIONS SHOWN. (PRESS ING DOWN ON THE CABINET TOP TAKES OUT THE CLEARANCE FROM "LOOSE" ASSEMBLY
FITS AND INSURES THE DOORS SHUT PROPERLY WHEN HANGING ON THE TekPanel WALL.)
B. LOCATE THE PANEL BRACKET (N) ON THE BACK OF THE CABINET AND SECURE IN PLACE WITH X8 TekPanel SCREWS
1 5/8"LONG. THE BRACKET HAS SELF LOCATING TABS FOR THE TOP , BUT BE SURE TO CENTER HORIZONTALLY ON THE
PREVIOUSLY INSTALLED POSTS (F). AGAIN, PRESS DOWN ON THE CABINET TOP TO TAKE OUT THE CLEARANCE WHEN
DRIVING THE SCREWS. REPEAT OF THE OTHER SIDE.
PAGE 3 OF 4 REV AUG 2021

J
B
DETAIL B
SCALE 1 : 6
I
I
I
P
G
C
C
DETAIL C
SCALE 1 : 12
PADLOCK
HOLES
C
INSTALL DOOR BIN, SHELVES AND LOGO
SNAP THE DOOR BIN (J) IN THE TRACKS ON THE INSIDE OF THE DOOR. A.
SNAP THE SHELF HOLDER STRIPS (i) X8 , INTO THE VERTICAL TACKS AROUND THE INSIDE OF THE CABINET. THERE ARE B.
X4 STRIPS PER LOCATION. THE STRIPS WITH THE ARCHED HOOD ARE IN THE BACK OF THE CABINET AND THE FLAT
TOPPED STRIPS ARE ON THE SIDES.
PLACE THE SHELVES (C) X2, ON THE STRIP HOLDER STRIPS (i). C.
APPLY THE GT LOGO (P), X1, ON THE LOCATION SHOWN. D.
ADDITIONAL SHELVES (C) CAN BE PURCHASED AS P/N: GT1007.
INSTALL HANDLE SET
A. ORIENTATE THE HANDLE SET (G) AS SHOWN WITH THE PACKLOCK HOLES IN-LINE ON EACH HANDLE AND ARE AT THE
BOTTOM OF THE HANDLE SET.
B. DO NOT USE A POWER TOOL. HAND SCREW AND SECURE THE HANDLE WITH A 1 1/2" SCREW (H) & 7/8" LONG SCREW
(K) PER SIDE SIDE.
C. ADJUST THE HANDLES TO BE IN-LINE AND LEVEL BY LOOSENING AND RETIGHTENING THE SCREWS AS NEEDED.
PAGE 4 OF 4 REV AUG 2021
