Garage Tek GT2011E User manual

INSTALLATION INSTRUCTIONS
GT2011E GOLF CENTER
CARTON CONTENTS
ITEM QUANTITY DESCRIPTION
A 1 SQUARE TUBE
B 1 TOP BAR W/ PANEL BRACKET
C 4 HANGER HOOK
D 2 SHELF
E 2 CORNER BRACE
F 2 SIDE FRAME
G 4 1/2" LONG SCREW
H 12 1 1/2” LONG SCREW
TOOLS REQUIRED - ELECTRIC DRIVER OR DRILL & PHILLIPS BIT
PG 1 QUESTIONS ???? CALL 1-866 664 2724 REV 1, 8/11

GOLF CENTER - ASSEMBLY INSTRUCTIONS
STEP 1 STEP 2
STEP #1: CHECK PARTS RECEIVED.
STEP #2: POSITION THE PARTS AS SHOWN AN USE THE 1 ½” LG SCREWS TO FASTEN IN SIX PLACES.
IMPORTANT: THE OPEN MESH ON THE SIDE FRAMES FACES OUT.
STEP 3 STEP 4
STEP #3: FLIP THE ASSEMBLY AND FASTEN AGAIN IN SIX PLACES.
STEP #4: USING THE 1/2” LG SCREWS, FASTEN THE CORNER BRACES.
STEP # 5 COMPLETE
STEP #5: PLACE THE FOUR HANGER HOOKS INTO THE HOLES PROVIDED.
STEP #6: MOUNT ON THE SLATWALL OR WALL TRAK USING THE TOP BAR W/ PANEL BRACKET (ITEM B).
PG 2 QUESTIONS ???? CALL 1-866 664 2724 REV 1, 8/11
