Garbin G STARTER PICCOLO User manual

Carefully read the following instructions before installing and starting the equipment.
i
G STARTER
PICCOLO BRAVO DELIZIOSO SUPERIORE
ELECTRIC CONVECTION OVENS
EN
INSTRUCTIONS FOR THE INSTALLATION,
USE AND MAINTENANCE

1 - Introduction
1.1 Reference guide
1.2 General remarks
1.3 Technical characteristics
1.4 Handling, transportation and unloading
1.5 Compliance with the standards and directives
2 - Instructions for installation and maintenance
2.1 Place of installation and placement
2.2 Power and water supply connection
2.3 Safety devices
2.4 Diagnosis of certain faults
2.5 Replacement of certain components
3 - Instructions for use
3.1 Preliminary remarks
3.2 Control panel and brief instructions
3.3 Cleaning and ordinary maintenance of the oven
3.4 Cooking advice
4 - Digital oven programming
4.1 User interface
4.1.1 Function keys
4.1.2 Display Icons
4.1.3 Display
4
4
6
6
6
7
7
8
9
10
11
11
12
13
14
15
16
4.2 Manual operation
4.2.1 Setting temperature values
4.2.2 Setting cooking time values
4.2.3 Manual humidication during cooking
4.2.4 Execution of a cooking cycle in manual mode
4.3 Programmed operation
4.3.1 Storing a new program
4.3.2 Setting temperature values
4.3.3 Setting cooking time values
4.3.4 Setting of steam
4.3.5 Cooking steps in a program
4.3.6 Accessing an already stored program
4.4 Automatic preheating
4.4.1 Disabling automatic preheating
4.5 Other functions
4.5.1 Opening and closing the oven door
4.5.2 Intervention reverse fans
4.6 Signals and alarms
4.7 Absence of voltage
4.8 Hidden menu
17
17
18
18
19
20
20
20
21
21
22
22
22
23
23
23
3
EN
1 - INDEX

1 - INTRODUCTION
4
We thank you for the trust you granted us when you purchased our
product and advise you to carefully read this guide before using the
ovens.
This document contains all the information you need for the correct
use and maintenance of the oven.
The purpose of this guide is to allow the user, most of all the direct
user, to take all the measures and prepare all the equipment and the
necessary materials for a safe and long-lasting use of the oven.
This guide must be consigned to the person in charge of its use who
shall keep it in a suitable place, in order to make it available for consul-
tation and for the ordinary maintenance of the oven. In case the oven
is resold, the guide must be consigned together with it.
This guide is also intended to be used by the technician when per-
forming commissioning and extraordinary maintenance operations.
The intended use and available congurations of the machines are
the only ones approved by the producer; do not attempt to use the
machines in a way which would not comply with the indications sup-
plied by the producer.
The intended use indicated is only valid for machines having full
structural, mechanical and system eciency.
The producer refuses to accept any liability deriving from improper
use or use by untrained personnel, from ‘do-it-yourself’ changes or
repairs performed by unauthorized personnel and from use of non-
original spare parts or non-specic for the oven model.
1.1 Reference guide
Also please pay attention to the text in bold, with LARGER or under-
lined fonts, because they refer to particularly important information
or operations.
The guide must be kept until the nal disposal of the machine in an
adequate place, making sure it is always available for consultation in
its best conservation state. In case of loss or deterioration, the substi-
tute document will have to be requested directly to the producer or
the reseller.
1.2 General remarks
• Carefully read the instructions contained in this guide in order to get
to know the things to watch out for when performing:
- the installation of the oven;
- its maintenance;
- its best use.
• These machines will have to be exclusively destined to the use for
which they have been expressly designed and that is for cooking or
heating food; any other use is to be considered improper and there-
fore dangerous.
• The oven is intended for professional use and must be used by qua-
lied personnel.
• Before exiting the premises of the producer, these machines were
tested and calibrated by expert specialized personnel in order to gua-
rantee the best operation results.
EN

Failure to observe these fundamental rules may compromise
the safety of the oven and therefore cause damage to the user.
The producer company declines all responsibilities in case of
failure to observe the norms contained in this guide, both by
the user and the technician in charge with the installation and
no potential incident or damage caused by such non complian-
ce can be attributed to it.
The producer declines all responsibility for potential inaccura-
cies contained in this manual caused by transcript or printing
errors.
Furthermore it reserves the right to make the product changes
it considers useful or necessary, without compromising the es-
sential characteristics of the product.
1 - INTRODUCTION
• The installation and/or all repairs or calibration that might become ne-
cessary must be performed with maximum diligence and attention by
qualied personnel.
For this reason we advise you to always contact the Dealer who sold
you your machine and make sure you specify the issue, the model and
the serial number of your oven.
• In case of repair and/or replacement of components, extraordinary
maintenance, fault or malfunction, contact only authorized personnel
indicated by the producer since only they have the necessary professio-
nal qualications.
• Only use original spare parts.
• Before the installation, make sure the power and water distribution va-
lues are compatible with the values indicated in the technical data tag.
• The electrical safety of the oven is ensured by means of a connection
to an ecient grounding system (it is reminded that it must be periodi-
cally inspected) and it complies with the National and local regulations
in force.
• The operation and supervision of the oven during its use must be en-
trusted only to specically trained people.
• Avoid installing the oven next to heat sources such as: deep fryers,
open res, etc.
• Do not obstruct the exhaust openings for any reason, do not prevent
the dispersion of heat and do not obstruct the steam exhaust of the
oven.
• Ask the installer for instructions for the correct use of water softener/
decalcier.
(Warning: a awed procedure of regeneration of the resins may
cause corrosion of the equipment).
• Before starting it for the rst time it is necessary to perform thorough
cleaning of the oven:
- externally it must be cleaned only with a wet piece of cloth;
- the inside of the cooking chamber must be cleaned with water;
- under no circumstances can wire wool be used to clean the oven.
5
EN

Oven model PICCOLO BRAVO DELIZIOSO SUPERIORE
Dimensions HxWxL 550 x 600 x 640 mm 640 x 600 x 640 mm 540 x 720 x 780 mm 650 x 720 x 780 mm
Electric power 2,6 kW 3,4 kW 4,2 kW 6,9 kW
Power source 230 V ~
50/60 Hz
230 V ~
50/60 Hz
380 V ~
50/60 Hz
380 V ~
50/60 Hz
Type of electric cables H05RN-F
3x1,5 mm2
H05RN-F
3x1,5 mm2
H05RN-F
3x1,5 mm2
H05RN-F
3x1,5 mm2
Weight 29 kg 46 kg 61 kg 71 kg
Number of trays 3 4 3 4
Number of fans 1 1 1 2
Positioning On counter-top
or on rack
On counter-top
or on rack
On counter-top
or on rack
On counter-top
or on rack
Water intake 3/4” 3/4” 3/4” 3/4”
Water pressure 200÷300 kPa
(2÷3 bar)
200÷300 kPa
(2÷3 bar)
200÷300 kPa
(2÷3 bar)
200÷300 kPa
(2÷3 bar)
Water hardness 7-11 °F 7-11 °F 7-11 °F 7-11 °F
Insulation class III I
IP degree of
protection IPX1 IPX1 IPX1 IPX1
Control panel Electromechanical
Digital
Electromechanical
Digital
Electromechanical
Digital
Electromechanical
Digital
You are advised to check whether the supply corresponds to
the specications of the order. You are advised not to trail or
tilt the oven for any reason.
The oven must be lifted perpendicularly to the oor, moved
horizontally, placed perpendicularly to the oor.
1.5 - Compliance with the standards and directives
• The ovens comply with the safety provisions and requirements indi-
cated in the following European Directives and their associated spe-
cic norms:
- European Machinery Directive 2006/42/EC as amended
- European Low Voltage Directive 2006/95/EC as amended (standard
EN 60335-1 and EN 60335-2)
- Electromagnetic Compatibility Directive 2004/108/EC as amended
(standard EN 50165, EN 55014, EN 50366, EN 61000-4)
Following the conformity with the above-mentioned standards, the
producer declares that his products comply with the European legisla-
tion in force and therefore are provided with the appropriate mar-
king that allows their sale in the European states.
Furthermore the noise emission of the functional components does
not exceed 70 dB (A).
1 - INTRODUCTION
6
1.3 Technical characteristics
1.4 - Handling, transportation and unloading
The packaging of the oven is produced by the company in compliance
with the stipulated agreements or, however, depending on the Country
of destination or the transportation means used.
After the installation, the packaging may be used again or disposed of
in accordance with the regulations in force in the Country of the buyer.
The ovens must be transported in their packaging close to the installa-
tion place.
For all the lifting and handling operations of the oven or of its autono-
mously transported components, please refer to specialized personnel.
The material that is shipped is accurate-
ly controlled before being delivered to
the shipping agent. Upon reception of
the oven, make sure that it hasn’t been
damaged during transport or that the
packaging has not been tampered with
and there has been no consequent re-
moval of components from the inside.
In case of detection of damages or mis-
sing parts inform the carrier and the
producer immediately producing pho-
tographic documentation.
Fig.1
EN

CAUTION
The installation and ordinary or extraordinary maintenance of
the oven must be performed exclusively by authorized techni-
cians or, however, by qualied personnel in compliance with
the safety regulations and/or local provisions in force.
FOR THE EXECUTION OF THESE OPERATIONS IT IS INDISPENSA-
BLE TO BE IN POSSESSION OF ALL THE NECESSARY MEASURE-
MENT TOOLS IN PERFECT WORKING EFFICIENCY AND PERIODI-
CALLY CALIBRATED (see Paragraph 1.3).
The producer declines all responsibility in case of failure to
observe these obligations.
Guarantee a distance of at least 30 cm from the ceiling if it is
made of combustible material or if it is not thermally insulated.
Fig. 3
2 - INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE
MIN: 100mm
MIN: 300mm
MIN: 100mm
2.1 Place of installation and placement
Fig. 2
2.2 Power and water supply connection
Connection to power grid
The connection to the power supply grid must be performed in accor-
dance with the international, national and local regulations in force.
Make sure, before connecting the oven, that the voltage and frequency
of the grid correspond to the values indicated on the technical data tag
of the oven (gure 3) placed on the backside of the oven.
It is reminded that a variation of the maximum voltage of ±10 % is ad-
mitted.
The oven must be permanently connected to the power grid with a ca-
ble no less than H05RN-F type (heavy duty poly-chloroprene rubber)
or higher with the section of the leading wires based on the maximum
charge absorbed (see paragraph 1.3).
Between the oven and the power grid there must be a general omnipo-
lar switch with a contact distance of at least 3mm, with a capacity close
to the load and equipped with the appropriate protection devices.
It is necessary to provide the appropriate automatic dierential protec-
tion devices, able to guarantee protection against direct and indirect
contact with the live parts and the ground fault currents in accordance
with the applicable Regulations; the maximum leakage current admit-
ted is of 1 mA/kW. 7
EN

CAUTION!
All potential reactivation operations must be performed by
specialized technical personnel after the elimination of the cau-
ses of interruption.
2 - INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE
8
This switch must be installed in the permanent electrical system of
the room where the oven is installed and in close proximity to the
oven itself so that operators have easy access to it.
For the dimensions of the power supply line, of the general switch
and the cable refer to the data given in the technical data table (see
paragraph 1.3).
In order to connect or replace the power supply cable to the ter-
minal box of the oven proceed as follows:
1) Connect the terminal box placed on the backside of the oven to
the wires of the electric cable, as indicated in the illustrated electrical
diagram.
Make sure the yellow/green grounding wire is longer than the others
(phase and neutral) of about 3 cms so that in case of pulling it is
going to be the last one to break loose guaranteeing the security of
the protection against electric shock.
2) Block the cable and close the lid of the terminal box.
Grounding
The oven must be connected to an ecient grounding system.
The yellow/green wire of the supply cable must be secured in the
clamp marked with the grounding symbol
The oven must be included in an equipotential system the connec-
tion of which will have to be performed with a cable having a mini-
mum section of 10 mm2 connected to the clamp marked with the
symbol placed on the backside of the oven.
Connection to water supply grid
Connect the water supply tube to the 3/4’’ connection piece of the
oven (X- Fig. 4).
The supply pressure admitted is minimum 200 kPa, maximum 300 kPa.
2.3 - Safety devices
The oven is equipped with the following protection and safety
devices:
• Cabinet safety thermostat (if present): in case of overheating of the
cooking cabinet, it intervenes by cutting o the chamber heating.
The safety thermostat (F1 - Fig. 5) may be reactivated only in manual
by pressing the red button after having removed the front panel in
order to reach the component. Before executing the operation make
sure you have disconnected the power supply.
• Door switch that interrupts the operation of the oven when the door
is opened: both the heating system and the cabinet ventilation fan
motor.
• Protection grilles preventing access to the moving parts of the coo-
king cabinet.
EN

X
Fig. 4
2 - INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE
Fig. 5
F1
Type of fault Possible causes
• Incorrect temperature setting.
• Intervention, if present, of the safety
thermostat (F1)
• Control thermostat is faulty.
• Resistor meter (if present) is faulty.
• Wires of cable to the resistors are di-
sconnected.
• Door is not properly closed.
The heating of the cooking
chamber does not start.
The thermostatic control of
temperature is not correct.
The ventilation fan motor
does not work.
The humidication function
is incorrect (insucient or
excessive).
• Control thermostat is faulty.
• Bulb of the thermostat is faulty or o
socket.
2.4 - Diagnosis of certain faults
9
EN
• Cable wires are disconnected.
• Capacitor is faulty.
• Foreign body blocking the fan.
• Door is not properly closed.
• The water supply from the water
grid is not correct.
• The solenoid valve is faulty.
• The pressure reducer is obstructed.

2.5 Substitution of certain components
CAUTION!
The substitution and regulation of components are operations
of extraordinary maintenance and therefore they must be per-
formed by an authorized technician.
Before starting any repair or maintenance action the general
switch must be disconnected in order to cut o the power sup-
ply to the oven.
Close the water supply faucets.
A
B C
Fig. 6
A
Fig. 7
2 - INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE
10
Removal of door
The hinges (A) are equipped with two mobile staples (B) that clasped
to the sections of the hinges (C), when the door is completely open,
block them.
The door is lifted towards the outside carrying out then the two mo-
vements described (Fig. 6); in order to perform these actions hold the
sides of the door close to the hinges.
To reassemble the door, insert the hinges in their specially devised
slots.
Before closing the door remember to remove the two mobile staples
(B) that were used to clasp the 2 hinges.
Oven lamp
Unscrew the protection cap (A - Fig. 7) protruding inside the oven
and then reach the light bulb. After having replaced the light bulb,
re-assemble the protection cap (A).
Heating element
The resistor is removed by unscrewing, from inside the chamber, the
screws that block it; the electrical connections are accessible from be-
hind once the back panel is removed.
Oven fan
Once the back panel of the oven is removed, from inside the oven, remove
the pan support and the fan protection. Unscrew the central nut, if needed
also unscrew the lateral screws xing it on the crank shaft, which sets the fan
loose. Pull the fan out and unscrew the screws of the motor ange.
Gasket
Manually extract the gasket from its position and replace it with the new one
without using tools.
EN
