INSTALLATION INSTRUCTIONS
G13/GL13 LUMINAIRE TO ROUNDPOLE
IMPORTANT:
WARNING:
Read all instructions before performing any work. Be sure prior to
installing luminaires.
Fixture must be grounded in accordance with appropriate codes. Failure to do so may
result in serious injury.
all power is off
NOTE: For installation other than a roundpole, follow the
instructions provided with the adaptor kit.
1. Place luminaire with lens facing up
on a non-scratching surface.
2. Unlatch door and slowly open until
stopped by safety cable. Remove
and retain wing nut that secures
safety cable. Disengage safety
cable from threaded stud and
pull free from ballast clamp.
Open door further until hinge
clamp lock is accessible. Rotate
hinge clamp lock to free hinge
clamp(Fig.1). Carefully rotate
door toward the closed position
until hinge disengages.
3. Place luminaire mounting surface
against round pole so that the
mounting holes align. With an
assistant holding the luminaire,
insert the bolster plate into the
inside of the pole. Secure the
luminaire using the 5/16” bolts
and lock washers supplied
(Fig.2). Tighten bolts to 15ft-lbs.
Gardco Lighting
1611 Clovis Barker Road, San Marcos, TX 78666
Gardco and Emco are Philips group brands
A817129
6/6/01 - REV D
1OF2

Fig. 3
A817129.CDR
INSTALLATION INSTRUCTIONS
G13/GL13 LUMINAIRE TO ROUNDPOLE
4. Feed luminaire wires into pole. Make electrical connections and secure supply wires using the wire tie
anchor mounted to the bolster plate(Fig.3). Where more than one luminaire is mounted to the pole,
make electrical connections after all luminaires are mounted.
5. Install pole top cap.
6. Aiming arrow on reflector must match aiming direction on site plan. If reflector rotation is required, see the
following instructions:
For HID units: Loosen the four 8-32 phillips pan head screws holding the reflector to the housing. Loosen
the two thumb screws and slide latches to disengage. Remove reflector, reposition as desired and re-install.
For LED units: Remove four #8 screws and matte surrounding LED board. Remove four #8 screws holding
heatsink/light engine assembly and rotate as desired. Secure heatsink/light engine assembly with screws
previously removed. Reinstall matte with four screws previously removed.
7. Install lamp (where applicable). Make sure the lamp and wattage are as indicated in the product
identification label on the reflector. Clear lamp required for optimum photometric performance.
8. Re-install door by engaging the hinge end with the door in the almost closed position. Swing door open
and lock the hinge clamp by returning the hinge clamp lock to its original position. Re-install safety cable
through ballast clamp and onto stud. Re-install wingnut and tighten.
9. Close door making sure latch is fully engaged.
