Garden Groom Garden Groom "Midi" GG10 User manual

3-in-1 Hedge Trimmer
Gar d en
GGROOM2242011
GGroomMNL_MIDI_R5.indd 1-2 3/14/11 10:10 AM

HISTORY & BACKGROUND
Several years ago, Graham Wilson a retired engineer
was trimming hedges in his garden. After a long hard
day he said to himself, “there must be an easier and
safer way to do this job!”
So he set about trying to solve the problems that all
gardeners face when they venture out to trim their
hedges.
At first was a hobby, but as Graham got closer to solv-
ing the problem, the more determind he was tocreate
a resolution. In 2000, he received a UK government
grants for safety and innovation, which helped him
fund the initial stages of the project. He approached
a number of leading garden tool manufacturers; in
hopes of them buying his invention, they all rejected his concept.
Graham was determind to see his vision through, convinced he had a concept that would
dramatically benefit gardeners around the world, by eliminating a potentially dangerous and time consum-
ing chore, into a far more pleasant and safe gardening function.
To achieve his goal Graham needed to raise substantial funds thus 1999, at the age of 53, he re-financed
his home and poured all his savings into the development this invention.
After spending a small fortune on development, manufacturing and patent costs and with many disap-
pointments and rejections along the way, Graham has succeeded in introducing the Garden Groom® trim-
mer to gardeners around the world.
He has truly solved the problems associated with hedge trimming and with the Garden Groom® trimmer
has presented a unique product that cuts, shreds and captures the majority of waste material and with its
concealed blade, makes it virtually impossible to cut the power cord.
Great ideas are always worth fighting for!
Thanks Graham
TABLE OF CONTENTS
SAFETY INSTRUCTIONS 1
PRODUCT OVERVIEW 4
USE OF THE GARDEN GROOM® TRIMMER 5
GARDEN GROOM® MEGA BAG INSTRUCTIONS 9
TROUBLESHOOTING 11
WARRANTY 12
ARBITRATION AGREEMENT 13
Graham Wilson - Inventor and Chairman of Garden Groom®
GGroomMNL_MIDI_R5.indd 3-4 3/14/11 10:10 AM

1 2
SAFETY INSTRUCTIONS
WARNING: When using electric hedge trimmers, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and personal injury, including the following:
READ ALL INSTRUCTIONS
Polarized Appliance Connections - To reduce the risk of electric shock, this appliance has a polarized plug
(one blade is wider than the other) and will require the use of a polarized extension cord. The appliance
plug will fit into a polarized extension cord only one way. If the plug does not fit fully into the extension
cord, reverse the plug. If the plug still does not fit, obtain a correct polarized extension cord. A polarized
extension cord will require the use of a polarized wall outlet. This plug will fit into the polarized wall outlet
only one way. If the plug does not fit fully into the wall outlet, reverse the plug. If the plug still does
not fit, contact a qualified electrician to install the proper wall outlet. Do not change the equipment plug,
extension cord receptacle, or extension cord plug in any way.
1) Avoid Dangerous Environment - Don’t use hedge trimmers in damp or wet locations.
2) Don’t Use In Rain.
3) Keep Children Away - All visitors should be kept at a distance from work area.
4) Dress Properly - Do not wear loose clothing or jewelry. They can be caught in moving parts. Use of
rubber gloves and substantial footwear is recommended when working outdoors. Wear protective
hair covering to contain long hair.
5) Use Safety Glasses - Always use face or dust mask if operation is dusty.
6) Ground Fault Circuit Interrupter (GFCI) protection should be provided on the circuit(s) or outlet(s) to
be used for the hedge trimmer. Receptacles are available having built-in GFCI protection and may be
used for this measure of safety.
7) Use Right Appliance - Do not use appliance for any job except that for which it is intended.
8) Warning - To reduce the risk of electric shock, use only with an extension cord intended for outdoor
use, such as SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJOW-A, SJTW-A or SJTOW-A.
9) Extension Cord - Make sure your extension cord is in good condition. When using an extension cord, be
sure to use one heavy enough to carry the current your product will draw. An undersized extension
cord will cause a drop in line voltage resulting in loss of power and overheating. Table 1 shows the
correct size to use depending on cord length and nameplate ampere rating. If in doubt, use the next
heavier gauge. The smaller the gage number, the heavier the cord. To reduce the risk of disconnec-
tion of hedge trimmer cord from the extension cord during operating, please make a knot as shown
on Page 3- Figure 1.
10) Avoid Unintentional Starting - Don’t carry plugged-in hedge trimmer with finger on switch. Be sure
switch is off when plugging in.
11) Don’t Abuse Cord - Never carry hedge trimmer by cord or yank it to disconnect from receptacle. Keep
cord from heat, oil, and sharp edges.
12) Danger - Risk of Cut - Keep Hands Away From Blades - Keep both hands on handles when power is on.
13) Don’t Force Hedge Trimmer - It will do the job better and with less likelihood of a risk of injury at the
rate for which it was designed.
14) Don’t Overreach - Keep proper footing and balance at all times.
15) Stay Alert - Watch what you are doing. Use common sense. Do not operate hedge trimmer when you
are tired.
16) Disconnect Hedge Trimmer - Disconnect the hedge trimmer from the power supply when not in use or
when changing accessories such as blades, and the like.
17) Store Idle Hedge Trimmer Indoors - When not in use, hedge trimmer should be stored indoors in dry,
and high or locked-up place - out of reach of children.
18) Maintain Hedge Trimmer With Care - Inspect hedge trimmer cord periodically, and if damaged, have
it repaired by an authorized electrician. Inspect extension cords periodically and replace if damaged.
Keep handles dry, clean, and free from oil and grease.
19) Check Damaged Parts - Before further use of the hedge trimmer, a guard or other part that is dam-
aged should be carefully checked to determine that it will operate properly and perform its intended
function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting,
and any other condition that may affect its operation. If a guard or other part is damaged, immedi-
ately discontinue use of Garden Groom. Contact dealer or go to www.gardengroomusa.com
20) Wear proper apparel, keep both hands on the grasping surfaces and keep supply cord away from the
cutting area.
21) The maximum diameter of stems intended to be cut with this hedge trimmer is 0.4”.
22) When operating the trimmer, keep extension cord behind trimmer. Never drape it over hedge being
trimmed.
SPECIFIC SAFETY WARNING
WARNING: Some dust created by this product contains chemicals known to the State of California to
cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:
• Compounds in fertilizers
• Compounds in insecticides, herbicides and pesticides
• Arsenic and chromium from chemically treated lumber
To reduce your exposure to these chemicals, wear approved safety equipment.
WARNING: Before operating the Garden Groom® trimmer, read this manual and follow all safety and
Operating Instructions.
•SAVE THIS MANUAL FOR FUTURE REFERENCE•
GGroomMNL_MIDI_R5.indd 1-2 3/14/11 10:10 AM

3 4
TABLE 1
Minimum guage for extension cords
Length / Feet 0-25 26-50 51-100 101-150
AWG 18 16 16 14
PRODUCT OVERVIEW
Back
Handle
Main
Switch
Waste
Container
Front
Handle
Head
Safety
Switch
Main
Switch
Interlock
Switch
Container
Clip
Interlock
Peg
Top
Switch
Static
Blade
Rotary
Blade
Container
Clip
Interlock
Switch
FIGURE 1
Method of Securing Cord Set
CORD SET APPLIANCE SETTING
(A) Tie Cord As Shown
(B) Connect Plug & Receptacle
Clipping Outlet
GGroomMNL_MIDI_R5.indd 3-4 3/14/11 10:10 AM

5 6
USING THE GARDEN GROOM® TRIMMER
Note: Either the waste container or the Mega Bag must be attached for the Garden Groom® trimmer
to operate.
1. SWITCH ARRANGEMENT
The Garden Groom® trimmer will operate when the
main switch and the front switches located on the
front handle are depressed. To operate the main
switch, you must first push the safety switch.
2. HORIZONTAL TRIMMING (Top of Hedges)
Move the Garden Groom® trimmer in a sweeping
pendulum motion from side to side. The flat underside
of the Garden Groom® trimmer provides a natural
guide, so the most inexperienced gardener can achieve
excellent results.
TIP: The Garden Groom® trimmer has been designed
to cut growth of up to 1 year in age, 0.4 inches in di-
ameter and 7 inches in length. Use on heavier material
may result in damage to the machine.
3. VERTICAL TRIMMING (Side of Hedge)
Move the Garden Groom® trimmer in a vertical sweeping action, ensuring the flat underside of the ma-
chine is level with the surface of the hedge (Fig. 1). Tip: For a tighter professional finish, bury the head
of the machine into the hedge, to the desired depth, working the machine upwards (Fig.2). To trim long
stalks growing parallel with the surface of the hedge, move the head down in the opposite direction to the
growth (Fig. 3).
Please note: The capture rate of material is reduced using this angle of cut.
4. TRIMMING EXTRA LONG GROWTH
The Garden Groom® trimmer has been designed to trim hedge growth of 7 inches in length or less.
However, it will trim exceptionally long growth, but this operation will inevitably result in a lower rate of
capture (on vertical cuts only), due to the sheer dynamics and volume of material to be managed.
To trim exceptionally long growth (within the recommended cutting diameters), we advise the following
techniques: Trim the growth in several stages (see Fig. 4 below) layering down, until you arrive at the
desired level.
In some circumstances you may wish to adopt a vertical technique (see Fig. 5 below) bringing the Garden
Groom® trimmer down onto the growth in a vertical action.
Front
Switch
Main
Switch
Safety
Switch
Hedge level
New Growth
FIG. 1 FIG. 2 FIG. 3
FIG. 4
FIG. 5
1st Pass
2nd Pass
3rd Pass
ACTION
GGroomMNL_MIDI_R5.indd 5-6 3/14/11 10:10 AM

7 8
USING THE GARDEN GROOM® TRIMMER (CONTD)
5. EMPTYING CONTAINER
For speed of operation, simply hold the Garden Groom® trimmer by the front handle, unclip and with-
draw the container from the main body and deposit the waste material into an appropriate receptacle. To
re-engage, push the front of the container over the exhaust, raise the rear of the container, ensuring align-
ment with clip, push clip forward with palm of hand to lock.
Note: the interlock peg MUST be connected to the interlock switch for the machine to function.
Container
Clip
1
FIG. 6
Extension
Tube
Hook &
Loop
Flexible
Extension
Hose
Zip
6. Mega Bag ATTACHMENT
For larger areas of hedge growth, a Mega Bag attachment has been developed. This optional accessory
has a specially refined container fixed to an exhaust hose and Mega Bag attachment is fitted in the same
manner as the standard container.
Tip: It is necessary to periodically shake the debris down the hose to ensure smooth conveyance of
waste material into the mega colletion bag. When full, unzip the rear panel of the bag and empty
into chosen receptacle.
Waste
Mega Bag
Mega Bag Cou-
pling
GGroomMNL_MIDI_R5.indd 7-8 3/14/11 10:10 AM

9 10
Optional Garden Groom® Mega Bag Instructions
The Mega Bag Attachment
The Mega Bag attachment is supplied fully assembled, (see Fig 7).
Check the assembly for damage and ensure all the component parts are in perfect condition and firmly
connected together before proceeding.
Preparing the Mega Bag
Lay the hose, extension tube and bag out in a straight line adjacent to the hedge to be trimmed, position-
ing the bag behind the anticipated direction of progress. Ensure the hose is not twisted and the bag is
sitting square on its flat base.
Attach the extension tube (Fig 8) the Garden Groom® trimmer as illustrated (Fig 9), by offering the inlet
of the tube to the clipping outlet of the trimmer. Lift the back of the tube up to the underside of the ma-
chine, ensuring the interlock peg is aligned with the interlock switch, in the same way as the conventional
container.
Secure the tube with the retaining clip.
Plug the Garden Groom® trimmer into the main electrical supply and turn on.
The Garden Groom® trimmeris now ready for use. If however it does not operate, check the interlock peg
is correctly aligned with the switch and the retaining clip firmly in place. If the problem persists, refer to
the Troubleshooting page at the back of the Garden Groom® trimmer manual.
Use of Mega Bag Attachment
Start up the trimmer in the normal manner by operating the main switch and the front switch, ensuring
the safety switch is released on the rear handle. The flexible hose and Mega Bag will inflate, providing a
clear passage for the debris to flow from the trimmer exhaust to the bag.
As progress is made, to avoid any restriction of movement and strain on the tube/hose coupling, occasion-
ally pull the bag along by the hose in advance of the cutting location.
During use, minor kinking of the hose is acceptable; however ensure the tube is not twisted, as this will
restrict the flow of waste material.
It will be necessary to periodically shake the debris down the hose to ensure smooth conveyance of mate-
rial into the volume bag.
When the bag is sufficiently full, unzip the flap at the rear and pour the shredded material into an appropri-
ate receptacle or onto a compost area.
Working from a ladder
When working from a ladder always ensure it is stable on solid ground and never overreach.
Take care when positioning the ladder, that there is sufficient freedom of movement for the power cable
and the flexible tube.
Always ensure the position of the ladder, bag and hose do not cause a potential tripping hazard or create
any restriction of movement during the hedge trimming operation.
Storage
Ensure the tube, hose and bag are completely free of waste material before storing away.
Store in a dry place, free of hazards that could cause damage to any of the component parts.
Safety
Check periodically there are no breaks or damage to the Mega Bag assembly.
The Garden Groom® trimmer should never be used without the extension tube or hose in position.
NEVER INSERT YOUR HAND UP THE EXTENSION TUBE
Warning
Always unplug your Garden Groom® trimmer from the main electrical supply before carrying out any
maintenance.
Damage
The three component parts of the Mega Bag attachment have been designed for easy detachment. If the
extension tube is damaged simply detach the hose by the hook and loop.
If the hose is damaged, unzip the coupling at the bag and untie the extension tube. For Mega Bag damage
simply unzip the hose.
Always wear
protective eyewear
FIG. 7
FIG. 8
FIG. 9
Extension Tube
Extension Tube
Interlock
Switch
Retaining
clip
Interlock
Peg
Exhaust
Mega Bag
Clipping Outlet
GGroomMNL_MIDI_R5.indd 9-10 3/14/11 10:10 AM

11 12
TROUBLESHOOTING
PROBLEM ACTION
MACHINE WILL NOT START - Check the machine is plugged in to a live supply
- Check that the waste container or Mega Bag
extension tube is correctly attached, remove and
refit to be sure.
- Check that you are pressing both the main
switch and front switch ensuring that the safety
switch has released the main switch.
- Contact dealer.
MACHINE DOES NOT COLLECT - Check collection box is not full.
- Check Mega Bag hose (accessory) is not blocked.
- Check exhaust is not blocked.
Note: The percentage of collection will vary on
the condition and type of hedge being
cut.
DAMAGE TO STATIC OR ROTARY BLADE - Unplug the machine immediately
- Contact: www.gardengroomusa.com
MODEL NO.: GG10
Input Voltage: 120-60Hz
Rated Current: 2.5A
No Load Speed: 3400/min
Double Insulaton is a design concept used in electric power tools which elimniates the need for the three
wire grounded power cord and grounded power supply system. It is recognized and approved by ETL and
confirms to UL1448
Not to be operated by or around children. Any attempt to modify, disable or override any of the safety
switches, will void all warranties and release the manufacturer and or distributor from any liability for
injury or damage that could occur as a result.
ONE YEAR LIMITED WARRANTY
The Garden Groom® trimmer is warranted to be free from defects in materials and workmanship for one
year from the original purchase date. Should the product have a defect in materials or workmanship,
we will repair or replace it without charge to you (a shipping and processing fee may apply). To obtain
service under warranty, simply call our Customer Service Center toll-free at: 800.498.0422
This warranty does not cover any damage caused by accident, misuse or any use other than as intended
and described in this owner’s guide, or damage resulting from failure to maintain and clean this product
as specified in this product manual. This warranty applies only to the original purchaser of the Garden
Groom® trimmer.
Contact Info for Warranty Service:
P.O. Box 9169 | Van Nuys, CA | 91409
800-498-0422 | www.gardengroomusa.com
© 2011 Garden Groom® LLC. All Rights Reserved.
WIPO Patent Nos. WO/2003/020010; WO/2000/015024
GGroomMNL_MIDI_R5.indd 11-12 3/14/11 10:10 AM

THIS ARBITRATION AGREEMENT (“AGREEMENT”) AFFECTS YOUR LEGAL RIGHTS AND REMEDIES BY PROVIDING THAT
DISPUTES BETWEEN YOU AND THE SELLER OF THIS PRODUCT (“COMPANY”), MUST BE RESOLVED THROUGH BINDING
ARBITRATION, RATHER THAN IN A COURT. PLEASE READ THIS AGREEMENT CAREFULLY. YOU ACCEPT THE TERMS OF
THIS AGREEMENT BY RETAINING THE PRODUCT(S) SHIPPED IN CONNECTION WITH THIS AGREEMENT (THE “PRODUCT”)
FOR MORE THAN FOURTEEN (14) DAYS AFTER RECEIPT. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT,
YOU MAY RETURN THE PRODUCT TO COMPANY WITHIN FOURTEEN (14) DAYS OF RECEIPT AT NO COST TO YOU.
1. RESOLUTION OF CLAIMS OR DISPUTES.
Any claim or dispute between you and Company (or any of Company’s subsidiaries or afliates) arising out of or relating in any way
to the Product or this Agreement shall be resolved through nal, binding arbitration. This arbitration obligation applies regardless of
whether the claim or dispute involves a tort, fraud, misrepresentation, product liability, negligence, violation of a statute, or any other
legal theory. Both you and Company specically acknowledge and agree that you waive your right to bring a lawsuit based on such
claims or disputes and to have such lawsuit resolved by a judge or jury.
2. LIMITATION OF LEGAL REMEDIES.
All arbitrations under this Agreement shall be conducted on an individual (and not a class-wide) basis, and an arbitrator shall have
no authority to award class-wide relief. You acknowledge and agree that this Agreement specically prohibits you from commencing
arbitration proceedings as a representative of others or joining in any arbitration proceedings brought by any other person.
3. ARBITRATION PROCEDURES.
a. Before commencing any arbitration proceedings under this Agreement, you must rst present the claim or dispute to Company by
calling [phone] and asking for the Legal Department and allowing Company the opportunity to resolve the claim or dispute. If
your claim or dispute is not resolved within sixty (60) days, you may commence arbitration proceedings in accordance with the terms
of this Agreement.
b. The arbitration of any claim or dispute under this Agreement shall be conducted pursuant to the American Arbitration Association’s
(“AAA”) United States Commercial Dispute Resolution Procedures and Supplementary Procedures for Consumer-Related Disputes.
These rules and procedures are available by calling the AAA or by visiting its web site at www.adr.org.
c. The arbitration of any claim or dispute under this Agreement shall be conducted in the State of California or the location in which
you received this Agreement.
d. All administrative expenses of arbitration proceedings commenced under this Agreement shall be divided equally between you
and Company, except that: (a) if the claim or dispute that is the subject of the arbitration proceedings is less than ten thousand
dollars (US$10,000), you will be responsible for no more than one hundred twenty-ve dollars (US$125) in administrative expenses;
(b) if the claim or dispute that is the subject of the arbitration proceedings is more than ten thousand dollars (US$10,000) but
less than seventy-ve thousand dollars (US$75,000), you will be responsible for no more than three hundred seventy-ve dollars
(US$375) in administrative expenses; and (c) if the claim or dispute that is the subject of the arbitration proceedings is more than
seventy-ve thousand dollars (US$75,000), then you will be responsible for administrative expenses in accordance with the
Commercial Fee Schedule provided by the AAA. You acknowledge and agree that each party shall pay the fees and costs of its own
counsel, experts and witnesses.
4. CHOICE OF LAW.
This Agreement shall be governed by the United States Federal Arbitration Act and the laws of the State of California.
5. SEVERABILITY.
If any provision of this Agreement is declared or found to be unlawful, unenforceable or void, such provision will be ineffective only
to the extent that it is found unlawful, unenforceable or void, and the remainder of the provision and all other provisions shall remain
fully enforceable.
ARBITRATION AGREEMENT
GGroomMNL_MIDI_R5.indd 13-14 3/14/11 10:10 AM

GGroomMNL_MIDI_R5.indd 15-16 3/14/11 10:10 AM
