Garden Oasis SS-K-135-5YT User manual

Date of purchase: _____/ _____/ _____
1
KSN: 03681941-5
UPC code: 769455 762238
Vendor Item: SS-K-135-5YT
OWNER’S
MANUAL
Cooper Round Lighted Tile
Top Bar Table

PARTS
Read through all the instructions before beginning assembly. Unpack and identify all the parts.
Place them on a flat, non-abrasive surface. Assembly by two people is recommended.
A (1)
Tabletop
(Attached with 8 bolts
and 8 metal washers)
B (1)
Metal Center Ring
ACCESSORIES
Ea (1)
Bolt
Eb (1)
Metal Washer
C (4)
Metal Leg ( Each
attached with 2 bolts
and 2 metal washers)
Ec (1)
Allen Wrench
Ed (1)
Assembly
Instructions Sheet owner’s
manual
Date of purchase: _____/ _____/ _____
Product code: 0-00000000-0
UPC code: 000000000000
PACIFICCOVE 42"ROUNDTABLE
2
Ee (1)
Glass Bumper
D (1)
Glass
Ef (1)
Light

ASSEMBLY INSTRUCTIONS
Your table is now ready for use. Enjoy!
1
4
CARE INSTRUCTIONS
Wash with a mild solution of soap and water; rinse thoroughly. Dry completely. Do not use bleach or solvents.
Cover furniture with outdoor furniture covers when not in use.
Place the tabletop (A) upside down on a non-abrasive work
surface.
Attach metal legs (C) to the table top (A). Insert a bolt (Ea)
through a metal washer (Eb), through the metal leg (C)
and secure into the tabletop (A). Do not tighten completely.
Repeat procedure for the other hole. See Fig.1. Repeat
the same procedure for the other 3 legs.
Turn the table over. Tighten all bolts by using the Allen
wrench (Ec) provided. Put the glass (D) onto the tabletop.
Insert the upper part of the light (Ef) through the hole of the
glass (D) and secure into the lower part of the light (Ef ).
See Fig.3. (Rotate the knob to lighten the light if needed)
Put the metal center ring (B) between the four metal legs (C).
Align the holes. Insert a bolt (Ea) through a metal washer (Eb),
through the metal center ring (B) and secure into the metal leg (C).
Do not tighten completely. Repeat procedure for the other hole.
See Fig.2. Repeat the same procedure for the other 3 legs.
3
3
2
CEa
Ea
Eb
Eb
B
A
Ea
Eb
C
A
B
C
D
Ef Fig.1.
Fig.2.
Fig.3.
For questions or comments about product:
Call toll-free: 800-457-4652
Please refer to part numbers when reordering
See our extensive assortment of outdoor living products
on-line at www.sears.com and www.kmart.com
Made in / Hecho en CHINA for Kmart Corporation, Hoffman Estates, IL 60179
SHOP kmart.com
