Gardena SR 1600 User manual

DBetriebsanleitung
Teichschlammsauger
GB Operating Instructions
Pond Silt Remover
FMode d’emploi
Aspirateur de bassin
NL Instructies voor gebruik
Vijvervuilzuiger
SBruksanvisning
Slamsugare för damm
IIstruzioni per l’uso
Pulitore per laghetti
EManual de instrucciones
Aspirador de lodo para estanque
PInstruções de utilização
Aspirador de lodo de lago
DK Brugsanvisning
Bassinstøvsuger
GARDENA®
D
GBFNLS
I
E
P
DK
SR 1600 Art.7946

10
GB
2. Safety instructions
Correct use:
Please note
GARDENA Pond Silt Remover SR 1600
Welcome to the Garden with GARDENA...
Translation of the original instructions from German. Please read these operating instruc-
tions carefully and observe the notes given. Use these operating instructions to familiarise
yourself with the Pond Silt Remover, its proper use and the notes on safety.
AFor safety reasons, children under the age of 16 and people who have not read these
operating instructions must not use this Pond Silt Remover.
Persons with reduced physical or mental abilities may use the product only if they are
supervised or instructed by a responsible person.
vPlease keep these operating instructions in a safe place.
1. Where to Use Your GARDENA Pond Silt Remover . . . . . . . . . . 10
2. Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6. Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
10. Service / Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1. Where to Use Your GARDENA Pond Silt Remover
As a Pond Silt Remover: The Pond Silt Remover is suitable for
the removal of particles of dirt up to 20 mm, thread algae, leaves
and silt from garden ponds, and for removal of large particles of
dirt from swimming pools.
As a Wet Suction Pump: The Pond Silt Remover is suitable for
suction of dirty water with particles of dirt up to 20 mm.
For dry suction: The pond silt remover can also be used for dry
suction with the filter bag.
The GARDENA Pond Silt Remover is not suitable for
continuous operation (e.g. industrial applications,
continuous pumping operations).
Contents
Operation:
When working by a pond always ensure the
equipment is securely mounted.
Do not apply sustained tension to the hoses.
Avoid sucking up oversize particles of dirt –
they could block the Pond Silt Remover.
Never make any technical modifications to
the equipment.
Always use original spare parts and
accessories for the equipment.
Repairs must only be carried out by
GARDENA Service centres.
DANGER ! Risk of explosion!
Never use the equipment in the
vicinity of explosive liquids or
vapours. The equipment is not
protected for use in explosive
environments.

11
GB
The Pond Silt Remover must not be used for
suction of flammable or poisonous materials
(such as petrol, asbestos, asbestos dust,
copier toner) or volatile substances, acids,
hot or glowing ashes, dust, sand or similar
dry dirty materials.
The Pond Silt Remover must always have its
foam filter in place when in use.
The foam filter is only suitable for liquids.
When in use as a Wet Suction Unit do not
suck up any dry dust or dirt – this can lead
to damage.
Electrical safety:
DANGER ! Electric shock !
Do not operate the equipment if there are
people or animals in the pond or suction area.
Before reaching into the water, always unplug
the mains plugs of all equipment in the water.
Compare the mains electrical power supply
with the information on the packaging / on
the model plate on the equipment.
Make sure that the equipment is supplied
through a residual current protection device
measuring a residual current of 30 mA or less.
Only connect the equipment to a properly
installed socket outlet.
Keep the mains plug and all connection
points dry!
Do not use the equipment in the rain or leave
it out in the rain.
Lay the connection cable so that it is protected
and cannot be damaged.
Use only permitted extension cables as per
HD 516.
vAsk your electrical specialist.
Never lift or carry the equipment by the
connection cable!
Do not use the equipment if the cable or
housing is defective!
Electrical installations at garden ponds
must satisfy the applicable national and
international installation regulations.
Never open the housing of the equipment
or its associated parts unless you are
expressly instructed so to do in the
Operating Instructions.
If you have questions or encounter
problems, for your own safety refer to
a qualified electrician!
3. Function
The Pond Silt Remover sucks the pond water into the collecting
tank 3via the adapter nozzle 1and suction pipe 2.
When the collecting tank is full, the Pond Silt Remover releases
the dirty water via the drainage hose 4over a 25 second period.
Circulation system:
The water flows back into the pond 5through the fine filter bag.
This means no pond water is lost, and the biological equilibrium
of the pond is maintained. The water that is fed back contains
biologically active floating particles. The resulting turbidity of
the pond can last several days.
Discharge system:
The pond water that is sucked out is discharged into the
environment. The fine filter bag 5can also be used for this.
Fine filter bag:
The particles of dirt and pond silt that are collected in the fine
filter bag 5can be used as fertiliser or disposed of in the
compost.
2
3
5
1
4
Circulation system
Discharge system

12
GB
z
2a
2
9
7
6
8
Fitting the Pond Silt Remover /
Wet Suction Unit /
Dry Suction Unit:
Applications of the various adapter nozzles
For sucking pond silt up from the bottom of the pond.
The bottom nozzle can be adjusted to suit the conditions at the
bottom of the pond:
•Bottom nozzle fully open (10 mm): use on pond liners (no
pebbles on the bottom, thick layer of silt).
•Bottom nozzle closed (2 mm): use on pond liners (pebbles as
bottom covering, thick layer of silt).
For optimum suction in rigid pond liners and of thin layers of silt,
turn the bottom nozzle through 180°.
Joints nozzle For sucking from narrow spaces, such as between stones and
plants.
Thread algae nozzle For sucking up thread algae.
Wide nozzle with For sucking up residual water e.g. on terraces, in garages,
rubber lip cellar etc.
4. Assembly
1. Undo the filter tray locks 6and remove the motor housing 7.
2. Remove all parts from the filter tray 3.
3. Replace the motor housing 7and lock it in position.
4. Insert the end piece of the suction hose 8into the upper
suction opening of the filter tray 3.
5. Attach the transparent suction tube z
2a to the handle 9.
6. Attach the black suction tubes 2.
Bottom nozzle
3

13
GB
5. Operation
The higher the filter tray 3above the surface of the water, the
less the suction power.
1. Pull mains plug of pond silt remover out of electric socket.
2. Position the filter tray 3at least 2 m from the edge of the
pond, max. 0.5 m above the surface of the water and so that
it will not overflow.
3. Insert the round end of the discharge hose 4into the lower
discharge opening of the filter tray 3.
The non-return flap
0
is located at the outlet of the
discharge hose
4
.
4. Lay the discharge hose 4on ground with a falling
gradient, so that the hose is self-draining.
5. If desired, attach the fine filter bag 5over the end of the
discharge hose 4(see 3. Function).
6. Attach the desired nozzle 1(see 3. Function) to the suction
tube 2.
7. Insert the Pond Silt Remover mains plug into a power socket.
8. Set the ON switch Ato position (I) ON.
When the collecting tank is full, the dirty water is drained via
the discharge hose
4
over a 25 second period. Then the
pond silt remover switches itself on again automatically.
9. Guide the nozzle on to the bottom of the pond. Then suck up
the dirt with slow and even movements.
10. After use, turn the ON switch Ato the (0) OFF position.
1. Pull mains plug of Wet Suction Unit out of electric socket.
2. Insert stopper plug Bin the lower discharge opening of the
filter tray 3.
3. Attach the wide nozzle 1(see 3. Function) to the suction
tube 2.
4. Insert the Wet Suction Unit mains plug into a power socket.
5. Set the ON switch Ato position (I) ON.
When the collecting tank is full, the suction unit switches off.
6. When it stops sucking, the filter tray 3is full. Then set the
switch Ato position (0) OFF.
7. At the chosen discharge location remove the stopper plug B
and empty the filter tray 3.
Use as a Pond Silt Remover:
Operation as Wet Suction Unit:
2
3
5
1
0
4
B
3
4
A
1
2
3
B
