Gardena 4000/5 Inox User manual

D
GB
F
NL
SIEPDK
GARDENA
®
DGebrauchsanweisung
Tauch-Druckpumpe
GB Operating Instructions
Submersible Pressure Pump
FMode d’emploi
Pompe immergée pour arrosage
NL Gebruiksaanwijzing
Dompel-druckopvoerpomp
SBruksanvisning
Dränkbar Tryckpump
IIstruzioni per l’uso
Pompa sommersa a pressione
EManual de instrucciones
Bomba sumergible a presión
PInstruções de utilização
Bomba submersível de pressão
DK Brugsanvisning
Dyk- / trykpumpe
4000/5 Inox Art. 1479

Intended use
Liquids to be pumped
Please note
GARDENA Submersible Pressure Pump 4000/5 Inox
Welcome to the garden of GARDENA ...
Please read these operating instructions carefully and observe
the notes given. Use the instructions to familiarise yourself with
the submersible pressure pump, its correct use, and the notes
on safety.
For safety reasons, children under 16 as well as persons not
familiar with these operating instructions should not use this
submersible pressure pump.
vKeep these operating instructions in a safe place.
1. Applications Range of Your GARDENA Submersible
Pressure Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. For Your Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Initial Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5. Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6. Trouble-Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7. Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
9. Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1. Applications Range of Your GARDENA Submersible Pressure
Pump
GARDENA Submersible Pumps have been designed for private use
around your house and garden. They are predominantly destinated
for taking clean freshwater from wells, shafts and other water
reservoirs or for operating irrigation accessories and systems.
Pump only clear water with the GARDENA Submersible Pressure
Pump.
The Submersible Pressure Pump can be used in bore holes with
a min. internal diameter of 130 mm (5”). The pump is fully sub-
mersible (waterproof sealed) and can be immersed in the liquid
down to a depth of 14 m.
Corrosive, easily combustible or explosive substances
(e.g. gasoline, petroleum, nitro thinner), fats, oils and food
must not be pumped. The temperature of the liquid handled
should not exceed 35 °C.
Contents
9
GB
2. For Your Safety
According to DIN VDE (German Electrical Engineers’ Associa-
tion) 0100, submersible pressure pumps may only be used in
swimming pools, garden ponds, and fountains if the pump is
Residual-current device

10
GB
operated via a residual-current device with a residual-current
rating of ≤30 mA. The pump must not be operated when there
are persons in the swimming pool or garden pond.
For safety reasons we recommend that you always operate
the submersible pressure pump via a residual-current device
(DIN VDE 0100-702 and 0100-738).
vPlease contact your electrician.
In Austria, according to ÖVE B/EN 60 555 part 1 to 3, pumps
which are used in swimming pools and garden ponds, and
equipped with firm power cable should be fed via an ÖVE
approved isolating transformer – rated voltage must not exceed
230 V.
In Switzerland mobile appliances which are used outdoors,
must be connected via a residual-current device.
According to DIN VDE (German Electrical Engineers’ Associa-
tion) 0620, mains power cables must not have a smaller cross-
section than the rubber-sheathed cables of the designation
H07 RNF. The cable length must be at least 10 m.
The power cable of the Submersible Pressure Pump must be
connected to a socket which is positioned at a height of max.
1.10 m (measured from ground). Take care that the power
cable leads downwards.
Data indicated on the type plate must match technical data of
the mains supply.
vTake care that the electrical connections are made within
dry area, protected from flooding.
Protect plug and power cable from heat, oil and sharp edges.
vDon’t use the power cable for plugging off.
The power cable must not be used for mounting or relocating
the pump. For submerging or lifting/securing the pump, please
use the fastening rope.
Extension cables must meet the requirements of DIN VDE 0620.
vBefore operating the pump, first make a visual check, if there
is any damage of the pump (esp. regarding power cable and
plug).
Please observe that the pump always have to be submerged
at least 20 cm in water during operation.
A damaged pump must not be used.
vIn case of damage, please have the pump checked by our
GARDENA Service Centre.
vClear the outlet line before use.
Dry-running operation causes increased wear and is to be
avoided. The pump must be immediately switched off when
water fails to flow.
Avoid running of the pump for more than 10 min. against closed
delivery side of the pump.
vObserve max. delivery height.
Sand and other abrasive substances cause increased wear
and reduce the pump’s output.
In Austria
In Switzerland
Mains power
Visual check
Notes on use

11
GB
When connecting the pump to the water supply system,
the country-specific sanitary regulations must be observed
to prevent water not of drinking water quality being drawn
back in.
➔ If necessary, contact your sanitary expert.
The pump is automatically switched off on overheating by
the built-in thermal motor protector. After having cooled down,
the motor automatically switches on again (see 6. Trouble-
Shooting).
3. Initial Operation
The pump fitting is equipped with a 33,3 mm (G 1”) thread to
which 13 mm (1/2”), 19 mm (3/4”) and 15 mm (5/8”) hoses can
be connected by using GARDENA hose connection system
fittings.
1. Screw the pump fitting 1onto the outlet of the pump and
tighten it manually until the washer fits closely.
2. Attach the hose to the pump fitting 1.
Best results in delivery capacity of the pump are achieved
when using 19 mm (3/4”) hoses in conjunction with GARDENA
“Profi” Maxi-Flow System fittings (e.g. Art. No. 1752) or
25 mm (1”) hoses with fittings available at your sanitary dealer.
When connecting simultaneously several hoses/accessories, we
recommend to use either our GARDENA Twin-Tap Connector
or our Four Channel Water Distributor (Art. No. 1210/1194)
which can be directly screwed onto the pump fitting 1.
vFasten the fastening rope 2to the loop 3for fastening rope.
4. Operation
To ensure that the pump draws the water out, the water to be
drained must be at least 20 cm deep.
1. Submerge the pump in the well or other water reservoirs,
using the fastening rope 2.
In order to avoid contaminations, the pump should not be
placed directly on the ground. It must hang freely min. 30 cm
above ground.
2. Secure the fastening rope 2.
3. When using the pump in deep wells or shafts (ot more than
approx. 5 m), the power cable 4is to be guided by means
of clamps alongside the fastening rope 2.
4. Plug the power cable 4into a mains socket.
Connecting the hose:
Tie the fastening rope
to the pump:
Thermal motor protector
1
3
2
2
4

12
GB
Cleaning the inlet sieve
and suction base:
5. Cleaning
The pumps are virtually maintenance-free.
Warning! Electric shock!
ARisk of injury due to electric shock.
VDisconnect the pump from the mains before clean-
ing the suction base.
1. Press in the 3 rear catches 5(e.g. using a screwdriver) and
pull the lower part of the suction base 6off the pump.
2. Clean the suction base and inlet sieve.
3. Push the lower part of the suction base 6with the inlet sieve
back onto the pump until the 3 rear catches 5snap into place.
For safety reasons a damaged turbine can only be exchanged
by the GARDENA Service Centre.
6. Trouble-Shooting
Problem Probable cause Remedy
Pump is running, Air cannot escape, since vOpen pressure line
but doesn’t deliver. pressure line is closed. (e. g. kinked pressure pipe).
Air locks in the suction base. vWait for max. 60 seconds
until the pump deaerates
automatically over the vent
valve. If necessary, switch
off and start it again.
Suction base is clogged. vDisconnect plug and clean
suction base (see 5. Clean-
ing).
When starting the pump, vSubmerge pump deeper.
water height falls below the
min. water level.
Pump doesn’t start or Thermal overload switch has vDisconnect plug and clean
suddenly stops during switched the pump off due suction base (see 5. Clean-
operation. to overheating. ing).
Observe max. media temper-
ature of 35 °C.
No power. vCheck fuses and electric
connections.
Dirt particles are jammed vDisconnect plug and clean
in the suction base. suction base (see 5. Clean-
ing).
Pump runs, but output Suction base is clogged. vDisconnect plug and clean
suddenly decreases. suction base (see 5. Clean-
ing).
5
6

13
GB
Performance characteristics
m
60
50
40
30
20
10
00 1000 2000 3000 4000
l/h
bar
6,0
5,0
4,0
3,0
2,0
1,0
4000/5 Inox
Attention! Repairs on electrical parts should only be done by our
GARDENA Service Centres.
If you have any problems with your Pump, please contact our Service.
7. Storage
Store the pump away from frost before the first frost sets in.
The product must not be added to normal household waste. It
must be disposed of properly.
8. Technical Data
Type 4000/5 Inox (Art. No. 1479)
Rated power 1000 W
Max. delivery capacity 4000 l/h
Max. pressure 5.5 bar
Max. delivery height 55 m
Max. submersion depth 14 m
Power cable 15 m H07 RNF
Pump connection 33.3 mm (G 1”)
Min. water level for operation 20 cm
Weight approx. 11.5 kg
Fastening rope 15 m
Max. media temperature 35 °C
Mains voltage /
mains frequency 230 V / 50 Hz
Noise level LWA1) 46 dB(A)
1) Measuring method according to EN 60335-1
Frost-free storage
Disposal:
(in accordance with
RL2002/96/EC)

14
F
Warranty
Product Liability
9. Service
GARDENA guarantees this product for 2 years (from date of
purchase). This guarantee covers all serious defects of the unit
that can be proved to be material or manufacturing faults. Under
warranty we will either replace the unit or repair it free of charge
if the following conditions apply:
•The unit must have been handled properly and in keeping
with the requirements of the operating instructions.
•Neither the purchaser or a non-authorised third party have
attempted to repair the unit.
•The turbine is a wearing part and is not covered by the guar-
antee.
This manufacturer’s guarantee does not affect the user’s existing
warranty claims against the dealer/seller.
If you have any problems with your pump, please contact our
Customer Service or return the defective unit together with a
short description of the problem directly to one of the GARDENA
Service Centres listed on the back of this leaflet.
We expressly point out that, in accordance with the product
liability law, we are not liable for any damage caused by our units
if it is due to improper repair or if parts exchanged are not original
GARDENA parts or parts approved by us, and, if the repairs were
not carried out by a GARDENA Service Centre or an authorised
specialist. The same applies to spare parts and accessories.
EU Certificate of Conformity
The undersigned
GARDENA Manufacturing GmbH · Hans-Lorenser-Str. 40 · D-89079 Ulm
hereby certifies that, when leaving our factory, the unit indicated below is in accordance with the
harmonised EU guidelines, EU standards of safety and product specific standards.
This certificate becomes void if the unit is modified without our approval.
Description of the unit: Submersible Pressure Pump
Type: 4000/5 Inox
Art. No.: 1479
EU directives: Machinery Directive 98/37/EC
Electromagnetic Compatibility 89/336/EC
Low Voltage Directive 2006/95/EC
Directive 93/68/EC
Harmonised
European standards: EN 292-1 Ulm, 15.08.2001
EN 292-2
EN 60335-1
EN 60335-2-41
Year of CE marking: 2001 Thomas Heinl
Technical Dept. Manager

Deutschland / Germany
GARDENA
Manufacturing GmbH
Service Center
Hans-Lorenser-Straße 40
D-89079 Ulm
Produktfragen:
([phone]
Reparaturen:
([phone]
[e-mail]
Argentina
Argensem®S.A.
Calle Colonia Japonesa s/n
(1625) Loma Verde
Escobar, Buenos Aires
Phone: [phone]
[e-mail]
Australia
Nylex Consumer Products
50-70 Stanley Drive
Somerton, Victoria, 3062
Phone: [phone]
[e-mail]
Austria / Österreich
GARDENA
Österreich Ges.m.b.H.
Stettnerweg 11-15
2100 Korneuburg
Tel.: [phone]
[e-mail]
Belgium
GARDENA Belgium NV/SA
Sterrebeekstraat 163
1930 Zaventem
Phone: [phone]
Mail: [e-mail]
Brazil
Palash Comércio e
Importação Ltda.
Rua Américo Brasiliense,
2414 - Chácara Sto Antonio
São Paulo - SP - Brasil -
CEP 04715-005
Phone: [phone]
[e-mail]
Bulgaria
DENEX LTD.
2 Luis Ahalier Str. - 7th floor
Sofia 1404
Phone: [phone]
[e-mail]
Canada
GARDENA Canada Ltd.
100 Summerlea Road
Brampton, Ontario L6T 4X3
Phone: [phone]
[e-mail]
Chile
Antonio Martinic y Cia Ltda.
Cassillas 272
Centro de Cassillas
Santiago de Chile
Phone: [phone]
[e-mail]
Costa Rica
Compania Exim
Euroiberoamericana S.A.
Los Colegios, Moravia,
200 metros al Sur del Colegio
Saint Francis - San José
Phone: [phone]
[e-mail]
Croatia
KLIS d.o.o.
Stanciceva 79
10419 Vukovina
Phone: [phone]
[e-mail]
Cyprus
FARMOKIPIKI LTD
P.O. Box 7098
74, Digeni Akrita Ave.
1641 Nicosia
Phone: [phone]
[e-mail]
Czech Republic
GARDENA spol. s r.o.
Шнpskб 20a, и.p. 1153
627 00 Brno
Phone: [phone]
[e-mail]
Denmark
GARDENA Norden AB
Salgsafdeling Danmark
Box 9003
S-200 39 Malmö
[e-mail]
Finland
Habitec Oy
Martinkyläntie 52
01720 Vantaa
France
GARDENA
PARIS NORD 2
69, rue de la Belle Etoile
BP 57080
ROISSY EN FRANCE
95948 ROISSY CDG CEDEX
Tél. [phone]
service.consommateurs@
gardena.fr
Great Britain
GARDENA UK Ltd.
27-28 Brenkley Way
Blezard Business Park
Seaton Burn
Newcastle upon Tyne
NE13 6DS
[e-mail]
Greece
Agrokip
Psomadopoulos S.A.
Ifaistou 33A
Industrial Area Koropi
194 00 Athens Greece
V.A.T. EL093474846
Phone: [phone]
[e-mail]
Hungary
GARDENA
Magyarország Kft.
Késmárk utca 22
1158 Budapest
Phone: [phone]
[e-mail]
Iceland
Ó. Johnson & Kaaber
Tunguhalsi 1
110 Reykjavik
[e-mail]
Ireland
Michael McLoughlin & Sons
Hardware Limited
Long Mile Road
Dublin 12
Italy
GARDENA Italia S.p.A.
Via Donizetti 22
20020 Lainate (Mi)
Phone: [phone]
[e-mail]
Japan
KAKUICHI Co. Ltd.
Sumitomo Realty &
Development Kojimachi
BLDG., 8F
5-1 Nibanncyo, Chiyoda-ku
Tokyo 102-0084
Phone: [phone]
[e-mail]
Luxembourg
Magasins Jules Neuberg
39, rue Jacques Stas
Luxembourg-Gasperich 2549
Case Postale No. 12
Luxembourg 2010
Phone: [phone]
[e-mail]
Netherlands
GARDENA Nederland B.V.
Postbus 50176
1305 AD ALMERE
Phone: [phone]
[e-mail]
Neth. Antilles
Jonka Enterprises N.V.
Sta. Rosa Weg 196
P.O. Box 8200, Curaçao
Phone: [phone]
[e-mail]
New Zealand
NYLEX New Zealand Limited
Building 2, 118 Savill Drive
Mangere, Auckland
Phone: [phone]
[e-mail]
Norway
GARDENA Norden AB
Salgskontor Norge
Karihaugveien 89
1086 Oslo
[e-mail]
Poland
GARDENA Polska Sp. z o.o.
Szymanów 9 d
05-532 Baniocha
Phone: [phone]
[e-mail]
Portugal
GARDENA Portugal Lda.
Recta da Granja do Marquês
Edif. GARDENA Algueirão
2725-596 Mem Martins
Phone: [phone]
[e-mail]
Romania
MADEX INTERNATIONAL SRL
Soseaua Odaii 117-123,
Sector 1,
Bucureєti, RO 013603
Phone: [phone]
[e-mail]
Russia / Россия
ООО ГАРДЕНА РУС
123007, г. Москва
Хорошевское шоссе, д. 32А
Тел.: (+ 7) 495 247 25 10
[e-mail]
Singapore
Hy - Ray PRIVATE LIMITED
40 Jalan Pemimpin
#02-08 Tat Ann Building
Singapore 577185
Phone: [phone]
[e-mail]
Slovak Republic
GARDENA Slovensko, s.r.o.
Panónska cesta 17
851 04 Bratislava
Phone: [phone]
[e-mail]
Slovenia
GARDENA d.o.o.
Brodiљиe 15
1236 Trzin
Phone: [phone]
[e-mail]
South Africa
GARDENA
South Africa (Pty.) Ltd.
P.O. Box 11534
Vorna Valley 1686
Phone: [phone]
[e-mail]
Spain
GARDENA IBÉRICA S.L.U.
C/ Basauri, nº 6
La Florida
28023 Madrid
Phone: [phone]
[e-mail]
Sweden
GARDENA Norden AB
Försäljningskontor Sverige
Box 9003
200 39 Malmö
[e-mail]
Switzerland / Schweiz
GARDENA (Schweiz) AG
Bitziberg 1
8184 Bachenbülach
Phone: [phone]
[e-mail]
Turkey
GARDENA / Dost Diþ Ticaret
Mümessillik A.Þ. Sanayi
Çad. Adil Sokak No. 1
Kartal - Ýstanbul
Phone: [phone]
[e-mail]
Ukraine / Украина
ALTSEST JSC
4 Petropavlivska Street
Petropavlivska
Borschahivka Town
Kyivo Svyatoshyn Region
08130, Ukraine
Phone: [phone]
[e-mail]
USA
Melnor Inc.
3085 Shawnee Drive
Winchester, VA 22604
Phone: [phone]
[e-mail]
1479-20.960.03 / 0207
©GARDENA
Manufacturing GmbH
D-89070 Ulm
http://www.gardena.com
60
