Gardenline 50752 User manual

User Manual
Product
Info
www.powertoolsupport.com
50752 IM Ed 9
50752
1200W
LAWN EDGER

QR codes take you where you want to go
quicky and easily
Whether you require product information, spare parts or accessories,
details on warranties or aftersales service, or if you want to watch
a product demonstration video, our QR codes will take you there in
no time at all.
What is a QR code?
A QR-code (QR=Quick Response) is a type of matrix that can be read
with a smartphone camera and that contains a link to a website or
contact details, for example.
Advantage: You are not required to manually enter a website address
or contact details.
How it works
To scan the QR code, all you need is a smartphone with QR codes reader
software and an Internet connection*. This type of software can be
downloaded for free from your smartphone’s app store.
Try it out now
Just scan the QR code with your smartphone and
find out more about the Aldi product you have
purchased*.
* Depending on your tarif you may be charged for the connection.
Product
Info
For Know How Videos, click on the
“Product Assistance” tab, then the
“How To Product Videos”link.

Contents
Pack Contents / Parts 2
Contents of Carton 2
Intended use of the 1200W Lawn Edger 2
Description of Symbols 3
Safe Operating Practises 4
General Safety Warnings 6
Additional Safety Rules for Lawn Edgers 9
Parts List 10
Assembling the Upper and Lower Shaft 12
Assembling the Auxiliary Handle 13
Setting the Edge Guide 14
Setting the Cutting Depth 15
Cord Routing / Cord Restraint 16
Operation of the Lawn Edger 16
Edging 17
Edging Tips 17
Landscaping 18
Trenching 18
Cleaning Chamber Guard 18
Maintenance 19
Safety / Deterioration Check 19
Changing the Blade 20
Cleaning and Maintenance 21
Warranty 21
What your 3 Year Warranty means 22
Service Support 22
Accessories 22
Troubleshooting 23
Recycling 24
Technical Specications 24

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
4
Pack contents / parts
Congratulations on the purchase of your Gardenline® 1200W Lawn Edger.
When you open your packaging, first remove all items and check there are
no parts damaged or missing. If you find anything wrong, do not operate
the product until the parts have been replaced or the fault has been
rectified. Failure to do so could result in serious personal injury.
Intended use of the 1200W Lawn Edger
NOTE: This product is for private domestic DIY use only.
It is not suitable for commercial or trade use.
This Lawn Edger is ideal for traditional hard surface edging along
driveways, sidewalks as well as landscaping tasks around the lawn.
By raising the edge guide, the edger can be used in the garden for such
tasks as shaping borders, around trees and flowerbeds.
Contents of carton
1 x Lawn Edger
1 x Blade Spanner
1 x Auxiliary Handle Assembly (includes handle, locking knob, & bolt)
1 x Upper Shaft Locking Knob (with short screw)
1 x Lower Shaft Locking Knob (with long screw)
1 x Instruction Manual
1 x Warranty Card & details
1 x Quick Start Guide
2

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
Description of symbols
The instruction manual or rating plate on your product may show symbols.
These represent important information about the product or instructions
on its use.
Conforms to relevant standards for electrical safety
and electromagnetic compatibility.
This edger is double insulated. There are two independent barriers of
insulation to protect you from the possibility of electric shock.
Wear hearing protection, eye protection and breathing protection.
Wear safety footwear.
Wear safety gloves.
Warning.
Read these instructions for use carefully.
Use at a distance of at least 15m from other people.
Thrown objects and rotating line can cause severe injury.
Do not operate the unit without the safety guard in place.
Keep away from rotating cutter.
Rotating cutting blade.
Direction of edger blade rotation.
Disconnect the mains plug if the cord is damaged or entangled.
Sharp blade, do not touch.
Do not put in water.
3

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
4
Safe operating practices
IMPORTANT: READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
WARNING. When using the machine the safety rules must be
followed. For your own safety and bystanders please read these
instructions before operating the machine. Please keep the
instructions safe for later use.
SAVE THESE INSTRUCTIONS
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
Safe operating practices
Training
a. Read the instructions carefully. Be familiar with the controls and the
proper use of the machine.
b. Never allow people unfamiliar with these instructions or children to use
the machine. Local regulations can restrict the age of the operator.
c. Keep in mind that the operator or user is responsible for accidents or
hazards occurring to other people or their property.
Preparation
a. Before use, check the supply and extension cord for signs of damage
or aging. If the cord becomes damaged during use, disconnect the
cord from the supply immediately. DO NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY. Do not use the appliance if the cord is
damaged or worn.
4

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
b. Never operate the machine while people, especially children, or pets are
nearby.
c. Wear eye protection and covered shoes at all times while operating the
machine.
Operation
a. Keep supply and extension cords away from the blade / cutting parts.
b. Use the machine only in daylight or good artificial light.
c. Never operate the machine with damaged guards or shields or without
guards of shields in place.
d. Switch on the motor only when the hands and feet are away from the
blade / cutting parts.
e. Always disconnect the machine from the power supply: Whenever
leaving the machine unattended and before clearing a blockage, before
checking, cleaning or working on the machine, after striking a foreign
object and whenever the machine starts vibrating abnormally.
f. Take care against injury to feet and hands from the cutting means.
g. Always ensure that the ventilation openings are kept clear of debris.
Maintenance and storage
a. Disconnect the machine from the power supply before carrying out
maintenance or cleaning work.
b. Use only the manufacturer’s recommended replacement parts and
accessories.
c. Inspect and maintain the machine regularly. Have the machine repaired
only by an authorized repairer.
d. When not in use store the machine out of the reach of children.
Recommendation
a. The appliance should be supplied via a residual current device (RCD) with
a tripping current of not more than 30 mA.
5

General safety warnings
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result
in electric shock, re and/or serious injury.
The word power tool used in the following warnings and
throughout this manual refers to both electrical power tools
and also petrol driven power tools.
This unit may not be used by people (including children) with reduced
physical, sensory or mental capacities, with a lack of experience and without
the appropriate knowledge, unless they are supervised by someone who is
responsible for their safety or have been instructed by such a person with
regard to how the unit is to be operated. Children should be supervised to
ensure that they do not play with the device.
Save all warnings and instructions for future reference
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite
accidents. Rags, cloths, cord, string and similar items should never be left
around the work area.
b. Do not operate power tools in explosive environments, such as in the
presence of ammable liquids, gases, or dust. Power tools
create sparks, which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool.
Distractions can cause the operator to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is increased risk of electric shock if your
body is grounded.
c. Do not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
6

d. Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Replace damaged cords immediately.
Damaged or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor reduces the risk
of electric shock.
f. To reduce the risk of electric shock, the manufacturer recommends the
use of a residual current of 30mA or less at all times.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious
personal injury.
b. Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard hat,
or hearing protection will reduce personal injures.
c. Prevent unintentional starting. Ensure the switch is in the“off”
position before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
d. Remove any adjusting key or wrench before turning the power tool
on. A wrench or key left attached to a rotating part of the power tool may
result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
7

General safety warnings
4. Power tool use and care
a. Do not force the power tools. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it“on” and
“o”. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools with care. Check for misalignment or binding
of moving parts, breakage of parts and any other condition that may
affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained
power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier
to control.
g. Use the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working
conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous
situation.
h. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person
responsible for their safety.
8

i) Children should be supervised to ensure that they do not play with
the appliance.
5. Service
a. Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the
power tool is maintained.
Additional Safety Rules for Lawn Edgers.
• Remove loose bracelets or similar jewellery from your wrist whenever
operating edgers or similar equipment.
• Before switching on always ensure that the blade and guard function
correctly and that they are free of any damage. A cracked blade or
guard must be replaced before operating the tool.
• Do not use edger in the rain, or trim edges when they are wet.
• The edger is a major appliance and should not be operated with other
major appliances on the same household circuit.
• Keep extension cord clear of operator, unit and any obstacles at all
times. Do not expose the cord to heat, oil, water, or sharp edges.
• Switch o and remove the plug from the ‘socket-outlet’ if the exible
cord becomes entangled or before adjusting or cleaning the edger.
• When making any adjustments to the tool always wait for the blade to
come to a complete stop and unplug the tool.
• Never attempt to unclog the blade chamber by tapping the tool on
the ground, this can damage the unit.
• Keep hands clear of edge guide and blade when cleaning as these
wear to a very sharp point during edging.
• Before landscaping or trenching, inspect and ensure there are no
exposed or buried cables or pipes or other objects that may create a
hazard or interfere with operating the edger.
• Set depth to only that required for the job, do not overload. If tool
slows, pull back slightly and wait until blade returns to normal speed.
• Never hang the edger by the power cord.
• Only use extension cords intended for outdoor use.
• Wear goggles
• Wear earmus
• Wear a breathing mask
9

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
10
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
Parts List
1. Handle
2. Trigger switch
3. Safety lock button
4. Cord restraint hook
5. Auxilliary handle
6. Auxilliary handle locking knob
7. Upper shaft
8. Upper shaft locking knob
9. Lower shaft
10. Lower shaft port
11. Lower shaft locking knob
12. Edge guide lever
13. Motor housing
14. Blade guard
15. Guard lock knob
16. 190mm serrated blade
17. Blade lock nut
18. Outer blade flange
19. Inner blade flange
20. Rear wheel (not shown)
21. Height adjustment knob
22. Guide wheel
23. Edge guide
24. Blade spanner
10
23
19
20
18
17

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
11
8
9
11
14
16
15
1
2
3
6
7
21
13
12
5
22
4
24

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
12
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
Assembly
Before using your product, the upper shaft (7)
and lower shaft (9) need to be connected, and the
auxiliary handle (5) needs to be assembled and fitted.
Assembling the Upper and Lower Shaft
The shaft must be assembled on removal from the
carton. Remove the bag containing the two small
screws from the shaft.
Note: Before assembling the upper and lower shafts,
you will need to remove and discard the protective
packaging.
1. Insert the lower shaft (9) into the lower shaft port
(10) at the back of the edger where the wiring
is already connected. Carefully feed the wire
through the tube. (Fig A)
2. Align the holes and insert the longer supplied
screw through the shaft. (Fig B)
3. Use the lower shaft locking knob to secure the
lower shaft into position. Secure until finger tight.
(Fig C)
4. Slide the upper shaft (7) over the lower shaft (9)
whilst aligning the holes. (Fig D)
5. Insert the shorter supplied screw through the
holes (Fig E), and then use the upper shaft locking
knob (8) to hold into position by securing finger
tight. (Fig F)
D. E.
A.
B.
C.
F.

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
13
Assembling the Auxiliary Handle
1. Remove the auxiliary handle locking knob (6)
and bolt from the auxiliary handle (5).
2. Fit the auxiliary handle (5) onto the upper
handle and rotate to choose the position most
suitable to the operator. (Fig G)
3. Insert the bolt through the handle (Fig H), and
then tighten by applying the washer and the
auxiliary handle locking knob (6) over the bolt
that has fed through the opposite side.
Secure until finger tight.
G.
H.

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
14
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
Setting the Edge Guide
The edge guide (23) is used when edging is required against a solid material
like a paved surface. It is important to ensure the edge guide is used in these
conditions as the edge guide will assist in preventing the blade from making
direct contact with the paved surface.
1. Position the edger so that the front wheel is approximately 15cm up from
the ground and resting on the back wheels. (Fig I)
2. To set the edge guide (23) in the down position, move the edger guide
lever (12) out away from the blade guard (14) from where it rests in the
notch, and move it towards the back wheels and push into the notch to
lock it into the down position. (Fig J)
3. To set the edge guide (23) in the up position, move the edge guide lever
(12) out away from the blade guard (14) from where it rests in the notch,
and move it towards the front wheel and push into the notch to lock it
into the up position. (Fig K)
I. J. K.

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
15
Setting the Cutting Depth
The cutting depth of the edger can be altered to
one of 3 settings to a Max of 38mm. (25mm,
31mm, 38mm)
1. To adjust the cutting depth, loosen the height
adjustment knob (21) approx 5–6 full turns, but
do not remove it from the screw. (Fig L)
2. Push the height adjustment knob (21) fully
towards the body of the edger whilst at the
same time pushing the guide wheel (22) arm
in the same direction towards the blade guard
(14). (Fig M)
3. Raise or lower the arm to the desired cutting
depth by aligning the notch on the radial arm
with one of the 3 cutting depth holes (Fig N),
and then pull the height adjusting knob (21)
outwards to secure the the chosen cutting
depth. (Fig O)
4. Tighten the knob until all of the slack is taken
out of the assembly. Check to ensure the guide
wheel arm has located into one of the pre
allocated cutting depth positions and the head
of the bolt securing the front wheel arm is sitting
flat on the surface of the wheel arm.
Firmly tighten the height adjustment knob (21).
(Fig L) O.
L.
TIGHTEN
LOOSEN
N.
M.

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
16
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
Cord routing
Always make sure that you route the cord away
from the work area to prevent it from coming near
the blade of the edger. Lay your cable route before
starting work.
Start your edger at the point nearest to the
electrical socket, and then move away whilst
working. This will mean that the cord will be
pulled through the area that has already been cut,
thereby keeping it out of danger of being cut through by the blade.
Cord Restraint
This edger is fitted with a cord restraint to prevent the power cable from
both being disconnected and also to prevent excessive strain on the
connecting plugs during use.
It is recommended the cord restraint is used as follows:
1. Approx 300mm from the end of the extension cable, form a tight loop in
the extension cable, and feed the loop through the hole above the cord
restraint hook (4).
2. Secure the loop over the cord restraint hook (4)
to prevent the cable pulling back through the
hole. (Fig I)
Operation of the Lawn Edger
Switching On and O
This lawn edger is fitted with a lock off button to
prevent accidental operation.
1. To start the edger, push in the side safety lock
button (3) and then depress the trigger switch
(2) fully. (Fig Q)
Keep your finger on the trigger switch (2) only
to maintain power to the edger. (Fig R)
2. To stop the edger, release the trigger switch (2).
NOTE: Take care when turning the edger “On”
that the cutter is in a safe position to operate.
Q.
R.
P.

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
17
Edging
1. Set the cut depth at 25mm and set edge guide
lever (12) to the down position.
2. The guard incorporates a raised rib section which
acts as a blade cut indicator. This rib will assist in
guiding the operator where the blade will cut.
(Fig S). During operation the operator can sight
down the rib of the guard to where the edge is
to be cut.
3. Before starting the edger, line up the edger so
the edge guide (23) rests against the edge of the
paved surface. Both rear wheels should be on
the paved surface when edging.
NOTE: When there is heavy overgrowth of grass
over the paved surface it may drag on the guard.
An initial cut may be required with the edger on
the grass side. This will require lifting up the edge
guide (23) and may require reducing the depth
of cut.
4. To avoid kickback of the edger, tilt the handle down so the blade is above
the ground. (Fig T)
5. Turn the edger on and allow the blade to spin without moving the edger.
6. Slowly raise the handle to lower the blade, finding the edge of the paved
surface and start edging. Then move forward slowly along the edge of the
paved surface, keeping the edge guide (23) pressed lightly against the
pavement edge.
Edging Tips:
- For the first edging each season, it is best to move forward slowly as grass
is thickest then. Subsequent edging will be completed more rapidly.
- If the edger slows down, back it up slightly until the blade returns to
normal speed.
- During edging some sparks may be generated from hitting stones: this
is normal. Do not attempt to edge when the grass or soil is wet or moist;
both for electrical safety and to prevent clogging of the blade chamber.
S.
T.

Understanding and using these operating instructions 1200W Lawn Edger
AFTER SALES SUPPORT
e-mail: [email protected] 1800 909 909
MODEL: №. 50752 • 10/2015 • 50752 (toll free)
18
Operating instructions and safety notes!
AFTER SALES SUPPORT
(toll free)
1200W Lawn Edger
e-mail: [email protected]1800 909 909
MODEL: №. 50752 • 10/2015 • 50752
Landscaping / Trenching
Before landscaping or trenching, inspect and ensure there are no exposed or
buried cables or pipes or other objects that may create a hazard or interfere
with operating the edger. Lift the edge guide (23) for all trenching. Set the
depth to only that required for the job. Do not overload. If the edger slows,
pull back slightly and wait until the blade returns to normal speed.
Cleaning the Guard Chamber
WARNING: Ensure the edger is switched off and is disconnected from
mains power before undertaking this task.
After each use the blade guard chamber should be cleared of dirt and grass
build-up, to maintain cutting efficiency.
1. Undo the guard lock knob (15) and open the blade guard (14). (Fig U/V)
2. Use a stick or screw driver to clean all debris build up in the guard chamber.
(Fig W)
3. When the debris are removed, close the blade guard (14) and ensure the
guard lock knob (15) is tightened.
NOTE: Edging of heavily overgrown edges and damp soils can create
greater build-up of difficult to remove waste. It may be necessary to remove
the bulk of this material using a long thin implement (ie. screwdriver).
U. V. W.
TIGHTEN
LOOSEN
