Garland MCOE5LDSMD Manual

MCOE5LDSMD Rev. 3 (08/01/08)
PARTS
IDENTIFICATION GUIDE
GARLAND ELECTRIC
CONVECTION OVEN
MODEL MCOE5LDSMD
MANUFACTURED EXCLUSIVELY FOR McDonald's BY
GARLAND COMMERCIAL INDUSTRIES, LLC
185 EAST SOUTH STREET FREELAND, PENNSYLVANIA 18224
TOLL FREE: [phone] PHONE: [phone] FAX: [phone]
E-mail: [email protected]om
http://www.garland-group.com

Page 2 MCOE5LDSMD Rev. 3 (08/01/08)
GARLAND ELECTRIC CONVECTION OVEN, MODEL MCOE5LDSMD

Page 3MCOE5LDSMD Rev. 3 (08/01/08)
GARLAND ELECTRIC CONVECTION OVEN, MODEL MCOE5LDSMD
Contents
Exploded View...................4
Card Reader Assembly ...........5
Side Partition Assembly ..........6
Control Panel Assembly ..........6
Element Assembly ...............7
Door Panel Assembly.............7

Page 4 MCOE5LDSMD Rev. 3 (08/01/08)
GARLAND ELECTRIC CONVECTION OVEN, MODEL MCOE5LDSMD
3
45
20
19
14
17
18
21
6
11
12
13
2
1
8
9
10
22
27
26
25
35
28
7
23
24
29
32
33
15
34
31
30
16
Exploded View

Page 5MCOE5LDSMD Rev. 3 (08/01/08)
GARLAND ELECTRIC CONVECTION OVEN, MODEL MCOE5LDSMD
Exploded View
Item Part # Description Item Part # Description
1953209 Double Deck Stacking Kit 21 1765704 Blower Wheel Assembly
1 1960901 Main Top MCOE5L 22 1951502 Motor 208-240 1/3 HP 5/8 Shaft
2 1960902 Cover, Micro Switch Access 23 1027801 Swivel Caster with wheel lock
3 1960502 Flue Box MCOE5 24 1027800 Swivel Caster W/O lock
4 1961199 Partition Side 25 1028500 3/8 x 90 BX Connector
5 1671101 Fan - 110MM, 208/240 V 26 1960504 BX Cable 15 3/8”
6 1951402 Body Side, CNTRL 27 1960503 High Limit Cover
7 1385497 Hinge Bracket Assembly 28 4520416 High Limit 135F Degree
8 1011201 Steel Tubing Chrome Spacer 29 1028501 3/8 BX connector
9 1951401 Body Side, Oven 30 1962196 Micro Switch Bracket
10 1960795 Bae MTG BRKT 31 9006401 Switch-Mini Snap Hi-Temp 1 Amp.
11 1766001 Oven Rack 32 8003221 4-40x1 PH Pan HD M/S ZC
12 1966503 Door Seal MCOE5 33 8001505 4-40 Keps Nut ZC
13 1766004 Rack Guide 34 1962207 Door Catch
14 1962199 Oven Door MCOE5
35
1834503 Cord Set w/NEMA-30P
15 1966501 Door Seal RT Silicon 1966411 Cord Set w/3P - Pin and Sleeve
16 1966502 Door Seal Top / Bottom Silicon 4513157 Fuse, (600V / 10A)
17 1765199 Element Assembly 1774101 Fuse Holder
18 1960797 Bae Assembly 1966406 Wire Harness; Relay Board to Controller
19 1946673 Control Panel Assembly 1966407 Wire Harness; Card Reader
20 1962299 Card Reader Assembly 1966408 Wire Harness; Main Power
Card Reader Assembly
Item Part # Description
1962299 Card Reader Assembly
1 1962203 Bracket, Card Reader
2 1966404 Card Reader
3 1955703 Stando-Nylon 1/4 Dia 3/4 LG
4 8001502 Nut W/Lock Washer 6-32 KEP
5 8005501 FHS Stud 6-32 x 7/8 L
1
4
2
3
5
Card Reader Assembly

Page 6 MCOE5LDSMD Rev. 3 (08/01/08)
GARLAND ELECTRIC CONVECTION OVEN, MODEL MCOE5LDSMD
2
1
3
2
4
7
5
8
6
12
9
11
11
10
11
10
3
4
1
2
Side Partition Assembly
Control Panel Assembly
Side Partition Assembly
Item Part # Description
1 1961101 Partition Side MCOE5L
2 9000902 #10-24 Hexagonal TNS
3 1637002 Contactor 240V Coil
4 1962201 Relay Board Mounting Brkt
5 1767901 Nylon PCB Spacer
6 1966405 Relay Board
7 1860113 Terminal Block 4 Lug
8 1962208 Bracket, Terminal Block
9 4521630 Transformer, 24 VAC
10 8002107 10x1/2 PH TRS HD
11 8003123 10-24x5/8 PH TRS HD
12 9006800 RTD Probe
Control Panel Assembly
Item Part # Description
1 1946623 Control Panel MCDS MCOE5L
2 1966401 Control, MCDS MCOE5
3 1966410 Card Reader Cover / Black
4 1872404 Power Switch

Page 7MCOE5LDSMD Rev. 3 (08/01/08)
GARLAND ELECTRIC CONVECTION OVEN, MODEL MCOE5LDSMD
1
3
2
4
5
4
6
5
7
7
2
4
5
3
1
7
8
6
7
9
9
Element Assembly
Door Panel Assembly
Element Assembly
Item Part # Description
1 1765101 Element Inner 208/240V 2500W
2 1765102 Element Outer 208/240V 2500 W
3 1765111 Element Center 208/240V 2500 W
4 1765105 Element Holder W/Flange
5 1765106 Element Holder W/O Flange
6 8003107 10-24 x 3/4 screw
7 8001501 10 - 24 Keps Nut
Door Panel Assembly
Item Part # Description
1 1962101 Door Panel Solid
2 1962197 Door Liner Solid
3 1962198 Door Frame
4 1961906 Insulation ATD T5000
5 1961908 Insulation Fiberglass
6 1952098 Handle Half Size Co
7 1952096 Handle End Latch, complete
1966604 Latch Roller only
1966607 Latch Spring only
8 G0728-1-9 T’Stat Guard
9 8003142 Screw 1/4 - 20x3/4
