Garland ECG User guide

P/N: 3073400 04/2001
INSTALLATION AND OPERATING
INSTRUCTIONS
FOR
ECG SERIES ELECTRIC CHAIN
GRIDDLES
THIS MANUAL SHOULD BE HANDED TO THE EQUIPMENT OWNER AND
RETAINED FOR FUTURE REFERENCE.
THE FOLLOWING INSTRUCTIONS SHOULD BE READ CAREFULLY AS THE
MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR ANY DAMAGE TO
PROPERTY OR PERSONS CAUSED BY INCORRECT INSTALLATION OR OPERATION
OF THE EQUIPMENT.
TABLE OF CONTENTS
GENERAL INFORMATION
TECHNICAL SPECIFICATIONS
GENERAL INSTALLATION
INSTALLATION PROCEDURE
COMMISIONING
OPERATING INSTRUCTIONS
MAINTENANCE & CLEANING
……………………………………
……………………………………
……………………………………
……………………………………
……………………………………
……………………………………
……………………………………
PAGE 1
PAGE 2
PAGE 3
PAGE 4
PAGE 4
PAGE 5
PAGE 6
MANUFACTURED BY: DISTRIBUTED BY:
GARLAND COMMERCIAL RANGES LIMITED GARLAND COMMERCIAL INDUSTRIED, INC.
1177 KAMATO ROAD, MISSISSAUGA, 185 EAST SOUTH STREET,
ONTARIO, CANADA L4W 1X4 FREELAND, PA 18224
Phone: [phone] Fax: [phone] Phone: [phone] Fax: [phone]
ECGTRAINING06

1
GENERAL INFORMATION
1. Damage Check: Check carton or crate for possible damages incurred in shipping. After
carefully examining, check for “Concealed” damage. Report any damage immediately to
your carrier.
2. Any protective material covering stainless steel parts must be removed.
3. All units are shipped from the factory with legs or casters fitted, unless specifically ordered
without
4. The type of voltage supply that the equipment was manufactured for at the factory is noted on
the data plate and on the packaging. This type of supply must be used.
5. Do not remove permanently affixed labels, warnings or data plates from the appliance, for
this may void approvals and create a safety hazard.
NOTE: The griddle top is raw steel and can react with moisture forming rust. This is normal and
not considered a defect. Clean with a stainless steel fiber pad. A light coating of salt free oil may
be applied to prevent further rusting.
INTRODUCTION
The Garland ECG series complies with the standards CSA C22.2 no. 109 – latest edition, the
UL197 – latest edition and the ANSI/NSF 4 – latest edition. The installation & connection of
this appliance must comply with current codes. In Canada – the Canadian Electrical Code Part 1
and in the USA – the National Electrical Code.
SAFETY
This manual pertains to Electric Chain Griddles. The reader/operator must interpret its contents
to applicable needs. If there is any question of interpretation of any of the literature pertaining to
Garland Electric Chain Griddles, please contact your Authorized Service Agency or our
Customer Service Department at 1 800 427 6668.
A qualified person must perform the installation in accordance with local codes.
Always follow these safety instructions when operating the Electric Chain Griddle:
Qualified persons must only operate the unit. DO NOT operate without reading this manual.
DO NOT operate the product unless it has been properly installed and grounded.
SAFETY - CONTINUED

2
DO NOT operate the product unless all service and access panels are in place and fastened
properly.
DO NOT attempt to repair or replace any part of this product unless all main power supplies
have been disconnected.
WARNING - to avoid personal injury:
USE EXTREME CAUTION in setting up, operating and cleaning this product to avoid coming
into contact with hot grill surfaces or hot grease. Suitable protective clothing should be worn to
prevent the risk of burns.
NOTE all warning labels and markings on the product, which call attention to further dangers
and necessary precautions.
WARNING – This appliance must not be cleaned with a water jet.
TECHNICAL SPECIFICATIONS
LOADING CHART
LOAD PER PHASE AMPS PER PHASE
MODEL TOTAL
kW LOAD Voltage X-Y X-Z Y-Z X Y Z
Amps
1 phase
8.60 208 2.60 3.00 3.00 23.3 23.3 25.0 41.3
ECG-24R 8.60 240 2.60 3.00 3.00 20.2 20.2 21.7 35.8
12.90 208 4.30 4.30 4.30 35.8 35.8 35.8 62.0
ECG-36R 12.90 240 4.30 4.30 4.30 31.0 31.0 31.0 53.8
17.20 208 5.60 6.00 5.60 48.3 46.6 48.3 82.7
ECG-48R 17.20 240 5.60 6.00 5.60 41.9 40.4 41.9 71.7
21.50 208 6.90 7.30 7.30 59.1 59.1 60.8 103.4
ECG-60R 21.50 240 6.90 7.30 7.30 51.2 51.2 52.7 89.6
25.80 208 8.60 8.60 8.60 71.6 71.6 71.6 124.0
ECG-72R 25.80 240 8.60 8.60 8.60 62.1 62.1 62.1 107.5
EXTERIOR DIMENSIONS
MODEL HEIGHT WIDTH DEPTH WEIGHT
mm ins mm ins mm ins kg Lb.
ECG-24R 905 35 5/8 610 24 889 35 120 265
ECG-36R 905 35 5/8 914 36 889 35 181 400
ECG-48R 905 35 5/8 1219 48 889 35 227 500
ECG-60R 905 35 5/8 1524 60 889 35 272 600
ECG-72R 905 35 5/8 1829 72 889 35 318 700
ELECTRICAL SUPPLY
Before attempting the electrical connection, the rating plate should be checked to ensure that the
equipment’s electrical characteristics agree. On Electric Chain Griddles, the supply entrance is
located at the rear of the main bottom. The supply terminal block is accessible from the front.
ELECTRICAL SUPPLY
CONTINUED
The electrical supply must be adequate for the voltage, phase and current marked on the rating
plate.

3
Note: A means of disconnection from the supply having a contact separation of at least 3 mm in
all poles must be incorporated in the fixed wiring.
WARNING: THIS APPLIANCE MUST BE GROUNDED
GENERAL INSTALLATION
A qualified person as required by the local electrical authorities must install this equipment.
WARNING: The appliance must be grounded.
CAUTION: Prior to installation, check the electrical supply to ensure input voltage and phase
match the equipment voltage rating and phase. See data plate located on the bottom of the
control section near the front.
The Electric Chain Griddle must be level front to back, side to side and diagonally. This leveling
must be done with the unit under the hood and in its normal operational position.
SITING
The base on which the unit is to be sited, must be capable of adequately supporting the weight of
the appliance and any ancillary equipment. (Refer to technical specifications in this manual).
Once in position check the equipment is level, both front to back, side to side and diagonally.
Adjust if necessary.
VENTILATION AIR
The Electric Chain Griddle (ECG) is intended to be installed under a ventilation hood.
Proper operation of exhaust fans (proper speed, rotation and adjustment) is essential. In addition,
a make-up air system (HVAC) for the kitchen to supply fresh air is recommended.
Any ventilation system will break down if improperly maintained. The duct system, the hood,
and filters must be cleaned on a regular basis and kept grease free.
CLEARANCES
The space in which the appliance is to be sited must include the minimum installation clearances
shown below:

4
COMBUSTIBLE WALL
MINIMUM CLEARANCE
NON-COMBUSTIBLE WALL
MINIMUM CLEARANCE
ALL MODELS
mm ins mm ins
SIDES 152 6 152 6
BACK 152 6 152 6
INSTALLATION PROCEDURE
GENERAL
1. Carefully remove the unit from the crate. All packing material must be removed from the
unit. The protective material covering the stainless steel must be removed immediately after
the unit is installed.
2. Adequate clearance must be provided for servicing, ventilation and proper operation. The
product must be kept clear of combustible material.
CASTERS
1. The front casters on the unit are equipped with brakes to limit movement of the range without
relying on the electrical connection to limit appliance movement.
2. A restraint can be attached to the unit near the electrical connection. If the restraint is
disconnected, be sure to reconnect it after the range has been returned to its originally
installed position.
COMMISSIONING
Ensure all circuit breakers located behind the access door on the control panel are set to the “ON”
position.
1. Ensure that all controls are in the “OFF” position and turn on the main electrical supply.
2. Operate each section of the unit in accordance with the operating instructions provided in this
manual.
3. Check that the product functions correctly and the voltage supply to the unit does not drop by
more than 5% when all sections are operated simultaneously.
When the operation has been checked, hand the manual to the user or purchaser for retention and
instruct them in the efficient and safe operation of the appliance.
OPERATING INSTRUCTIONS
GRIDDLES
Griddle tops are designed to have food cooked directly on the surface. Do not put pots or pans on
the griddle surface as this will scratch or nick the surface and will result in improper cooking or

5
sticking of product. Never salt food over griddle since this will build up a gummy residue making
it difficult to clean.
Avoid hitting the surface of the griddle with the edge of a spatula since this will cause nicks. The
most frequently used temperatures are 149C to 182C (300F to 360F). After one cycle, the
griddle plate will discolour. This is normal and will not affect cooking performance.
Check the grease container and drain frequently during heavy use to prevent overflow.
OPERATING THE GRIDDLE:
NOTE: Ensure the electrical supply to the appliance is turned "ON".
1. Switch “ON” main power switch on the control panel.
2. Switch “ON” desired section(s).
3. Set the thermostat to the desired temperature.
SHUTTING THE GRIDDLE DOWN:
1. Set the thermostat to the OFF position.
2. Switch “OFF” all sections.
3. Switch “OFF” main power switch on the control panel.
MAINTENANCE & CLEANING
CLEANING:
STAINLESS STEEL:
Stainless steel should be cleaned using a mild detergent, a soft cloth and hot water. If it is
necessary to use a non-metallic scouring pad, always rub in the direction of the grain in the metal

6
to prevent scratching. Wash a small area at a time and rinse the washed area with a clean sponge
dipped into a disinfectant and wipe dry with a soft clean cloth before it can dry.
Use only stainless steel, wood or plastic tools to scrape off heavy deposits of grease or oil. Do not
use ordinary steel scrapers or knives, as particles of iron may become embedded and rust.
NEVER USE STEEL WOOL.
GRIDDLES
PREPARING A NEW GRIDDLE:
1. Remove the protective coating on the surface using a mild detergent.
2. Thoroughly rinse the griddle with vinegar and a water solution (3/4-cup vinegar per quart of
water) and dry.
SEASONING THE GRIDDLE:
1. Using a clean cloth, rub a thin and even layer of oil into the griddle surface. Oil should be an
unsalted shortening or high temperature cooking oil.
2. Set the griddle thermostat to 66C (150F) and heat the griddle surface until the oil begins to
caramelize (turn a golden brown colour).
3. Scrape off the caramelized oil with a standard spatula.
4. Repeat step 1, and set the griddle thermostat to 135C (275F).
5. Repeat steps 2 &3. The griddle is now seasoned and ready for use.
GRIDDLES -CONTINUED
CLEANING INSTRUCTIONS (AFTER EACH USE)
1. Using a traditional 64mm-76mm (2 ½”-3”) scraper or spatula scrape the griddle surface (to
remove food particles and oil residues) towards the grease trough using even back to front
strokes. Deposit debris into the chute.
2. Using a clean cloth, rub a thin and even layer of oil into the griddle surface.

7
3. Remove the grease drawer, empty and wash thoroughly with soap & water. Replace.
CLEANING INSTRUCTIONS (FOR HEAVY BUILD UP)
(After using cleaners & grease cutter, re-season the griddle)
Apply to a warm griddle for best results.
1. Using a traditional 64mm-76mm (2 ½”-3”) scraper or spatula scrape the griddle surface (to
remove food particles and oil residues) towards the grease trough using even back to front
strokes. Deposit debris into the chute.
2. Apply griddle cleaner evenly over the griddle surface and let sit as directed. Follow the
procedures on the label of the specific cleaning product.
3. Using a traditional scraper or spatula, slosh around the griddle cleaner to remove the build up.
4. Scrape the griddle surface towards the grease trough using even back to front strokes. Repeat
step 2 if necessary.
5. Using a mild detergent, clean the surface and rinse thoroughly with a water and vinegar
solution. Dry griddle.
6. Using a clean cloth rub a thin and even layer of oil into the griddle surface.
7. Re-season the griddle as detailed above. The griddle is now ready for use.
GRIDDLE DO’S & DON’TS
DO’S
1. Season the griddle. This will prevent foods from sticking and make it easier to keep the
surface clean.
2. Keep the surface clean. Scraping the surface throughout production to clear foods and oils
prevents build up and will make it easier to keep the surface clean.
3. Turn the temperature down during slow periods. Reducing the temperature or turning
sections off during slow periods will conserve energy and prevent the plate from overheating.
DON’TS
1. Do not use salt to clean the griddle surface. Salt is corrosive and can cause pitting of the
griddle.
2. Do not allow metal utensils (Spatula, scraper, etc.) to nick and/or dent the surface of the
griddle. The edges of these utensils are sharp and will create divots that oil can collect in and
caramelize which will cause sticking.

8
3. Do not use the griddle as a hot top. A large pan or pot will trap heat and can cause the griddle
plate to warp.
4. Do not overheat the griddle to preheat faster. Preheating only takes 15-20 minutes.
SERVICING
To ensure efficient and safe operation of the appliance it is recommended that servicing be
carried out at regular intervals, the frequency of which will vary, depending on the installation
conditions and usage. Usually once per year is adequate.
Servicing must be carried out by competent persons in accordance with the law.
SAFETY
It is essential that the instructions in this booklet be strictly followed for the safe and economical
operation of the equipment. If it is known or suspected that a fault exists on the appliance then it
must not be used until a competent person has rectified the fault.

9
