Garmin Honda NUVI 350 GPS User manual

Honda Portable
Navigation System
personal travel assistant
quick reference guide

2
Register Your Honda Portable Navigation System
Go to http://my.garmin.com to register your Honda Portable Navigation System.
Placing the unit on the Mount
1. Flip up the GPS antenna.
2. Fit the bottom of your unit into the cradle on the vehicle mount.
3. Tilt the unit back until it snaps into place.
To remove your unit from the cradle, press the small tab on the
bottom of the cradle up, rotate the unit, and remove it.
Turning the unit on and off
Press and hold the Power button on the top of the unit.
Charging the Honda Portable Navigation System
You can charge the unit using the vehicle mount, connecting the USB cable to the unit and your
computer, or by connecting the AC adapter to the unit and a wall outlet.
Acquiring Satellites
Before the unit can nd your current location and navigate a route, you must do the following:
1. Go outdoors to an open area, away from tall buildings and trees.
2. Flip up the GPS antenna on the back of the unit, so that it is parallel to the ground.
3. Turn on the Honda Portable Navigation System.
Acquiring satellite signals can take a few minutes. The bars indicate satellite strength.
NOTE: The rst time the Honda Portable Navigation System acquires satellites (or if the unit
has moved hundreds of miles since last acquiring satellites) it may take several minutes.
Afterward, acquisition times are quicker during normal use.
Tab

3
Tips and Quick Settings
Tips
• To quickly return to the Menu page, press and hold the Back button.
• Touch and to see more choices. Touch and hold an arrow to scroll faster.
• Touch the Help button to learn more about the Travel Kit features.
• To extend the battery life, close the GPS antenna when you do not need GPS signals. You can
also decrease the brightness.
Quick Settings
Press and quickly release the Power button or
touch on the Menu page. Move the sliders to
adjust the volume and brightness. Touch Lock to
prevent accidental screen taps. To unlock the screen,
press the Power button.
Loading Items to Your Honda
Portable Navigation System
1. Connect the small end of the USB cable into the mini-
USB port on your unit.
2. Connect the larger end of the cable to an available
USB port on your computer.
3. Windows® Computer: Double-click the My Computer icon on your computer’s desktop. Two new
removable disk drives appear in your list of drives: “nuvi” and “nuvi sd.”
Mac®Computer: The “nuvi” and “nuvi sd” drives mount onto your Mac desktop as two mounted
volumes.
4. Double-clickoneoftheunitdrives/volumestoopenit.Copyandpastelesintothedrive(Windows)or
draganddroplesontothevolumeicon(Mac).
MCX connector (for
an optional external
antenna)
Headphone jack
SD card slot
Power button
Mini-USB port

4
Finding Your Destination
You can search for an exact address or browse the Find menu categories. Touch and
to see more choices.
Touch a category. Touch a sub category.
Touch Where to.
➊ ➋ ➌
Touch your destination.
➍
Touch Go.
➎
Enjoy the route!
➏
TIP: Touch Near to narrow your
search area.
TIP: Touch Spell to narrow
your search.
Following Your Route
Follow the route to your destination using the Map page. As you travel, the Honda Portable
Navigation System guides you to your destination with voice prompts, arrows on the map, and
directions at the top of the Map page. If you depart from the original route, the unit recalculates the
route and provides new route instructions.

5
Viewing the Map Page
From the Menu page, touch View Map to open the Map page. The position icon shows
your location. Touch and drag the map to view different areas.
Map Page while Navigating a Route
Touch Arrival or
Speed to open the
Trip Information page.
Touch Turn In to
open the Next Turn
page.
Touch the text bar
to open the Current
Route page.
Touch to zoom out.
Touch to zoom in.
Touch Menu to return
to the Menu page.
Adding Stops to Your Route
You can add a stop (via point) to your route. The unit gives you directions to the via point and then
to your nal destination. With a route active, touch Menu > Where to.
Touch Go.Touch Yes to add this stop
before your destination.
Search for the extra stop.
➊ ➋ ➌

6
Setting a Home Location
Touch Set Home. Select an option.
Touch Where to >
My Locations.
➊ ➋ ➌
Locking Your Honda Portable Navigation System
To help prevent theft of the unit, do the following:
1. Flip up the GPS antenna and acquire satellites.
2. On the Menu page, touch Settings > System.
3. Touch the button next to Garmin Lock. Touch OK.
4. Enter a four-digit PIN. Touch Yes to accept the PIN.
5. Touch OK. Drive to a security location, and touch Set.
6. Eachtimeyouturnontheunit,enterthefour-digitPINordrivetothesecuritylocation(withtheantenna
up).
NOTE: If you forget your PIN and your security location, you must send your unit to Garmin to get
it unlocked. You must also send a valid product registration or proof of purchase.

7
Resetting the Honda Portable
Navigation System
If the screen stops functioning, turn the unit off and on
again. If this does not help, do the following:
1. Disconnect the unit from external power.
2. Flip up the GPS antenna.
3. Press the Reset button.
4. Connect the unit to a power source. It should automatically
turn back on and operate normally.
Using the Travel Kit
The Travel Kit includes several functions that are helpful when
you are traveling (for example, MP3 Player, Audible
Book Player, and Currency Converter). On the Menu page,
touch Travel Kit. Touch the arrows to view more items.
Touch Help to learn more about each feature.
➋
➌

© 2007 Garmin Ltd. or its subsidiaries
Garmin®is a registered trademark, and nüvi™, MyGarmin™, Garmin Travel Guide™, and Garmin Lock™are trademarks
of Garmin Ltd. or its subsidiaries and may not be used without the express permission of Garmin. Windows®is a
registered trademark of Microsoft Corporation. Mac®is a registered trademark of Apple Computer, Inc.
For the latest free software updates (excluding map data) throughout the life of your Garmin products, visit the Garmin
Web site at www.garmin.com.
April 2007 190-00745-03 Rev. A Printed in Taiwan
Important Information
This guide provides short instructions for various operations of your Honda Portable Navigation System. Fold
and keep this guide in your glove box.
See the Important Safety and Product Information guide for product warnings and legal information.
CAUTION: This product contains a lithium-ion battery. See the Important Safety and Product Information
guide in the product box for important battery safety information.
Notice: Check your state and local trafc laws before mounting. Currently, state laws in California and
Minnesota prohibit drivers from using suction mounts on their windshields while operating motor vehicles.
Other Garmin dashboard or friction mounting options can be used. See the Important Safety and Product
Information guide that came with your Honda Portable Navigation System for more details.
Customer Support
For product services and repairs, contact your Honda dealer. For questions about using your Honda Portable
Navigation System, contact Honda Customer Relations by phone: [phone], Monday–Friday, 8:00
AM–7:30 PM Eastern Time; or go to www.garmin.com/support, and click Product Support.
More Information
Refer to the owner’s manual located on your “nuvi” drive and on the Garmin Web site: www.garmin.com/
hondaportablenavigation. Click the Manuals link and then select Download.

Système de Navigation
Portatif Honda
assistant personnel de voyage
guide de référence rapide

10
Enregistrer votre système de navigation portatif Honda
Accédez au site http://my.garmin.com pour enregistrer votre système de navigation portatif Honda.
Vous pourrez également vous y procurer des mises à jour de logiciel,
des cartes, des services et des accessoires pour votre appareil.
Installation de l’appareil sur la base
1. Relevez l’antenne GPS.
2. Insérez le bas de l’appareil dans le socle de la base pour véhicule.
3. Redressez l’appareil jusqu’à ce qu’il s’enclenche en position.
Pour retirer l’appareil du socle, appuyez sur la languette au bas du
socle, faites pivoter l’appareil et enlevez-le.
Mise sous/hors tension de l’appareil
Maintenez enfoncé le bouton Power situé sur le dessus de l’appareil.
Chargement du système de navigation portatif Honda
Pour charger l’appareil, vous pouvez utiliser la base pour véhicule, brancher le câble USB dans
l’appareil et dans un ordinateur ou brancher l’adaptateur c.a dans l’appareil et dans une prise murale.
Acquisition des satellites
Pour que l’appareil puisse déterminer votre position actuelle et vous permettre de suivre un
itinéraire, vous devez d’abord effectuer la procédure suivante :
1. Allez à l’extérieur dans un espace découvert, sans grands immeubles ou arbres à proximité.
2. Relevez l’antenne GPS qui se trouve à l’arrière de l’appareil, de manière qu’elle soit parallèle au sol.
3. Allumez l’appareil.
L’acquisition des signaux satellites peut prendre quelques minutes. Les barres vous
indiquent la puissance du signal.
REMARQUE : L’acquisition peut prendre quelques minutes s’il s’agit de la première fois que
votre système de navigation portatif Honda capte des signaux satellite, ou lorsque
l’appareil se trouve à plusieurs centaines de kilomètres de l’endroit où vous aviez
capté les signaux pour la dernière fois. Par la suite, le délai d’acquisition est plus
court en utilisation normale.
languette
