Garmin StreetPilot III User manual

quick start
guide
portable GPS with
auto-routing and voice
StreetPilot™ III
Read
This
First!
real qs.indd 3/16/01, 5:54 PM1

2
Before using your StreetPilot III, check to see that your package includes the following items. If you
are missing any parts, please contact your GARMI dealer immediately.
Standard Package:
• StreetPilot III with Detachable Antenna
• Owner’s Manual
• Quick Start Guide
• Dash Mount Kit
• External Speaker System with 12-volt Adapter
• MapSource City avigator CD-ROM
• USB Programmer
• USB Programmer User’s Manual
• MapSource User’s Manual
• 32MB Blank Data Card
• PC Cable
• Single DCA Unlock Code Certifi cate
Optional accessories for the StreetPilot III are listed in the Owner’s Manual, starting on page 48.
Quick Start
Packing List
Help us better support you by completing your on-line regis-
tration today! Why should you register your StreetPilot III?
• Notifi cation of Product pdates
• Notifi cation of New Products
• Lost or Stolen unit tracking
Visit our website (www.garmin.com) and look for the
Product Registration link on the home page. If you have any
questions or comments regarding the use of the StreetPilot III
you can visit our web site or contact our Customer Service
Department M-F, 8:00-5:00 Central Time (except holidays)
at 1-800-800-1020.
real qs.indd 3/16/01, 5:54 PM2

3
Thank you for purchasing the GARMI StreetPilot III—the result of our continuing effort to
provide quality, user-friendly automotive navigation systems to suit all your needs. This Quick Start
Guide is designed to introduce the basic functions of the unit. Please take a few moments now to
review the features of your StreetPilot III, as illustrated below. After reading through this guide, if
you have additional questions regarding a particular feature, more information can be found in the
Owner’s Manual.
Quick Start
Unit Features
Power/Data Connector
(Back Side) Connections for
Power, Ground, Serial Data
In and Serial Data Out.
16 Color LCD Display
On screen information is
referred to as a “page”.
Press PAGE key to select
a different screen.
Detachable Antenna
Rotate upright for best
satellite reception.
Power/Backlight Key
Press and hold to turn
on/off. Press momentarily
to adjust screen backlight
and contrast.
Battery Door
(Back Side) To open, turn metal D ring
counterclockwise 1/4 turn and pull
battery door away from unit.
Cartridge Door
(Bottom) Insert programmed card
for increased map detail and infor
mation lookup capability.
Rocker Keypad
Moves the cursor, pans
the Map Page and
enters data.
real qs.indd 3/16/01, 5:54 PM3

4
The StreetPilot III uses six (6) AA batteries, which are installed at the back of the unit. Alkaline,
rechargeable, Lithium, or i-Cad batteries can be used. Battery life will vary due to a variety of factors,
including surrounding temperature and the use of backlighting. You may fi nd that Lithium batteries
provide longer life in colder conditions. Saved information will not be lost when you replace the
batteries.
WARNING: It is very important to install ALL batteries with the proper polarity, positive (+
or negative (- , orientation as indicated in the unit’s battery compartment. Batteries can
leak and cause personal injury and property damage if you install them incorrectly.
A power symbol (electrical plug) appears at the bottom of the Main Menu and in the upper left
hand corner of the Trip Information Page (see page 13) when the unit is running on external power.
When the unit is running on AA batteries, instead of the power symbol a green battery strength bar
indicator appears. The bar shortens as the unit uses battery power. To conserve battery life you can
switch to Battery Saver mode (see Owner’s Manual page 41) or you can use the Vehicle Power Cable.
When the battery power falls below a certain level, the bar indicator turns red. You should replace
the batteries when this occurs. In addition, a ‘battery voltage is low’ message appears at the bottom
of the page.
To install the batteries:
1. Lift up the metal D ring at the back of the unit and turn it ¼ turn counterclockwise to open the
compartment door.
2. Install the batteries (as shown at left and as marked in the battery compartment).
3. Turn the D ring ¼ turn clockwise to lock the door in place.
Quick Start
Installing The Batteries
I
• Observe correct polarity when installing batteries.
• Replace all batteries at the same time.
• Do NOT mix new and used batteries.
• Do NOT mix Alkaline batteries with Lithium or Ni-Cad
rechargeable batteries.
Immediately after you install new batteries, turn the unit on
to ensure that the unit’s battery strength indicator displays a
fully-charged battery condition.
If the unit does not turn on or the battery level indicator
displays a partially charged battery condition, recheck for
proper battery installation. If, after checking installation,
the battery level indicator continues to indicate a partially
charged condition, the newly installed batteries may be
depleted from long-term storage. Replace with fresh batteries.
real qs.indd 3/16/01, 5:54 PM4

5
Quick Start
Vehicle Installation
Do Not Mount Where Driver’s
Field of Vision is Blocked
Do Not Mount Over
Airbag Panels
Do Not Place nsecured
on the Vehicle Dash
Do Not Mount in Front
of an Airbag Field of
Deployment
The StreetPilot III is portable, allowing you to easily carry the unit from vehicle to vehicle or take
it with you once you reach your destination. A Dash Mount kit consisting of a mounting bracket,
mounting base, required hardware and adhesive pads is included with the StreetPilot III. Installation
of the mounting bracket should be performed with consideration for the following safety diagram
and warnings:
Installing the Mounting Base
1. Select a suitable location for installation that allows routing of an external power cord and/or
antenna cable (if needed) to the GPS unit. If you are NOT using a remote antenna, be certain to
select a location where the GPS unit’s antenna has a relatively unobstructed view of the sky.
2. To secure the mounting base to the dash of the vehicle you may choose either the permanent (hole
in disk) or repositionable adhesive options (no hole in disk). Carefully clean the area where the base
is to be placed using an alcohol dampened cloth. Wipe the area dry with a clean, dry cloth. Remove
one side of the protective backing from the adhesive, and place on the bottom of the base. Remove
the remaining backing from adhesive and position the base on the cleaned area. Be certain the
locking lever on the base faces forward for easy access.
Secure Mounting Base with Disk Adhesive
Mounting Base
Adhesive Disk
(permanent shown)
Mounting Surface
NOTE: Allow the permanent adhesive to set 24 hours
before using the dash mount. If permanent adhesive is later
removed, use rubbing alcohol to clean any adhesive residue.
Repositionable adhesive should only be used on clean, dust-
free surfaces.
WARN NG: For use in vehicles, it is the sole responsibility
of the owner/operator to place and secure the GPS unit so
that is will not interfere with the vehicle operating controls
and safety devices, obstruct the driver’s view of driving
conditions, or cause damage or personal injury in the event
of an accident. Do not place this mounting bracket over
airbag panels or in the fi eld of airbag deployment. Airbags
expand with a rapid fi re force that can propel objects in
their path towards the vehicle driver or passengers causing
possible injury. Refer to airbag safety precautions contained
in the vehicle owner’s manual. Do not place this mounting
bracket where the driver or passengers are likely to impact
it in an accident or collision. The mounting hardware
provided by GARMIN is not warranted against collision
damage or the consequences thereof.
real qs.indd 3/16/01, 5:54 PM5

6
Quick Start
Vehicle Installation
Installing the GPS Unit into the Mounting Bracket
1. Locate the tabs on the base/top of the mounting bracket (see fi gure to the left) and the correspond
ing notches on the bottom/top of the GPS unit’s case.
2. Align the bottom notches on the GPS unit with the corresponding two tabs on the mounting
bracket base and push the top of the GPS unit back into the bracket until the top notch and tab
snap in place.
3. Secure the GPS unit in the bracket by tightening the locking knob on the top of the mounting
bracket.
Attaching the External Speaker System with 12 DC Adapter to the GPS
1. Locate the power connector on the rear of the StreetPilot III (behind the rubber weather cap). The
connector is “keyed” with a notch located between two of the four pins.
2. Mate the round, 4 pin power plug on the External Speaker System with 12VDC Adapter to this
connector by aligning the notches and pushing the plug into the connector until fully seated. Insert
the 2.5mm speaker plug into the speaker jack located below the antenna (see fi gure to the left).
Press the speaker cable into the two cable holders on the back of the mounting bracket.
The 2.5mm mini jack may be used with the External Speaker System or with your own speaker/
headphone (unpowered and rated at 8 ohms). The speaker which is built into the External Speaker
System with 12VDC Adapter will work without the cable being plugged into the vehicle’s power
source.
3. Plug the cigarette lighter portion of the External Speaker System with 12VDC Adapter into an
available cigarette lighter receptacle in your vehicle. Use care when routing the adapter cable being
certain that it does not interfere with vehicle operation in any way.
Speaker Plug
Speaker Cable
Holders
Power
Connector
Bottom Tabs
Top Tab
Mounting Bracket
Locking
Knob
Locking
Knob
real qs.indd 3/16/01, 5:54 PM6

7
Quick Start
Vehicle Installation
Attaching Mounting Bracket to Base
1. Slide the locking lever, on the mounting base, to the left (unlocked position).
2. Attach the bracket assembly to the mounting base by sliding the disk on the bottom of the bracket
into the base until it clicks into place.
3. Rotate the bracket assembly left or right until the desired angle is achieved. Slide the locking lever to
the right (lock) to secure the bracket assembly to the base.
Adjusting the Mounting Bracket’s iewing Angle
1. Tilt the GPS unit forwards or backwards by pressing and holding down on the adjustment button on
the back side of the bracket assembly. Adjust the unit as desired and release the button.
2. Rotate the entire bracket assembly by sliding the locking lever to the left (unlocked position). Adjust
the angle as desired and move the lever back (right) to the locked position.
Removing the Bracket Assembly from the Base
1. Slide the locking lever, on the mounting base, to the left (unlocked position).
2. Press the release tab downward and slide the bracket assembly to the right (see fi gure below).
Press Down to
Adjust Tilt
( nlocked) Press
Down to Release
nlock to Adjust
Left/Right
real qs.indd 3/16/01, 5:55 PM7

8
MapSource City Navigator CD-ROM Overview
A CD-ROM containing all U.S. and Canadian detailed coverage area (DCAs) is included
with your StreetPilot III. The MapSource City avigator CD is designed specifi cally for the
StreetPilot III and contains detailed street maps for major cities. This mapping software allows for
automatic routing and the map data also contains turn restrictions and other routing information. By
simply entering an address, intersection or pointing at the map, the StreetPilot III will automatically
plan a route and provide turn-by-turn directions to that location. You can also look up services or
points of interest and view the address, phone number and map location. Be aware that not all areas are
covered in detail by the City avigator CD. But to get detailed, street-level routing for major cities, you
need to download maps from the City avigator CD.
The StreetPilot III will also work with MapSource Roads & Recreation, WorldMap, Topo, and
MetroGuide CDs but, with these products, will not provide detailed automatic routing. If you’re using
StreetPilot III without downloaded maps from the City avigator CD, you’ll still have automatic routing
capabilities along major streets and highways contained in the built-in “basemap”.
Unlock Codes
The data on the City avigator CD is protected by unlock codes. Before you can download
maps from a detailed coverage area, you’ll need to “unlock” that region. Additional instructions for
completing these steps are printed on the MapSource Unlock Certifi cate (provided with the City
avigator CD). The Certifi cate directs you to the GARMI Web site, where you’ll enter your personal
information, the Unit ID number from your StreetPilot III (see Owner’s Manual page 39), and the
code contained on the certifi cate. From the web site, you’ll also select a coverage area and see what
cities are included. After you’ve completed the information, the website will provide your offi cial 25
digit unlock code. ow you’re ready to install the City avigator CD-ROM and start downloading
maps from your PC.
Quick Start
Datacard Installation & Using
MapSource
You’ll need an uplock code (provided on GARMIN web site
or by phone) to download a detailed coverage area from the
City Navigator CD. nlock codes are a cost effective way to
distribute all available areas on a single CD.
The MapSource City Navigator CD is designed specifi cally
for the StreetPilot III and contains detailed street maps for
major North American cities.
Record your 25-digit nlock Code here.
real qs.indd 3/16/01, 5:55 PM8

9
Quick Start
You received one Metro Area DCA unlock code through web (or phone) registration with the
purchase of your StreetPilot III. So what if you plan to use your StreetPilot III when you’re traveling in
a major city that’s outside the detailed coverage area that you have access to? Just purchase an unlock
code for another DCA, or for the entire U.S. and Canada. You can purchase additional unlock codes
from the GARMI Web site. Then, using the same City avigator CD that came with your unit, you’ll
have access to more coverage areas. Keep in mind you will always have good map information from
your StreetPilot III’s built-in basemap without using the City avigator detail.
Transferring City Navigator CD Data to a Data Card (US Programmer)
Included with your purchase of the StreetPilot III is a Universal Serial Bus (USB) Data Card
Programmer, which allows you to quickly download maps from your PC to a 32-megabyte data card
that is also included with the StreetPilot III. Follow the directions in the USB Data Card Programmer
User’s Manual to install the software, then connect the programmer to your PC’s USB port. Once you’ve
inserted the City avigator CD and started the MapSource program on your PC, move the cursor to the
pull-down menu at the top of the screen and select “City avigator.”
ow, select the detailed coverage areas you want to download. You can continue to add map areas
until the total map size reaches 32-megabytes. Click on the download button at the top of the screen,
and the information quickly downloads to the data card. As you load different map areas, MapSource
will overwrite previously stored data.
Installing The Data Card
When you’re fi nished downloading, remove the Data Card from the USB Programmer and insert it
into the slot-with the label facing toward the front of the StreetPilot III. Make sure the connector end of
the cartridge is inserted into the slot, OT the handle end. When properly inserted, the cartridge will
protrude slightly from the slot (not fl ush).
CAUTION: Incorrect data card installation can result in internal damage to your GPS unit!
The SB Programmer will allow you to download City
Navigator Maps very rapidly using your PC. Refer to the
SB Programmer Owner’s Manual for additional instruc-
tions.
NOTE: Older model PC’s may not have a SB port or
operating system support for a SB connection. In such
instances, you can program the Data Card directly through
the StreetPilot III. Connect the StreetPilot III to your PC
using the supplied PC Cable. Insert the Data Card into
the SteetPilot III. Then, run the MapSource program (see
MapSource Owners Manual) to transfer map data.
sing this method to program your Data Card is M CH
slower than a SB connection. Map data that transfers in
minutes using a SB programmer can take 1/2 hour or
longer when programmed through the StreetPilot III.
I
Datacard Installation & Using
MapSource
real qs.indd 3/16/01, 5:55 PM9

10
Quick Start
eypad Usage
POWER (Red Bulb Symbol)- Press and hold to turn the StreetPilot III on and off. Press momentarily while
power is on to display the backlight/contrast adjustment window.
PAGE- Switches between main pages and returns display from an option window back to a main page.
QUIT- Returns display to a previous page. When entering data, restores the previous value (cancels
data entry).
ENTER/MAR - Confi rms a selected menu option. When entering data, it allows you to initiate entry, and
then to accept the selected value(s). Press and hold to capture your present position and save it as a
waypoint. ENTER/MAR can also capture the location of the panning arrow on the Map Page.
ROC ER EYPAD- Selects menu options and enters data. Also controls movement of the panning cursor
on the Map Page.
Zoom IN and OUT- Adjusts map scale to show a smaller area (more detail) or a larger area (less detail).
FIND- Searches the database for Cities, Interstate Exits, Waypoints, and Recently found places. If an
optional MapSource City avigator or MetroGuide map data card is installed, it also searches for Points
of Interest, Addresses, or Intersections. Allows the listed items to be viewed on a map or selected as a
destination ( ote: MetroGuide will not provide turn-by-turn navigation or voice commands).
MENU- Displays a menu of options for the current page. Press twice to display System Setup options.
ROUTE- Displays a pop-up window of route navigation features.
VOL/SPEA - Press and hold to adjust the external speaker volume. Pressing VOL/SPEA will repeat the
most recent voice instructions when navigating and display the ext Turn pop-up window.
real qs.indd 3/16/01, 5:55 PM10

11
Quick Start
Screen Features / Data Entry
CURSOR- A highlighted area on the screen which can be moved up/down/left/right with the
ROC ER EYPAD to select individual fi elds on the display. Moving the cursor to a given location allows
you to begin data entry or scroll through a list.
DEFAULT- A system-selected format, built into the operating software or the unit’s memory, that
will be followed unless the user chooses a different setting. For example, the default setting for speed
readings is ‘miles per hour’ or but can be changed to ‘kilometers per hour’. Once a setting is changed,
the new setting is retained until another change is made or a ‘Restore Original Settings’ menu option
is selected.
FIELD- The location on a page where a group of characters or an option is entered and displayed.
The cursor is placed on a fi eld (using the ROC ER EYPAD) to begin data entry or selection of options.
To enter data in a data fi eld:
1. Use the ROC ER EYPAD to highlight the desired data fi eld. Press ENTER to begin data entry.
2. Use the ROC ER EYPAD to enter the desired data. UP/DOWN to select the desired character and
RIGHT to move to the next character fi eld. LEFT allows you to back up to the previous character
fi eld or, when at the left most character fi eld, to clear the entire data fi eld.
3. Once the desired data has been entered, press ENTER to confi rm.
ON-SCREEN BUTTON- Similar to “Field”. Place the cursor on a button and press ENTER to select
the action corresponding to that button. An example of an on-screen button is the ‘Route to It’ button
appearing at the bottom of the Waypoint Marked Page (see example at right).
SCROLL BAR- When viewing a list of items too long to display on a single page, a scroll bar
will appear along the right-hand side of the list (see example at right). The position of the scroll bar
indicates which portion of the list is currently being displayed. The height of the scroll bar indicates
the number of items in the list. To scroll through a list of items, use the UP/DOWN portion of the
ROC ER EYPAD.
An example of an on-screen button—the ‘Route to It’
button on the Waypoint Marked Page.
The scroll bar appears on the right side of a list too long
to fi t on a single page.
real qs.indd 3/16/01, 5:55 PM11

12
Quick Start
Turning On/Off
Adjusting Backlighting,
Contrast and Volume
Turning the StreetPilot III On and Off
Press and hold the POWER key to turn the unit on (a power tone will momentarily sound). The
Welcome Page appears briefl y, followed by the MapSource Copyright Page. Press ENTER to acknowledge
the copyright, or wait briefl y until the Safe Driving Warning Message appears. Once again, press ENTER
to acknowledge the warning or wait until the Warning Page is replaced by the Map Page. When the
Map Page appears, the unit is ready for operation.
When you are ready to turn the unit off, press and hold the POWER key.
Adjusting the acklight, Contrast, and Speaker Volume
The StreetPilot III display and keys can be illumi-
nated for operation at night or in bright sunlight. Back-
light intensity and screen contrast are adjustable. When
operating the StreetPilot III at extreme temperatures,
you may fi nd that minor adjustments are needed to
obtain the clearest screen.
To adjust screen backlighting and contrast:
1. Press the red POWER key momentarily. An on screen window appears allowing you to adjust the
backlight and contrast levels.
2. Use the ROC ER EYPAD to adjust the backlight and the contrast to the desired level. (Alterna
tively, backlighting can be cycled between three settings by repeatedly pressing the red POWER key.)
The backlight and contrast window will disappear after a few seconds of inactivity.
To adjust the external speaker volume:
1. Press and hold the VOL/SPEA key. A slider adjustment window appears.
2. Adjust the speaker volume by using the ROC ER EYPAD. The loudest setting is eight, the
softest is one. (Alternatively, volume can be cycled between three settings by repeatedly pressing
VOL/SPEA .)
IN POINT THREE MILE
S
TURN RIGHT
When the external speaker is connected, your StreetPilot
III provides audible prompts during route navigation.
These ‘spoken’ prompts include approaching turn notifi -
cation (direction of turn and distance), off course notifi -
cation, and arrival at destination.
Spoken messages are also provided for poor GPS cover-
age and low battery power.
Automatic voice prompting can be turned off via a
system setup option (but can always be triggered by
pressing the VOL/SPEAK key (see page 40).
real qs.indd 3/16/01, 5:55 PM12

13
Quick Start
Main Page Sequence
Unit Pages at a Glance
There are three main pages on the StreetPilot III: the Map Page, Trip Information Page, and Current
Route Page. Press the PAGE or QUIT key to sequence through these pages.
Virtual Tour
Let’s use the StreetPilot III’s built-in simulator to select a destination, plan a route, and see how
the unit would operate in actual use. This simulated trip will involve the use of the FIND key to show
you how the StreetPilot III guides you through every turn with audible directions. First, if you haven’t
already done so, take the StreetPilot III outside and let it determine your current location.
To determine your current position:
1. Turn the StreetPIlot III on by pressing the red POWER key. Make sure the antenna is pointing upward
and you are located in an area with a clear view of the sky.
2. Press ENTER to acknowledge the power on pages. The power on process is complete when the Map
Page appears (see page 12).
3.
Observe the message banner at the top of the Map Page. When the message changes from “Acquiring
Satellites” to “Ready for Navigation” your StreetPilot III has determined your current position.
You can now continue the remainder of the Virtual Tour indoors. Find a comfortable chair, sit
back and enjoy the trip!
Map Page Trip Information Page
Current Route Page
The fi rst time you use your new StreetPilot III, it will
need to search for GPS satellites and determine its loca-
tion. This process may take several minutes.
StreetPilot III is ready to guide you when the “Ready for
Navigation” message appears.
Appears only when a destination is selected.
PAGE QUIT
real qs.indd 3/16/01, 5:55 PM13

14
Quick Start To use the StreetPilot III indoors or simulate a trip:
1. With the StreetPilot III turned on, press the MENU Key.
2. Select ‘Use Indoors’ using the ROC ER EYPAD and press ENTER.
3. Press ENTER again to acknowledge the “GPS turned off” message banner. The StreetPilot III is now
in a simulated operation mode.
NOTE: In normal use you WILL NOT follow the steps above to enable the built-in simulator.
Simply turn the StreetPilot III on, select a destination (see steps below and drive!
Your StreetPilot III includes a built-in database of cities and interstate highway exits. If you’ve
already programmed the data card using your City avigator CD, you’ll also have access to a second
database that includes Points of Interest, Address lookup and road Intersections. In this Virtual Tour
we’ll use examples for cities (built-in) and points of interest (data card). Once you’ve read through these
examples feel free to experiment on your own with other categories.
To fi nd a destination location:
1. Press the FIND key. The Find Window appears asking what type of location you are looking for.
2. Use the ROC ER EYPAD to select the desired location type (in this case, Cities) and press
ENTER.
3. The StreetPilot III will search its internal database and present a list of nearby cities.
4. Use the ROC ER EYPAD to highlight a nearby city on the list and press ENTER. An information
page will appear showing the city name, size, direction and distance to the city (from present
position) and several buttons at the bottom of the page.
NOTE: You can fi nd cities by name or from the nearest list. We’ll use the nearest list in this
demonstration, but experiment on your own later (see Owners Manual page 27 .
F
F
Select ‘ se Indoors’ when you want to use simulate
navigation.
Press F ND and select ‘Cities’ to display a list of nearby
cities and select a destination.
Finding a Destination
real qs.indd 3/16/01, 5:55 PM14

15
Quick Start
5. To select this city as a destination, use the ROC ER EYPAD to highlight “Route To It” and press
ENTER. (Otherwise, press QUIT to return to the nearest city list and repeat step #4.)
6. A pop up window will appear for you to indicate a route preference. Use the ROC ER EYPAD
to select “Faster Time” (higher speed roads) or “Shorter Distance” according to your driving
preferences. Press ENTER.
7. SIMULATED OPERATION ONLY: A second pop up window will appear asking if you wish to “Simulate
driving this route?” Use the ROC ER EYPAD to highlight the “Yes” button and press ENTER.
Your current position is symbolized on the Map Page by a pointer arrow moving along the route
(a magenta line).
The Map Page displays turn-by-turn directions as you “drive”. Along the right-hand side of the page
you’ll fi nd your speed, distance travelled or distance to next turn, and the time remaining to the next
turn. The map display also shows the map scale (bottom left corner) and geographic details such as
lakes, rivers, highways and towns. You can use the I and OUT keys to change the map scale.
To change the map scale:
1. Press the IN zoom key to display more detail for a smaller area.
2. Press the OUT zoom key to display a larger area.
Map Scale
Vehicle Speed
Route Line
Your Current
Position
Vehicle Direction
Distance to Go
Time to Go
Driving Instructions
The map can be displayed in a square, wide or full
screeen confi guration for custom viewing. The square
confi guration is shown to the left, the wide
confi guration is shown above. Both square and wide con-
fi gurations show navigation information along the right-
hand side of the page.
If you just want to see the route without the unit
simulating navigation, select “No” and press ENTER.
Map Page
real qs.indd 3/16/01, 5:55 PM15

16
Quick Start
When the StreetPilot III is navigating a route, the Current Route Page is displayed between the
Map Page and the Trip Information Page. The Current Route Page shows a pointer which indicates
the next three turns, and the destination (turn direction arrow, turn description, distance and time
for each).
If the Current Route Page is not currently displayed, press PAGE (repeatedly) until the
Current Route Page appears.
The time displayed on the Current Route Page can be time to reach each turn or arrival time
at each turn.
To change the time displayed on the Current Route Page:
1. With the Current Route Page displayed, press MENU.
2. Show Times to Go or Show Arrival Time are displayed. Press ENTER.
NOTE: The Current Route Page only appears when a destination has been selected.
You can change the displayed time to show arrival times
or time to reach each turn.
Scroll Bar
Distance to Go
Time to GoDriving Instructions
Direction of Turn
F
Current Route Page
real qs.indd 3/16/01, 5:55 PM16

17
Quick Start
If the Trip Information Page is not currently displayed, press PAGE (repeatedly) until
the Trip Information Page appears.
The last of the main pages is the Trip Information Page. On long trips, you will fi nd the Trip
Information Page very useful. This page indicates your current speed and many helpful statistics about
your trip including:
Driving Status Information - Displayed at the top of the page. Shows the next intersection (the
crossroad name) or interstate exit if one is approaching. Otherwise, it shows the road you are on.
Speed - This is the current vehicle speed.
Odometer - A running total of distance traveled, based upon the distance between second-by-
second location readings, since the Trip Computer was last reset.
Current Direction - Displayed to the right of the speed.
Power/Battery - Displayed to the left of the odometer. If the StreetPilot III is using internal AA
batteries, a battery strength bar is shown (and labeled “Battery Power”). otice the shaded area of
the bar. The farther right the shading extends, the more battery power remains. When operating on
batteries, the bar and the label turn red when power is low (20% or less). When operating from
an external power source, a power plug symbol is shown in place of the bar (and labeled “External
Power”).
Battery power is shown in the upper left corner of the
Trip Information Page. When it turns red, its time to
replace the batteries.
Trip Speed
Figures
Trip Timer FIgures
Current Driving
Direction and Time
Driving Instructions
Battery Level Indicator
You can reset the trip information by pressing MENU
and selecting ‘Reset Trip Computer’.
Trip Information Page
real qs.indd 3/16/01, 5:55 PM17

18
Quick Start
Be certain to reset the Trip Computer before beginning your trip. Instructions can be found in
the Owners Manual on page 25. If you make frequent stops, leave the StreetPilot III powered on and
receiving satellites. This will allow the unit to accurately measure elapsed time during the trip. Some
vehicles disconnect power to the cigarette lighter when the ignition is turned off. In such cases, leave a
fresh set of batteries in the StreetPilot III. When external power is lost, a pop-up window will appear
asking if you wish to continue operating from battery power.
Once you have reached your destination city, a checkered fl ag replaces the directional arrow telling
you that the destination has been reached. With the external speaker connected, there is also a voice
confi rmation that the you have arrived at the destination.
The Virtual Tour thus far has relied on built-in StreetPilot III data. If you’ve programmed the data
card using the City avigator CD, you can explore your area in more detail—searching for nearby
restaurants, lodging, entertainment, shopping, etc. Let’s take a brief look at how this works.
To search nearby Points of Interest and fi nd a destination:
1. Press the FIND key. The Find Window appears asking what type of location you are looking for.
2. Use the ROC ER EYPAD to select the desired location type (in this case, Points of Interest) and
press ENTER.
3. The StreetPilot III will ask for a Points of Interest
category. Fo r this tour select “Food & Drink” and
press ENTER.
4. StreetPilot III even lets you defi ne the type of restau
rant you’re looking for! For this example, select “All
Types” and press ENTER.
5. The StreetPilot III will search its internal database and present a list of nearby restaurants.
6. Use the ROC ER EYPAD to highlight a nearby restaurant on the list and press ENTER. An
information page will appear showing the restaurant name, address, phone number and several
buttons at the bottom of the page.
Both fl ag and voice (below) confi rm that you have arrived.
With the City Navigator CD-ROM, you can program the
data card and search for Points of Interest.
ARRIVING AT DESTINATION
ON RIGHT
Points of Interest
real qs.indd 3/16/01, 5:55 PM18

19
Quick Start
7. To select this restaurant as a destination, use the ROC ER EYPAD to highlight “Route To It” and
press ENTER. (Otherwise, press QUIT to return to the nearby restaurant list and repeat step #6.)
8. A pop up window will appear for you to indicate a route preference. Use the ROC ER EYPAD
to select “Faster Time” (higher speed roads) or “Shorter Distance” according to your driving
preferences. Press ENTER.
9. SIMULATED OPERATION ONLY: A second pop up window will appear asking if you wish to “Simulate
driving this route?” Use the ROC ER EYPAD to highlight the “Yes” button and press ENTER.
With your destination restaurant selected, take a few moments to again explore the main pages of
your StreetPilot III and watch as the simulator drives the selected route.
We’ve covered just some of the most important features of your StreetPilot III in this Quick
Start Guide. To learn more, be sure to read the information in the Owner’s Manual. Some suggested
additional reading topics include:
• Searching for cities or points of interest by name (page 27).
• Searching for a particular address (page 31).
• Using the ext Turn Page (page 21).
• Setting speed/distance measurements to metric units (page 39).
If you need more help with any of the features of the StreetPilot III, visit the GARMI Web site,
where you’ll fi nd answers to many frequently-asked questions, or feel free to talk to a GARMI dealer
or technical support representative.
By downloading detailed coverage area (DCA) data from
your City Navigator CD-ROM to a data card, your
StreetPilot III can quickly provide a list of nearby points
of interest.
Detailed information is available including name, address
and phone number.
Additional Reading
real qs.indd 3/16/01, 5:55 PM19

© 2001 GARMI Corporation
GARMI International, Inc.
1200 East 151st Street, Olathe, Kansas 66062, U.S.A.
GARMI (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9AQ, U.K.
GARMI Corporation
o. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
www.garmin.com
Part umber 190-00206-01 Rev. A
real qs.indd 3/16/01, 5:55 PM20
