GarrettCom Magnum TF14 User manual

www G arrettCom com .. www G arrettCom com ..
Corporate Headquarters
GarrettCom, Inc.
47823 Westinghouse Drive
Fremont, CA 94539
Phone [phone]
Fax [phone]
Website: http://www.GarrettCom.com
email [email protected]
Magnum TF14 and TB14
10Mb/s Media Converters
Installation and User Guide

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
i
www G arrettCom com ..
Magnum

TF14 and TB14 10Mb/s Media Converters
Installation and User Guide
Part #: 84-00121 Rev. C (04/01)
Trademarks
Ethernet is a trademark of Xerox Corporation
NEBS is a trademark of Telcordia Technologies
UL is a registered trademark of Underwriters Laboratories
GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a
registered trademark of GarrettCom, Inc.
Important: The Magnum TF14/TB14 10 Mb/s Media Converters contains no
user serviceable parts. Attempted service by unauthorized personnel shall
render all warranties null and void. If problems are experienced with Magnum
TF14/TB14 10 Mb/s Media Converters products, consult Section 5,
Troubleshooting, of this User Guide.
Copyright 2001 GarrettCom, Inc. All rights reserved. No part
of this publication may be reproduced without prior written permission from
GarrettCom, Inc. Printed in the United States of America.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
ii
www G arrettCom com ..
Federal Communications Commission
Radio Frequency Interference Statement
This equipment generates, uses and can radiate frequency energy and if not
installed and used properly, that is in strict accordance with the manufacturer's
instructions, may cause interference to radio communication. It has been tested and
found to comply with the limits for a Class A computing device in accordance with the
specifications in Subpart J of Part 15 of FCC rules, which are designed to provide
reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference, in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
iii
www G arrettCom com ..
Contacting GarrettCom, Inc
Please use the mailing address, phone and fax numbers and email address listed below:
GarrettCom, Inc.
47823 Westinghouse Drive
Fremont, CA 94539
Phone [phone]
Fax [phone]
Website: http://www.GarrettCom.com
email [email protected]

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
iv
www G arrettCom com ..
TABLE OF CONTENTS Page
1.0 SPECIFICATIONS .................................................................................................1
1.1. Technical Specifications...............................................................................1
1.2. Summary of models and descriptions............................................................7
2.0 INTRODUCTION...................................................................................................8
2.1 Inspecting the Package and the Product..........................................................8
2.2 Product Description .......................................................................................9
2.3 Features and Benefits ...................................................................................13
2.4 Applications for TF14 (fiber-series) and TB14 (BNC).................................15
2.5 Full-duplex twisted-pair to fiber applications ............................................18
2.6 Link Pass-through option, applications for the TF14-LP..............................18
3.0 INSTALLATION ..................................................................................................21
3.1 Locating the Media Converter Unit ............................................................21
3.2 TF14-series (fiber units) Power Supply Installation.....................................24
3.3 TB14 (BNC) Power Supply Installation.......................................................24
3.4 Rack Mount Tray option for TF14’s and TB14’s........................................26
3.5 Calculating Overall Segment Distances........................................................28
3.6 Connecting Ethernet Media..........................................................................31

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
v
www G arrettCom com ..
TABLE OF CONTENTS (CONTINUED) .......................................... Page
3.6.1 Connecting Twisted Pair (RJ-45, standard and Link Pass-through) .31
3.6.2 Connecting Fiber ST, multi-mode & sgl.mode, full/half duplex......33
3.6.3 Power budget calculations for fiber media........................................34
3.6.4 Connecting ThinNet 10BASE2 (BNC) ...........................................35
4.0 OPERATION ........................................................................................................36
4.1 Power Requirements, Power Supply Types for TF14’s vs. TB14’s..............36
4.2 Front Panel LEDs - Magnum TF14, TF14s, TF14-LP (fiber)...................36
4.3 Front Panel LEDs - Magnum TB14 (BNC)..............................................37
4.4 BNC port, Internal Termination Switch……………………………………38
4.5 Up-Link (Cross-over) Switch on RJ-45 port...............................................39
4.6 Full- and half-duplex transparent mode, fiber models................................39
5.0 TROUBLESHOOTING.........................................................................................40
5.1 Before Calling for Assistance.......................................................................40
5.2 When Calling for Assistance.........................................................................42
5.3 Return Material Authorization (RMA) Procedure .......................................43
5.4 Shipping and Packaging Information............................................................45
Appendix A: Warranty Information.................................................................................46

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
vi
www G arrettCom com ..
Revisions
Rev C 04/01 : Change the company name to GarrettCom, Inc. (Formerly it was
Garrett Communications). There are no changes to the content of the material at
this time
Rev B 02/00 : The power budged calculations for the fiber media were changed.
Rev A 02/99 : This revision is the initial release of the 4K8 Switches user
manual.
GarrettCom, Inc. reserves the right to change specifications, performance characteristics and/or
model offerings without notice.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
1
www G arrettCom com ..
1.0 SPECIFICATIONS
1.1. Technical Specs - fiber full/half Models: TF14, (TP to multi-mode fiber),
TF14s (TP to single-mode fiber), and TF14-LP (multi-mode fiber with link-
pass), and standard “BNC Collision-indicating” Model TB14
Performance:
Data Rate: 10 Mbps (IEEE 802.3)
Network Standards:
Ethernet V1.0/2.0 IEEE 802.3: 10BASE2, 10BASE-T, 10BASE-FL
(Magnum Media Converters are physical layer standard Ethernet products,
and operate independently of all software.)
Number of Media Converters in series:
Experience shows that up to three units can be used in series between repeaters.
For 4 or more in series, noise build-up will typically preclude proper operation.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
2
www G arrettCom com ..
Maximum Standard Ethernet Segment Lengths:
10BASE-T (twisted pair): 100 m (328 ft)
10BASE2 ThinNet (BNC): 185 m (607 ft)
FOIRL Fiber optic: 1.0 km (3,281 ft)
10BASE-FL Fiber optic : 2.0 km (6,562 ft)
10BASE-FL Single-mode Fiber optic: 10.0 km (32,810ft)
(for single-mode, use full-duplex operation for distances over approx. 4Km.)
Note: Magnum Media Converters DO NOT support full length Ethernet
segments. See Section 3.2 of this manual for media lengths and segment
distance calculations.
Operating Environment:
Ambient Temperature: 32ºF to 104ºF (0ºC to 40ºC)
Storage Temperature: -20ºC to 60ºC
Ambient Relative Humidity: 10% to 95% (non-condensing)

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
3
www G arrettCom com ..
Power Supply (External):
Power Input: 95 - 125 vac at 60 Hz for “-d” U.S. and Canadian models,
200 - 250 vac at 50 Hz for “-i” international models
Power Consumption: 2 watts typical and 3 watts max. for TF14 (fiber),
4 watts typical and 6 watts max. for the TB14 (BNC) Media Converter
Connectors:
RJ-45 Port: Modular 8-Pin female, with “cross-over” up-link switch
Fiber Port: Fiber optic (standard ST type)
BNC Port: Standard BNC connector, RG-58 ThinNet with internal term sw.
Fiber, Full- and half-duplex:
TF14 Fiber models operate in the full- or half-duplex transparent mode. They do
not detect and do not indicate collisions, even when the traffic is half-duplex.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
4
www G arrettCom com ..
Packaging:
Enclosure: High strength sheet metal.
Dimensions, Media Converter unit:
TF14, TF14s, TF14-LP: 2.1”x 3.0”x 0.8” (5.3 cm x 7.6 cm x 2.0 cm)
TB14: 2.1 in x 3.0 in x 0.8 in (5.3 cm x 7.6cm x 2.0 cm)
Dimensions, Power Supply units:
TF14, TF14s, TF14-LP: 1.7 in x 2.2 in x 1.5 in (4.3 cm x 5.5 cm x 3.8 cm)
TB14: 2.0 in x 2.0 in x 1.5 in (5.1 cm x 5.1 cm x 3.8 cm)
Weight:
TF14, TF14s, TF14-LP: 4.6oz. (131g); power supply 5.75 oz (164g)
TB14: 4.6 oz. (131g); power supply 10 oz (285g)

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
5
www G arrettCom com ..
Media Converter LED Indicators:
LED TF14 TF14s, TF14-LP TB14 Description
PWR unit unit unit Indicates unit is receiving DC power.
Link TP, Fiber TP, Fiber * TP Steady ON when proper link is
established at both ends of the segment.*
RX TP, Fiber TP, Fiber TP, BNC Indicates port is receiving packets.
POL n.a. n.a. TP. Indicates the unit has detected a TP receive
wire-pair signal inversion (polarity).
COL* n.a. n.a. TP, BNC Indicates unit is simultaneously transmitting
and receiving data from the cables.
JAB* n.a. n.a. unit Indicates jabber (illegal packet length fault)
condition. Segment is partitioned when lit.
* for TF14-LP Link Pass-through, either both LEDs are lit or neither is lit. See Section 2.6
NOTE:
*COL and JAB LEDs, only on TB14 units, are indicators applicable to standard
collision domains with only half-duplex operation.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
6
www G arrettCom com ..
Agency Approvals:
115v 60 Hz Power Supply is UL Listed (UL 1950 and cUL) and CE.
230v 50 Hz Power Supply is same.
Emissions: Meets FCC Part 15 Class A, CE
Warranty: Three years, return to factory Made in USA

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
7
www G arrettCom com ..
1.2 Summary of models and descriptions:
FIBER:
Magnum TF-14-d = TP to fiber, transparent hdx/fdx, ST connector, multi-mode, 115V 60Hz AC
Magnum TF-14-i = TP to fiber, transparent hdx/fdx, ST connector, multi-mode, 230V 50Hz AC
Magnum TF-14s-d = TP to fiber, transparent hdx/fdx, ST connector, single-mode, 115V 60Hz AC
Magnum TF-14s-i = TP to fiber, transparent hdx/fdx, ST connector, single-mode, 230V 50Hz AC
Magnum TF-14LP-d = TP to fiber, transparent hdx/fdx, ST, multi-mode, Link Pass-through, 115V
60Hz AC
Magnum TF-14LP-i = TP to fiber, transparent hdx/fdx, ST, multi-mode, Link Pass-through , 230V
50Hz AC
BNC:
Magnum TB-14-d = TP to BNC, half-duplex, 115V 60Hz AC power supply
Magnum TB-14-i = TP to BNC, half-duplex, 230V 50Hz AC power supply
MC14-TRAY = 19” Rack-mount tray for 14-series Media Converters, up to 16 units

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
8
www G arrettCom com ..
2.0 INTRODUCTION
This section describes the TF14, TF14s, TF14-LP, and TB14 models,
including appearance, features and typical applications.
2.1 Inspecting the Package and the Product
Examine the shipping container for obvious damage prior to installing this
product; notify the carrier of any damage which you believe occurred during shipment or
delivery. Inspect the contents of this package for any signs of damage and ensure that the
items listed below are included.
This package should contain:
1 Magnum TF14 or TB14 Media Converter Unit
1 External Power Supply, either 115 vac 60 Hz or 230 vac 50 Hz
1 set Metal mounting clips and screws, 2 each
1Velcro
Tape section, approximately 3 inches in length
1 User Guide, i.e., this manual (continued next page)

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
9
www G arrettCom com ..
Remove the Magnum Media Converter from the shipping container. Be sure to
keep the shipping container should you need to ship the unit at a later date.
In the event there are items missing or damaged contact your supplier. If you need
to return the unit use the original shipping container. Refer to Section 5,
Troubleshooting, for specific return procedures.
2.2 Product Description
Magnum TF14 and TB14 10Mb Media Converters offer a compact, cost-effective
way to adapt to non-RJ-45 Ethernet cabling as network requirements change and grow.
The design provides units that are very small, power-efficient, but also full-function.
The “14” series offer a graceful way to convert and transmit data among twisted
pair, fiber and thin coaxial network cabling environments. A variety of twisted-pair-to-
fiber models provide for multi-mode or single-mode, transparent full- and half-duplex
mode, and normal or Link Pass-through operation. Magnum TF14 and TB14 Media
Converters cost significantly less than full repeaters and can be used whenever media
distance limitations will not be exceeded in the segment. All units are compatible with
Ethernet V 1.0 / 2.0 specifications and comply with IEEE 802.3 standards.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
10
www G arrettCom com ..
Magnum TF14 and TB14 10Mb Media Converters are designed for quick and
easy installation even in very tight spaces. Media cables are easily attached to the
corresponding Media Converter. Because of their compact size, Magnum Media
Converters can be Velcro®-mounted on an office wall or the side of a desk or cabinet. A
rack-mount tray that neatly holds the units and associated power supplies is available.
The standard “1-per-unit” external power supply plugs into a nearby AC wall
socket or power strip. Each converter features a full set of LEDs that convey essential
diagnostic and status information. See Section 4.1, for LED function specifications.
Magnum Media Converters are designed to provide low-temperature operation
over an extended period to make them some of the most reliable in the industry. Their
high-strength fabricated steel packaging shields against Radio Frequency Interference
(RFI) and Electromagnetic Interference (EMI).
Magnum TF14 and TB14 10Mb Media Converters are specifically designed to
convert data signaling to allow transmission between two different Ethernet cabling
types, allowing migration to a new media type while preserving segments of the pre-
existing wiring structure. In addition, the TF14 allows fiber segments to be used with
new RJ-45 Ethernet hubs and switches that have insufficient (or none at all) fiber ports.

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
11
www G arrettCom com ..
All of the Magnum “14” Media Converters comply with the IEEE 802.3
10BASE-T specification for 10 Mb/sec traffic via shielded (STP) or unshielded twisted
pair (UTP) segments. They feature an up-link or cross-over switch to eliminate the need
for a special cross-over cable when connecting to a hub or concentrator.
Note: experience shows that the maximum number of 10Mb Media Converters
that can be used in series is three. The cumulative signal noise from 4 or more units
together in series may cause packet alignment errors.
Fiber models: The Magnum TF14 (multi-mode ST), TF14s (single-mode ST), and
TF14-LP (Link Pass-through, ST) are equipped with one fiber-ST and one twisted pair
RJ-45 connector for use in IEEE FOIRL or 10BASE-FL compliant networks. The up-link
GARRETT
9VDC .3AMP
Magnum TF14
Media Converter
Link
RX
TX
RX LinkPwr
RX
TWISTED PAIR FIBER
UP LINK
(
10BASE-T
)
Fiber o
p
tic - ST Connector
(
10BASE-FL and FOIRL
)

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
12
www G arrettCom com ..
(or crossover) switch on the RJ-45 port simplifies cable installation and connection.
All fiber models operate in transparent full- or half-duplex mode, supporting
matched sets of either mode type, i.e., attached devices are either both full-duplex or both
half-duplex.
BNC model:
The
Magnum TB14 is
equipped with one
BNC and one RJ-45
port. The BNC port
has an internal
termination switch, allowing BNC attachment without a “T” connector. The BNC
connector complies with IEEE 802.3 10BASE2 specifications.
ThinNet-BNC
(10BASE-2)
Twisted Pair
(10BASE-T)
Pol
GARRETT
Magnum TB14
Media Converter
Col
RX
Col
RX
Pol
Link
Pwr
Jab
TWISTEDPAIR COAX
UPLINK
INT
EXT

Magnum “14” 10Mb Media Converters Installation and User Guide (04/01)
13
www G arrettCom com ..
2.3 Features and Benefits
!
!!
!Reduces Network Costs
Magnum Media Converters offer the ideal solution to quickly and
inexpensively connect Twisted Pair with Fiber or ThinNet media within
an expanding Ethernet network where full repeaters are not required.
!
!!
!No added Repeater Hop Count
Media Converters do not add signal timing delays associated with full
repeaters, and can be installed without increasing the repeater hop count
of an existing network.
!
!!
!Fiber / twisted-pair models for all fiber modes
A variety of twisted-pair-to-fiber models provide for multi-mode or single-
mode fiber, transparent full- or half-duplex mode, ST connectors, and
normal or Link Pass-through operation.
