Magnum 10Mb/s Media Converters
Half- and full-duplex fiber models
Installation and User Guide
M agnum TF15 Media Converter
GARRETT
UPLINK
Pwr Jab Link TX Col RX Col RX Pol Link Jab
FIBERTW ISTED PAIR
12 VDC 1 AM P
GARRETT 12 VDC 1 AM P
M agnum TB15 Media Converter
Col RX Col RX Pol Link Pwr Jab
TW ISTED PAIRCOAX
UPLINK

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
Magnum

10Mb/s Media Converters
Installation and User Guide
Part#: 84-00001 (R07/98)
Trademarks
UL is a registered trademark of Underwriters Laboratories
Ethernet is a trademark of Xerox Corporation
Velcro is a trademark of Velcro U.S.A.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
Important: Magnum Media Converters contain no user serviceable parts.
Attempted service by unauthorized personnel shall render any and all
warranties null and void. If problems are experienced with a Magnum Media
Converter, consult Section 5, Troubleshooting, of this User Guide.
1998 Garrett Communications, Inc.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
Please use the mailing address, email, phone and fax numbers listed below:
GarrettCom, Inc.
47823 Westinghouse Drive
Fremont, CA 94539
Phone [phone]
Fax [phone]
email: [email protected]

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
FCC STATEMENT
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if not installed and used
properly, that is, in strict accordance with the communication. It has been tested and found to
comply with the limits for a Class A computing device in accordance with the specifications in
Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such
interference when the equipment is operated in a commercial environment. Operation of this
equipment in a residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct the interference.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
TABLE OF CONTENTS Page
1.0 SPECIFICATIONS .................................................................................................1
1.1. Technical Specifications................................................................................1
2.0 INTRODUCTION...................................................................................................7
2.1 Inspecting the Package and Product ...............................................................7
2.2 Product Description ***..................................................................................9
2.3 Features and Benefits ***.............................................................................16
2.4 Applications, TB15, BF15, and TP/fiber Link Pass-through ***.................18
2.5 Full-duplex twisted-pair/fiber applications *** ............................................21
3.0 INSTALLATION ..................................................................................................22
3.1 Locating the Media Converter Unit..............................................................22
3.2 Calculating Overall Segment Distances........................................................23
3.3 Connecting Ethernet Media..........................................................................27
3.3.1 Connecting Twisted Pair (RJ-45, standard and Link Pass-through) .27
3.3.2 Connecting ThinNet 10BASE2 (BNC) ...........................................29
3.3.3 Connecting Fiber (ST & SC, mm & sgl.mode, Full/half duplex)*** 29

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
TABLE OF CONTENTS (CONTINUED) Page
4.0 OPERATION ........................................................................................................32
4.1 Power Requirements, Power Supply Types..................................................32
4.2 Front Panel LEDs - Magnum TB15............................................................33
4.3 Front Panel LEDs - Magnum BF15…………………………………………34
4.4 Front Panel LEDs - Magnum TF15, TF15s, TF15SC, TF15-hdx *** …35
4.5 Up-Link (Cross-over) Switch........................................................................36
5.0 TROUBLESHOOTING.........................................................................................37
5.1 Before Calling for Assistance .......................................................................38
5.2 When Calling for Assistance.........................................................................40
5.3 Return Material Authorization (RMA) Procedure .......................................41
5.4 Shipping and Packaging Information............................................................43
Garrett Communications reserves the right to change specifications, performance characteristics
and/or model offerings without notice.
*** Changes made in 1998. Fiber SC-type connector models, full- and half-duplex transparent
operation fiber models, and Link Pass-through fiber models added.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
1
1.0 SPECIFICATIONS
1.1. Technical Specs - fiber full/half Models: TF15, TF15s, TF15SC, TF15LP
and, standard “Collision-indicating” models: TB15, BF15, TF15-hdx
Performance:
Data Rate: 10 Mbps (IEEE 802.3)
Network Standards:
Ethernet V1.0/2.0 IEEE 802.3: 10BASE2, 10BASE-T, FOIRL,
10BASE-FL
(Magnum Media Converters are physical layer standard Ethernet products,
and operate independently of all software.)
Number of Media Converters in series:
Experience shows that up to three units can be used in series between repeaters.
For 4 or more in series, noise build-up will typically preclude proper operation.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
2
Maximum Standard Ethernet Segment Lengths:
10BASE-T (unshielded twisted pair): 100 m (328 ft)
10BASE2 ThinNet (BNC): 185 m (607 ft)
FOIRL Fiber optic: 1.0 km (3,281 ft)
10BASE-FL Fiber optic : 2.0 km (6,562 ft)
10BASE-FL Single Mode Fiber optic: 10.0 km (32,810ft)
(for single-mode, full-duplex operation for distances over approx. 4Km.)
Note: Magnum Media Converters DO NOT support full length Ethernet
segments. See Section 3.2 of this manual for media lengths and segment
distance calculations.
Operating Environment:
Ambient Temperature: 32ºF to 122ºF (0ºC to 50ºC)
Storage Temperature: -20ºC to 60ºC
Ambient Relative Humidity: 10% to 95% (non-condensing)

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
3
Power Supply (External):
Power Input: 95 - 125 vac at 60 Hz for U.S. and Canadian models,
200 - 250 vac at 50 Hz for international models which have
IEC power cable connector.
Power Consumption: 6 watts max. for the Media Converter
Connectors:
RJ-45 Port: Modular 8-Pin female, with “cross-over” up-link switch
BNC Port: Standard BNC connector, RG-58 ThinNet
Fiber Port: Fiber optic (standard ST & SC types), 10BASE-FL
Fiber, Full- and half-duplex:
Fiber models capable of full- or half-duplex transparent operation have a tag on
the bottom marked “FULL/HALF DUPLEX”, and do not indicate collisions.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
4
Packaging:
Enclosure: High strength sheet metal.
Dimensions:
TB15: 2.5 in x 3.75 in x 0.75 in (6.35 cm x 9.53 cm x 1.9 cm)
BF15: 2.5 in x 3.75 in x 0.75 in (6.35 cm x 9.53 cm x 1.9 cm)
TF15, TF15s, TF15SC, TF15LP, TF15-hdx:
2.5 in x 3.9 in x 0.75 in (6.35 cm x 9.90 cm x 1.9 cm)
Power Supply: 2.0 in x 2.0 in x 1.5 in (5.1 cm x 5.1 cm x 3.8 cm)
Weight: All Models: 6.9 oz. (197g); power supply 10 oz (285g)

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
5
Media Converter LED Indicators:
LED TB15 BF15 TF15,TF15s, SC, LP,-hdx Description
PWR unit unit unit Indicates unit is receiving DC power.
Link TP Fiber TP, Fiber Steady ON when proper link is
established at both ends of the segment.
RX TP, BNC BNC, Fiber TP, Fiber Indicates port is receiving packets.
TX n.a. BNC, Fiber Fiber Indicates port is transmitting packets
POL TP n.a. TP Indicates the unit has detected a TP receive
wire-pair signal inversion (polarity).
COL* TP, BNC BNC, Fiber TP, Fiber Indicates unit is simultaneously transmitting
and receiving data from the cables.
JAB* unit BNC TP, Fiber Indicates jabber (illegal packet length fault)
condition. Segment is partitioned when lit.
NOTE:
*COL and JAB LEDs (when present) are disabled for “FULL/HALF DUPLEX” units,
which are transparent to the Collision and Jabber conditions and do not indicate them.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
6
Agency Approvals:
115v 60 Hz Power Supply is UL Listed (UL 1310), CSA Certified
230v 50 Hz Power Supply is same, also TUV and GS approved
Emissions: Meets FCC Part 15 Class A, cUL
Warranty: Three years, return to factory Made in USA

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
7
2.0 INTRODUCTION
This section describes the TF15, TF15s, TF15SC, TF15LP, TF15-hdx, TB15
and BF15 including appearance, features and typical applications.
2.1 Inspecting the Package and Product
Examine the shipping container for obvious damage prior to installing this
product; notify the carrier of any damage which you believe occurred during shipment or
delivery. Inspect the contents of this package for any signs of damage and ensure that the
items listed below are included.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
8
This package should contain:
1 Magnum Media Converter Unit
1 External Power Supply, either 115 vac 60 Hz or 230 vac 50 Hz
1Velcro
Tape section, approximately 3 inches in length
1UserGuide
Remove the Magnum Media Converter from the shipping container. Be sure to
keep the shipping container should you need to ship the unit at a later date.
In the event there are items missing or damaged contact your supplier. If you
need to return the unit use the original shipping container. Refer to Section 5,
Troubleshooting, for specific return procedures.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
9
2.2 Product Description
Magnum 10Mb Media Converters offer a compact, cost-effective way to adapt a
pre-existing Ethernet cabling configuration as network requirements change. They offer
a graceful way to convert and transmit data among twisted pair, thin coaxial and fiber
network cabling environments. A variety of twisted-pair-to-fiber models provide for
multi-mode or single-mode, full- or half-duplex, ST or SC connectors, and normal or
Link Pass-through operation. Magnum Media Converters cost significantly less than full
repeaters and can be used whenever media distance limitations will not be exceeded in
the new environment. All units are compatible with Ethernet V 1.0 / 2.0 specifications
and comply with IEEE 802.3 standards.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
10
Magnum Media Converters are designed for quick and easy installation even in
very tight spaces. Media cables are easily attached to the corresponding Media
Converter. Because of their compact size, Magnum Media Converters can be Velcro®-
mounted on an office wall or the side of a desk or cabinet. The external power supply
plugs into a nearby AC wall socket or power strip. Each converter features a full set of
LEDs that convey essential diagnostic and status information. See Section 4.1, LED
Indicators, for specific LED function information.
Magnum Media Converters are designed to provide low-temperature operation
over an extended period to make them some of the most reliable in the industry. Their
high-strength fabricated metal packaging shields against Radio Frequency Interference
(RFI) and Electromagnetic Interference (EMI).

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
11
Magnum Media Converters are specifically designed to convert data signaling
to allow transmission between two different Ethernet cabling types, allowing migration to
a new media type while preserving segments of the pre-existing wiring structure.
All of the Magnum Media Converters comply with the IEEE 802.3 10BASE-T
specification for 10 Mb/sec traffic via shielded (STP) or unshielded twisted pair (UTP)
segments. The Media Converters feature an up-link or cross-over switch to eliminate the
need for a special cross-over cable when connecting to a hub or concentrator.
Note: experience shows that the maximum number of 10Mb Media Converters
that can be used in series is three. The cumulative noise from 4 or more units together
causes packet alignment errors.

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
12
The TB15 is equipped with one BNC and one RJ-45 port. The BNC connector
complies with IEEE 802.3 10BASE2 specifications for ThinNet segments.
The TB15 integrates 10BASE-T and 10BASE2 Ethernet networks.
GARRETT 12 VDC 1 AMP
Magnum TB 15 Media Converter
Col RX Col RX Pol Link Pwr Jab
TWISTED PAIR COAX
ThinNet-BNC
(10BASE-2)
Twisted Pair
(10BASE-T)
UP LINK

Magnum 10Mb Media Converters Installation and User Guide (07/98)
GARRETT
13
The Magnum BF15 is equipped with one BNC and one Fiber-ST connector for
connection to IEEE FOIRL or 10BASE-FL compliant networks.
The BF15 integrates ThinNet and Fiber Ethernet networks.
Magnum BF 15Media Converter
GARRETT
ThinNet-BNC
(10BASE-2)
Pwr Jab Link TX Col RX Col RX Pol Link Jab
FIBERTWISTED PAIR
12 VDC 1 AMP
Fiber Optic - ST Connector
(10BASE-FL and FOIRL)
TX RX
