STAINLESS STEEL BREW KETTLE SET
Stainless Steel Brew Kettle 6 PC Set (Available in 32, 40, 64 QT)
GAS ONE
Fuel Your Fire, Fuel Your irst, Live Outdoors.
INSTRUCTION MANUAL
(For Model No. BP-32, BP-40, BP-64)
GAS ONE
HOW TO INSTALL THERMOMETER
THERMOMETERRED
“O”
RINGS
HEX
NUT
1. Unscrew hex nut and rst “O” Ring from thermometer.
2. Insert thermometer stem into hole in stockpot wall.
3. Gently slide “O” Ring onto thermometer stem and over threads.
4. Use one wrench to hold the thermometer in upright position.
Slide hex nut onto thermometer stem and tighten with other wrench.
Do not tighten by holding the dial face of the thermometer, you
could damage the thermometer seals.
HOW TO INSTALL BALL VALVE AND SPIGOT
1. Disassemble all pieces from the Ball Valve and Spigot
2. Insert Nipple into hole in the stockpot wall
3. Gently slide one“Red O Ring” and one Hex Nut onto each
sides of the stockpot wall.
4. Use mini wrench to tighten hex nuts on both sides of the
stockpot
5. Insert White Silicone “O Ring” onto the outer side of the stockpot.
6. Use Sealing Tape onto the outer side of the nipple.
7. Twist on the Ball Valve and Spigot until it is tight.
8. Install Lock Nut by twisting it onto the nipple on the inner
side of the stockpot.
*Use sealing tape on
the Nipple on the
outer side of stockpot
HEX
NUT
SILICONE
“O”
RING
BALL VALVE
& SPIGOT
LOCK NUT NIPPLE
RED
“O”
RING
a. (x1)Stockpot
b. (x1) Lid
c. (x1) False Bottom
d. (x1) Bazooka Screen
e. (x1) Ball Valve & Spigot
f. (x1) ermometer
g. (x1) Mini Wrench
h. (x1)Set of Spare O Rings
i. (x1) Sealing Tape
CONTENTS INCLUDE
a.
b.
c.
e.
f.
g.
h.
i.
d.
DO NOT use Brew ermometer for Frying.
Brew ermometer can not be used for frying because the temperature indicator is not high enough for use with
hot oil.
e face of the thermometer becomes very hot during use.
Sweat or condensation from cold beverages, if allowed to drip on the cover glass, could cause it to break.
TO TEST Temperature Reading on THE DIAL
Determine the ambient or room temperature by using a reference thermometer of known accuracy
If thermometers read dierent temperatures, you will need to reset the brew thermometer
TO RESET Temperature Reading on THE DIAL:
1. Locate the reset screw on the backside of thermometer. the reset screw can be turned on with a slotted
screwdriver.
2. e Dial Facing will rotate as the reset screw is turned.
3. Pointer should match temperature on reference thermometer.
NOTE: Turn on dial facing a few degrees left or right. is thermometer is a sensitive measuring device; rotating
the dial facing up to 360 degrees could alter the accuracy.
4. Once ambient or room temperature is set, the thermometer is ready for installation.
READ BEFORE OPERATING
STOCKPOT
WALL
“O”
RING
THERMOMETER
HEX
NUT
STOCKPOT
WALL
If you need help, don’t hesitate to reach out to us on www.gasone.com or call 1.800.698-5070If you need help, don’t hesitate to reach out to us on www.gasone.com or call 1.800.698-5070
SET OF RED
“O” RINGS SEALING TAPE
MINI WRENCH
HEX
NUTS
WHITE
SILICONE“O”
RING
BALL VALVE
& SPIGOT
LOCK NUT
NIPPLE
PARTS
