GENERAL INFORMATION
Contents
Section Page
General Information 2
General Assembly 3
Lighting Procedure 4
Operating Procedure 5
Care And Maintenance 6
Exploded Diagram And Parts List 7-9
Assembly Instructions 10-20
Leak Test Instructions 21
Safe Locations 22
Warranty 23
Gas Installation Codes
• Barbecues must be used in accordance with
New Zealand Standard 5601 “Gas Installations”.
• Barbecues for use with bottled gas are labelled
LPG/ULPG.
• Barbecues for use with natural gas are labelled ‘natural
gas’ and must be installed by an authorised person.
Check the gas type sticker attached to the barbecue.
Clearances
Minimum Clearances from combustible materials must be:
Rear - 600mm Sides - 600mm Above 600mm
Hose & Regulator Safety
The regulator and hose assembly supplied with the
barbecue are suitable for LPG only.
A gas regulator adjusted to have an outlet pressure of
2.75kPA is supplied for connection to the LPG cylinder.
The pressure regulator and hose assembly supplied
with the barbecue must be used. Replacement pressure
regulators and hose assemblies must be those specied by
the barbecue manufacturer.
When connecting the hose and regulator assembly to the
gas cylinder, take care to avoid unnecessary twisting or
kinking of the exible hose.
After the assembly has been secured, turn on the gas and
check for leaks by brushing a soap and water solution over
all connections.
If you are unable to correct the leak by tightening the
connections, turn off the gas and contact the supplier
immediately.
Always ensure the barbecue is kept away from ammable
materials and the gas cylinder clear of any heat source.
When changing over from an empty gas cylinder to a full
one make sure this procedure is carried out in a ame free
atmosphere.
WARNING
Failure to comply with these instructions could result in a
re or explosion which could cause serious bodily injury,
death or property damage.
Accessible parts may be very hot.
Keep young children away.
Any modications of this barbecue may be dangerous.
Do not move this barbecue during use.
Turn off gas supply at the cylinder after use.
Read instructions before using the barbecue.
Parts sealed by the manufacturer or their agent must not
be manipulated by the user.
This barbecue is only to be used and stored outdoors.
Never operate this barbecue wihout a regulator.
Do not test for gas leaks with an open ame.
If this information is not followed exactly a re causing
death or serious injury may occur. Do not store a spare
gas cylinder under or near this barbecue. Never ll the
cylinder beyond 85% full. This barbecue is only to be
used and stored outdoors.
If you smell gas
1. Shut off gas to the barbecue at its source, if possible.
2. Extinguish any open ame.
3. Open hood.
4. If odour continues immediately call your gas supplier
or re department.
Do not connect your barbecue to a gas cylinder
exceeding this capacity.
Never connect an unregulated gas cylinder to your
barbecue.
Read carefully before assembling and operating your
barbecue.
Specifications
Barbecue specifications can be found on the data label
attached to the door panel or the barbecue body.
Gas Cylinder Use & Safety
This is a low pressure barbecue and must only be used
with the hose and regulator supplied. Your barbecue is
designed for use with 9Kg LPG cylinders.
The cylinder should be lled by a reputable gas supplier
and visually inspected and re-qualied at each lling.
Always keep cylinder in an upright position. Always close
the cylinder valve when the barbecue is not in use.
Do not subject the cylinder to excessive heat.
Never Store your Gas Cylinder Indoors.
If you store your barbecue indoors, ALWAYS disconnect the
cylinder rst and store it safely outside. Cylinders must
be stored outdoors in a well ventilated area out of reach of
children, and must not be stored in a building, garage or
any other enclosed area.
