GASTROBACK®
Instructions For Use
Design Mincer Electronic Pro
Art.-Nr. 41406 Design Mincer Electronic Pro Read all provided instructions before first usage!
Model and attachments are subject to change!
For domestice use only!
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

Carefully read all provided instructions before you start running the
appliance and pay regard to the warnings mentioned in these
instructions.
!
Important Instructions
•Never assemble or disassemble crossed-blade knife, worm or grinding disc
when the plug is connected to the power outlet.
In case of unintentional pressing of the on and off button the motor would
start running and therefore cause personal injury.
• Before first usage rinse all the units of the appliance with water that come into contact with
food and clean them with dishwashing detergent.
•Note: You can only use the sensor button of the control panel when the plug is connected
to the power outlet and the appliance is turned on pressing the power button
•ATTENTION: Always turn the appliance off using the on and of button when
in operational mode before pressing the power button. If the on and off button
is not pressed before the power button the appliance might turn itself on after
a short warm up time when pressing the power button again.
•ATTENTION: To avoid damage, do not use any abrasive cleaners, corrosive chemicals
(i.e. disinfectants, bleach) or cleaning pads for operation or cleaning. Never clean or operate
the appliance or units of the appliance with abrasive or hard sharp-edged items. Never put
the appliance or parts of the appliance in the dishwasher for cleaning! This will
cause discolouration and corrosion.
• To avoid personal injury always turn the appliance off pressing the on and off button first
and then the power button, wait for the motor to stop completely and pull the plug before
assembling or disassembling, cleaning or moving the appliance.
• While proceeding do not push the pusher too hard down to avoid blocking the motor.
Only use the provided pusher to guide food through the feed chute.
• The mincer cannot mince hard or stingily ingredients (for example: bones, nuts, ginger). If
you use hard ingredients like onions or carrots, you have to steam them before adding them to
the meat otherwise they can block the motor.
• Never put fingers, wooden spoons or other foreign substance (such as hair, clothing,
brushes, cloths) into the feed chute or the holes of the grinding disc when the appliance is
plugged into the power point. Always ensure that there is no foreign substance (such as
bones, stems of vegetables or wooden spoons) in the feed chute before turning on the appliance.
Only use the provided pusher to push food through the feed chute. Never hold your face or
other body parts over the feed chute when the motor is running because little pieces of food
could be thrown out of the feed chute.
•Never use the crossed-blade knife and grinding disc in combination with the sausage filling
attachment, adaptor disc, cookie attachment or Kebbe attachment. Only use either the
crossed-blade knife with the grinding disc or one of the attachments.
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

Control panel
D) Release button G) Power switch
Name of the units
A) Pusher
B) Feed pan
C) Worm housing
D) Release button
E) Motor housing
F) LCD control panel
G) Power button
g) Caution light
H) Reverse button
h) On and off button
I) fine grinding disc 3 mm
J) medium grinding disc 4,8 mm
K) Worm
L) Crossed-blade knife
M) Coarse grinding disc 8 mm
N) Closing ring
0) Adaptor disc
P) Sausage filling attachment
Q) Kebbe attachment A
R) Kebbe attachment B
S) Cookie attachment
T) Cookie attachment blade
g
F
H
h
25
Directions for Use
Note: The sausage filling attachment, adapter disc and the
Kebbe attachment are stored inside the pusher.
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

Design Mincer Electronic Pro
Please read all the advice and instructions with care and keep the manual.
The mincer is used for mincing meat (uncooked or cooked) and soft vegetables. Please
prepare the ingredients before filling them into the feed chute. Using the pusher you
press the food slowly into the worm which pushes it against the spinning crossed-blade
knife.
The knife and the worm are driven by a 1.000 watt motor. The finished mince discharges
through the grinding disc. The appliance has an overload protection which prevents
the motor form overheating.
The appliance is maintenance-free, very insusceptible and easy to use. All parts that
come into direct contact with the food are easily to remove and easy to clean. No
extra tools are necessary for assembling or disassembling the appliance.
Important safeguards
Please read all the advices and instructions with care and keep the manual.
Only use the appliance as stated and only for thus use. Any non-appropriate use
and misusage can cause damages and heavy personal injuries through voltage, fire and
moving units. Only proceed the appliance as described in the directions and for the
intended purpose. Never leave the appliance unattended when in operational
mode.
Reparation and technical maintenance of the appliance or line cord are just allowed
to be accomplished by an authorised specialist reparation shop.
Safeguards for Daily Operation
• Only use the appliance indoors. Do not use the appliance in moving vehicles or
boats. Do not use the appliance outdoors. Only use units, spare parts and supplies
which are provided and recommended by the manufacturer. Damaged or improper units
may break in use, damage the appliance or cause risk of overheating, fire, electricity or
personal injury. Never try to take the appliance to pieces or open it.
•Never leave children unsupervised when the appliance or units of the appliance are
in reach. Never let children play with the appliance or units of the appliance. Children
and invalid people have to be supervised using the appliance.
•Never leave the mincer unattended. Keep the appliance well out of reach of
children. Store the appliance and units in a dry, clean area out of reach of children.
• The work space has to be easily accessible, solid, even, dry and of sufficient
size. The mincer should only be set up on a firm level work surface. Never situate
26
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

the appliance close to the edge of the working area. Ensure that the power supply
cable does not hang down from the work surface as it could be easily pulled, particularly
by small children, thereby causing serious accidents.
•Never immerse the motor block in water! Short-circuit danger! Do not put any
cloth or napkins underneath the appliance to avoid endangering by fire and electric
shocks.
•Never cover the air box underneath the appliance. Never place the appliance on
paper towels or uneven working areas. The air has to able to circulate.
•Never situate the appliance close to a strong heat source or a hot surface (for
example: heater, stove or grill).
• Ensure that the switch and cable do not come into contact with water!
Should this inadvertently happen, all parts must be completely dry before the appliance is
used again.
•Never let water or other liquids run into the motorblock. Do not use the appliance
in moist and wet areas.
•Never clean the line cord or the appliance in the dishwasher, pour liquids
over the appliance or douse or dip it in water or other liquids. In case that water or other
liquids ran into the appliance while operating turn off the appliance immediately, pull the
plug and dry the appliance with a clean cloth (´Care and cleaning`).
•Never leave the appliance unattended when the plug is connected
to the power outlet. Always disconnect the power supply cable from the mains
before assembling, dismantling and cleaning the appliance or before exchanging
the grinding discs. Always uncoil the line cord completely before installing the appliance.
When pulling the plug always catch hold of the enclosure of the plug. Always grab
hold on both sides underneath the appliance when moving it.
• Do not let the motor run longer then necessary to prevent overheating. After turning
off the appliance the motor needs about 6 sec. to stop moving. Wait for the motor
to stop completely and press the power button before disassembling the appliance
or continuing operation.
• Clean the appliance straight after use and rinse off leftover food. Remove such
dirt immediately and operate according to the instructions ´Care and cleaning`
before storing the appliance. Do not let food desiccate on the appliance.
• To avoid damage, do not use any abrasive cleaners, corrosive chemicals
(i.e. disinfectants, bleach) or cleaning pads for operation or cleaning. Never clean
or operate the appliance or units of the appliance with abrasive or hard sharp-edged
items. Never put the appliance or parts of the appliance in the dishwasher
for cleaning! This will cause discolouration and corrosion.
27
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

• Do not use the appliance if it is damaged or units of the appliance are damaged. Do
not use the appliance if it does not function properly or if it was excessively loaded.
The appliance is likely damaged if the appliance or units of the appliance show
cracks, exorbitant wearing down, alterations or leaks. It is also likely damaged if the
drive wheel of the motorblock moves slowly. Take the appliance for technical main-
tenance and repair to an authorised specialised reparation shop.
•Never use force assembling or disassembling the appliance. The single parts
should be put together easily. Only operate the mincer after it has been carefully
assembled following the instructions ´Assembling the appliance`.
•Never use the crossed-blade knife and grinding disc in combination with the
sausage filling attachment, adaptor disc, cookie attachment or Kebbe attachment.
Only use either the crossed-blade knife with the grinding disc or one of the attachments.
• Always turn the appliance off (pressing the on and off button and then the power
button), wait for the motor to stop moving before pulling the plug or disassembling
the mincer.
• For the case that the worm housing or the closing ring loosen while operating turn
off the appliance immediately (pressing the on and off button and then the power button)
and pull the plug. Operate according to the instructions ´Trouble shooting` before
turning the appliance on again.
• The mincer must only be used to process meat and vegetables. Do not mince
hard parts such as bones. Do not mince hard-fibre foods such as ginger, etc. The
mincer cannot mince hard or stingily ingredients (for example: bones, nuts, ginger).
If you use hard ingredients like onions or carrots, you have to steam them before adding
them to the meat otherwise they can block the motor. If the motor or if the worm is
blocked turn off the mincer (pressing the on and off button and then the power button) and
wait for approx. 6 seconds to be certain that the motor is no longer running. Work
according to the instructions ´Trouble shooting` before continuing operation.
•Do not let the motor run permanently for longer then 30 minutes to avoid
overheating. After 30 minutes turn off the appliance and let the motor cool down
for at least 17 minutes before continuing operation.
Movable and sharp-edged units – risk of injury
• Never put fingers, wooden spoons or other foreign substance (such as hair, clothing,
brushes, cloths) into the feed chute or the holes of the grinding disc when the appliance
is plugged into the power point. Always ensure that there is no foreign substance
(such as bones, stems of vegetables or wooden spoons) in the feed chute before turning
on the appliance. Only use the provided pusher to push food through the feed chute.
While proceeding do not push the pusher too hard down to avoid blocking the motor.
28
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

29
• Take care handling the crossed-blade knife because it is very sharp.
•Never hold your face or other body parts over the feed chute when the motor is
running because little pieces of food could be thrown out of the feed chute.
Important Safeguards for all Electrical Appliances
• Always uncoil the line cord completely before installing the appliance.
• Place the appliance close to a power point and connect it directly without using
any extension cords to avoid additional risks of injury through fire or voltage.
• Only install the appliance in proper form secure grounding receptacle with adequate
electric power supply (alternating current; 230/240 V, 50 Hz) and ground fault circuit
interrupter. You should also install a fuse with a release current of maximum 30mA.
If necessary ask your electrician for help.
• Never pull, rip, bend, clamp, squish or knot the line cord. Pay attention to the
line cord not hanging of the table. Attend to nobody getting caught in loops of the
line cord or pulling the appliance of the work space. When pulling the plug always
catch hold of the enclosure of the plug.
Operating
Before first usage
Rinse all the units of the appliance with water that come into contact with food and clean
them with dishwashing detergent. Operate according to the instructions ´Care and
cleaning´.
This appliance is equipped with an electronic thermostat to prevent the motor from
overheating. In case of exceeding the tolerable temperature, the mincer will be shut
down automatically.
Your appliance stops operating suddenly:
1. Press the “POWER”-button to switch the appliances off.
2. Disconnect the appliance from the power supply and pull the plug of the power
cord out of the wall outlet.
3. Let the appliance cool down for 60 minutes.
4. Insert the plug of the power cord back to the wall outlet.
5. Press the “POWER”-button. The operation can be continued.
6. Press the circuit breaker button at the bottom of the appliance to turn the appli-
ance on.
7. If overheating protection system triggers very often, please contact your
authorized service center.
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

Assembling the appliance
WARNING: The work space has to be easily accessible, solid, even, dry and of
sufficient size. The mincer should only be set up on a firm level work surface.
Never situate the appliance close to the edge of the working area. Ensure that the
power supply cable does not hang down from the work surface as it could be easily
pulled, particularly by small children, thereby causing serious accidents. Do not put
any cloth or napkins underneath the appliance to avoid endangering by fire and electric
shocks. Never place the appliance on paper towels or uneven working areas. The air
has to able to circulate.
IMPORTANT: Always ensure that the plug is not connected to the power outlet
before assembling or disassembling the appliance.
Place the mincer on a flat, dry surface such as a bench top.
Assembling for mincing
1. Picture A: Take the worm housing into the right
hand and insert with your left hand the worm inside
the worm housing. The side of the worm with the plastic
end has to face the worm housing when putting it
inside the worm housing. If the worm is correctly
assembled when the plastic end of the worm pokes a
few millimetres out of the worm housing.
2. Take the crossed-blade knife and attach it to the
worm. The rounded side of the knife (picture B) must face the
worm when attaching it to the axis of the worm. Ensure the
square opening of the crossed-blade knife fits over the four cor-
nered shaft of the worm.
WARNING: The blades of the crossed-blade knife are very
sharp. Pay attention when you handle the crossed-blade knife.
ATTENTION: Never use the crossed-blade knife and the grinding
disc together with the attachments. How to work with the
attachments is explained further back in the instructions.
Mount the grinding disc on the knife. The arresting pin must
lock precisely into the corresponding recesses.
IMPORTANT: If the tools overlap the edges of the worm hous-
ing the worm is not placed all the way inside of the worm housing. Turn the worm
a little bit to make it fit inside but do not use force. If mounted correctly the grinding
30
A
rounded side
cutting side
B
C
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

31
disc pokes out approx. 2mm of the front of the worm housing and the axis of the
worm pokes out 2 mm of the grinding disc.
Firmly screw the closing ring on the worm housing and tighten by hand.
ATTENTION: Do not use any tools, for tightening the screw and pay attention not to cant
the screw. If the screw cants the screw thread gets damaged. If the screw does not
turn easily put some sunflower oil (or other edible oil) on the screw.
3. Firmly secure the worm housing in the opening for the
drive shaft. The small end of the worm housing has to
face the mincer (picture D). Incline the worm housing a
little bit to the right, when assembling it. When the worm
housing is fitted all the way into the opening of the drive
shaft the release button sinks into the motor housing. Turn
the worm housing counter clockwise until the shaft is facing
upright.
NOTE: When the worm housing is securely attached you can
hear a click sound and the release button comes out of the
recess again (picture F).
4. Press the feed pan onto the worm housing (picture G).
5. Place the pusher into the opening of the feed chute (picture H).
The appliance is ready for operation.
Assembling for making sausages
1. Picture I: Take the worm housing into the right hand
and insert with your left hand the worm inside the
worm housing. The side of the worm with the plastic
end has to face the worm housing when putting it
inside the worm housing. If the worm is correctly
assembled when the plastic end of the worm pokes a
few millimetres out of the worm housing.
D
F
G
H
I
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

32
2. Take the adaptor disc. The small end with the recess has to face the worm when
attaching. If necessary turn the adaptor disc a little bit until the arresting pin of the
worm housing locks precisely into the corresponding recesses of the adaptor disc.
IMPORTANT: If the tools overlap the edges of the worm housing the worm is not
placed all the way inside of the worm housing. Turn the worm a little bit to make it
fit inside but do not use force. If mounted correctly the adaptor disc is flush with the
front of the worm housing and the axis of the worm pokes out 2 mm of the adaptor disc.
3. Place the sausage attachment on the worm housing and fit
the closure ring over the sausage attachment (picture J). Firmly
screw the closing ring on the worm housing and tighten by hand.
ATTENTION: Do not use any tools, for tightening the screw and pay attention not to cant
the screw. If the screw cants the screw thread gets damaged. If the screw does not
turn easily put some sunflower oil (or other edible oil) on the screw.
4. Refer to ´Assembling for mincing` step 3 for further steps for assembling.
Assembling for making Kebbe
1. Picture A: Take the worm housing into the right
hand and insert with your left hand the worm inside
the worm housing. The side of the worm with the plastic
end has to face the worm housing when putting it
inside the worm housing. If the worm is correctly
assembled when the plastic end of the worm pokes a
few millimetres out of the worm housing.
2. Take the Kebbe attachment A. The flat end with the
recess has to face the worm housing when attaching. If necessary turn the Kebbe
attachment A a little bit until the arresting pin of the worm housing locks precisely
into the corresponding recesses of the Kebbe attachment A.
IMPORTANT: If the tools overlap the edges of the worm housing the worm is not
placed all the way inside of the worm housing. Turn the worm a little bit to make it
fit inside but do not use force. If mounted correctly the Kebbe attachment A is flush
with the front of the worm housing and the axis of the worm pokes out 2 mm of the
grinding disc.
3. Place the Kebbe attachment B on the worm housing and
fit the closure ring over the Kebbe attachment B (picture B).
Firmly screw the closing ring on the worm housing and tighten
by hand.
A
B
J
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

33
ATTENTION: Do not use any tools, for tightening the screw and pay attention not to cant
the screw. If the screw cants the screw thread gets damaged. If the screw does not
turn easily put some sunflower oil (or other edible oil) on the screw.
4. Refer to ´Assembling for mincing` step 3 for further steps for assembling.
Assembling for making cookies
1. Picture C: Take the worm housing into the right
hand and insert with your left hand the worm inside
the worm housing. The side of the worm with the plastic
end has to face the worm housing when putting it
inside the worm housing. If the worm is correctly
assembled when the plastic end of the worm pokes a
few millimetres out of the worm housing.
2. Take the adaptor disc. The small end with the
recess has to face the worm when attaching. If necessary turn the adaptor disc a lit-
tle bit until the arresting pin of the worm housing locks precisely into the correspon-
ding recesses of the adaptor disc.
IMPORTANT: If the tools overlap the edges of the worm housing the worm is not
placed all the way inside of the worm housing. Turn the worm a little bit to make it
fit inside but do not use force. If mounted correctly the adaptor disc is flush with the
front of the worm housing and the axis of the worm pokes out 2 mm of the grinding disc.
3. Place the cookie attachment on the worm housing. The flat
end has to face the worm housing when attaching. Fit the closure
ring over the cookie attachment (picture D). Firmly screw the
closing ring on the worm housing and tighten by hand.
ATTENTION: Do not use any tools, for tightening the screw and
pay attention not to cant the screw. If the screw cants the screw
thread gets damaged. If the screw does not turn easily put some
sunflower oil (or other edible oil) on the screw.
4. Refer to ´Assembling for mincing` step 3 for further steps for
assembling.
5. If the appliance is assembled take the cookie attachment
blade and slide it into the cookie attachment (picture E)
and choose the desired cookie shape. Ensure the handle is
facing away from the attachment when sliding it in other-
wise you cannot use the cookie shape that is the closest to
the handle (picture F).
The cookie attachment is ready for operation.
C
D
E
F
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

34
Operating - Mincing meat
The mincer operates absolutely dependently and clean. If any problems should
occur while operating act upon instructions ´Trouble shooting`.
WARNING: For the case that liquid runs over the mincer while operating turn the
mincer off immediately and pull the plug. Clean and dry the appliance according
to the instructions ´Care and cleaning`.
TIP: If you use special mince-recipes you can mix the ingredients (for example
steamed onions or spices) with the meat before mincing. This way the ingredients
get mixed really well. Use the medium grinding disc when making tartar and mince
the ingredients twice.
IMPORTANT: The mincer cannot mince hard or stingily ingredients (for example:
bones, nuts, ginger). If you use hard ingredients like onions or carrots, you have to
steam them before adding them to the meat. Place a dry towel beside the mincer to
dry off overrunning liquids.
1. Cut the meat into stripes (10 cm long and 2cm wide) that will fit in the feed chute
and remove hard parts like bones, shells or stems.
2. Assemble the appliance as described and place a plate or dish in front of the
worm housing.
WARNING: Always make sure that the mincer is turned off before plugging in the
power supply.
3. Plug the power supply cable into a mains socket and switch
on the mincer. You can hear a signal. The appliance is ready.
WARNING: Never hold your face or other body parts over the
feed chute when the motor is running because little pieces of food
could be thrown out of the feed chute. Never push the food
into the feed chute with your fingers or put foreign substances
(hair, towels, cutlery) into the feed chute. Always use the pusher
for this purpose!
4. Press the power button on the back of the appliance
(picture A). The display illuminates and you can see the motor
temperature, working time and two circles (picture B).
5. When the appliance operates in the “ON”-mode, the LCD
display shows one circle rotating countercklockwise
(picture C).
6. When switches into the “REVERSE”-mode, the appliance will wait a few seconds,
A
B
C
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

35
then the LCD display shows one circle rotating clockwise (pic-
ture D).
WARNING:
• When you press the “POWER”-button, a signal sounds,
indicating that the appliance is connected to the power supply.
• When the appliance operates in the “ON”-mode, only press the
“ON/OFF”-button to stop the appliance. It is not available to press
the “REVERSE”-button when the appliance is in the “ON”-mode.
• When switching into the “REVERSE”-mode, you have to wait
4 seconds till the motor runnings.
• When the temperature of the motor reaches 80° C, the red warning lamp starts
flashing, a signal sounds and the indicator shows the time remaining to automatic
shutdown of the motor. A minute after the warning signal the appliance will be shut
down automatically to avoid the motor overheating.
7. Slowly feed the meat pieces into the feed chute and push down with the pusher. Do
not apply excessive force when pushing down the pusher. Only use the pusher to
press down the meat. Never use the fingers!
IMPORTANT: Operate in a slow and constant pace. Do not try to rush the procedure
by pushing down the meat with force. This way the worm might gets blocked and stops
operating. If no meat is coming out the worm housing even though there is still meat in
the feed chute turn the mincer off (pressing the on and off button first and then the
power button) and work according to the instructions ´Trouble shooting guide`.
IMPORTANT: Do not let the motor run permanently for longer then 30 minutes
to avoid overheating. After 30 minutes turn off the appliance and let the motor cool
down for at least 30 minutes before continuing operation.
In the case of overloading the motor a red warning light will start blinking in the display.
If the motor temperature reaches 80 degrees both circles will illuminate in the
display. In this case the motor will stop automatically. Let the motor cool down for
at least 30 minutes before you continue operation.
7. As soon as the last bit is minced turn the appliance off (pressing the on and off but-
ton first and then the power button) and pull the plug.
8. Clean and disassemble the appliance right after use and make sure that no
leftover food desiccate on the appliance. Work according to the instructions ´Care
and cleaning`.
E
D
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

36
Making Sausages
1. Prepare the meat according to the instruction ´Operating- Mincing meat`. Season
the meat as desired.
2. Assemble the sausage attachment according to the instruction ´Assemble for
making sausages`
3. Soak the sausage skin for 10 minutes in lukewarm water. Slide the sausage skin
over the sausage attachment.
TIP: If the skin gets stuck to the sausage attachment, wet it with some water.
4. As soon as the last bit has run through the appliance turn the appliance off (pressing
the on and off button first and then the power button) and pull the plug.
5. Clean and disassemble the appliance right after use and make sure that no
leftover food desiccate on the appliance. Work according to the instructions ´Care
and cleaning`.
Making Kebbe
Ingredients for the filling:
100 g mutton, once or twice minced with the mincer
1 1/2 tablespoon olive oil
1 1/2 tablespoon fine chopped onions
1/3 teaspoon grounded pimento
1/2 teaspoon salt
1 1/2 tablespoon flour
Ingredients for the wrapping:
at least 450 g fatless meat of mutton, calf or beef
the most 150-200 g flour*
1 teaspoon grounded pimento
1 teaspoon grounded nutmeg
1 pinch of chilli powder
1 pinch of pepper
*The consistency of the wrap is better if you use less flour and more meat.
1. Prepare the filling: Steam the onions. Mince the meat once or twice with the mincer
and then mix the ingredients.
2. Prepare the wrapping: Mince the meat for the wrapping 3 times in total. For the
first mincing procedure use the medium grinding disc then use the fine grinding
disc. After mixing all the ingredients for the wrapping mince it one more time
with the medium grinding disc.
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

37
3. Unscrew the closing ring and take out the grinding disc and crossed-blade knife.
Operate according to the instructions ´disassembling` the appliance.
WARNING: Do not cut yourself removing the crossed-blade knife.
4. Assemble the appliance this time using the Kebbe attachments (Refer to
´Assembling for making Kebbe`).
ATTENTION: Never assemble the appliance with the Kebbe attachment AND
the crossed-blade knife with the grinding disc.
5. Process the wrapping mixture in the mincer with the attached chopper attachments.
The finished product will be one long wrapping. Cut the wrapping into convenient seize.
6. Freeze the wrapping shortly.
7. Fill the wrapping with the filling mixture and fry the wraps with some olive oil
until it has the favoured browning.
Care and Cleaning
WARNING: Never hold your face or other body parts over the feed chute when
the motor is running because little pieces of food could be thrown out of the feed
chute. Never put foreign substance or hard objects into the feed chute.
Before the mincer is used for the first time and after each usage, all parts – with the
exception of the motor block – must be thoroughly cleaned in warm soapy water. In
case of blockage work according to the instructions ´Trouble shooting guide`.
Disassemble the appliance
WARNING: To avoid injury and damages of the appliance turn the
appliance off (pressing the on-/off button first and then the power
button) and then wait for approx. 6 seconds to be certain that the
motor is no longer running. Always pull the plug before you start
disassembling or cleaning the appliance.
1. Switch off the mincer and disconnect the power supply cable from the mains.
Check that the motor has completely stopped.
2. Take the pusher and the feed pan of the feed chute.
3. Press the release button and turn the worm housing clockwise until you can take
the worm housing off the appliance without resistance.
4. Unscrew the closing ring turning it counterclockwise.
5. Remove the closing ring of the worm housing and take the inner unit (such as the
worm, crossed-blade knife and grinding disc, Kebbe attachment, sausage attachment or
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

38
cookie attachment) off the worm housing.
TIP: If the tools are stucked knock the mincer carefully on a stable cutting board.
The grinding disc should be facing up.
ATTENTION: Be careful not to damage your bench top, the cutting board or the mincer.
6. Remove meat residues.
Operate as described:
ATTENTION: Never put the appliance or parts of the appliance in the
dishwasher or use abrasives for cleaning! This will cause discolouration
and corrosion.
7. Wash all parts thoroughly in hot soapy water. Do not use aggressive detergents.
The parts are not suitable for dishwasher. Soak parts with desiccated food leftovers
a few minutes in warm soapy water and use a nylon cleaning brush or cleaning
sponge for cleaning. Rinse all parts with running water and dry them accurately.
8. Grease the grinding disc and knife with salad oil to prevent air corrosion.
WARNING: Ensure that the switch and cable do not come into contact with
water! Should this inadvertently happen, all parts must be completely dry before the
appliance is used again. Never let water or other liquids run into the motorblock.
Never clean the line cord or the appliance in the dishwasher, pour liquids over the
appliance or douse or dip it in water or other liquids. In case that water or other liquids
ran into the appliance while operating turn off the appliance immediately, pull the plug
and dry the appliance with a clean cloth.
9. The motor block must only be wiped clean with a moist cloth. Do not clean the
motor block under flowing water, nor should it be immersed in water! Do not use
alcohol, benzine, etc.!
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

39
Trouble shooting guide
Always clear blockage according to the following instructions. For the case that you
are unsuccessful take the appliance to an authorised specialist reparation shop.
Possible problem Easy solution
The mince is not fine enough. Use a smaller grinding disc and/or mince the ingredients more then once.
There are still ingredients in the feed chute The mincer is blocked. Turn the appliance off immediately and operate
but no mince is coming out of the mincer. according to the instructions ´Clear a blocking`.
The motor stops running while operating. The overload protection might got activated. Turn the appliance off
immediately and operate according to the instructions ´Clear a blocking`.
After cleaning the motor does not get started • Is the power cord plugged in?
again when turning the appliance ON. • The motor might be blocked with some hard substance (for example
a bone). Turn the appliance off immediately and pull the plug.
• Disassemble and clean the appliance. Operate according to the
instructions ´Care and cleaning`.
• If the problem is not solved after the cleaning, take the appliance
for technical maintenance and repair to an authorised specialised
reparation shop.
The mincer blocks up permanently • To ensure that the mincer does not seize, never operate it under
while operating. excessive pressure. Operate in a slow and constant pace. Do not
try to rush the procedure by pushing down the meat with force.
• For mincing hard ingredients really fine start with the grinding disc
with the bigger holes. Mincing the second time use the finer grinding
disc.
The worm housing moves while operating The closing ring loosened. Turn the appliance off immediately. Assemble
the worm housing according to the instructions ´Assemble for mincing`.
The mince leaks out at the side of the The closing ring is not screwed on tight enough. Turn the appliance off
closing ring. immediately and then pull the plug. Tighten the closing ring but do not
overwind the winding. If the problem still occurs disassemble and clean the
appliance.
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

Clear a blocking
If the worm housing is blocked no mince comes out of the mincer while operating or the
motor stops moving automatically because of the overload protection.
ATTENTION: If a blocking occurs turn off the appliance immediately. Clear the
problem before turning on the motor again.
1. Turn the appliance off and take the pusher out of the feed chute.
2. If the motor stopped running because of overloading, press the power button to
turn the appliance off.
3. Press the reverse button and let the motor run in reverse mode for a few seconds.
The worm will turn backwards and loosen the blockage.
ATTENTION: If the motor does not start moving backwards immediately turn
off the appliance and pull the plug. Disassemble and clean the appliance.
4. After a few seconds in reverse mode press the on and off button. If the appliance
still does not run smooth or the blockage occurs again, turn the appliance off (pressing
the on and off button first and then the power button), pull the plug and clean the
appliance according to the instructions ´Care and Cleaning`.
Storage
Always clean the appliance before storing.
ATTENTION: Store and use the appliance in a clean, frost free environment
where it is protected from dampness, moistness and immoderate and extraordinary
burden (such as: downfall, beat, overheating, moisture in the motor block). Never
lay heavy or hard objects on top of the appliance.
Always assemble the appliance for storing. This way the parts are protected and
cannot get lost.
You can store the power cord coiled up in the storage place
underneath the appliance (picture A).
ATTENTION: Never pull, rip, bend, clamp, squish or knot
the line cord.
The attachments and the adaptor disc can be stored
inside the pusher (picture B).
40
A
B
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

Waste disposal
The appliance has to be deposed by the definition of the regional waste disposal
of electrical scrap.
If necessary get information of the regional waste management enterprise.
Warranty
We guarantee that all our products are free of defects at the time of purchase.
Any demonstrable manufacturing or material defects will be to the exclusion of any
further claim and within warranty limits of the law free of charge repaired or substi-
tuted.
There is no Warranty claim of the purchaser if the damage or defect of the appliance is
caused by inappropriate treatment, over loading or installation mistakes.
The Warranty claim expires if there is any technical interference of a third party
without an written agreement.
The purchaser has to present the sales slip in assertion-of-claims and has to bear all
charges of costs and risk of the transport.
The warranty becomes invalid and GASTROBACK does not assume liability if:
1. The user did not follow the instructions or the user did not use the appliance as
stated and only for thus use (improper use, misusage).
2. The appliance was connected to a power supply with improper current.
3. The mincer got opened by an unauthorised person.
4. Other then original spare-parts got used.
5. The appliance was in commercial use. Used up parts from commercial use
are no warranty claim.
The mincer is intended for use in the household only!
41
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite

Notes
41406_designfleischwolfelectronicpro_manual_GermanEnglisch_neu.qxp 20.10.2009 11:00 Seite
