gbics GMZP088-VSL01D Quick start guide

SFP28 Module Installation Notes
PRODUCT NAME DESCRIPTION
GMZP088-VSL01D 25GBASE-SR SFP28 850nm MMF 150m DDM LC
GSZP318-DSL10D 25GBASE-LR SFP28 1310nm SMF 10Km DDM LC
This installation note provides the installation instructions for the GBICS.com SFP28 modules. These SFP28
modules are hot-swappable input/output (I/O) devices, which connect the module port with the bre-optic or
copper network.
Ensure that you understand safe handling of lasers and have the following tools and parts available to install an
optical transceiver in a switch chassis:
• Electrostatic discharge (ESD) grounding strap
• A rubber safety cap for the transceiver
Ensure you understand how to prevent ESD damage.
To install an SFP28 in an uplink socket please follow the below instructions
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to the
ESD point on the chassis.
2. Remove the SFP28 from its packaging.
3. Ensure that the SFP28 is covered by a rubber safety cap. If it is not, cover the SFP28 with a safety cap.
4. Remove the dust cover covering the port in the uplink module. Save the dust cover in case you need to
cover the port later.
5. Using both hands, carefully place the SFP28 in the empty port in the uplink module. The connectors
should face the uplink module.
6. Slide SFP28 in gently until it is fully seated.
7. Remove the rubber safety cap when you are ready to connect the cable to the transceiver.
Caution:Ensure the transceiver is aligned correctly when you slide it into the port; misalignment
might bend the pins and make the transceiver unusable.
Unit 4 Global Business Park, 14 Wilkinson Road, Cirencester, Gloucestershire, GL7 1YZ, United Kingdom.

Laser and LED Safety Guidelines and Warnings
SFP28 transceivers are classied as Class 1M Laser Products (IEC 60825-1 2001–01).
Observe the following guidelines and warnings:
General Laser Safety Guidelines
When working around ports that support optical transceivers, observe the following safety guidelines to prevent
eye injury:
•Do not look into unterminated ports or at bres that connect to unknown sources.
• Do not examine unterminated optical ports with optical instruments.
• Avoid direct exposure to the beam.
Warning:Unterminated optical connectors can emit invisible laser radiation. The lens in the human eye
focuses all the laser power on the retina, so focusing the eye directly on a laser source—even a low-power
laser—could permanently damage the eye.
Class 1 Laser Product Warning
Warning:Class 1 laser product.
WaarschuwingKlasse-1 laser produkt.
Varoitus Luokan 1 lasertuote.
AttentionProduit laser de classeI.
WarnungLaserprodukt der Klasse1.
AvvertenzaProdotto laser di Classe1.
AdvarselLaserprodukt av klasse1.
AvisoProduto laser de classe1.
¡Atención!Producto láser ClaseI.
Varning!Laserprodukt av klass1.
Class 1M Laser Radiation Warning
Warning:Class 1M laser radiation when open. Do not view directly with optical instruments.
Unit 4 Global Business Park, 14 Wilkinson Road, Cirencester, Gloucestershire, GL7 1YZ, United Kingdom.

Laser Beam Warning
Warning:Do not stare into the laser beam or view it directly with optical instruments.
WaarschuwingNiet in de straal staren of hem rechtstreeks bekijken met optische instrumenten.
VaroitusÄlä katso säteeseen äläkä tarkastele sitä suoraan optisen laitteen avulla.
AttentionNe pas xer le faisceau des yeux, ni l’observer directement à l’aide d’instruments optiques.
WarnungNicht direkt in den Strahl blicken und ihn nicht direkt mit optischen Geräten prüfen.
AvvertenzaNon ssare il raggio con gli occhi né usare strumenti ottici per osservarlo direttamente.
AdvarselStirr eller se ikke direkte p strlen med optiske instrumenter.
AvisoNão olhe xamente para o raio, nem olhe para ele directamente com instrumentos ópticos.
¡Atención!No mirar jamente el haz ni observarlo directamente con instrumentos ópticos.
Varning!Rikta inte blicken in mot strålen och titta inte direkt på den genom optiska instrument.
Unterminated Fiber-Optic Cable Warning
Warning:Invisible laser radiation might be emitted from the unterminated connector of a ber-optic cable. To
avoid injury to your eye, do not view the ber optics with a magnifying optical device, such as a loupe, within
100mm.
WaarschuwingEr kunnen onzichtbare laserstralen worden uitgezonden vanuit het uiteinde van de onafgebroken
vezelkabel of connector. Niet in de straal kijken of deze rechtstreeks bekijken met optische instrumenten.
Als u de laseruitvoer met bepaalde optische instrumenten bekijkt (zoals bijv. een oogloep, vergrootgras of
microscoop) binnen een afstand van 100 mm kan dit gevaar voor uw ogen opleveren.
VaroitusPäättämättömän kuitukaapelin tai -liittimen päästä voi tulla näkymätöntä lasersäteilyä. Älä tuijota sä-
dettä tai katso sitä suoraan optisilla välineillä. Lasersäteen katsominen tietyillä optisilla välineillä (esim. suuren-
nuslasilla tai mikroskoopilla) 10 cm:n päästä tai sitä lähempää voi olla vaarallista silmille.
AttentionDes émissions de radiations laser invisibles peuvent se produire à l’extrémité d’un câble en bre ou
d’un raccord sans terminaison. Ne pas xer du regard le rayon ou l’observer directement avec des instruments
optiques. L’observation du laser à l’aide certains instruments optiques (loupes et microscopes) à une distance
inférieure à 100 mm peut poser des risques pour les yeux.
WarnungEine unsichtbare Laserstrahlung kann vom Ende des nicht angeschlossenen Glasfaserkabels oder
Steckers ausgestrahlt werden. Nicht in den Laserstrahl schauen oder diesen mit einem optischen Instrument
direkt ansehen. Ein Betrachten des Laserstrahls mit bestimmten optischen Instrumenten, wie z.B. Augenlupen,
Vergrößerungsgläsern und Mikroskopen innerhalb eines Abstands von 100 mm kann für das Auge gefährlich sein.
AvvertenzaL’estremità del connettore o del cavo ottico senza terminazione può emettere radiazioni laser invis-
ibili. Non ssare il raggio od osservarlo in modo diretto con strumenti ottici. L’osservazione del fascio laser con
determinati strumenti ottici (come lupette, lenti di ingrandimento o microscopi) entro una distanza di 100 mm
può provocare danni agli occhi.
AdvarselUsynlig laserstråling kan emittere fra enden av den ikke-terminerte berkabelen eller koblingen. Ikke se
inn i strålen og se heller ikke direkte på strålen med optiske instrumenter. Observering av laserutgang med visse
optiske instrumenter (for eksempel øyelupe, forstørrelsesglass eller mikroskoper) innenfor en avstand på 100
mm kan være farlig for øynene.
AvisoRadiação laser invisível pode ser emitida pela ponta de um conector ou cabo de bra não terminado. Não
olhe xa ou diretamente para o feixe ou com instrumentos ópticos. Visualizar a emissão do laser com certos
instrumentos ópticos (por exemplo, lupas, lentes de aumento ou microscópios) a uma distância de 100 mm pode
causar riscos à visão.
Unit 4 Global Business Park, 14 Wilkinson Road, Cirencester, Gloucestershire, GL7 1YZ, United Kingdom.

¡Atención!El extremo de un cable o conector de bra sin terminación puede emitir radiación láser invisible.
No se acerque al radio de acción ni lo mire directamente con instrumentos ópticos. La exposición del ojo a una
salida de láser con determinados instrumentos ópticos (por ejemplo, lupas y microscopios) a una distancia de
100 mm puede comportar lesiones oculares.
Varning!Osynlig laserstrålning kan komma från änden på en oavslutad berkabel eller -anslutning. Titta inte
rakt in i strålen eller direkt på den med optiska instrument. Att titta på laserstrålen med vissa optiska instrument
(t.ex. lupper, förstoringsglas och mikroskop) från ett avstånd på 100 mm kan skada ögonen.
