GCAN GC-6501 User manual
GC-6501
Extended Wifi communication module
User manual
Document version
：
V2.01
（
2020/8/22
）
Vhandy Technology GC-6501 user manual
Revise history
Version
Date
Reason
V1.00
2019/09/16
Create document
V2.00
2020/3/22
Correct equipment working parameters
V2.01
2020/8/22
Adjust the document structure
Vhandy Technology GC-6501 user manual
Contents
1. Function introduction ............................................................................................. 4
1.1 Functional Overview ....................................................................................4
1.2 Performance characteristics ......................................................................... 4
1.3 Typical application ........................................................................................4
2. Equipment installation and use .............................................................................. 5
2.1 Module fixed ................................................................................................ 5
2.2 Wiring method ............................................................................................. 5
2.3 System statusindicator ..................................................................................7
2.4 Instructions ...................................................................................................8
3. Technical specifications ....................................................................................... 10
4. Disclaimer ............................................................................................................ 11
5. Module selection table ......................................................................................... 12
Sales and service ...................................................................................................... 14
Vhandy Technology GC-6501 user manual
1. Function introduction
1.1 Functional Overview
The GC-6501 module is an extended communication module that integrates 1
channel Wifi. This module can be used to expand Wifi communication, and can
be connected to AP nodes, collect data through TCP and UDP communication,
and send the collected values to the GCAN-PLC-510 series PLC controller
through the internal bus, and at the same time expand the serial port function
by calling Block programming to achieve complex bus control requirements.
This module can be used in conjunction with any other GC series IO module to
realize the receiving and sending of data in industrial automation or distributed
control systems.
1.2 Performance characteristics
●The form of extended Wifi is Station;
●Support TCP Client and UDP communication form;
●Ethernet parameters are set by function blocks in the program;
●Electrical isolation is 500Vrms;
●Power supply through GCAN-PLC-510 and external 24V-DC power supply;
●Current consumption is200mA;
●Configuration without address setting, configuration through bus coupler or
controller;
●Operating temperature range:-40
℃
~+85
℃
;
●Dimensions: length 100mm * width 69mm * height12mm.
1.3 Typical application
●Add Wifi extension function to PLC controller;
●The bus data can be sent and received by calling the extended Wifi function
block in the program.
Vhandy Technology GC-6501 user manual
2. Equipment installation and use
This chapter will explain in detail the installation method, wiring method,
meaning of indicator lights and interface meaning of GC-6501 module.
2.1 Module fixed
The installation method of GC-6501 module is shown in Figure 2.1, you need
to use a flat-blade screwdriver to assist installation.
Figure 2.1 GC-6501 Module installation
First, you need to install the fieldbus coupler on the rail, and then attach the
GC-6501 module to the right side of the fieldbus coupler or other modules to
add this component. Please insert the GC-6501 module inward along the slot as
shown in Figure 2.1 until the lock catches and makes a "click" sound.
GC-6501 module needs to be used with GCAN-PLC-510 coupler
。
2.2 Wiring method
As shown in Figure 2.2, first insert a flat-blade screwdriver into the square hole
and hold the screw in the square hole. Then insert the cable into the circular
hole. After plugging it in, pull out the screwdriver and the cable can be firmly
locked in the circular hole.
Vhandy Technology GC-6501 user manual
Figure 2.2 GC-6501 module installation
Figure 2.3 GC-6501 module wiring terminal block
The wiring terminal block of the GC-6501 module is shown in Figure 2.3. GC-
6501 includes 1 Wifi extension function. The serial number corresponding to
each terminal and its meaning are shown in Table 2.1.
Vhandy Technology GC-6501 user manual
Terminal
Serial number
Meaning
ANTEN(+)
1
Antenna positive
ANTEN(-)
2
Antenna shield
24V
3
Power positive
24V
4
Power positive
0V
5
Power negative
0V
6
Power negative
NC
7
Occupancy
NC
8
Occupancy
Table 2.1 GC-6501 Module indicator
2.3 System statusindicator
The GC-6501 module has 4 indicator lights to indicate the operating status of
the device. The specific indication function of the indicator light is shown in
Table 2.2. When the indicator light is on, the GC-6501 module status is shown
in Table 2.3.
Indicator light
Color
Indicating status
RUN
Green
Operation instructions
SYS
Green
System instructions
Table 2.2 GC-6501 Module indicator
GC-6501 After the module is initialized normally, the running indicator will
light up.
Indicator light
Status
Indicating status
RUN
Flashing
Wifi Function start
Not bright
No error
SYS
Flashing
Module initialized successfully
Not bright
Open circuit
Table 2.3 GC-6501 Module indicator status
Vhandy Technology GC-6501 user manual
2.4 Instructions
GC-6501 module can directly refer to the routines shipped with PLC, the
specific routines are as follows.
VAR
inst0_EXT_WIFI_INIT:EXT_WIFI_INIT;
mEn:bool; mError:usint; wifiInit:bool:=false; rec:string(250); reclen:int;
inst2_EXT_WIFI_READ_STR:EXT_WIFI_READ_STR;
inst4_EXT_WIFI_WRITE_STR:EXT_WIFI_WRITE_STR;
inst6_EXT_WIFI_READ_BIN:EXT_WIFI_READ_BIN;
inst7_EXT_WIFI_WRITE_BIN:EXT_WIFI_WRITE_BIN;
recd :array[0..200] of byte; pt_rec:pointer;
END_VAR;
if wifiInit=falsethen
inst0_EXT_WIFI_INIT(EN_IN :=1 , NUMBER :=1 ,
MODE :='TCP' ,// Two working modes of TCP and UDP can be selected
AP_SSID :=
‘
*******
’
;'// The name of the router to be connected
AP_PASSWORD :='***********' ,// The password of the router that
needs to be connected
SERVER_IP_ADDR :='192.168.0.100' , // Target host IP address
SERVER_PORT := '8001', // Target host port number LOCAL_PORT :=
'8000'// Local port number
| mEn:=EN_OUT, mError:= ERROR); if mEn=true and mError=0then
Vhandy Technology GC-6501 user manual
wifiInit:=true; end_if;
else
pt_rec:=&recd;
inst6_EXT_WIFI_READ_BIN(EN_IN :=1 , NUMBER := 1,
PTR_RXDATA :=pt_rec ,MAXLENGTH:=200 | mEn:=EN_OUT, reclen:=
RXLENGTH, mError:=ERROR);
if reclen>0 then
inst7_EXT_WIFI_WRITE_BIN(EN_IN :=1 , NUMBER :=1 ,
PTR_TXDATA := pt_rec,TXLENGTH:=reclen | mEn:= EN_OUT,
mError:=ERROR);
else
inst7_EXT_WIFI_WRITE_BIN(EN_IN :=0 , NUMBER :=1 ,
PTR_TXDATA := pt_rec, TXLENGTH :=reclen| mEn :=
EN_OUT, mError:=ERROR);
end_if; end_if;
Vhandy Technology GC-6501 user manual
3. Technical specifications
Connection method
Wiring form
2-wire system
Interface characteristics
Communication signal
1 channel
Communication type
TCP Client and UDP
Electrical isolation
500 Vrms （GC-bus/ Signal voltage）
Power supply
Power supply via GCAN-PLC-510 coupler
Configuration method
Automatic configuration in order
Environmental test
Operating temperature
-40℃~+85℃
Working humidity
95%RH，No condensation
EMC test
EN 55024:2011-09
EN 55022:2011-12
Vibration/shock
resistance
EN 60068-2-6/EN 60068-2-27/29
Anti-electromagnetic
interference/anti-electr
omagnetic radiation
performance
EN 61000-6-2 /EN 61000-6-4
Protection level
IP 20
Basic Information
Dimensions
100mm *69mm *12mm
Weight
50g
Vhandy Technology GC-6501 user manual
4. Disclaimer
Thank you for purchasing GCAN's GCAN series of hardware and software
products. GCAN is a registered trademark of Shenyang Vhandy Technology
Co., Ltd. This product and manual are copyrighted by Vhandy Technology.
Without permission, it is not allowed to reproduce in any form. Before using,
please read this statement carefully. Once used, it is deemed to be an
endorsement and acceptance of the entire content of this statement. Please
strictly abide by the manual, product description and related laws, regulations,
policies and guidelines to install and use the product. In the process of using
the product, the user promises to be responsible for his actions and all
consequences arising therefrom. Vhandy Technology will not be liable for any
losses caused by improper use, installation, or modification by users.
The final interpretation right of the disclaimer belongs to Vhandy Technology
Vhandy Technology GC-6501 user manual
5. Module selection table
GCAN-PLC-400 series products consist of a programmable main control
module, several GC series IO modules and a terminal resistance module.
GC series IO modules currently include five categories: digital input, digital
output, analog input, analog output, and communication extension. The specific
selection table is shown in Table 5.1.
I/O
Type
Characteristic
Signal
Channel
PLC
Control
module
GCAN-PLC-400
CPU:168M
-
-
GCAN-PLC-510
CPU:400M
-
-
GCAN-PLC-511
CPU:400M (2CAN)
-
-
Digital
input
GC-1008
Digital input (PNP)
24V DC
8-channel
GC-1018
Digital input (NPN)
24V DC
8-channel
GC-1502
Counter（200kHz max）
-
2-channel
Digital
output
GC-2008
Digital output (PNP)
24V DC
8-channel
GC-2018
Digital output (NPN)
24V DC
8-channel
GC-2204
relay output
-
4-channel
GC-2302
PWM （20Hz~200kHz）
-
2-channel
Analog
input
GC-3604
Voltage input, 16 bits
-5~+5V
4-channel
GC-3624
Voltage input, 16 bits
10V~+10V
4-channel
GC-3644
Current input, 16 bits
0-20mA
4-channel
GC-3654
Current input, 16 bits
4-20mA
4-channel
GC-3664
Voltage input, 16 bits
0~+5V
4-channel
GC-3674
Voltage input, 16 bits
0~+10V
4-channel
GC-3804
2-wire PT100, 16 bits
Thermal
resistance
4-channel
GC-3822
3-wire PT100, 16 bits
Thermal
resistance
2-channel
Vhandy Technology GC-6501 user manual
GC-3844/3854/3
864
K type / S type / T type
thermocouple
Thermocouple
4-channel
Analog
output
GC-4602
Voltage output, 16 bits
-5V~+5V
2-channel
GC-4622
Voltage output, 16 bits
-10V~+10V
2-channel
GC-4642
Current output, 16 bits
0-20mA
2-channel
GC-4652
Current output, 16 bits
4-20mA
2-channel
GC-4662
Voltage output, 16 bits
0~5V
2-channel
GC-4672
Voltage output, 16 bits
0~10V
2-channel
GC-4674
Voltage output, 12 bits
0~10V
4-channel
Special
module
GC-6101
RS232/RS485 extension
-
-
GC-6201
GPRS extension
-
-
GC-6221
4G extension
-
-
GC-6501
WiFi extension
-
-
Table 5.1 Selection table
