GCX M Series Installation instructions

DU-WMM-0001 Rev B 4/12/07 GCX Corp. Page 1 of 3
INSTALLATION & OPERATING MANUAL FOR M-SERIES MOUNTS
WARNING: Do not position support arm or device over a patient.
Before mounting the arm:
1. Verify that the Channel has been installed and approved in accordance with the GCX Wall Channel Installation
Instructions.
2. Check the weight of the device to be mounted. This arm is either rated for 30 lbs [13.6 kg] or 60 lbs [27.2 kg],
depending on the front-end mounting configuration. Refer to the duty rating label located on top of the arm at the Slide
pivot point. It is not recommended that you attempt to use the arm for weights outside of this range.
3. If you are unsure of your application, please contact a GCX product specialist at [phone] for assistance.
Installing Arm in Channel
1. Install Adjustable Stop in top of Channel, slide
to bottom of Channel and tighten center screw.
2. While supporting the bottom of the Arm with one hand,
guide the Slide (rear of the arm) into top of the Channel.
3. Guide Arm to desired height and tighten two (2) set
screws with 1/8" [3 mm] hex wrench (provided).
Mounting a Device on the Arm
• Most devices will require the attachment of device-
specific mounting hardware provided by GCX.
Please attach this hardware in accordance with
instructions provided with the Mounting Adapter.
• Most arms will have either a “slide-on” or a “VESA Standard”
Mounting Plate at the front of the arm. The arm may
have either a Tilt Adjustment Lever installed for rear
mounted devices or a Tilt Limit Screw for bottom
mounted devices.
• The Tilt Limit Screw may be removed with the ¼” hex wrench provided.
• The Tilt Adjustment Lever may be removed by rotating
the Lever counterclockwise
Mounting Device on Slide-on Mounting Plate
1. Pull Spring Plunger at the front of the Mounting Plate.
Slide the device laterally into the Mounting Plate until the
Plunger snaps into the clearance hole at the front of the
Mounting Adapter.
2. Tighten the Nylon Locking Screws located on bottom or rear of
the Mounting Plate.
Tilt Limit Scre
w
Tilt Adjustment Lever
Slide
Set Screws (2)
Wall Channel
A
djustable Stop
Mounting Plate
Locking Screws (4)
“Slide-on” Mounting Plate
Plunge
r

DU-WMM-0001 Rev B 4/12/07 GCX Corp. Page 2 of 3
M4 Screws (2)
VESA Mounting Plate
M4 Screws (2)
VESA Standard Mounting Plate
Mounting Device on VESA Standard Mounting Plate
1. Start two (2) M4 screws by hand into the upper threaded
holes in the rear of the device or mounting adapter.
2. Lift the device by guiding the M4 screws into the slots in
the Mounting Plate.
3. Insert two (2) remaining M4 screws through the lower
holes of Mounting Plate.
4. Tighten all fasteners.
Making Adjustments to the Arm
Positioning Arm in Channel
WARNING: Do not attempt to remove the Arm
from the channel while loaded with a device.
1. Loosen the set screws in the Slide.
2. To raise or lower the Arm in the channel, relieve the
weight of the mounted device by lifting the underside of
the Arm, near the device. Simultaneously, push up or pull
down the opposite end of the Arm immediately in front of the Slide.
Pivot & Pivot Tension
Pivot Arm/Flush Mount – Single Pivot Point
1. To pivot at the Slide, simply push on the side of the
Arm or mounted device.
2. To adjust the pivot tension at the Slide, use a ½"
[13 mm] socket wrench to tighten or loosen the Pivot
Tension Bolt.
Articulating Arm – Dual Pivot Points
1. To pivot the Arm at the Slide, simply push on the
side of the Arm or mounted device.
2. To pivot the Arm at the midway pivot point, simply push
on the side of the front Arm or mounted device while
holding the rear arm in place.
3. To adjust the pivot tension at the Slide, use a ½”
[13 mm] socket driver to tighten or loosen the Pivot
Tension Bolt.
4. To adjust the pivot tension at the midway pivot point,
use a ½” [13 mm] socket wrench to tighten or loosen
the Pivot Tension Bolt.
Swivel & Swivel Tension
1. In most configurations, the mounted device will swivel at
the end of the Arm. To rotate the device simply push or
pull the corners of the device.
2. To adjust the swivel tension, remove bolt cap from
front end of the Arm and use a ½” [13 mm] socket wrench
to tighten or loosen the Swivel Tension Bolt.
Pivot Tension Bolt
Swivel Tension Bolt
Pivot Arm
Pivot Tension Bolt
Pivot Tension Bolt
(
Mid Point
)
Bolt Cap
Articulating Arm
Channel
Set Screws (2)

DU-WMM-0001 Rev B 4/12/07 GCX Corp. Page 3 of 3
Swivel Fitting
Post
10-32 x 3/8" SHCS (3)
Flexible Cable Covers
Pass-through Slide
Tilt & Tilt Tension
In most configurations, the tilt of the mounted device can be adjusted.
1. Loosen the Adjustment Lever (if included).
2. Grasp the top and bottom of the device and tilt it to the
desired angle.
3. Tighten the Adjustment Lever (if included).
4. Using a 5/32'' hex wrench, equally tighten or loosen the two (2) Tilt
Tension Screws.
Cable Management
Two cable management features allow convenient placement and flow of
cables:
1. An open cavity beneath the arm with flexible cable covers manages
cables going between front and rear of the arm.
2. A “pass-through” channel slide allows cables to run behind the arm
within the Channel. Note: If cable connectors are too large to fit
through the pass-through, try placing the cables in the path of the
Slide before installing the arm in the Channel. Contact GCX for
optional Channel Covers available to further manage the flow of
cables in the Channel.
Attachment of Down Post
Some applications may require a Down Post to mount
module racks or other devices.
Attaching Down Post to Arm
1. Align the screw holes in the Post with corresponding threaded
holes in the Swivel Fitting.
2. Using the 5/32 [4 mm] hex wrench provided, fasten Down Post to
Swivel Fitting with three (3) #10-32 x 3/8" SHCS.
Routine Maintenance
Periodically inspect all fasteners associated with the mounting system. Tighten or adjust fasteners as necessary for
optimal operation and safety.
Cleaning the Mounting Assembly
1. The mounting assembly may be cleaned with most mild, non-abrasive solutions commonly used in the hospital
environment (e.g. diluted bleach, ammonia, or alcohol solutions).
2. The surface finish will be permanently damaged by strong chemicals and solvents such as acetone or
trichloroethylene.
3. Do not use Steel wool or other abrasive material.
4. Damage caused by the use of unapproved substances or processes will not be warranted. It is recommended that you
test any cleaning solution on a small area of the arm that is not visible to verify compatibility.
5. Never submerge or allow liquids to enter the arm. Wipe any cleaning agents off of the arm immediately, using a water-
dampened cloth. Dry the arm thoroughly after cleaning.
CAUTION: GCX makes no claims regarding the efficacy of the listed chemicals or processes as a means for controlling
infection. Consult your hospital’s infection control officer or epidemiologist. To clean or sterilize mounted devices or
accessory equipment, refer to the specific instructions delivered with those products.
Tilt Adjustment Lever
Tilt Tension Screws (2)
