GE Interlogix KTD-405 User manual

KTD-405 and KTD-405A
Controller Keypads

© 2003 GE Interlogix, Video Systems Group
All Rights Reserved.
Any GE Interlogix, Video Systems Group, software
supplied with GE Interlogix, Video Systems Group,
products is proprietary and furnished under license
and can be used or copied only in accordance with
the terms of such license.
This document contains proprietary information that is
protected by copyright. No part of this document may be
reproduced or transmitted in any form or by any means
without the prior written permission of GE Interlogix,
Video Systems Group.
The information contained in this document is subject to
change without notice. GE Interlogix, Video Systems
Group, in keeping pace with technological advances, is a
company of product innovation. Therefore, it is difficult to
ensure that all information provided is entirely accurate
and up-to-date. GE Interlogix, Video Systems Group,
accepts no responsibility for inaccuracies or omissions
and specifically disclaims any liabilities, losses, or risks,
personal or otherwise, incurred as a consequence, directly
or indirectly, of the use or application of any of the
contents of this document.
For the latest product specifications, visit GE Interlogix,
Video Systems Group, online at www.GE-Interlogix.com or
contact your GE Interlogix, Video Systems Group, sales
representative.
For technical support before and after installation, call 800-469-1676.
Technical support is available 24 hours a day, 7 days a week.
Call: Tech Support 800-469-1676 (6 A.M. – 5 P.M. PST Monday through Friday)
Tech Support 541-740-3589 (all other times)
Main 800-343-3358 or 541-754-9133
Fax: Tech Support 541-752-9096 (available 24 hours a day)
Main 541-754-7162
Web: www.GE-Interlogix.com
1036547C / December 2003
This equipment has been tested and found
to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications.
You are cautioned that any changes or
modifications not expressly approved by the
party responsible for compliance could void
the user's authority to operate the
equipment.

KTD-405/405A User Manual Table of Contents
1036547C / December 2003 3
Table of Contents
BEFORE YOU BEGIN ..........................................................................................................5
1PACKAGE CONTENTS...................................................................................................6
2OPERATING MODES.....................................................................................................7
2.1 DIGIPLEX MODE .................................................................................................. 7
2.2 ZONE MODE ....................................................................................................... 7
3INSTALLATION .............................................................................................................8
3.1 INSTALLATION GUIDELINES................................................................................... 8
3.2 BACK PANEL CONNECTIONS................................................................................. 9
3.2.1 KTD-405 Connections ..................................................................................................... 9
3.2.2 KTD-405A Connections ................................................................................................. 10
3.3 I/O BOX CONNECTIONS ..................................................................................... 11
3.3.1 RJ-Cable Connections................................................................................................... 11
3.3.2 Twisted-Pair Connections.............................................................................................. 12
3.3.3 Connecting a Multiplexer or DVMRe and Domes.......................................................... 13
3.3.4 Connecting Multiple Keypads with RJ45 Cables........................................................... 14
3.3.5 Connecting Multiple Keypads with STP Cable .............................................................. 15
3.3.6 Connecting New and Old I/O Boxes.............................................................................. 16
4PROGRAMMING .........................................................................................................17
4.1 ENTERING THE PROGRAMMING MODES ............................................................... 18
4.2 SUPERVISOR PROGRAMMING ............................................................................. 18
4.2.1 Soft Key Reprogramming .............................................................................................. 21
4.3 USER PROGRAMMING ........................................................................................ 23
4.3.1 Standard Digiplex Menus .............................................................................................. 23
4.3.2 Zone Menus................................................................................................................... 25
4.4 REMOTE PROGRAMMING.................................................................................... 28
4.4.1 Switcher/MPLX .............................................................................................................. 28
4.4.2 Alarms............................................................................................................................ 28
4.4.3 Camera/RCVR............................................................................................................... 28
4.4.4 CyberScout ShadowTour .............................................................................................. 29
5OPERATION...............................................................................................................30
5.1 STANDARD DIGIPLEX MODE ............................................................................... 31
5.1.1 LCD Normal Screen....................................................................................................... 31

Table of Contents KTD-405/405A User Manual
4 1036547C / December 2003
5.1.2 Selecting a Camera ....................................................................................................... 33
5.1.3 Controlling a Camera..................................................................................................... 33
5.1.4 Selecting a Monitor ........................................................................................................ 34
5.1.5 Operating Group Switching on Digiplex IV Switchers ................................................... 35
5.1.6 Controlling a DVMRe/Multiplexer .................................................................................. 35
5.1.7 Controlling a Recording Device ..................................................................................... 35
5.2 ZONE MODE ..................................................................................................... 36
5.2.1 LCD Normal Screen....................................................................................................... 36
5.2.2 Selecting a Zone............................................................................................................ 36
5.2.3 Selecting a Camera ....................................................................................................... 36
5.2.4 Controlling a Camera..................................................................................................... 36
5.2.5 Selecting a Monitor ........................................................................................................ 37
5.2.6 Selecting and Controlling a DVMRe/Multiplexer ........................................................... 37
5.2.7 Controlling a Recording Device ..................................................................................... 39
5.2.8 Programming a DVMRe/Multiplexer Camera Sequence............................................... 40
5.3 AUDIO .............................................................................................................. 40
5.3.1 Annunciation .................................................................................................................. 40
5.3.2 Two-Way Audio ............................................................................................................. 41
6TROUBLESHOOTING...................................................................................................42
APPENDIX A. ZONE RECEIVER SITE ADDRESSING..............................................................44
APPENDIX B. REPROGRAMMABLE KEYS AND COMMANDS ..................................................46
APPENDIX C. SAMPLE SYSTEM CONFIGURATIONS .............................................................47
KTD-450 DIGIPLEX CONFIGURATION .......................................................................... 47
KTD-405A DIGIPLEX CONFIGURATION........................................................................ 48
DIGIPLEX HYBRID CONFIGURATION ............................................................................. 49
ZONE CONFIGURATION............................................................................................... 50
APPENDIX D. OLD I/O BOX CONNECTIONS........................................................................51
OLD I/O BOX CONNECTIONS FOR NONAUDIO- AND AUDIO-VERSION KEYPADS................ 51
CONNECTING A MULTIPLEXER OR DVMRE TO THE OLD I/O BOX ................................... 52
CONNECTING MULTIPLE KEYPADS TO THE OLD I/O BOX ............................................... 53
APPENDIX E. SYSTEM PLANNING GUIDE ...........................................................................54

KTD-405/405A User Manual Before You Begin
1036547C / December 2003 5
BEFORE YOU BEGIN
Read these instructions before installing or operating this product.
Note: This installation should be made by a qualified service person and should conform to local codes.
This manual provides installation and operation information. To use this document, you must have the
following minimum qualifications:
! A basic knowledge of CCTV systems and components
! A basic knowledge of electrical wiring and low-voltage electrical hookups
Intended use
Use this product only for the purpose for which it was designed; refer to the product specification and user
documentation.
Customer Support
For assistance in installing, operating, maintaining, and troubleshooting this product, refer to this
document and any other documentation provided. If you still have questions, please contact GE Interlogix
Technical Support and Sales:
GE Interlogix, Video Systems Group
Call: 800-469-1676
Fax: [phone]
Note: You should be at the equipment and ready with details before calling Technical Support.
Conventions Used in this Manual
Boldface or button icons highlight command entries. The following WARNING, CAUTION, and Note
statements identify potential hazards that can occur if the equipment is handled improperly:
* WARNING:
Improper use of this equipment can cause severe bodily injury or equipment damage.
** CAUTION:
Improper use of this equipment can cause equipment damage.
Note: Notes contain important information about a product or procedure.
* This symbol indicates electrical warnings and cautions.
** This symbol indicates general warnings and cautions.

Package Contents KTD-405/405A User Manual
6 1036547C / December 2003
1 PACKAGE CONTENTS
The KTD-405 and KTD-405A packages include a user manual (1036547) and a quick reference guide
(1047307) in addition to the items shown in Figures 1 and 2. Read the manual before beginning
installation and programming so that you can plan your system’s configuration.
Keypad
(N. American: KTD-405)
(European: KTD-405U)
Power supply
(1037229)
I/O box
(1043406)
RJ45 control cable
(1044203)
Power cord
(N. American: 1037376)
(European: 1037377)
Figure 1. KTD-405 package contents
Keypad
(N. American: KTD-405A)
(European: KTD-405AU)
Power supply
(1037229)
I/O box
(1043406)
RJ45 control cable
(1044203)
RJ11 audio cable
(D0304A894)
Power cord
(N. American: 1037376)
(European: 1037377)
Figure 2. KTD-405A package contents

KTD-405/405A User Manual Operating Modes
1036547C / December 2003 7
2 OPERATING MODES
The KTD-405 can be programmed to operate in either of two modes: standard Digiplex®or zone
(DVMRe/multiplexer/PTZ control). See Appendix C. Sample System Configurations.
Be aware that the addressing between domes and multiplexers is offset. When setting up and controlling
your cameras in zone mode, refer to Appendix A (Zone Receiver Site Addressing).
2.1 DIGIPLEX MODE
In standard Digiplex mode, the system’s main switching device is a standard matrix switcher. The keypad
can address and control 512 PTZ receiver sites, operate a matrix switcher with 64 monitor outputs, address
and select views from 32 multiplexers, operate up to 32 recorders, and manage access control points.
You can also operate a DVMRe/multiplexer when operating in a hybrid Digiplex mode. This enables the
DVMRe or multiplexer to provide multi-screen views by connecting the output of the unit to an input on the
matrix switcher. Digiplex mode (standard or hybrid) does not require that the DVMRe’s have dedicated
monitors. If you are using CaliburTM units, they must be connected to the keypad’s RS485 control signal;
other brands must be connected to the keypad’s RS422 control signal using a KTD-93 interface. When you
press the zone key, the keypad switches to the zone-mode style of operation (hybrid Digiplex mode), which
enables it to control the DVMRe/multiplexer. See Figure 4. If the zone is assigned to a camera input on the
matrix switcher (done in programming), when you select the zone, the keypad sends a command to the
matrix switcher to call up the assigned input on the active monitor. While in the hybrid Digiplex mode, key
functions are the same as those used during normal zone mode operation, except the esc key, which
returns the keypad to the standard Digiplex mode of operation.
Note: Camera control (PTZ) is disabled while in the hybrid zone mode.
CAMERA 0
MONITOR 1 ZONE 01 DVMRE TRI CAM -- MON A ESC=EXIT
F
igure 3. LCD display of standard Digiplex mode Figure 4. LDC display of hybrid Digiplex mode
2.2 ZONE MODE
A zone is a remote switching device (multiplexer or DVMRe) that serves a group of cameras. A system
can be divided into as many as 32 zones, and each zone can have from 1 to 32 cameras.
The outputs from the zone’s switching device connect to dedicated monitors directly. Each zone is
assigned a device type (multiplexer or DVMRe) and a size (1 to 32 cameras) and can be assigned a
15-character name.
To call up a camera in a zone you must know the zone number (or name) and the camera number. See
Figure 5 and refer to Appendix A (Zone Receiver Site Addressing).
ZONE -- ZONE TITLE
CAMERA -- MONITOR -
Figure 5. LCD display of zone mode

Installation KTD-405/405A User Manual
8 1036547C / December 2003
3 INSTALLATION
CAUTION:
Plan your system’s camera and device assignments before installing the system. To help plan
your system, refer to Appendix E. System Planning Guide.
Note: The keypads now ship with an updated I/O box that provides RJ45 ports for the RS485 data line and an RJ11 port for audio.
See section 3.3.6Connecting New and Old I/O Boxesfor connections between the newand old I/O boxes. For connection details
about the old I/O boxes, see Appendix D. Old I/O Box Connections.
3.1 INSTALLATION GUIDELINES
Installation Guidelines
• Recommended cable types:
Signal Cable Minimum Size
RS485 STP (shielded twisted-pair) 22 AWG
RS422 UTP (unshielded twisted-pair) 22 AWG
Audio STP (shielded twisted-pair) 18 AWG
Note: Refer to device manuals for specific cabling requirements.
• Each keypad requires its own I/O box. You can connect multiple I/O boxes to each other to establish multiple
keypads for controlling one system. For systems that are more complicated than are diagrammed in these
instructions, contact GE Interlogix Technical Support for assistance.
• The audio and speaker connections are used only with a KTD-405A.
• Observe polarity when installing the RS422, RS485, and 12 VDC (if not using the provided transformer with
positive polarity center plug) cables.
• The earth grounds for the I/O boxes are separate from the earth grounds for the RS485 shield.
• The keypad itself is not grounded.
• Grounding the I/O box is optional, but it does provide some additional protection against equipment damage
due to electrical storm induced power surges.
• There must be no current flowing in the shield of shielded cables. Maintain an open circuit (non-continuous
path) for the shield and hold it at the earth ground potential by grounding it at only one location.
• You can connect the RS485 shield of individual cable segments to each other, but to nothing else. You will
still ground the resulting shield circuit at one location only, despite the number of shield junctions.
• Each electrical circuit (RS485 segment) must be biased. If keypads reside on separate electrical circuits
(i.e., separated by fiber or Ethernet bridges), then more than one keypad might have the bias switch set to
ON (one for each circuit).
• The bias is 12-VDC polarity sensitive. If polarity on the power line is reversed, the keypad will not be
damaged but it will not operate correctly.
• Each electrical segment being terminated must be terminated at each end, and at one location for the bias.
Termination is generally required for the first and last device on a longer line. The termination switches are
located within or on the devices themselves (e.g., keypads and cameras). Refer to device manuals for
termination requirements and methods.
• Your system should contain only one RS422 chain of devices. Only one KTD-405 keypad should be in that
chain, which can contain any number of other keypads such as KTD-404s.

KTD-405/405A User Manual Installation
1036547C / December 2003 9
3.2 BACK PANEL CONNECTIONS
3.2.1 KTD-405 CONNECTIONS
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
RS232 programming port (future use) I/O box
RS485 and RS422 in/out Power supply
RS485 termination switch Power cord
RJ45 control cable*
*GE Interlogix uses two different RJ45
cables. You must use the RJ45 cable
provided with the unit.
Figure 6. KTD-405 back panel connections

Installation KTD-405/405A User Manual
10 1036547C / December 2003
3.2.2 KTD-405A CONNECTIONS
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
RS232 programming port (future use) RS485 termination switch I/O box
Audio port RJ11 audio cable Power cord
RS485 and RS422 in/out RJ45 control cable* Power supply
*GE Interlogix uses two different
RJ45 cables. You must use the
RJ45 cable provided with the unit.
Figure 7. KTD-405A back panel connections

KTD-405/405A User Manual Installation
1036547C / December 2003 11
3.3 I/O BOX CONNECTIONS
3.3.1 RJ-CABLE CONNECTIONS
The RJ-cable connections make new installations or additional devices easy to connect. If you are
replacing an old phone-style I/O box in an existing installation, you can use the existing twisted-pair wires
(STP for RS485 and UTP for RS422), if desired. See section 3.3.2 Twisted-Pair Connections.
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
Multiplexer or DVMRe
PIN 1:
RS485 shield
(ground one end only;
preferably at mux/DVMRe)
PIN 3:
RS485A
PIN 6:
RS485B
PINs 2, 4, 5, 7, and 8 are
not connected.
Observe polarity for:
• Audio
• RS422
• RS485
• 12 VDC
(12 VDC transformer
must have a positive
center polarity plug
)
RS485 (optional RJ45 connection*)
(for GE Interlogix DVMRes, multiplexers,
ProBridges, and additional KTD-405 I/O boxes)
RS485 (optional RJ45 RS485 connection*)
(for GE Interlogix DVMRes, multiplexers,
ProBridges, and additional KTD-405 I/O boxes)
KEYPAD (black RJ45 ( ) control cable)
Note: The old phone-style I/O box used a silver
( ) RJ45 keypad cable. You must use the
new cable with the new I/O box.
AUDIO (silver RJ11 ( ) cable from
keypad (provided only with the KTD-405A))
Crossover cable Straight-through cable *The installer supplies the optional RJ45
RS485 cable(s) with the stated pinouts
(an RS485 connection is also available
on the terminal strip)
Figure 8. RJ-cable connections to the I/O box

Installation KTD-405/405A User Manual
12 1036547C / December 2003
3.3.2 TWISTED-PAIR CONNECTIONS
The twisted-pair connections are available to connect additional devices or for existing installations where
individual wires were used to connect to the old phone-style I/O box. Easy-to-use RJ-cable connections
are also available on the new I/O box. See section 3.3.1 RJ-Cable Connections.
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
Bias switch
The bias switch maintains an appropriate load on the RS485 line.
Set the bias switch to ON for one keypad in a typical system (any one keypad and
only one keypad). If your system is divided into groups that are separated by fiber or
Ethernet bridges, you must set the bias switch to ON for one keypad in each group.
For safety, use a
tie-wrap to secure
the power cable to
the tie-in.
12 VDC power
(12 VDC transformer
must have a positive
center polarity plug
)
Earth ground (to ground)
RS485 connection*
RS422 IN
(from keypad or
alarm unit, if used)
RS422 OUT
(to switcher or cameras)
Speaker/Shield
(to remote speaker,
if used)
*For multiplexer, DVMRe, or I/O
box of additional keypad (RS485
connections are also available
with the RJ45 connectors)
Observe polarity for:
• 12 VDC
• RS422
• RS485
Figure 9. Wire connections to the I/O box

KTD-405/405A User Manual Installation
1036547C / December 2003 13
3.3.3 CONNECTING A MULTIPLEXER OR DVMRe AND DOMES
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
RS485 OUT
(data out to devices such as multiplexers
or DVMRe’s; ground at mux/DVMRe)
KEYPAD IN
(RS422 and RS485 data in from keypad;
RS422 data and power out to keypad)
RS422 IN
(data in from devices such as alarm units,
ASCII converters, or keypads (see guidelines))
Observe polarity for:
• RS422
• RS485
• 12 VDC power
(12 VDC transformer
must have a positive
center polarity plug
)
PIN 1 to RS485 shield
(ground one end only)
PIN 3 to RS485 A
PIN 6 to RS485 B
Note: PINs 2, 4, 5, 7, and 8 are not
connected.
12 VDC (observe polarity,
if provided transformer not used)
RS422 OUT
(data out to devices such as domes,
switchers, or keypads (other than KTD-405s))
Figure 10. Connecting a keypad (KTD-405 shown) to a multiplexer or DVMRe (shown) and domes

Installation KTD-405/405A User Manual
14 1036547C / December 2003
3.3.4 CONNECTING MULTIPLE KEYPADS WITH RJ45 CABLES
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
12 VDC (observe polarity, if provided transformer and plug not used)
RS422 IN (data in from devices such as alarm units, ASCII converters, or keypads (see guidelines))
RS422 OUT (data out to devices such as domes, switchers, or keypads (other than KTD-405s))
AUDIO OUT (to speaker and speaker shield)
RS485 OUT (data out to devices such as multiplexers or DVMRe’s; ground at mux/DVMRe)
Observe polarity for:
• Audio
• RS422
• RS485
• 12 VDC power
(12 VDC transformer
must have a positive
center polarity plug
)RS485 to I/O box of additional keypad via RJ45 cable
KEYPAD IN (RS422 and RS485 data in from keypad; RS422 data and power out to keypad)
AUDIO IN (from keypad)
PIN 1 to RS485 shield (ground one end only)
PIN 3 to RS485 A
Note: When using
multiple keypads,
you can connect
CyberDomes and
other receivers to
the RS422 output
from any keypad.
PIN 6 to RS485 B
Note: PINs 2, 4, 5, 7, and 8 are not connected.
Figure 11. KTD-405 and KTD-405A connections via RJ45 cables

KTD-405/405A User Manual Installation
1036547C / December 2003 15
3.3.5 CONNECTING MULTIPLE KEYPADS WITH STP CABLE
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
12 VDC (observe polarity, if provided transformer and plug not used)
RS485 to I/O box of additional keypad via STP cable (with floating shield)
RS422 IN (data in from devices such as alarm units, ASCII converters, or keypads (see guidelines))
RS422 OUT (data out to devices such as domes, switchers, or keypads (other than KTD-405s))
AUDIO OUT (to speaker and speaker shield)
Observe polarity for:
• Audio
• RS422
• RS485
• 12 VDC power
(12 VDC transformer
must have a positive
center polarity plug
)
RS485 OUT (data out to devices such as multiplexers or DVMRe’s; ground at mux/DVMRe)
Note: When using STP for the RS485 connection between I/O boxes, you can use only one of the two
RJ45 RS485 OUT connections to a multiplexer or DVMRe. This ensures proper termination.
KEYPAD IN (RS422 and RS485 data in from keypad; RS422 data and power out to keypad)
AUDIO IN (from keypad)
PIN 1 to RS485 shield (ground one end only)
PIN 3 to RS485 A
Note: When using
multiple keypads,
you can connect
CyberDomes and
other receivers to
the RS422 output
from any keypad.
PIN 6 to RS485 B
Note: PINs 2, 4, 5, 7, and 8 are not connected.
Figure 12. KTD-405 and KTD-405A connections via STP cable

Installation KTD-405/405A User Manual
16 1036547C / December 2003
3.3.6 CONNECTING NEW AND OLD I/O BOXES
Adhere to all installation guidelines while making connections, including your local codes and those
provided in section 3.1 Installation Guidelines.
Note: For additional connection details about the old I/O boxes, see Appendix D. Old I/O Box Connections.
RS485 shield (float)
12 VDC (no polarity on old I/O box)
RJ45 from keypad (RS422 data in from keypad; silver crossover cable for old I/O box)
RS422 IN (data in from devices such as alarm units, ASCII converters, or keypads (see guidelines))
RS422 OUT (data out to devices such as domes, switchers, or keypads (other than KTD-405s))
Observe polarity for:
• Audio
• RS422
• RS485
• 12 VDC power
(12 VDC transformer
must have a positive
center polarity plug
)12 VDC (observe polarity on new I/O box)
RS485 to I/O box of additional keypad
RS485 OUT (data out to devices such as multiplexers or DVMRe’s; ground at mux/DVMRe)
Note: When using STP for the RS485 connection between I/O boxes, you can use only one of the two
RJ45 RS485 OUT connections to a multiplexer or DVMRe. This ensures proper termination.
KEYPAD IN (RS422 and RS485 data in from keypad; black straight-through cable for new I/O box)
PIN 1 to RS485 shield (ground one end only)
PIN 3 to RS485 A
Note: When using
multiple keypads,
you can connect
CyberDomes and
other receivers to
the RS422 output
from any keypad.
PIN 6 to RS485 B
Note: PINs 2, 4, 5, 7, and 8 are not connected.
Figure 13. New to old I/O box connections

KTD-405/405A User Manual Programming
1036547C / December 2003 17
4 PROGRAMMING
There are three programming modes for the keypad:
! Supervisor Programming Mode: Establishes such essentials as the keypad’s nonvolatile memory, title, and
PTZ-to-KB3 command communication.
! User Programming Mode: Establishes the keypad’s system architecture for operations.
! Remote Device Programming Mode: Enables you to program system devices such as cameras and VCRs.
Refer to the menu keys in Figure 14 and the navigation keys in Table 1 while moving through the
programming menus.
Figure 14. Menu keys (gray keys are available on the KTD-405A only)
Table 1. Navigating the programming menus
Key Function
!displays the next menu
"displays the previous menu
#scrolls up when indicated by !in the menus
$scrolls down when indicated by "in the menus
scrolls right when indicated by #in the menus
scrolls left when indicated by $in the menus
Joystick scrolls up, down, left, or right when indicated by !,",$,#in menus
seq advances menus; or exits menus if held for 3 sec
1st displays the previous menu

Programming KTD-405/405A User Manual
18 1036547C / December 2003
4.1 ENTERING THE PROGRAMMING MODES
When you provide power to the unit, the following menu appears:
CAMERA 0
MONITOR 1
1) To access the programming mode, press and hold the key until you hear a tone and the
following menu appears:
ENTER PROGRAMMING
CODE:
Note: The ENTER PROGRAMMING CODE menu times out after 5 seconds.
2) Enter your programming code.
! To enter supervisor menus, press 1-4-7-6-seq and proceed to section 4.2 Supervisor Programming.
! To enter user menus, press 5-7-9-seq and proceed to section 4.3 User Programming.
! To enter remote device programming, press 9-5-1-seq and proceed to section 4.4 Remote Programming.
Note: Menus time out after 4 minutes.
Note: Menus that were not implemented in this release are indicated by two beeps and the following menu:
NOT IMPLEMENTED
4.2 SUPERVISOR PROGRAMMING
From the ENTER PROGRAMMING CODE menu, pressing 1-4-7-6-seq enters the supervisor menus.
The RESET T0 DEFAULTS option erases data in the KTD-405’s nonvolatile memory and reloads factory
values. RESET ALL clears programmed keypad and zone titles; RESET ALL BUT TITLES retains the
zone titles; and RESET CAMERA reinitializes CyberScout cameras so that they find all of their orientation
points.
Note: Access the CyberScout that you want to reset before you enter supervisor programming.
Note: CyberDomes are reset from the CyberDome programming menus. Refer to the CyberDome Programming Manual.

KTD-405/405A User Manual Programming
1036547C / December 2003 19
Note: Pressing !forwards you through programming without changing set parameters.
RESET TO DEFAULTS? NO
(+)=YES (-)=NO "NEXT!+ 1 = RESET ALL BUT TITLES
2 = RESET ALL 3 = CAMERA
–!If 1pressed.
PARTIAL. ARE YOU SURE?
(+)=YES (-)=NO "NEXT!
If 2pressed.
COMPLETE. ARE YOU SURE?
(+)=YES (-)=NO "NEXT!
If 3pressed.
RESET CAMERA X ?
ARE YOU SURE? +,YES -,NO
Note: Only CyberScout cameras are reset (i.e.,
reinitialized) when 3is selected. CyberDomes are reset
from the CyberDome programming menus. Refer to the
CyberDome Programming Manual.
KEYPAD ADDRESS: 99
(01-99) "NEXT!INITIALIZING DEFAULTS
PLEASE WAIT
A keypad address is a two-digit number (01 – 99) that distinguishes a keypad from other devices. This
address is automatically assigned when the keypad is first connected into the RS485 communication line.
The address doesn’t change unless you assign a new address or the system configuration changes.
Note: Entering an address that is already assigned displays a menu that reads ADDRESS ALREADY IN USE.
Entering a keypad address or pressing !displays the following menu:
KB3 PTZ PROTOCOL? NO
(+)=YES (-)=NO "NEXT!
If the KTD-405 is being used in a system that needs to communicate PTZ commands to a Calibur
CBR-KB3/J keypad or ProBridge, you must select YES so that the KTD-405 communicates properly with
these devices.
ENABLE REMOTE PRGMG? YES
(+)=YES (-)=NO "NEXT!
Enabling remote programming allows the keypad’s user to enter the 9-5-1-seq code for programming
remote devices in the system. If disabled, a tone sounds when the 9-5-1-seq code is entered.

Programming KTD-405/405A User Manual
20 1036547C / December 2003
KEYPAD TITLE: (!,",#,$)
"NEXT!
Use #,$,, or or the joystick to title the keypad. Titles can include A through Z, 0 through 9, and
spaces:
#or ! Moves from a space to A through Z, to 9 through 0.
$or " Moves from a space, to 0 through 9, to Z through A.
or # Moves the cursor right.
or $ Moves the cursor left.
A keyboard title can be up to 14 characters. If a keypad is programmed with a title, it can be programmed
with a user-defined four-digit seize control code, which enables a supervisor to seize control of the
keypad’s addressed site. An addressed site is a device such as a camera, DVMRe, or VCR, or an entire
zone if the keypad is programmed in a zone mode.
Note: The next two seize control menus are for future use.
SEIZE CONTROL CODE: 8624
USE NUMBER KEYS "NEXT!
Entering a four-digit code or !displays the following menu:
SEIZE CONTROL TIME: 5
(1-10) MINUTES "NEXT!
The seize control time is the minutes of user inactivity that must elapse before the keypad automatically
exits the seize control state.
LOWEST USER PRGMD PRESET
(01-64) 58 "NEXT!
PTZ presets (0 – 63) are normally stored in the programming menus to protect them from being changed
by the keypad user. The lowest user programmed preset defines which presets are protected. Any
number greater than or equal to the lowest programmed preset can be user-stored during normal
operation by pressing the store key and entering a two-digit preset number, then pressing store again.
If presets 58 through 61 are not protected (default), they work in combination with the aux keys to quickly
store presets aux 1 is 58, aux 2 is 59, aux 3 is 60, and aux 4 is 61. Presets 62 and 63 are used to
store autopan left and right limits using the and keys. Preset 0 (home position) can be stored only
in the programming menus.
Note: Pressing the store button and then aux 1,2,3, or 4prompts you to press store again, which sets the quick store position.
Pressing the find button and then aux 1,2,3, or 4recalls the quick store position.
