Installation Manual
PREMIER RKP8PLUS/16PLUS
INS181-5

INS181-5 2/9
Content
1.0 Installation 3 ..............................................................................................................................
1.1 Mounting RKP8/16 Plus 3 ........................................................................................................
1.2 Selecting an Address 4 ...........................................................................................................
1.3 Wiring 5 ..................................................................................................................................
1.4 Programming/Confirm Devices 6 ............................................................................................
1.5 Technical Specifications 7 ......................................................................................................
1.6 Standards 8 ............................................................................................................................
1.7 Warranty 8 .............................................................................................................................

INS181-5 3/9
1.0 Installation
The Premier RKP8/16 Plus remote keypads are suitable for use with the following
Texecom control panels: Premier 412 and Premier 816 with Version 2.1 or higher
panel software. Up to 6 keypads may be connected to the system
1.1 Mounting RKP8/16 Plus
Open the keypad by carefully inserting a small flat-blade screwdriver into each slot
at the base of the unit. Gently push the screwdriver to ease the retaining clips
upward, DO NOT LEVER OR TWIST. Excessive force is NOT required. The front flap
and front cover can now be removed.

INS181-5 4/9
1.2 Selecting an Address
Each keypad MUST be given a different address using the DIP switch on the left
hand side of the PCB as follows:
N NEVER set two RKPs to the same address. Keypads are factory set to Address
1 (all switches off).

INS181-5 5/9
1.3 Wiring
It is strongly recommended that the system is completely powered down (mains
and battery) before wiring a keypad. Connect the keypad to the control panel using
4-core cable as follows:
Up to six keypads may be connected in parallel (‘star’) or series (‘daisy‑chain’) or
any combination.
N When using long cable runs or connecting keypads in series (‘daisy‑chain’)
ensure that the voltage at the keypad is no less than 10.0V. When using 6-core or
8-core cable always use the spare cores to ‘double-up’ on 0V. This will allow longer
cable runs particularly when connecting keypads in series (‘daisy‑chain’). As a rule
‘trebling‑up’ on 0V will be more beneficial than ‘doubling-up’ on 12V and 0V.
Keypad Zones
The Premier RKP8/16 Plus has two fully programmable zone inputs (Z1 COM Z2).
For information on wiring configuration options please refer to the Premier 412/816
Installation Manual.
In order to use the keypad zones, you must first enable the zones using Menu 43
Option 1 (refer to the Premier 412/816 Installation Manual). When a keypad has its
zones enabled they are mapped onto the system as shown:

INS181-5 6/9
1.4 Programming/Confirm Devices
When the system is powered up you will need to confirm the devices connected to
the data bus.
To Confirm Devices on all types of RKP’s panel firmware version 14.06 onwards
please use the following procedures. The method for each keypad is detailed.
N For previous versions (14.04 and below) you can only confirm devices with an
LCD RKP.
RKP+8
Allow system to operate for 30 seconds1.
Enter installer/engineer code – would display confirm devices2.
Press Yes Key – Enter confirm devices menu (All zone LED’s will illuminate)3.
Press Yes Key – Accept Detected network devices (All zone LED’s will un-4.
illuminate)
Press Yes Key – Confirm detected devices, exit installer menu and returns to5.
day mode operation
RKP+16
Allow system to operate for 30 seconds1.
Enter installer/engineer code – would display confirm devices2.
Press Yes Key – Enter confirm devices menu (All zone LED’s will illuminate)3.
Press Yes Key – Accept Detected network devices (All zone LED’s will un-4.
illuminate)
Press Yes Key – Confirm detected devices, exit installer menu and returns to5.

INS181-5 7/9
day mode operation
N Any premier International panels containing a software version prior to
V14.02 that is flashed with version V14.02 or later, The Confirm Devices strings are
not loaded in the panel’s memory so any reference to them results in black
squares being shown.
Reload English Text Strings
This can be achieved by entering the Installers code and then pressing the
keypad’s “Menu” key this provides a short cut to the language setting menu. Once
the selected language is transferred from flash to memory the Confirm Devices
strings will be displayed.
N Updated versions of the panel firmware can be found on our FTP server, or by
contacting Technical Support.
1.5 Technical Specifications
Operating Voltage: 9 – 13.7VDC
Current Consumption: Nominal: 35mA; When fully back lit: 85mA
Zone Indicators: 16 on the RKP16Plus; 8 on the RKP8Plus
Status Indicators: RKP Plus Alarm: Red; Service: Yellow; Fire: Red; Bypass/Omit:
Red; Instant: Red; Stay/Part: Red; Ready: Green; Armed: Red
Status Indicators: RKP4/8/16 Alarm: Red; Trouble: Yellow; Armed: Red; Ready:
Green
Data Bus: 4-wire up to 250m Star, Daisy-Chain or any combination
Operating Temperature: -10°C to +45°C
Storage Temperature: -20°C to +60°C
Maximum Humidity: 95% non-condensing
EMC Environment: Residential/Commercial/Light Industrial or Industrial
Material: 3mm Polycarbonate
Dimensions: RKP Plus 140mm x 115mm x 30mm
Packed Weight: RKP Plus 260g Approx.

INS181-5 8/9
1.6 Standards
Hereby, Texecom declares that this product complies with the following Directives
2014/53/EU RE Directive and 2011/65/EU ROHS Directive.The product therefore
meets all the requirements to enable it to be CE marked.
Weee Directive: 2012/19/EU (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European Union. For
proper recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For
more information see: www.recyclethis.info.
This product Type B Moveable device. And is suitable for use in systems designed
to comply with EN 50131-1 & EN50131-3 at Grade 2 and Environmental Class II.
1.7 Warranty
All Texecom products are designed for reliable, trouble-free operation. Quality is
carefully monitored by extensive computerised testing. As a result the Premier
RKP8/16 Plus is covered by a two year warranty against defects in material or
workmanship (details on request).
As the Premier RKP8/16 Plus is not a complete alarm system but only a part
thereof, Texecom cannot accept responsibility or liability for any damages
whatsoever based on a claim that the Premier RKP8/16 Plus failed to function
correctly. Due to our policy of continuous improvement Texecom reserve the right
to change specification without prior notice.

INS181-5 9/9
