GE Dishwashers User manual

GEAppliances.com
Stainless Steel
Tub with Front
Controls
Owner’s Manual
Dishwashers
29-5928 12/13 MC
Write the model and serial
numbers here:
Model # ___________________
Serial #____________________
You can find them on a label on the
tub wall just inside the door.
Safety Instructions.........2-5
Operating Instructions
Control Panel and Settings. . . . . . 6-7
UsingtheDishwasher..........8-9
Loading the
Dishwasher Racks...............10
Care Instructions
Care and Cleaning ...........11-12
Troubleshooting Tips . . . 13–14
Consumer Support
Warranty .......................15
Consumer Support ..............16

2
IMPORTANT SAFETY INFORMATION.
5($'$//,16758&7,216%()25(86,1*³
SAVE THESE INSTRUCTIONS
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire,
explosion, electric shock, and to prevent property damage, personal injury, or death.
WATER HEATER SAFETY
PROPER INSTALLATION AND MAINTENANCE
This dishwasher must be properly installed and located in accordance with the Installation
Instructions before it is used. If you did not receive an Installation Instructions sheet with
your dishwasher, you can receive one by visiting our website at GEAppliances.com. In
Canada, GEAppliances.ca.
Contents washed in Anti-bacterial mode, if
available, may be hot to the touch. Use care
before handling.
Using a detergent that is
not specifically designed
for dishwashers will cause
the dishwasher to fill with
suds.
If your dishwasher is connected to a
wall switch, ensure that the switch is
on prior to use.
On dishwashers with electronic
controls, if you choose to turn the wall
switch off between wash cycles, allow
5–10 seconds after turning the switch on
before touching ON/OFF to allow the control to
reboot.
Non-Dishware Items: Do not wash items such
as electronic air cleaner filters, furnace filters
and paint brushes in your dishwasher. Damage
to dishwasher and discoloration or staining of
dishwasher may result.
Close supervision is necessary if this appliance
is used by or near children.
Load light, plastic items so they will not become
dislodged and drop to the bottom
RIWKHGLVKZDVKHU³WKH\PLJKWFRPHLQWR
contact with the heating element and be
damaged.
Connect the dishwasher/appliance to a grounded
metal, permanent wiring system; or run an
equipment-grounding conductor with the circuit
conductors and connect to the equipment-
grounding terminal or lead of the appliance.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded.
Dispose of discarded appliances and shipping or
packing material properly.
Do not attempt to repair or replace any part
of your dishwasher unless it is specifically
recommended in this manual. All other servicing
should be referred to a qualified technician.
To minimize the possibility of electric shock,
disconnect this appliance from the power supply
before attempting any maintenance.
NOTE: Turning the dishwasher off does not
disconnect the appliance from the power supply.
We recommend having a qualified technician
service your appliance.
WARNING!
CAUTION: To prevent minor injury or property damage
Under certain conditions, hydrogen gas may be produced in a water heater that has not been used
for two or more weeks. HYDROGEN GAS IS EXPLOSIVE.
If the hot water has not been used for two or more weeks, prevent the possibility of damage or
injury by turning on all hot water faucets and allow them to run for several minutes. Do this before
using any electrical appliance connected to the hot water system. This simple procedure will allow
any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke, use an open flame,
or use the appliance during this process.

3
INFORMACIÓN IMPORTANTE DE SEGURIDAD
/($72'$6/$6,16758&&,21(6$17(6'(86$5³
GUARDE ESTAS INSTRUCCIONES
¡ADVERTENCIA!
Para su seguridad, debe cumplirse con la información de este manual a fin de minimizar el
riesgo de incendio o explosión, descarga eléctrica o para prevenir daños a la propiedad, lesiones
personales o la muerte.
SEGURIDAD DEL CALENTADOR DE AGUA
Los elementos lavados en el modo anti-bacterial, si
se encuentra disponible, pueden quedar calientes al
tacto. Tenga cuidado antes de tocarlos.
Utilizar un detergente no
diseñado específicamente
para lavaplatos provocará
que el aparato se llene de
espuma.
Si su lavaplatos se encuentra
conectado a un interruptor de
pared, verifique que el interruptor se
encuentre encendido antes del uso.
En lavaplatos con controles electrónicos,
si usted elije apagar el interruptor de
pared entre ciclos de lavado, deje pasar
5-10 segundos después de encender el interruptor
antes de presionar ON/OFF para permitir que el
control se inicie.
Elementos no aptos para lavaplatos: No lave
elementos como filtros de limpiadores de aire
electrónicos, filtros de hornos y pinceles de pintura
en su lavaplatos. Pueden producirse daños en el
lavaplatos y decoloración o manchas en el aparato.
Se requiere una supervisión estricta cuando cualquier
aparato es utilizado por niños o en su cercanía.
Cargue elementos livianos y plásticos de modo que
no se desplacen y caigan al fondo del lavaplatos,
ya que pueden entrar en contacto con el elemento
calentador y dañarse.
INSTALACIÓN Y MANTENIMIENTO ADECUADOS
Este lavaplatos debe instalarse de manera adecuada y ubicarse de acuerdo con las Instrucciones
de Instalación antes de comenzar el uso. Si usted no ha recibido una página de Instrucciones de
instalación con su lavaplatos, puede obtener una visitando nuestro sitio Web en GEAppliances.com.
En Canadá, GEAppliances.ca.
Conecte el lavaplatos/aparato a un sistema de
cableado permanente con conexión a tierra o debe
utilizarse un conductor de conexión a tierra del
equipamiento con los conductores de circuito, y
debe conectarse a la terminal de conexión a tierra o
conductor del aparato.
Una conexión inadecuada del conductor de conexión
a tierra de equipo puede provocar un riesgo de
descarga eléctrica. Consulte a un electricista
calificado o representante de servicio técnico si tiene
dudas sobre la correcta conexión a tierra del aparato.
Elimine los aparatos que no va a utilizar más y el
material de empaque o envío como corresponde.
No intente reparar o cambiar ninguna pieza de
su lavaplatos a menos que esté específicamente
recomendado en este manual. Cualquier otro servicio
debe realizarlo un técnico calificado.
Para minimizar la posibilidad de una descarga
eléctrica, desconecte este aparato de la fuente
de energía antes de realizar cualquier clase de
mantenimiento.
NOTA: Apagar el lavaplatos no desconecta el aparato
del suministro de energía. Recomendamos que un
técnico calificado realice el servicio técnico de su
aparato.
¡ADVERTENCIA!
PRECAUCIÓN: Para evitar lesiones menores y daños a la propiedad
Bajo ciertas condiciones, puede producirse gas de hidrógeno en un calentador de agua que no se ha usado
durante dos semanas o más. EL GAS DE HIDRÓGENO ES EXPLOSIVO.
Si el agua caliente no se ha utilizado por dos semanas o más, evite la posibilidad de daños o lesiones
abriendo todos los grifos de agua caliente y dejándolos correr durante varios minutos. Haga esto antes de
utilizar cualquier aparato eléctrico que se encuentre conectado al sistema de agua caliente. Este simple
procedimiento permitirá que se libere cualquier clase de acumulación de gas de hidrógeno. Ya que el gas
es inflamable, no fume o utilice una llama abierta o un aparato durante este proceso.
GEAppliances.com

4
PROPER DISPOSAL OF THE DISHWASHER
Junked or abandoned dishwashers are
dangerous… even if they will sit for “just a
few days.” If you are getting rid of your old
dishwasher, please follow the instructions
below to help prevent accidents.
Before You Throw Away Your Old
Dishwasher:
Take off the door of the washing compartment
or remove the door latch keeper (as shown).
WARNING! RISK OF CHILD ENTRAPMENT
Door latch
keeper
Hold nut at top of dishwasher
while removing screw
Use this appliance only for its intended purpose
as described in this Owner’s Manual.
Use only powder, tabs, liquid detergents or rinse
agents recommended for use in a dishwasher and
keep them out of the reach of children. Cascade®,
Cascade®Complete Automatic Dishwashing
Detergents, and and Cascade Crystal Clear®
rinse agents) have been approved for use in all GE
dishwashers.
Locate sharp items so that they are not likely
to damage the door seal.
Load sharp knives with the handles up to reduce
the risk of cut-type injuries.
Do not wash plastic items unless marked
“Dishwasher Safe” or the equivalent. For plastic
items not so marked, check the manufacturer’s
recommendations.
Do not touch the heating element during or
immediately after use.
Do not operate your dishwasher unless all
enclosure panels are properly in place.
Do not tamper with controls.
Do not abuse, sit on or stand on the door or dish
rack of the dishwasher.
Do not allow children to play around dishwasher
when opening or closing door due to the possibility
of small fingers being pinched in door.
Do not discard a dishwasher without first removing
the door of the washing compartment or the door
latch.
Do not store or use combustible materials,
gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
Do not allow children to play with, on or inside this
appliance or any discarded appliance.
WARNING! When using your dishwasher, follow basic precautions,
including the following:
SAVE THESE INSTRUCTIONS
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
IMPORTANT SAFETY INFORMATION.
5($'$//,16758&7,216%()25(86,1*³
SAVE THESE INSTRUCTIONS

5
ELIMINACIÓN CORRECTA DEL LAVAPLATOS
Un lavaplatos desechado o abandonado resulta
peligroso…aun si quedará en un lugar por “sólo
unos días”. Si va a desechar su viejo lavaplatos,
siga las siguientes instrucciones para prevenir
accidentes.
Antes de desechar su viejo lavaplatos:
Quite la puerta del compartimento de lavado
o saque la traba de la puerta (como puede
verse).
¡ADVERTENCIA! RIESGO DE ENCIERRO PARA NIÑOS
Traba de la puerta
Sujete la tuerca en la parte
superior del lavaplatos mientras
retira el tornillo
Use este aparato sólo con el objetivo para el que
fue creado, como se describe en este Manual del
Propietario.
Utilice sólo detergentes en polvo, líquido o tabletas
o agentes de enjuague recomendados para uso
en lavaplatos y manténgalos alejados del alcance
de los niños. Los detergentes para lavaplatos
automáticos Cascade®, Cascade® Complete, y
los agentes de enjuague Cascade Crystal Clear®
han sido aprobados para el uso en todos los
lavaplatos GE..
Ubique los elementos filosos de modo que no
dañen el sellado de la puerta.
Cargue cuchillos filosos con los mangos hacia
arriba para reducir el riesgo de una lesión
personal.
No lave elementos plásticos a menos que
estén marcados como aptos para lavaplatos o
equivalente. En el caso de elementos plásticos
que no estén marcados así, verifique las
recomendaciones del fabricante.
No toque el elemento calentador durante el uso o
inmediatamente después de finalizar el uso.
No haga funcionar el lavaplatos a menos que
todos los paneles del recinto se encuentren en su
lugar.
No altere o modifique los controles.
No maltrate, ni se siente o se pare sobre la puerta
o bandejas de los platos del lavaplatos.
No permita que los niños jueguen alrededor del
lavaplatos cuando abra o cierre la puerta debido a
la posibilidad de pellizcar sus dedos con la puerta.
No deseche el lavaplatos sin antes quitar la puerta
del compartimento de lavado o la traba de la
puerta
No almacene o use materiales combustibles,
gasolina u otros vapores o líquidos inflamables
cerca de este o cualquier otro aparato.
No permita que los niños jueguen sobre, con
o dentro de este o cualquier otro aparato
desechado.
¡ADVERTENCIA! Cuando use su lavaplatos, siga precauciones básicas
de seguridad, incluyendo las siguientes:
CONSERVE ESTE INSTRUCTIVO
LEA Y SIGA CON CUIDADO ESTA INFORMACIÓN DE SEGURIDAD.
INFORMACIÓN IMPORTANTE DE SEGURIDAD
/($72'$6/$6,16758&&,21(6$17(6'(86$5³
GUARDE ESTAS INSTRUCCIONES GEAppliances.com

ter: 25 liters, Time: 130 minutes
LIGHT WASH
6
About the dishwasher control panel
Control Settings
1Power
Press the POWER button to turn on the unit to be operated. The LED will be displayed when the dishwasher is on.
2Programs
When the dishwasher is turned on, you can press the PROGRAMS button to select the wash cycle. A light on the display
will indicate which cycle has been selected.
NOTE : The following information about cycle duration and water consumption are approximate. Results will vary
based on various factors, including but not limited to incoming water temperature and pressure as well as soil level.
HEAVY WASH Wa
This cycle is meant for heavily soiled dishes or cookware with dried-on or baked-on soils. This cycle may not
remove burned-on foods. Everyday dishes are safe to be used in this cycle.
NORMAL WASH Wa
This cycle is meant for loads of everyday dishes, glasses and cookware with medium soils that have not been
pre-rinsed.
LIGHT WASH
This cycle is meant for loads of everyday dishes, glasses and cookware with medium soils that have not been
pre-rinsed. This cycle features reduced wash times to allow for faster cycle completion. This cycle also has a
reduced time heated dry.
RINSE ONLY Water: 7.3 liters, Time: 25 minutes
For rinsing partial loads that will be washed later. Do not use detergent with this cycle. This cycle does not include
heated dry.
1423 5
ter: 25 liters, Time: 130 minutes
ter: 14.3 liters, Time: 130 minutes
Water:14.3liters, Time:95 minutes
Heated Dry Programs Power
Start
Cancel
Child Lock

When the wash cycle has been selected, you can choose the option by pressing the “Heated Dry”
ATED DRY
button for 3 seconds, the LOCK light
button for 3 seconds the LOCK light will display on the LCD. No buttons
7
3
button.
1Press the
4
5
Start / Cancel
When the program and options have been selected, make sure the door is closed press the START/
CANCEL button. To stop or reset the wash cycle, press the START/CANCEL button, the dishwasher will
stop washing.
Child Lock
Press the
can be operated when the dishwasher controls are locked.
To cancel the “Child Lock” option, press the
will no longer be shown on the LCD and the dishwasher controls will be unlocked.
GEAppliances.com
button once, the “Heated Dry” will be selected;
Child Lock
Child Lock
HEATED DRY
ATED DRY
HEATED DRY
HEATED DRY When the “Heated Dry” option is selected, the heater will be activated during the drying
of the cycle.portion

8
Using the dishwasher.
Use Cascade Crystal Clear®Rinse Agent
Cascade Crystal Clear®rinse agent removes spots and prevents new film buildup on your dishes, glasses,
flatware, cookware and plastic.
Filling the Dispenser
The rinse agent dispenser holds 99.4 ml of rinse agent. Under normal conditions,
this will last approximately one month. Try to keep it full, but do not overfill.
1Make sure the dishwasher door is fully open.
2Turn the dispenser cap to the left and lift it out.
3Add rinse agent until the indicator window looks full.
4Clean up any spilled rinse agent with a damp cloth.
5Replace the dispenser cap.
Rinse Aid Setting
The amount of rinse agent released into the final wash can be adjusted.
The factory setting is at the midpoint. If there are rings of calcium
(hard water) spots on dishes, try a higher setting. If you observe foam
in the final rinse, try a lower setting.
To adjust the setting
Remove the dispenser cap; then turn the adjuster counterclockwise
to increase the amount of rinse agent or clockwise to reduce the amount
of rinse agent dispensed.
Check the Water Temperature
The entering water should be at least 49°C (120°F)
and not more than 65°F (150°F) for effective
cleaning and to prevent dish damage. Check
the water temperature with a candy or meat
thermometer. Turn on the hot water faucet nearest
the dishwasher, place the thermometer in a glass
and let the water run continuously into the glass
until the temperature stops rising.
M
i
n
M
a
x
Indicator
Dispenser cap
Adjustable setting
 No prerinsing of normal food soil is required if using
Heavy, Normal or wash cycles.
 Scrape off hard soils, bones, toothpicks, skins and
seeds.
 Remove large quantities of any remaining food.
 Remove leafy vegetables, meat, trimmings and
excessive amounts of grease or oil.
 Remove acidic food soils that can discolor stainless
steel.
Dish Preparation Prior to Loading
Light

GEAppliances.com
Proper Use of Detergent
Use only detergent specifically made for use
in dishwashers. Cascade®Automatic
Dishwashing Detergent has been approved.
Keep your detergent fresh and dry. Don’t put
detergent into the dispenser until you’re ready to
wash dishes.
The amount of detergent to use depends on
whether your water is hard or soft. With hard
water, you need extra detergent. With soft water,
you need less detergent.
Protect your dishes and dishwasher by
contacting your water department and asking
how hard your water is. Twelve or more grains
is extremely hard water. A water softener is
recommended. Without it, lime can build up in
the water valve, which could stick while open
and cause flooding. Too much detergent with
soft water can cause a permanent cloudiness
of glassware, called etching.
Use the information in the table below as a
guideline to determine the amount of automatic
dishwasher detergent to place in the dispenser.
When using automatic dishwasher detergent
tablets, simply place one tablet in the dispenser
and close the cover.
To open the wash cover, press the button and the
cover will flip back.
For heavily-soiled loads, use the HEAVY wash cycle
and add a little extra detergent.
DO NOT USE HAND DISH DETERGENT
NOTE: Using a detergent that is not specifically
designed for dishwashers will cause the dishwasher
to fill with suds. During operation, these suds will spill
out of the dishwasher vents, covering the kitchen
floor and making the floor wet.
Because so many detergent containers look alike,
store the dishwasher detergent in a separate space
from all other cleaners. Show anyone who may use
thedishwasherthe correct detergent and where it
is stored.
While there will be no lasting damage to the
dishwasher, your dishes will not get clean using a
dishwashing detergent that is not formulated to
work with dishwashers.
A forgotten dish can be added any time before
the main wash.
1Unlatch the door to interrupt the cycle. Pull
the door handle to release the door.
2Do not open the door until the water spray
action stops. Steam may rise out of the
dishwasher.
3Add forgotten dishes.
4Close the door and push it in to relatch.
Forgot to Add a Dish?
Button
Open
cup
Detergent Cups to Fill
15 cup
25 cup
15 and 25 cups
15, 25 cups and the open cup
Number
of Grains
Less than 4
4 to 8
8 to 12
Greater than 12
9

10
12 place setting10 place setting
8place setting
5
Glasses
Bread and butter
Silverware Basket
How to use the LowerRack
How to use the UpperRack
Loading the DishwasherRacks.
Forbest performance of the dishwasher,follow these loading guidelines.Featuresand appearance
of racksand silverware baskets may vary from your model.
The upper rackis designed tohold more delicateand lighter dishware suchasglasses,coffee andtea cup and
saucers,as wellas plates,smallbowls and shallowpans(as long astheyare not t oo dirty).
Position the dishesand cookware sothat theydonot getmoved bythesprayof water.
1Cups
2
Serving bowl
3
4
Fruit bowl
We recommend thatyou place largeitems whichare most difficult toclean intothe l ower rack: pots,pans,lids,
serving dishes andbowls,as shownin the figuretothe right.
It is preferabletoplace serving dishes and lidson the sideof the racksin order toavoid blocking the r otation of the
top sprayarm.
Pots,serving bowls,etc,must alwaysbe placed top d own.
Deep pots should be slanted toallow water toflow out.
8
Saucer
7
9
Dinner plates
Silverware basket
6
plates
Serving plate
Silverware should beplaced in thesilverware basket withhandles at the b ottom: Iftherackhas sidebaskets,
the spoon shouldbe loaded individuallyintothe appropriateslots,Especiallylongutensils should beplaced
in the horizontalposition at the front of theupper rack.
Do not letanyitemextendthroughbottom.
WARNING!
Teaspoons
4
Soup spoons
2
Salad Forks
1
Serving fork
Serving spoon
6
Knife5
3
Dinner forks
7
4
4
32
6
7
4
4
4
5
4
4
4
4
1
1
1
1
1
1
1
1
1
4
4
4
1
1
1
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
3
3
6
12 place setting10 place setting
8place setting

11
Caring for the dishwasher. GEAppliances.com
To clean the control panel, use a lightly dampened cloth, then dry thoroughly. To clean the exterior, use a good
appliance polish wax. Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
Cleaning the Door Panel
Before cleaning the front panel, make
sure you know what type of panel you
have. Refer to the last two letters of your
model number. You can locate your model
number on the left-hand tub wall just
inside the door. If your model number ends
with BB or WW, then you have a Painted
Door panel. If your model number ends
with SS, then you have a Stainless Steel
Door panel.
Follow the instructions below for cleaning
the door panel for your specific model.
Painted Door Panel (model numbers
ending in BB–black or WW–white)
Use a clean, soft, lightly dampened cloth,
then dry thoroughly. You may also use a
good appliance wax or polish.
Stainless Steel Door Panel (model
numbers ending in SS)
The stainless steel panels can be cleaned
with Stainless Steel Magic or a similar
product using a clean, soft cloth. Do not
use appliance wax, polish, bleach or
products containing chlorine on Stainless
Steel doors.
You can order Stainless Steel Magic
#WX10X15 through GEParts by calling
800.661.1616.
Do not wipe the dishwasher with a soiled
dish cloth or wet towel. These may leave
a residue. Do not use scouring pads or
powdered cleaners because these products
can scratch the finish.
Cleaning the Exterior
Cleaning the Control Panel
To clean the control panel, use a lightly
dampened cloth; then dry thoroughly. Do
not use sharp objects, scouring pads or
harsh cleaners on the control panel.
Stainless Steel Interior Tub and
Inner Door
The stainless steel used to make the
dishwasher tub and inner door provides
the highest reliability available in a GE
dishwasher. If the dishwasher tub or inner
door is ever scrached or dented during
during normal use, they will not rust or
corrode. These surface blemishes will not
affect their function or durability.
The dishwasher will flush away all normal food soils. However, objects (fruit pits, bones, etc.) may collect in
openings and should be removed occasionally to avoid clogging the drain system.
CAUTION
Personal injury hazard. Before cleaning the interior, wait at least 20 minutes after a cycle for the heating
element to cool down. Failure to do so could result in burn injuries.
Cleaning the Spray Arms
Because hard water chemicals will clog the
spray arm jets and bearings, it is necessary
to clean the spray arms regularly. Wash the
arms in soapy, warm water and use
a soft brush to clean the jets. Replace them
after rinsing thoroughly.
To remove the upper spray arm, unscrew the
nut clockwise.
To remove the lower spray arm, pull upward.
Cleaning the Spray Arms and the Filters
UNSCREW
PULL OUT
Upper
Arm
Lower
Arm

12
Cleaning the Filters
For best performance and results, the filter assembly must
be cleaned once a month. The filter efficiently removes food
particles from the wash water, allowing water to be recirculated
during the cycle. For this reason, it is a good idea to remove the
large food particles trapped in the filter frequently by rinsing the
main filter and cup under running water. To remove the filter
assembly, follow the 3 steps shown below. To clean the main
filter and fine filter, use a cleaning brush. The dishwasher must
never be used without the filters. Improper replacement of the
filter may reduce the performance level of the appliance and
may damage dishes and utensils.
Protect Against Freezing
If your dishwasher is left in an unheated
place during the winter, ask a service
technician to:
1Cut off electrical power to the dishwasher.
Remove fuses or trip circuit breaker.
2Turn off the water supply and
disconnect the water inlet line from
the water valve.
3Drain water from the water inlet line
and water valve. (Use a pan to catch
the water.)
4Reconnect the water inlet line to the
water valve.
Check the air gap any time your
dishwasher isn’t draining well.
Does Your Dishwasher Have
an Air Gap?
An air gap protects your dishwasher against
water backing up into it if a drain clogs.
The air gap is not a part of the dishwasher.
It is not covered by your warranty. Not all
plumbing codes require
air gaps, so you may not have one.
The air gap is easy to clean.
1Turn off the dishwasher and lift off the
chrome cover.
2Remove the plastic cap and clean with
a toothpick.
Two types of
air gaps
Caring for the dishwasher.
General Care Instructions
Cleaning the Spray Arms and the Filters (Continued)
STEP 1: Turn the filter counter-clockwise and lift up.
STEP 2: Lift the main filter up
STEP 3: Lift the fine filter up

13
Before you call for service…
Problem Possible Causes What To Do
Noise Some of the sounds you’ll 'HWHUJHQWFXSRSHQLQJ
hear are normal 7KHPRWRUVWDUWLQJGXULQJWKHGU\LQJSHULRG
  :DWHUGUDLQLQJRXWRIWKHWXELPPHGLDWHO\DIWHU\RX
start the dishwasher.
Utensils are not secure in the  0DNHVXUHHYHU\WKLQJLVVHFXUHGLQGLVKZDVKHU
rack or something small has
dropped into the rack
Motor hums 'LVKZDVKHUKDVQRWEHHQXVHGRQDUHJXODUEDVLV,I\RX
do not use your dishwasher often, set it to fill and pump
out once every week. This will help keep the seal moist.
  'LVKZDVKHUFRQWUROZDVQRWDGYDQFHGSURSHUO\WRWKHVWDUW
of the desired cycle. Advance the control to the start of
the desired cycle.
Detergent left in Dishes are blocking the 5HSRVLWLRQWKHGLVKHV
dispenser cups detergent cups
Water standing in the Drain is cloggedIf you have an air gap, clean it.
bottom of the tub  &KHFNWRVHHLI\RXUNLWFKHQVLQNLVGUDLQLQJZHOO,IQRW
you may need a plumber.
  ,IWKHGLVKZDVKHUGUDLQVLQWRDGLVSRVHUUXQGLVSRVHUFOHDU
This is normal $VPDOODPRXQWRIFOHDQZDWHUDURXQGWKHRXWOHWRIWKHWXE
bottom at the back of the tub keeps the water seal lubricated.
Suds in the tub Correct detergent wasn’t used 8VHRQO\DXWRPDWLFGLVKZDVKHUGHWHUJHQWVWRDYRLGVXGVLQJ
Cascade®Dishwashing Detergent has been
approved for use in all GE dishwashers.
  7RUHPRYHVXGVIURPWKHWXERSHQWKHGLVKZDVKHUDQGOHW
suds evaporate. Add 3.8 liters of cold water to the tub. Close
and latch the dishwasher. Repeat if necessary.
Rinse agent was spilled $OZD\VZLSHXSULQVHDJHQWVSLOOVLPPHGLDWHO\
Stained dishwasher parts Detergent with 6RPHGHWHUJHQWVFRQWDLQFRORUDQWSLJPHQWRUG\HVWKDW
colorant was used will discolor the tub interior with extended use. Check the
detergent cup for signs of any discoloration. If cup is
discolored, change to detergent without any colorant.
Cascade®Dishwashing Detergents has been
approved for use in all GE dishwashers.
Some tomato-based  8VHRIWKHRINSE ONLY cycle after adding the dish to the
foods can stain load can decrease the level of staining.
Troubleshooting Tips - Save time and money! Review the charts on the following pages, or visit
GEAppliances.com. In Canada, visit GEAppliances.ca. You may not need to call for service.
Dishwasher won’t run Fuse is blown, or the  5HSODFHIXVHRUUHVHWFLUFXLWEUHDNHU5HPRYHDQ\RWKHUDSSOLDQFHV
circuit breaker tripped from the circuit.
Power is turned off  ,QVRPHLQVWDOODWLRQVWKHSRZHUWRWKHGLVKZDVKHULVSURYHGWKURXJKD
wall switch, often located next to the disposer switch. Make sure it is on.
Reboot your control  7XUQRIISRZHUWRWKHGLVKZDVKHUDWFLUFXLWEUHDNHURUZDOOVZLWFKIRU
30 seconds, then turn back on.
Steam This is normal  6WHDPFRPHVWKURXJKWKHYHQWGXULQJZDVKLQJGU\LQJDQGZKHQ
water is being pumped out.
Beeping at the end This is normal   7KHGLVKZDVKHUZLOOEHHSWLPHVXQOHVVLQWHUXSWHGDQGWKH&/($1OLJKW
of the cycle will display at the end of the wash cycle.

14
Control panel Door latch may not be  0DNHVXUHWKHGRRULVILUPO\FORVHG
responded to input properly seated
but dishwasher never
filled with water Water vale may be   0DNHVXUHZDWHUYDOYHXVXDOO\ORFDWHGXQGHUWKHVLQNLVWXUQHGRQ
turned off
Dishwasher beeps This is normal  &ORVHWKHGRRUDIWHURSHQLQJLWPLGF\FOH 
once every 15 seconds
This is a reminder that the  3UHVVON/OFF to turn OFF the dishwasher.
door has been left open
during operation
Problem Possible Causes What To Do
Dishes and flatware Low inlet water temperature  0DNHVXUHLQOHWZDWHUWHPSHUDWXUHLVFRUUHFWVHHSDJH
not clean Water pressure is temporarily low  7XUQRQDIDXFHW,VZDWHUFRPLQJRXWPRUHVORZO\WKDQXVXDO"
If so, wait until pressure is normal before using your dishwasher.
Air gap is clogged  &OHDQWKHDLUJDS
Improper rack loading  0DNHVXUHODUJHGLVKZDUHGRHVQRWEORFNWKHGHWHUJHQW
dispenser or the wash arms.
No air gap or high drain loop  9HULI\WKDW\RXKDYHDQDLUJDSRUDKLJKGUDLQORRS5HIHUWRWKH
Installation Instructions.
Filter needs cleaning  7KHILOWHUDVVHPEO\PXVWEHFOHDQHGUHJXODUO\WRDOORZWKHILOWHUWR
efficiently remove food particles from the wash water. See Cleaning the
Filter section on page 1.
Spots and filming Extremely hard water  8VHCascade Crystal Clear®rinse agent to remove spots and
on glasses and prevent new film buildup.
flatware Low inlet water temperature 
Make sure water temperature is at least 49°C (120°F).
Overloading the dishwasher / Load dishwasher as shown in the Loading the Dishwasher Racks
Improper loading section.
Old or damp powder detergent Make sure detergent is fresh.
Rinse agent dispenser empty If water is extremely hard, a water softener may be required.
Too little detergent
Cloudiness on Combination of soft water and   7KLVLVFDOOHGHWFKLQJDQGLVSHUPDQHQW7RSUHYHQWWKLVIURPKDSSHQLQJ
glassware too much detergent use less detergent if you have soft water. Wash glassware in the shortest
cycle that will get them clean.
Water temperature entering Lower the water heater temperature.
the dishwasher exceeds 65°C (150°F)
Black or gray Aluminum utensils have  5HPRYHPDUNVZLWKDPLOGDEUDVLYHFOHDQHU
marks on dishes rubbed against dishes
Yellow or brown film Tea or coffee stains  5HPRYHWKHVWDLQE\KDQGXVLQJDVROXWLRQRIFXSEOHDFKDQG
on inside surfaces 3 cups warm water.
WARNING
Before cleaning interior wait at least 20 minutes after a cycle for the
heating element to cool down. Failure to do so can result in burns.
An overall yellow or brown film can  $VSHFLDOILOWHULQWKHZDWHUVXSSO\OLQHLVWKHRQO\ZD\WRFRUUHFW
be caused by iron deposits in water this problem. Contact a water softener company.
White film on inside Hard water minerals  7RFOHDQWKHLQWHULRUDSSO\GLVKZDVKHUGHWHUJHQWWRDGDPSVSRQJH
surfaces Wear rubber gloves. Do not use any type of cleanser other than
dishwasher detergent because it may cause foaming or sudsing. Cascade®
Automatic Dishwashing Detergent has been approved
for use in all GE dishwashers.
Dishes don’t dry Low inlet water temperatureMake sure inlet water temperature is correct (see page 6).
Rinse agent dispenser is emptyCheck the rinse agent dispenser.
Before you call for service…

15
What GE Will Not Cover:
GE Dishwasher Warranty.
For The Period Of: GE Will Replace:
One Year Any part of the dishwasher which fails due to a defect in materials or workmanship. During this
From the date of the limited one-year warranty, GE will also provide, free of charge, all labor and in-home service to
original purchase replace the defective part.
Service trips to your home to teach you how to use
the product.
Improper installation, delivery or maintenance.
Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
Replacement of house fuses or resetting of circuit
breakers.
Damage to the product caused by accident, fire, floods
or acts of God.
Incidental or consequential damage caused by possible
defects with this appliance.
Cleaning or servicing of the air gap device in the
drain line.
Damage caused after delivery.
Product not accessible to provide required service.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is
not available, you may be responsible for a trip charge or you may be required to bring the product to an
Authorized GE Service location for service. In Alaska, the warranty excludes the cost of shipping or service calls
to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
on-line, visit us at GEAppliances.com, or call 800.GE.CARES
(800.432.2737) in the United Sates. In Canada, call 1.800.561.3344.
Please have serial number and model number available when
calling for service.
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQ
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
What Is Not Covered (for customers in Canada):
Service trips to your home to teach you how to use
the product.
Improper installation.
If you have an installation problem, contact your dealer or installer.
You are responsible for providing adequate electrical, exhausting
and other connecting failures.
Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
Replacement of house fuses or resetting of circuit breakers.
Damage to the product caused by accident, fire, floods
or acts of God.
Damage caused after delivery.
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV
Limited Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a
particular purpose, are limited to one year or the shortest period allowed by law.
This warranty is extended to the original purchaser and any succeeding owner for products purchased in Canada for home use within
Canada. In home warranty service will be provided in areas where it is available and deemed reasonable by MC Commercial to provide.
WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
Warrantor: MC Commercial

16
Consumer Support.
Purchase a GEextended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires. In Canada, please visit our Website
or contact your local extended warranty provider.
Parts and Accessories In the U.S. : GEAppliances.com
,QGLYLGXDOVTXDOLILHGWRVHUYLFHWKHLURZQDSSOLDQFHVFDQKDYHSDUWVRUDFFHVVRULHVVHQWGLUHFWO\WRWKHLUKRPHV9,6$
MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally
should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause
unsafe operation.
Customers in Canada should consult the yellow pages for the nearest Mabe service center, or call 1.800.661.1616.
Contact Us In the U.S. : GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
In Canada: www.GEAppliances.ca, or write to: Director, Consumer Relations, MC Commercial
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
GE Appliances Website In the U.S. : GEAppliances.com
+DYHDTXHVWLRQRUQHHGDVVLVWDQFHZLWK\RXUDSSOLDQFH"7U\WKH*($SSOLDQFHV:HEVLWHKRXUVDGD\DQ\
day of the year! For greater convenience and faster service, you can now download Owner’s Manuals, order
parts or even schedule service on-line. In Canada: www.GEAppliances.ca
Schedule Service In the U.S. : GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business
hours.
In Canada, call 1.800.561.3344
Real Life Design Studio In the U.S. : GEAppliances.com
*(VXSSRUWVWKH8QLYHUVDO'HVLJQFRQFHSW³SURGXFWVVHUYLFHVDQGHQYLURQPHQWVWKDWFDQEHXVHGE\
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen design
ideas for people with disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.
GEAC (800.833.4322).
In Canada, contact: Director, Customer Relations, MC Commercial
Bureau 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Extended Warranties In the U.S. : GEAppliances.com
Register Your Appliance In the U.S. : GEAppliances.com
5HJLVWHU\RXUQHZDSSOLDQFHRQOLQH³DW\RXUFRQYHQLHQFH7LPHO\SURGXFWUHJLVWUDWLRQZLOODOORZIRUHQKDQFHG
communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.
In Canada: www.GEAppliances.ca
Printed in China

www.electromenagersge.ca
Cuve en acier
inoxydable avec
contrôles à l’avant
Manuel
d‘utilisation
Lave-vaisselle
Inscrivez ci-dessous les numérosde
modèle et de série :
N° de modèle _______________
N° de série _________________
Ils se trouvent sur une étiquette apposée sur
la paroi de la cuve, à l‘intérieur de la porte.
Consignes de sécurité .....2-3
Directives de fonctionnement
Tableau de commande et réglage des
commandes ...................4-5
Utilisation du lave-vaisselle.....6-7
Chargement des paniers
du lave-vaisselle . . ...............8
Directives d’entretien
Entretien et nettoyage.........9-10
Dépannage............... 11–13
Service à la clientèle
Garantie ........................15
Service à la clientèle.............16
29-5928 12/13 MC

2
CONSIGNES DE SÉCURITÉ IMPORTANTE
VEUILLEZ LIRE TOUTES LES CONSIGNES AVANT D‘UTILISER
L‘APPAREIL – CONSERVEZ CES DIRECTIVES
AVERTISSEMENT!
Pour votre sécurité, veuillez suivre les directives données dans le présent manuel afin de
réduire au minimum les risques d‘incendie, d‘explosion et de chocs électriques et prévenir
tout dommage et blessure grave ou mortelle.
SÉCURITÉ DU CHAUFFE-EAU
INSTALLATION ET ENTRETIEN APPROPRIÉS
Ce lave-vaisselle doit être correctement installé, en conformité avec les directives d‘installation
fournies, avant d‘être utilisé. Si vous n‘avez pas reçu les directives d‘installation avec
votre appareil, vous pouvez vous les procurer en visitant notre site Web à l‘adresse www.
electromenagersge.ca.
Les articles lavés au mode antibactérien, le
cas échéant, peuvent être chauds au toucher.
Manipulez-les avec prudence.
L‘utilisation d‘un détergent
non conçu pour les lave-
vaisselle peut provoquer la
formation de mousse.
Si votre lave-vaisselle
est branché sur un circuit relié à un
interrupteur mural, assurez-vous
d‘actionner celui-ci avant d‘utiliser
votre appareil.
Sur les lave-vaisselle dotés de
commandes électroniques, si vous
fermez l‘interrupteur mural entre les
cycles de lavage, attendez de 5 à 10 secondes
après avoir ramené l‘interrupteur à ON (Marche)
avant d‘appuyer sur la touche ON/OFF (Marche/
réinitialisation) pour permettre aux commandes
de se réinitialiser.
Articles autres que la vaisselle : ne lavez pas
dans le lave-vaisselle des articles comme des
filtres de purificateur d‘air, des filtres de systèmes
de chauffage ou des pinceaux. Vous pourriez
endommager le lave-vaisselle et provoquer une
décoloration ou des taches dans l‘appareil.
Une surveillance attentive est nécessaire lorsque
cet appareil est utilisé par ou près des enfants.
Placez les articles légers en plastique de
manière qu‘ils ne se déplacent pas ou
QHWRPEHQWSDVDXIRQGGHO¶DSSDUHLO³LOV
pourraient entrer en contact avec l‘élément
chauffant, ce qui pourrait les endommager.
Cet appareil doit être relié à un système de
câblage électrique permanent en métal, mis
à la terre. Sinon, un fil de mise à la terre pour
appareillage doit être installé et raccordé à la
borne ou au fil de mise à la terre de l‘appareil..
Un raccordement incorrect du fil de mise à la
terre peut présenter un risque d‘électrocution.
Consultez un électricien ou un technicien qualifié
si vous n‘êtes pas certain que l‘appareil est
correctement mis à la terre.
Veuillez vous débarrasser de la façon appropriée
de vos vieux électroménagers et des matériaux
d‘emballage ou d‘expédition.
Ne tentez pas de réparer ou de remplacer une
pièce quelconque de votre lave-vaisselle, à moins
que cela ne soit spécifiquement recommandé
dans le présent manuel. Confiez toutes les autres
réparations à un technicien qualifié..
Pour réduire au minimum les risques
d‘électrocution, débranchez l‘appareil de sa
source d‘alimentation avant d‘en effectuer
l‘entretien.
Remarque : Le fait d‘arrêter le lave-vaisselle ne
coupe l‘alimentation électrique de l‘appareil. Nous
vous recommandons de confier la réparation de
votre électroménager à un technicien qualifié.
AVERTISSEMENT!
ATTENTION: Pour éviter les blessures mineures ou les dommages matériels
Dans certaines conditions, il peut se former de l‘hydrogène dans un chauffe-eau qui n‘a pas été
utilisé pendant deux semaines ou plus. L‘HYDROGÈNE EST UN GAZ EXPLOSIF.
Si vous n‘avez pas utilisé votre chauffe-eau pendant deux semaines ou plus, ouvrez tous les
robinets d‘eau chaude et laissez couler l‘eau pendant plusieurs minutes afin de réduire les risques
de dommages matériels ou de blessures. Prenez cette précaution avant même d‘utiliser un
électroménager raccordé au chauffe-eau pour éliminer l‘hydrogène qui pourrait s‘y être accumulé.
Puisqu‘il s‘agit d‘un gaz inflammable, ne fumez pas ou n‘utilisez pas une flamme nue ou un
électroménager au cours de ce processus.

3
ÉLIMINATION APPROPRIÉE DU LAVE-VAISSELLE
Les lave-vaisselle jetés ou abandonnés sont
dangereux…même si vous ne les laissez là «que
pour quelques jours». Si vous voulez jeter votre
vieux lave-vaisselle, veuillez suivre les directives
ci-dessous pour éviter les accidents.
Avant de jeter votre vieux lave-vaisselle
Enlevez la porte de l‘appareil ou enlevez
la gâche de la porte (comme indiqué dans
l‘illustration).
AVERTISSEMENT! RISQUE DE SUFFOCATION POUR
UN ENFANTÉCOINC À L‘INT RIEUR DE L‘APPAREIL
CONSERVEZ CES DIRECTIVES
Gâche de la
porte
Retenez l’écrou à la partie
supérieure du lave-vaisselle
pendant que vous enlevez la vis
N‘utilisez cet appareil que pour l‘usage pour lequel
il a été conçu, comme expliqué dans le présent
manuel.
N‘utilisez que des détergents en poudre, en
liquide ou en tablettes, ou des produits de
rinçage recommandés pour les lave-vaisselle et
gardez-les hors de portée des enfants. L‘utilisation
des détergents pour lave-vaisselle automatiques
Cascade®, Cascade® Complete, et les produits de
rinçage Cascade Crystal Clear® est approuvée
dans tous les lave-vaisselle GE.
Placez les articles coupants de manière à ce qu‘ils
n‘endommagent pas le joint d‘étanchéité de la
porte.
Placez dans le panier à couverts les couteaux
tranchants le manche vers le haut afin de réduire
les risques de coupures.
Ne lavez-pas les articles en plastique, à moins
qu‘ils portent la mention «Lavable au lave-
vaisselle» ou l‘équivalent. Dans le cas des articles
en plastique qui ne portent pas cette mention,
reportez-vous aux recommandations du fabricant.
Ne touchez pas à l‘élément chauffant pendant
ou immédiatement après le fonctionnement de
l‘appareil.
Ne faite pas fonctionner le lave-vaisselle si tous
les panneaux de la carrosserie n‘ont pas été
correctement réinstallés.
Ne modifiez pas le fonctionnement des
commandes.
N‘utilisez pas le lave-vaisselle de façon abusive,
et ne vous assoyez pas ou ne montez pas sur la
porte ou les paniers de l‘appareil.
Ne laissez pas les enfants jouer à proximité du
lave-vaisselle lorsque vous ouvrez ou fermez
la porte afin d‘éviter que leurs petits doigts se
coincent dans la porte.
Ne jetez pas un lave-vaisselle sans d‘abord enlever
la porte ou la gâche de la porte de l‘appareil.
N‘entreposez pas ou n‘utilisez pas de produits
combustibles, d‘essence ou autres vapeurs ou
liquides inflammables à proximité de votre lave-
vaisselle ou de tout autre électroménager.
Ne laissez pas les enfants jouer avec le lave-
vaisselle, ou à l‘intérieur de celui-ci ou de tout autre
électroménager mis aux rebuts.
AVERTISSEMENT! Lors du fonctionnement de votre lave-vaisselle, prenez
les précautions de base, notamment les suivantes:
VEUILLEZ LIRE ET SUIVRE À LA LETTRE CES CONSIGNES DE
SÉCURITÉ.
www.electromenagersge.ca

4
Tableau de commande du lave-vaisselle.
Réglage des commandes
1Pouvoir
Appuyez sur le bouton POWER pour mettre l’appareil en MARCHE afin qu’il commence à fonctionner Le voyant POWER
s’allume lorsque le lave-vaisselle est en MARCHE.
2Programmes de lavage
Lorsque le lave-vaisselle est activé, vous pouvez appuyer sur le bouton PROGRAMS afin de choisir le cycle de lavage
désiré. Un voyant lumineux s’allumera sur le panneau de contrôle pour indiquer le cycle choisi.
REMARQUE : Les renseignements concernant la durée des programmes et leur consommation d’eau, fournis dans
la présente section, sont approximatifs. Les résultats réels dépendent de plusieurs facteurs, y compris mais non de
façon limitative la température et la pression de l’eau qui alimente le lave-vaisselle ainsi que le niveau de saleté.
Eau: 25 litres, Durée approx.: 130 minutes
HEAVY WASH Ce programme est conçu pour la vaisselle ou les ustensiles de cuisson très sales, sur lesquels des aliments
sont séchés ou cuits. Il est possible que ce programme ne puisse pas déloger les aliments brûlés. Vous
pouvez laver en toute sécurité la vaisselle de tous les jours à ce programme.
NORMAL Eau: 1 . litres, Durée approx.: 130 minutes
(NORMAL WASH) Ce programme est conçu pour laver la vaisselle de tous les jours, les verres et les ustensiles de cuisson
moyennement sales qui n’ont pas été rincés au préalable.
Eau: 14.3 litres, Durée approx.: 95 minutes
(LIGHT WASH) Ce programme est conçu pour la vaisselle de tous les jours, les verres et les ustensiles de cuisson
moyennement sales qui n’ont pas été rincés au préalable. La durée de lavage de ce programme est plus
courte pour un programme de lavage plus rapide. Ce programme comprend un séchage avec chaleur
d’une durée réduite.
RINÇAGE SEULEMENT Eau: . litres, Durée approx.: minutes
(RINSE ONLY) Pour rincer les charges partielles que vous désirez laver plus tard. N’utilisez pas de détergent avec ce
programme. Ce programme ne comprend pas de séchage avec chaleur.
2573
1423 5
Heated Dry Programs Power
Start
Cancel
Child Lock
LAVAGE INTENSE
43
LAVAGE L GER
É
