DNCD450EA/GA – GE Super 7.0 Cu. Ft. Capacity Commercial Dryer
Specification Revised 2/03
GE Appliances
Dryer Dimensions (in inches)
Exhaust Options:
Electric: 4-way via rear, right, left and bottom. Maximum recommended exhaust
duct length is 45 feet of 4" rigid ducting with two 90° elbows and a 4" dampered
wall cap.
Gas: When viewed from the front of the unit, exhaust 3-way via rear, left and
bottom. Maximum recommended exhaust duct length is 15 feet of 4" rigid
ducting with two 90° elbows and a 4" dampered wall cap.
Circuit Requirements:
An individual, properly-grounded branch circuit, protected by a 30-amp circuit
breaker or a time-delay fuse, is required.
Electric Dryer Rating:
208/240V, 5600W, 24A, 60Hz
208V, 4400W, 22A, 60Hz
Note: Dryer wall outlet must be located within 36" of service cord entry and
accessible when dryer is mounted in position.
Installation Information: For complete information, see installation instructions
packed with your dryer.
36 42
27
23-1/2
2-1/2
25-1/2*
Side View Rear View
8-1/2
28-1/4
23-1/2
11-1/2
*24-1/2" from the edge of the side panel to the front.
25-1/2" from front to edge of endcaps.
For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories

GE Appliances
DNCD450EA/GA – GE Super 7.0 Cu. Ft. Capacity Commercial Dryer
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust duct. If “all rigid metal”
duct cannot be used, then “flexible all metal” venting can be used, but it will reduce the maximum recommended
duct length.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or bottom of dryer,
add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is shown in the table.
The maximum length for flexible ducts are less than for rigid duct.
2. A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated as a 90° elbow.
A turn over 45° should be treated as a 90° elbow.
Exhausting the dryer to the outside is strongly recommended to prevent large amounts of moisture and lint
from being blown into the room. Gas dryers or any dryer located in a closet must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed house floor (crawl
space), or into an attic, since the accumulated lint could create a fire hazard or moisture could cause damage.
Never terminate the exhaust into a common duct or plenum with a kitchen exhaust, since the combination of lint
and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting, etc. The wall cap
must also be located at least 12" above the ground or any other obstruction with the opening pointed Down.
Other terminations, such as louvered wall boxes, are acceptable provided they are equivalent to a 4" opening
dampered wall cap.
For more information on venting kits and accessories, please call 1-800-GE CARES.
Specification Revised 2/03
For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Dryer Exhausting Information – Use Metal Duct Only
Vertical and Horizontal Ducting
0150 ft. 127 ft. 75 ft. 52 ft.
1140 ft. 117 ft. 65 ft. 42 ft.
2130 ft. 107 ft. 55 ft. 32 ft.
7.3 Capacity Electric 3 120 ft. 97 ft. 45 ft. 22 ft.
and Gas Dryers 4 110 ft. 87 ft. 35 ft. 12 ft.
090 ft. 60 ft. 55 ft. 45 ft.
160 ft. 45 ft. 40 ft. 30 ft.
7.0 and 6.0 2 45 ft. 35 ft. 30 ft. 20 ft.
Capacity Models 3 35 ft. 25 ft. 20 ft. 15 ft.
all Electric Dryers 4 25 ft. 15 ft. 15 ft. 10 ft.
090 ft. 60 ft. 55 ft. 45 ft.
7.0 and 6.0 1 60 ft. 45 ft. 40 ft. 30 ft.
Capacity Models 2 45 ft. 35 ft. 30 ft. 20 ft.
all Gas Dryers 3 35 ft. 25 ft. 20 ft. 15 ft.
060 ft. 48 ft. 30 ft. 18 ft.
152 ft. 40 ft. 22 ft. 14 ft.
244 ft. 32 ft. 14 ft. 10 ft.
5.7 Capacity Electric 3 32 ft. 24 ft. — —
and Gas Dryers 4 28 ft. 16 ft. — —
Number
of
90°
Turns
Maximum Length of 4"
Dia. Rigid Metal Duct
Maximum Length of 4"
Dia. Flexible Metal Duct
Exhaust Hood Type Exhaust Hood Type
Domestic
Dryer Models
A
4" Opening
B
2-1/2"
Opening
A
4" Opening
B
2-1/2"
Opening
A
4
Best Performance
B
2-1/2
A
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side
3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in. of
open area equally distributed. If this closet contains both a washer and a dryer, doors must contain
a minimum of 120 sq. in. of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides
3" rear

Specification Revised 2/03
GE Appliances
DNCD450EA/GA – GE Super 7.0 Cu. Ft. Capacity Commercial Dryer
Commercial
Dryer
HIGH
MED
LOW
EXTRA
LOW
E
ST.
T
IME
R
EMAINING
HEAT
SETTINGS
AUTOMATICSETTINGS
CLOTHESCARESELECTION
DOOROPENDRYINGCOOLDOWN
STATUS
CLEANLINTFILTER
COTTONS: HIGHHEAT
MIXEDLOADS:HIGHHEAT
PERMPRESS:MEDHEAT
KNITS:LOWHEAT
DELICATES:EXTRALOWHEAT
AIRDRY:NOHEAT
KNITS
COTTONS
DELICATES
MIXED
LOADS
AIRDRY
PERM
PRESS
START
PAUSE
STOP
CANCEL
Features and Benefits
• Super 7.0 Cu. Ft. Capacity
• 5 Dry Cycles: Cottons (High Heat); Mixed Loads (High Heat); Permanent Press
(Medium Heat); Knits (Low Heat); Delicates (Extra Low Heat)
• 4 Temperatures
• Air Dry
• Digital Cycle Countdown
• Hush Quiet Package
• Lockable Lint Filter
• Reversible Door Swing
• DuraDrum™Interior
• Model DNCD450EAWC – White
• Model DNCD450GAWC – White
