GE Monogram ZGG540NBPSS Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
170134
Specification Created 10/08
ZGG540NBPSS - Natural Gas Built-in Outdoor Grill
ZGG540LBPSS - LP Gas Built-in Outdoor Grill
Dimensions and Installation Information (in inches)
Outdoor Built-in Cooktop
These grills are designed to be installed into a non-
combustible enclousure.
• The grill drops into the opening and hangs from
the side flanges. It does not require support from
the bottom.
• The cutout must be completely covered with
non-combustible material such as stone, brick,
ceramic tile, concrete board, etc. The countertop
surface and edges must be flat and level.
• If the countertop has an overhang, it must be
notched or cut back flush with the front face of
the cabinet below. See notched detail below.
• Allow at least 12" minimum clearance at the
back of the grill when the exhaust is directed to a
window or surface that is difficult to clean. Allow
at least 4" clearance behind the grill to allow the
hood lid to open.
• Allow 12" minimum clearance on both sides
and the back of the grill to adjacent vertical
combustible construction.
• These gas grills cannot be used below any type of
overhead construction.
• These grills are designed for outdoor use only. Do
not locate the cooktop in a building, garage or
other enclosed or semi-enclosed area.
• Locate the backside of the grill away from
prevailing winds and avoid cooking in windy
conditions.
53-7/8"
27"
12" Min. to Combustibles
4" Min. Clearance for Lid
to Non-Combustibles
26"
*The weight of the grill is fully supported by
the side trims. The back of the grill overlaps
the back edge of the cutout.
10-1/4" from
Bottom of
Support Flange
*25-1/2"
Countertop Depth
27" to Front
of Control Panel
28-1/2" to Front of Bullnose
52-3/4"
36"
Min. 1-1/8" Min.
10-7/8"
24-1/2"
Grill Cutout
Gas and
Electrical
Locations
Opening
for Optional
Access Doors

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
170134
Specification Created 10/08
ZGG540NBPSS - Natural Gas Built-in Outdoor Grill
ZGG540LBPSS - LP Gas Built-in Outdoor Grill
Features and Benefits
• Heavy-duty, 304 stainless steel construction with
professional styling complements Monogram ranges
and other cooking products, allowing a seamless
transition between indoor and outdoor spaces. A
double-wall design insulates the canopy to minimize
heat loss and allow for cooler surfaces
• 25,000-BTU, stainless steel burners offer precise
control across a wide spectrum of temperature
settings while Gourmet Randiant™trays ensure even
heat distribution and reduce flare-ups
• Ceramic-infrared rotisserie burner allows you to
slow-roast lamb, pork and other meats to succulent
perfection. The rotisserie motor assembly plugs in
and detaches easily for convenient cooking and
storage. Stainless steel spit rod and forks included
• 23,000-BTU ceramic infrared searing burner delivers
the high radiant heat needed to sear the outside
of foods, locking in natural juices and flavors.
Adjustable output allows you to cook everything
from thick fillets of steak to delicate fish and
vegetables
• Integrated illumination sets the stage for nighttime
grilling with red LED lights above the knob controls,
along with interior halogen lighting
• Stainless steel, drop-in smoker box infuses foods
with flavorful aromas, such as mesquite or hickory
• Model ZGG540BNPSS - Naural gas
• Model ZGG540BLPSS - Liquid propane
Monogram grills are factory-set for Natural or LP gas
operation. Be sure to order the correct model for the
installation situation.
Conversion kits (WB28X10116 - LP to Natural gas and
WB28X10117 - Natural gas to LP) are available if the
wrong fuel type is ordered.
High altitude kit (WB28X10119) is also available for
operation above 2,000 feet. Order WB28X10118
to change the connection from LP portable (20 lb.
tank) to whole house stationary tank or to change a
stationary tank to portable.
Conversion kits must be installed by a qualified
service technician at additional cost. Order these kits
from your Monogram supplier.
