GE Spacemaker GTUP270EMWW How to use

GE Appliances
General Electric Company
Louisville, Kentucky 40225
31-9208
GTUP270EMWW
GTUP270GMWW
GTUP240EMWW
GTUP240GMWW
Technical Service Guide
March 2011
GE Appliances
24- and 27-in. Unitized
Laundr y Cent er s
EASY CARE
COTTONS
COTTONS
DELICATES
PERMANENT PRESSS
DELICATES
S
WASHER | DRYER TIMED DRY
DRYER
TEMPERATURES LOAD SIZE
WASHER
TART

– 2 –
GE App l i an ces
Tec h n i c a l Ser vi ce Gu i d e
Co p y r i g h t © 2 0 1 1
All rights reserved. This service guide may not be reproduced in whole or in part in
any form without written permission from the Gen er al Electric Com pa ny.
IMPORTANT SAFETYNOTICE
The information in this service guide is intended for use by individuals possessing
adequate backgrounds of electrical, electronic, and mechanical experience. Any
attempt to repair a major ap pli ance may result in personal injury and property
damage. The man u fac tur er or seller cannot be responsible for the in ter pre ta tion
of this in for ma tion, nor can it assume any liability in connection with its use.
WARNING
If the information in this manual is not followed exactly, fi re or ex plo sion may result
causing property damage, personal injury or death. If you smell gas:
– Do not try to light any appliance.
– Do not touch any electrical switch; do not use any phone in the building.
– Immediately call the gas supplier from a neighbor’s phone. Follow the
gas supplier’s instructions.
– If you cannot reach the gas supplier, call the fi re department.
WARNING
To avoid personal injury, disconnect power before ser vic ing this prod uct. If electrical
power is required for di ag no sis or test pur pos es, disconnect the power immediately
after per form ing the nec es sary checks.
RECONNECT ALL GROUNDI N G DEVI CES
If grounding wires, screws, straps, clips, nuts, or washers used to complete a path
to ground are removed for service, they must be returned to their original position
and properly fastened.

– 3 –
Table of Contents
Agitator .............................................................................................................................................................................41
Air Duct Assembly .......................................................................................................................................................27
Airfl ow ...............................................................................................................................................................................15
Automatic Temperature Control (ATC) ................................................................................................................54
Blower Wheel .................................................................................................................................................................32
Burner Assembly and LP Conversion .................................................................................................................35
Component Locator Views ......................................................................................................................................16
Control Features ............................................................................................................................................................ 7
Control Panel..................................................................................................................................................................22
Cover Assembly ............................................................................................................................................................42
Diagnostics and Service Information .................................................................................................................58
Door Switch ....................................................................................................................................................................27
Drain Pump ....................................................................................................................................................................42
Drive Belt ..........................................................................................................................................................................28
Drum ..................................................................................................................................................................................29
Drum Shaft and Bearing ...........................................................................................................................................29
Drum Slide Assembly .................................................................................................................................................26
Dryer Components......................................................................................................................................................21
Dryer Front Panel .........................................................................................................................................................25
Dryer Operation Overview ......................................................................................................................................14
Dryer Timer and Start Switch .................................................................................................................................24
Dryer Timer Chart ........................................................................................................................................................58
Flame Detector .............................................................................................................................................................37
Front Panel ......................................................................................................................................................................41
Fuses ..................................................................................................................................................................................22
Gas Valve .........................................................................................................................................................................36
Gas Valve Coils ..............................................................................................................................................................35
Heater Assembly ..........................................................................................................................................................32
High Limit Thermostat ...............................................................................................................................................34
Idler Assembly ...............................................................................................................................................................30
Ignitor ................................................................................................................................................................................37
Ignitor Circuit Operation ...........................................................................................................................................38
Inlet Control Thermostat ..........................................................................................................................................33

– 4 –
Introduction ...................................................................................................................................................................... 5
Leveling Legs .................................................................................................................................................................21
Lid Lock .............................................................................................................................................................................47
Lid Switch ........................................................................................................................................................................46
Motor and Blower Assembly ..................................................................................................................................30
Nomenclature ................................................................................................................................................................. 6
Outer Tub .........................................................................................................................................................................51
Outlet Control Thermostat .......................................................................................................................................34
Overfl ow Pipe ...............................................................................................................................................................43
Pressure Dome Cleanout Port ..............................................................................................................................43
Safety Thermostat ......................................................................................................................................................33
Service Panel..................................................................................................................................................................21
Shipping Rod ..................................................................................................................................................................21
Spin Basket .....................................................................................................................................................................49
Suspension Rods .........................................................................................................................................................44
Timer Voltage-Dropping Resistor .........................................................................................................................25
Transmission Assembly ...........................................................................................................................................53
Troubleshooting ...........................................................................................................................................................56
Tub Cover .......................................................................................................................................................................44
Warranty .........................................................................................................................................................................69
Washer Buttons and LED Assembly ...................................................................................................................23
Washer Components .................................................................................................................................................41
Washer Control Board Connector Locator View ...........................................................................................20
Washer Motor ................................................................................................................................................................45
Washer Motor and Drive System Overview ....................................................................................................39
Washer Selector Controls ........................................................................................................................................23
Washer Service Mode ................................................................................................................................................59
Water Pressure Sensor ..............................................................................................................................................49
Water Valve ....................................................................................................................................................................53
Wiring Diagrams ..........................................................................................................................................................66

– 5 –
Introduction
The new GE 24-in. and 27-in. Unitized Laundry Centers have the following features:
PerfecTemp - senses the incoming water temperature and adjusts the fi ll water to obtain a more precise
temperature range for all wash temperatures.
Auto Load Sensing - automatically provides the correct amount of water suited to the size and type of load
placed in the unit.
Quick Release Lid Lock - prevents opening the lid during the spin cycle and while the basket is spinning.
Washer Electronic Control with LED status lights - the stage the washer is operating in is indicated by the
status lights. When the selector knob is set to a new cycle, the status lights will fl ash momentarily, showing
the stages the cycle will go through.
Built-in Service Test Mode - Specifi c washer components can be operated. Error codes are recorded and
accessible using the control panel LED status lights.
4 Drying Cycles - Timed, Auto Cottons, Easy Care, Delicate
Large 5.9-cu.ft. steel dryer drum on 27-in. models, and 4.4-cu.ft. steel drum on 24-in. models.
UV Stabilizers - The control panel has UV stabilizers to prevent yellowing when exposed to sunlight.
27-in. Model24-in. Model

– 6 –
Nomenclature
The nomenclature tag is lo cat ed
inside the dryer on the front panel.
Not e: The technical sheet is taped on
the inside of the control panel.
Product
U = Unitized Washer/Dryer
G T U P 2 7 0 E M W W
Brand
G = General Electric
Co n figuration
T = Top Load
Key Feature
P = Permatuf Tub
Col o r
WW = White
Model Year Designator
M = 2011
Fu el
E = Electric
G = Gas
Se r i e s
Nomenclature
Technical Sheet
Serial Number
The fi rst two characters of the serial number
identify the month and year of manufacture.
Ex a m p l e: FV123456S= March, 2011
F - MAR
G - APR
H - MAY
L - JUN
M - JUL
R - AUG
S - SEP
T - OCT
V - NOV
Z - DEC
A - JAN
B - FEB
2011 - V
2010 - T
2009 - S
2008 - R
2007 - M
2006 - L
2005 - H
2004 - G
2003 - F
2002 - D
2001 - A
2000 - Z
The letter des ig nat ing
the year re peats every
12 years.
Ex a m p l e:
V - 20 11
V-1999
V-1987

– 7 –
Control Features
(Co n t i n u ed n ex t p a g e)
About t he Washer cont r ol panel.
Quick St ar t Gui de



St ep 1

St ep 2

otherwashoptions

St ep 3

START
St ep 4
Lid Lock
Yo u r w a s h e r h a s a s e c u r i t y s y s t e m t h a t p r e v e n t s o p e n i n g t h e l i d d u r i n g t h e s p i n c y c l e . Th e l i d l o c k p r e -
vents anyone (especially children) from reaching into the washer while the basket is spinning. The lock will
be released approximately 2 minutes after the basket stops spinning.
NOTE: If there is a power outage the lid lock can take 3 minutes to release.
AB
C
A
Co n t r o l s
Wash Cycle Selector
Th e w a s h c y c l e c o n t r o l s t h e l e n g t h a n d i n t e n s i t y o f t h e w a s h i n g p r o c e s s . T h e k n o b c a n b e t u r n e d i n e i t h e r d i r e c t i o n . Tu r n i n g t he
Cy c l e Sel e c t o r k n o b a f t er st a r t i n g a c y c l e w i l l st o p t h e w a s h er a n d r eset t h e c y c l e t o t h e n e w se l ec t i o n . Pr e ss START t o begin the
new cycle selection.
Th e c h a r t b e l ow w i l l h el p y o u m a t c h t h e w a sh c y c l e se t t i n g w i t h y o u r c l o t h i n g . Th e c h a r t i s r a n k ed f r o m l o n g e st t o sh o r t es t
cycle time and wash intensity. (Cycles vary by model.)
COTTON S - For heavy tolightly soiled cottons,household linens,work and play clothes.
PERMANENT PRESS - For wrinkle-free and permanent press items, and knits.
DELICATES - For lingerie and special-care fabrics with light to normal soil.
SPI N ON LY - For draining the tub and spinning water out of clothes.
QUI CK RINSE - Rinses and spins non-soiled items where a rinse only is desired.
OFF - Washer isturned off and the START button does not function.
NOTE: When the control is turned to OFF, the STATUS lights are off.
NOTE: The cycle selector does not rotate during the operation of the washer.
D
BFABRIC SOFTENER
Set t h i s o p t i o n w h e n a d d i n g f a b r i c so f t en e r t o t h e w a sh er .
E
F
Liquid
Bleach
Det er gent
Fa br i c
So f t en e r

– 8 –
DTemp er a t ur e
Se l e c t t h e w a t e r t e m p e r a t u r e f o r t h e w a s h a n d r i n s e c y c l e s . A l w a y s f o l l o w f a b r i c m a n u f a c t u r e r ’ s c a r e l a b e l o r i n s t r u c t i o n s
when laundering.
Per f ec Tem p senses the incoming wat er t emperature and adjusts the fill wat er t o obtain a more precise temperature range
for all wash temperatures. For example, in a COLD wash selection,some warm water may be added to reach a temperature
needed to better dissolve detergents. Often, detergents are not completely dissolved in very cold water, especially in cooler
climates.
Dur ing w int er m ont hs, w hen t he w at er ent ering y our hom e is colder , or for locat ions wit h ver y col d w at er y ear r oun d, use t he
Per f ec Tem p plus COLD to help dissolve powdered detergents and to improve the cleaning of your clothes.
Th e TAP COLD feature turns the Per f ec Tem p feature on your washer off, and uses your household tap water temperature for a
COLD w a sh . Th i s c a n p r o vi d e en e r g y sa v i n g s b y r ed u c i n g t h e a m o u n t o f h o t w a t e r u se d i n y o u r w a sh .
ELoad Size
L o o s e l y l o a d c l o t h e s n o h i g h e r t h a n t h e t o p r o w o f h o l e s i n t h e w a s h e r b a s k e t .
Pr eci seFi l l - This selection automatically provides the correct amount of water suited to the size and type of load placed in the
unit.
FSTART
Pr ess START to begin the cycle. With the lid closed pressing START again will PAUSEthe cycle and STATUS lights will blink. To
continue the cycle, close the lid and press START again. The water fill will continue with the lid opened, except when Pr eci seFi l l
is selected as the load size. (The lid must be closed to continue filling when Pr eci seFi l l is selected.
If the lid is opened during the cycle, the cycle will PAUSE and the STATUS lights will blink. To resume the cycle, close the lid and
press START.
If the machine is paused for more than 24 hours, the cycle will be cancelled. To stop the cycle, turn the Cycle Selector to the
OFF position.
CSTATUS l i g h t s
Th e STATUS lights show the stage the washer is in. When the selector knob is set to a new cycle, the STATUS lights will flash
momentarily, showing the stages the cycle will go through.
STATUS l i g h t I l l u m i n a t es
ON Wh en t he f ab ric sof t en er opt i on has been select ed.
WASH When t he washer is in t he w ash por t ion of t he cy cle.
RI NSE Wh e n t h e w a sh e r i s i n t h e r i n s e p o r t i o n o f t h e c y c l e.
SPI N Wh e n t h e w a sh e r d r a i n i n g a n d / o r sp i n n i n g .
LID LOCKED When the washer lid is locked. This feature prevents the lid from being opened while the
washer is in the spin cycle or coasting to a stop.
NOTE: If the STATUS lights are blinking, the operation of the washer has been paused. To resume operation
press the START button (the lid must be closed).

– 9 –
About t he Washer feat ur es.
The Fa br i c Sof t ener Di spen ser
The f ab r i c sof t ener d i spen ser automatically
releases liquid fabric softener at the proper time
during the cycle.
Do not st op t he washer during t he first spin.
Thi s w i l l ca u se t h e di sp en ser t o emp t y
too soon.
To u se, f o l l ow t h ese st e p s:
1Make sure dispenser is securely attached to
agitator.
2Use only diluted liquid fabric softener.
Po u r i n t o d i sp e n se r , u s i n g a m o u n t
recommended on package.
Never pour fabric soft ener directly on clothes. It
may stain them.
NOTE: Do not pour bleach into FABRI C SOFTEN ER
dispenser.
3Add water to dispenser until it reaches the
maximum fill line.
4Select FABRI C SOFTENER button on control
panel for proper dispersion of the fabric
softener.
Do not pou r any t h ing int o t he
agitator if the dispenser is removed.
Separate for cleaning
Cl ea n i n g t h e Fa b r i c So f t en er Di sp en ser
1Remove the dispenser from the top of the agitator.
2Separate the dispenser cup from the cover by grasping the top and pushing down on the inside of
the cup with your fingers. Dispenser cup will pop free from the cover.
3To clean the dispenser, soak both the dispenser cup and the dispenser cover in the following
solution:
1 USgallon (3.8 liters) warm water
1/4 cup (60 ml) heavy-duty liquid detergent
1 cup (240 ml)bleach
4If necessary, loosen buildup with a clean, soft cloth after soaking. Do not use a stiff brush; you may
roughen the surface of the dispenser.
5Rinse and reassemble dispenser. Place dispenser back on the agitator.
Liquid Bleach Funnel
Th e w a t e r f i l l d i l u t es l i q u i d c h l o r i n e b l ea c h a s t h e w a sh er f i l l s f o r t h e w a sh c y c l e.
1Check clothing care labels for special instructions.
2Measure liquid bleach carefully, following instructions on the bottle.
Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.
Do not pour powdered bleach into bleach funnel.
3Before starting the washer, pour measured amount of bleach directly into bleach funnel. Avoid
splashing or over-filling dispenser. If you prefer t o use powdered bleach, add it into the wash basket
with your detergent.
Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover. Mixing
can produce a toxic gas which may cause death.
NOTE: Do not pour bleach into FABRI C SOFTEN ER dispenser.

– 10 –
So r t i n g W a s h Lo a d s
So r t b y c o l o r (w h i t e s, l i g h t s, c o l o r s), so i l l ev el ,
fabric type (sturdy cottons, easy care, delicates)
and whether the fabric produces lint (terry cloth,
chenille) or collects lint (velveteen, corduroy).
Pr op er Use o f Det er g en t
Add det ergent and st ar t t he wa sher bef or e adding
clothes so that the detergent can work effectively.
Using t oo lit t le or t oo much det ergent is a common
cause of laundry problems.
Yo u c a n u se l e ss d et er g e n t i f y o u h a v e so f t w a t e r ,
a smaller load or a lightly soiled load.
Loading t he Washer
Loa d dr y it ems loosel y , no higher t han t he t op row of
holes in the washer basket. When loading wet items,
make sure you set the load/water level high enough
to allow the items to move freely.Water level should
just cover the clothes. To add items after washer has
start ed, lift the lid and submerge additional items next
to the agitator.
Do not w rap long items like sheets or pant s
around the agitator.
Do not wash fabrics containing flammable materials
(w axes, cleani ng f l uids, et c.).
Agitation will not start with the lid up.
Wash Basket : Leave the lid open after washing to allow
moisture to evaporate. If you want to clean
the basket,use a clean soft cloth dampened with liquid
detergent; then rinse. (Do not use harsh or
gritty cleaners.)
Fi l l Hoses: GE r ec o m m en d s c h a n g i n g t h e h o se s
every 5 years.
Ext er i o r : Immediately wipe off any spills. Wipe
with damp cloth. Try not to hit surface with
sharp objects.
Moving and St orage: Ask t he service t echnician t o
remove water from drain pump and hoses. See the
Installation Instructions packed with product for
information on how to reinstall the shipping rod
to keep the tub stationary when moving the washer.For
more information, visit GEApp l i an ces.com or call 800.
GE.CARES (800.432.2737). Do not st ore
the washer where it will be exposed to the weather.
Long Vacat ions: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will
be below freezing.
Care and cleaning of the washer.
Loading and using the washer.
Alw ays f ollow fabric manufact urer’s care label w hen launder ing. GEAp p l i a n ces .c om

– 11 –
About t he Dr yer cont r ol panel .
1
2
IMPORTANT: Clean the lint filter each time you use the dryer
Fa br i c Car e/ Tem per a t u r e
REGULAR
or COTTONS
REG. HEAT
For regu l a r t o heavy c ot t on s.
MEDIUM,
EASY CARE
MED. HEAT,
EASY CARE
or PERMA PRESS
MED. HEAT
For sy n t h et ic s, bl ends, d elica t es an d it ems la b eled per m anen t p r ess.
DELICATES
LOW HEAT For del ica t es, sy nt het i cs an d it em s l abel ed t um bl e dr y l o w.
QUICK FLUFF
NO HEAT For  items without heat . Use the TIMED DRY cycle.
1
Drying Cycles
COTTONS Fo r co t t o n s a n d m o st l i n en s. Fo r m o st l o ad s, se lect OPTIMUM Dr y .
EASY CARE/
PERMANENT PRESS For w ri n kl e- f r ee, p er m anent press and del i cat e i t em s, an d knit s.
DELICATES For del ica t e i t em s, spec i a l- care f ab r ics and kni t s.
TIMED DRY Set t h e Cy c l e Sel e c t o r a t t h e d esi r ed d r y i n g t i m e .
DEWRINKLE For r em ovi ng w r in kles f r om it em s t h a t a re clea n and d r y or t hat a r e ver y l ight l y dam p.
QUICK FLUFF FLUFF
NO HEAT. Provides 10 minut es of no heat t umbling.
Aut omat ic cy cles aut omat ically det er mine f abr ic dr y ness. Select LESS DRY if y ou want your clothes slightly damp at the
end of the drying cycle. Select MORE DRY if you want them to feel drier. Timed cycles run for a selected time.
Aut o Cycl e / Timed Cycle
AUTO CYCLE For aut o m at ic sen sored dr y in g . The t im er d oes not rot a t e d u r ing t he c y cle un t i l t he t her mo-
stat s sense that the clot hes are dry, then the timer rotates automatically t o OFF.
TIMED DRY For m anua l d r y ing. The t i mer r ot at es du ri n g t he en t ire cy c l e.
START-Close the dryer door.Press START. Opening t he door during operat ion will stop t he dry er. To
restart the dryer, close the door and select START to complete the cycle.
2

– 12 –
About t he Dr yer f eat ur es. GEAp p l i a n ces .co m
St a i n l es s St eel D r u m
Th e st a i n l e ss st ee l u s ed t o m a ke t h e d r y er d r u m p r o v i d es t h e
highest reliability available in a GEdryer. If the dryer drum
should be scratched or dented during normal use, t he drum
will not rust or corrode. These surface blemishes will not affect
the function or durability of the drum.
The Ext er i or : Wipe or dust any spills or washing
compounds with a damp cloth. Dryer control panel

pretreatment soil and stain remover products. Apply
these products away from the dryer. The fabric may
then be washed and dried normally.Damage to your
dryer caused by these products is not covered by your
warranty.
The Li nt Fi l t er :



sheets. To remove t his buildup, wash t he lint screen
in warm, soapy water. Dry thoroughly and replace. Do


from the dryer once a year.
The Exh a ust Duct : Inspect and clean the exhaust
ducting at least once a year to prevent clogging. A
partially clogged exhaust can lengthen the drying
time.
Fol l ow t h ese st ep s:
1. Turn off electrical supply by disconnecting the plug
from the wall socket.
2. Disconnect the duct from the dryer.
3. Vacuum the duct with the hose attachment and
reconnect the duct.
The Exhaust Hood: Ch ec k w i t h a m i r r o r t h a t t h e

Make sure that there is no wildlife (birds, insects, et c.)
nesting inside the duct or hood.
Ca r e a n d Cl ea n i n g o f t h e Dr y er .
Not e: 27-in. models utilize a standard fi lter located in front of the air plenum.
*Grid
*Clean lint from mesh
*On some models

– 13 –
Loading and using t he Dr yer.
For t h e b est d r y i ng p er f o r m an ce, t h e d r y er n eed s t o b e p r op er l y ven t ed . Th e d r y er w i ll u se m or e en er g y
and run longer if it is not vented to the below specifications. Carefully follow the details on Exhausting in the
Installation Instructions.
Use only rigid metal 4” diameter ductwork inside the
dryer cabinet. Use only rigid metal or UL approved
flexible metal 4” diameter ductwork for exhausting
to the outside.
Do not use plastic or other combustible ductwork.
Use the shortest length possible.
Do not crush or collapse.
Avoid resting the duct on sharp objects.
Venting must conform to local building codes.
Vent ing t he Dr y er
Co r r ect
Vent ing
Incorrect
Vent ing

– 14 –
Dryer Operation Overview
Air enters the dryer cabinet, passing thru the heating elements (gas combustion chamber for gas models),
and into the drum. The hot air heats the wet clothes and gradually removes their moisture in the form of
water vapor. The moist air is vented through the dryer exhaust. Overall heating temperature is regulated by
means of 2 temperature thermostats: an inlet control thermostat located near the heating elements and
an outlet control thermostat located at the blower. (Note: Gas models use only an outlet control thermostat
for overall temperature regulation.) A safety thermostat, located near the heating elements (diffuser for
gas models), cycles the heating elements (burner for gas models), if overheating occurs. Also, the high limit
thermostat, located near the heating elements (diffuser for gas models), provides additional safety and
interrupts motor and heater operation if temperature rises above safe limits.
Dryer
Cabinet
Diffuser
Drum Lint trap Blower Exhaust
Safety Thermostat
Safety Thermostat
Inlet Control Thermostat
t°
t°
Outlet Control Thermostat
Heater
Pan/Electric
Elements
Gas
Combustion
Chamber
Dryer Air Flow System
The typical dryer cycle progresses as follows:
1. A cycle is selected and the start key is pressed.
2. The motor is activated.
3. The heater coils (burner for gas models) are activated. The coils (burner) cycle on and off to achieve the
desired temperature throughout the heating portion of the cycle.
4. If sensor drying is selected, the heater coils (burner for gas models) are activated. The coils (burner) cycle
on and off until the load has achieved the desired dryness level.
5. If timed drying is selected, the heater coils (burner for gas models) are activated and cycle on and off for
the selected time at the selected temperature.
6. The heater coils (burner for gas models) discontinue operation after the dryness level or elapsed time has
been achieved.
7. The motor continues operating until the clothes temperature drops below specifi ed temperature (Cool
Down).
8. The display turns off.
High Limit Thermostat
t°
High Limit Thermostat
t°
t°
t°

– 15 –
Air flow

– 16 –
Washer Components
Component Locator Views
(Continued Next Page)
Overflow Pipe
Pressure Dome Cleanout Port
Motor and Transmission
Drain Pump
Motor Capacitor
Tub Cover

– 17 –
El ect r i c Dr y e r Co m p o n en t s
Safety Thermostat
Inlet Control Thermostat
High Limit Thermostat
Outlet Control Thermostat
Idler Pulley
Heater Assembly
Motor and Blower
Assembly
(Continued Next Page)

– 18 –
Ga s Dr y er Co m po n en t s
Motor and Blower
Assembly
Outlet Control Thermostat
Idler Pulley
Safety Thermostat
High Limit Thermostat
Inlet Control Thermostat
Burner Assembly
(Continued Next Page)

– 19 –
Electric Dryer Components (27-in. model shown with service panel and heat shield removed)
Water Pressure Sensor Washer Control Board Fuses
Control Panel
Dryer Harness Connectors
Water Pressure Sensor Washer Control Board
Control Panel
Dryer Harness Connectors
Gas Dryer Components (24-in. model shown with service panel and heat shield removed)

– 20 –
Washer Control Board Connector Locator View
J8
J 1 - Motor Windings - Clockwise and Counterclockwise
J4 - Lid Switch
J5 - Motor Speed Sensor
J7 - Motor Line Out, Wax Motor, Lid Lock, Lid Lock Solenoid, Drain Pump, Water Valve
J8 - 120 VAC Input
J9 - Control Panel Buttons and LEDs
J10 - Pressure Sensor
J11 - Control Panel Selector Controls
J12 - Water Temperature Sensor (Automatic Temperature Control)
J9
J11
J4
J10
J1
J5
J7
J12
