Specification Revised 5/04
320358
JKP86SH – GE 27" Built-In Double Microwave/Thermal Oven
Dimensions (in inches)
(Must support 275 lbs.)
6015 Built-In MW/Double Ovens
(Pub. 1-G003 pg 105B) May 12, 1993
Built-In Microwave/Double Ovens
Dimensions (in inches)
E
Minimum
cutout location
from floor
Allow minimum of
21" for clearance
to adjacent corners,
drawers, walls, etc.
21
2" X 4" or
equiv. runners
Conduit
(49" long)
Allow 3/4" for overlap
of oven over all
edges of cutout
10
A
D
Recommended
junction box
locations.
Locate junction
box either 5" MIN.
below cutout
floor or 48" MIN.
above cutout
floor
C
B
F
G
H
C
L
Suitable
bracing
to support
runners 18"
Over centerline
of cabinet
2" x 4" or
equivalent
runners
Note: Cabinets installed adjacent to wall ovens must have an adhesion spec of at least a 194°F
temperature rating.
Note: If marks, blemishes or the cutout opening is visible above the installed oven, it may be
necessary to add wood shims under the runners and front trim until the marks or openings
are covered.
KW Rating
240V 6.4
208V 5.1
Breaker Size
240V 30 Amps
208V 30 Amps
Cabinet 27"
A – Cabinet Width Required 27" min.
B – Minimum Cabinet Depth 23-5/8"
C – Opening Width 25" min.-25"-1/4 max.
D – Opening Height 41-1/4" max.
E – Minimum Cutout Location from Floor 22"
Oven
F – Overall Depth 23-5/8"
w/o trim 41-1/8"
G – Overall Height with trim 42-1/8"
H – Overall Width 26-5/8"
Note: Cabinets installed adjacent to wall ovens must have an adhesion spec
of at least a 194°F temperature rating.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
® GE Profile™ or
GE® appliance questions, visit our website at
GEAppliances.com or call GE Answer Center®
service, 800.626.2000.
Electric wall ovens are not approved for installation with a plug and receptacle.
They must be hard wired in accordance with installation instructions.

GE Appliances
Specification Revised 5/04
320358
JKP86SH – GE 27" Built-In Double Microwave/Thermal Oven
Features and Benefits
• Upper Oven – 1.6 cu. ft. Capacity Microwave/1000 Watts with Turntable
• Sensor and Convenience Cooking Controls
• Electronic Touch Controls with Kitchen Timer
• Lower Oven – Extra-Large 3.9 cu. ft. Capacity Self-Cleaning Thermal Oven
with Delay Clean Option
• TrueTemp™ System
• SmartSet Electronic Oven Controls with Digipad
• 2 Oven Racks with 4 Embossed Rack Positions
• Frameless Glass Oven Door with Big ClearView™ Window and Interior Oven Light
• Model JKP86SHSS – Stainless steel
