GE Profile PT960DR Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
Specification Revised 7/10
220150
KW Rating
240V 7.6
208V 5.7
Breaker Size
240V 40 Amps
208V 40 Amps
PT960DR
GE Profile™30" Built-In Double Convection Wall Oven
Note: Cabinets installed adjacent to wall ovens
must have an adhesion spec of at least a 194°F
temperature rating. Electric wall ovens are
not approved for installation with a plug and
receptacle. They must be hard wired in accordance
with installation instructions.
Door handle protrudes 3" from door face. Cabinets
and drawers on adjacent 45° and 90° walls should be
placed to avoid interference with the handle.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
21" minimum
Door Opening
Allowance
B
B
A
A
Cutout height
51-13/16" MIN.
51-15/16" MAX.
Minimum cutout location
12" from the floor.
Cutout depth
23-1/2" MIN
5
47" to
bottom of
junction box
Cutout width
28-1/2'' MIN.
28-5/8'' MAX.
21
Cabinet
width 30"
C
E
D
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.
Conduit
48-1/2"
Junction box
location
C
L2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
(must support 325 lbs.)
Cabinet 30"
A – Overlap of oven over side of edges of cutout 11/16"-3/4"
B – Overlap of oven at top and bottom of cutout 1"
Oven
C – Overall depth* 23-1/2"
D – Overall height with trim 53-3/8"
Overall height without trim 52-7/8"
E –Overall width 29-3/4"
*Depth including door handle is approximately 26-6/10" min. to
26-9/10" max.
Dimensions and Installation Information (in inches)
21" minimum
Door Opening
Allowance
B
B
A
A
Cutout height
51-13/16" MIN.
51-15/16" MAX.
Minimum cutout location
12" from the floor.
Cutout depth
23-1/2" MIN
5
47" to
bottom of
junction box
Cutout width
28-1/2'' MIN.
28-5/8'' MAX.
21
Cabinet
width 30"
C
E
D
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.
Conduit
(72"
long)
Junction box
location
C
L2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
(must support 325 lbs.)
Cabinet 30"
A – Overlap of oven over side of edges of cutout 11/16"-3/4"
B – Overlap of oven at top and bottom of cutout 1"
Oven
C – Overall depth* 23-1/2"
D – Overall height with trim 53-3/8"
Overall height without trim 52-7/8"
E – Overall width 29-3/4"
*Depth including door handle is approximately 26-6/10" min. to
26-9/10" max.

Specification Revised 7/10
220150
PT960DR
GE Profile™30" Built-In Double Convection Wall Oven
Features and Benefits
• GlassTouchLCDControls–Combineasmooth,easy-to-cleanglassdesignwith
large, easy-to-read graphics to facilitate easier usage
• BlackGlossOvenInterior-Blackoveninterioraddsastylishtouch
to any kitchen
• PreciseAir™ConvectionSystem–Areversingfancirculatesheatandairforevenly
browned and baked foods
• Heavy-DutyRollerRack-Racksprovideeasyaccesstoitemsinsidetheovenby
simplifying loading and unloading
• ConvectionBake–Thissettingisoptimalforbakingcasserolesorlasagnas,yeast
breads, pies and pizzas with no need to turn the pan
• ConvectionRoast–Optimalforlargercutsofmeat,thissettingrotatestheheat
around all sides, sealing in the juices, producing rotisserie results at up to 25%
faster than a conventional oven
• FlatBackConvection–Convectionfansystemisonly1"deeptoprovide
additional room for cookware
• HiddenBakeOvenInterior–Concealsthelowerovenbakeelementtoeliminate
hard-to-reach areas that collect food and spills for easy cleaning
• Self-CleanOven–Self-cleanallowsyoutospareyourselffromthetroubleand
effort it takes to scrub the oven interior
• Super-LargeOvenCapacity-Remarkablylargeoveninteriorisidealforholidays,
dinner parties and everyday family cooking
• ModelPT960DRBB–Blackonblack
PT960WM/BM
