Specification Created 5/09
320371
JKP55SP
GE®27" Built-In Double Wall Oven
Dimensions and Installation Information
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
KW Rating
240V 6.8
208V 5.1
Breaker Size
240V 30 Amps
208V 30 Amps
Note: Cabinets installed adjacent to wall ovens must have
an adhesion spec of at least a 194°F temperature rating.
Note: If marks, blemishes or the cutout opening is visible
above the installed oven, it may be necessary to add
wood shims under the runners and front trim until the
marks or openings are covered.
Note: Door handle protrudes 3" from door face.
Cabinets and drawers on adjacent 45° and 90° walls
should be placed to avoid interference with the handle.
Electric wall ovens are not approved for installation
with a plug and receptacle. They must be hard wired in
accordance with installation instructions.
Cabinet 27"
A – Cabinet width required 27" min.
B – Minimum cabinet depth 23-5/8"
C – Opening width 25" min. - 25-1/4" max
D – Opening height 50-1/8" max
E – Recommended minimum cutout location from floor 13-1/4"
Oven
F – Overall depth* 23-5/8"
G – Overall height with trim 51-7/8" - 52-3/4"
Overall height without trim 51"
H – Overall width 26-5/8"
*Depth including door handle is approximately 26-7/10" min. to 26-8/10" max.
C
L
Suitable
bracing
to support
runners 18"
Over centerline
of cabinet
(must support 300 lbs.)
2" x 4" or
equivalent
runners
10
Locate
j
unction box
for 27"models
either 5" MIN.
below cutout
floor or 44"
MIN. above
cutout floor
Access
from
adjacent
cabinet
required
Allow 3/4"
for overlap
over all edges
of cutout
A
Minimum
cutout location
from floor
D
E
2" X 4" or
equiv. runners
(cutout floor) 21" MIN.
door opening
allowance
B
C
H
F
G
Locate
junction box
for 24"models
56" MIN. above
cutout floor
Conduit
(48-1/2" Long)
21
Cabinet 27"
A – Cabinet width required 27" min.
B – Minimum cabinet depth 23-5/8"
C – Opening width 25" min. - 25-1/4" max
D – Opening height 50-1/8" max
E – Recommended minimum cutout location from floor 13-1/4"
Oven
F – Overall depth* 23-5/8"
G – Overall height with trim 51-7/8" - 52-3/4"
Overall height without trim 51"
H – Overall width 26-5/8"
*Depth including door handle is approximately 26-7/10" min. to 26-8/10" max.
C
L
Suitable
bracing
to support
runners 18"
Over centerline
of cabinet
(must support 300 lbs.)
2" x 4" or
equivalent
runners
10
Locate
j
unction box
for 27"models
either 5" MIN.
below cutout
floor or 44"
MIN. above
cutout floor
Access
from
adjacent
cabinet
required
Allow 3/4"
for overlap
over all edges
of cutout
A
Minimum
cutout location
from floor
D
E
2" X 4" or
equiv. runners
(cutout floor) 21" MIN.
door opening
allowance
B
C
H
F
G
Locate
junction box
for 24"models
56" MIN. above
cutout floor
Conduit
(48-1/2" Long)
21
Dimension and installation information are shown in inches.

Specification Created 5/09
320371
JKP55SP
GE®27" Built-In Double Wall Oven
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
JKP55SP
Features and Benefits
• Extra-largeOvenCapacity-Enoughroomtocookanentiremealatonce
• Self-cleanOven-Self-cleanallowsyoutospareyourselffromthetroubleandeffort
it takes to scrub the oven interior. The oven does all the work!
• TrueTemp™Oven System - Provides even heat distribution and precise oven control
• InteriorOvenLight-Brightinteriorlighthelpsyoucheckontheprogressofyour
cooking
• Eight-passBakeElement-Interiorheatingelementloopseighttimestodistribute
heat quickly and evenly for optimal baking results
• 6-PassBroilElement-Providesbetterandmoreevencoverageofthefoodonthe
broiler pan
• HiddenBakeOvenInterior-Concealsthelowerovenbakeelementtoeliminate
hard-to-reach areas that collect food and spills for easy cleaning
• Heavy-dutyOvenRacks-Tough,durableracksinclude50%thickercrossbarsfor
extrastrength
• ElectronicOvenControls-Electronicpadsonthecontrolpanelareeasytooperate
with just a touch
• TwoOvenRacks-Includestwoovenracksthataresturdyandreliable
•ModelJKP55SPSS–Stainlesssteel
