GE Monogram ZET2SMSS Manual

Dimensions and Installation Information (in inches)
Installation Flexibility
These ovens may be installed in combination with a Monogram
warming drawer.
Note: Cabinets installed adjacent to wall ovens must have an
adhesion spec of at least a 194°F temperature rating.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Created 4/07 130181
ZET2SM
GE Monogram®30” Built-In Double Oven
KW Rating
240V 8.6
208V 7.8
Breaker Size
240V 40 Amps
208V 40 Amps
Listed by
Underwriters
Laboratories
28-1/2" Min.
28-5/8" Max.
51-13/16"
Min.
51-15/16"
Max.
12"
Locate Junction Box 47"
Above Cutout Floor, Within 5"
of Right Rear Wall
30"
52-7/8"
23-1/4"
Recessed
Depth
29-3/4"
23-1/2"
Min.
28-1/2" Min.
28-5/8" Max.
51-13/16"
Min.
51-15/16"
Max.
12"
Locate Junction Box 47"
Above Cutout Floor, Within 5"
of Right Rear Wall
30"
52-7/8"
23-1/4"
Recessed
Depth
29-3/4"
23-1/2"
Min.
The solid bottom or runners must be level with the bottom of the
cutout, or the bottom trim may not install correctly and could
interfere with the door opening. If the cabinet does not have a
solid bottom, two braces or runners must be installed level with
the bottom of the cutout to support the weight of the oven. The
runners and braces must support 375lbs. (90 kg).
NOTE: Install the
oven only with
specific models
listed on the label
located on top of
the oven.
Anti-Tip Block
Against Rear
Wall Per
Warming
Drawer
Requirement
2 (5.1 cm)
Min.
1 (2.5 cm) Min. Above Toekick
Per Warming
Drawer
Requirement

Features and Benefits
• Electronic Dial Controls - As elegant as they
are ergonomic
• Halogen Light Columns - On the oven walls
provide brilliant task lighting for each
rack position
• Exclusive Self-Cleaning, Full-Extension
Oven Racks - Glide in and out smoothly
on stainless steel ball bearings, and are
designed to be left in the oven during
the self-clean cycle
• 4.4 Cu. Ft. Capacity (Each Oven) - Easily
accommodates even the largest meals
• True Hidden Bake Element – Concealed beneath
the oven floor, allowing additional capacity and
improved cleanability
• Reverse-Air Convection System - Uses an
innovative fan that reverses direction for optimal
air and heat circulation, providing even cooking
and multi-rack baking capability
• Six-Element Design - Two bake, two broil and
two convection elements provide precise cooking
control, with fast preheating
• 208V Performance Compensation - Utilizes
the six-element design to boost power in
reduced-voltage installations
• Signature Tubular Handles - Are smooth, sleek
and easy to grasp
• Hand-Finished Edges - Reflect the meticulous
quality and craftsmanship for which Monogram
products are renowned
• Two Broil Elements with Reflector Shield -
Offer intense, dual-zone broiling
• Large Viewing Window - Allows you to view your culinary work in progress
• Model ZET2SMSS – Stainless steel
ZET2SMSS
COOK
TIME
DELAY
START
PROBE TIMER CLOCK
PUSH
TO
ENTER
Specification Created 4/07 130181
ZET2SM
GE Monogram®30” Built-In Double Oven
