GE GE PROFILE JGSP48SH Manual

TM
Specification Created 4/04
230126
JGSP48SH – GE Profile™ 30" Slide-In Gas Range
Dimensions (in inches) and Installation Information
For answers to your Monogram,® GE Profile™ or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
30_profile_gas_slide_in.eps
2-7/8"
To Front
Surface Of
Countertop
20-5/8"
Door Clearance
From Front
Surface of
Countertop
31-1/4
30
27-1/2
44-3/4
4
Accessory
Backguard
36
2"
(Grates)
24
Acceptable
Gas Line &
Electrical
Outlet Area
Max. depth of
cord, plug,
receptacle box
& gas hookup
3-1/2 to prevent
interference
with drawer
30 Min.
30 Min.
Shave Raised Edge To Clear
31-1/8 Wide Control Panel
gas_slide_in_install.eps
36
4 Min.
From Walls
23-3/16
18 Min.
13 Max.
3
29-15/16 Min.
30-1/16 Max.
25
9/16
7
12
15
Counter Cutout Dimensions (in inches)
28-1/4*
36
Maintain
at least 6"
from nearest
combustible
surface.
Acceptable
Electrical
Outlet Area
30" Slide-In Range
Dimensions (in inches)
45-1/8
2-1/4
5
6
4-1/2
30
30 Min.
15 Min. 6
30" Slide-in Elec. Range
Aug. 8, 2003 -km
23-3/16
30
30
If you are NOT using the
optional Filler or Backguard:
If you are using the
optional Filler or Backguard:
25
*Wall to front of
closed door handle
on model JSP34.
28" on models
JSP26/JSS26/16.
Note: Range may be placed with 0" clearance (flush) at the back wall and side walls
below countertop if the range side trims above the countertop extend beyond the cabinet
fronts at least 1/4". (Self-clean models only.) Maintain at least 6" distance from nearest
combustible surface.
30
30-3/4
28-1/4*
36
Maintain
at least 6"
from nearest
combustible
surface.
Acceptable
Electrical
Outlet Area
30" Slide-In Range
Dimensions (in inches)
45-1/8
2-1/4
5
6
4-1/2
30
30 Min.
15 Min. 6
30" Slide-in Elec. Range
Aug. 8, 2003 -km
23-3/16
30
30
If you are NOT using the
optional Filler or Backguard:
If you are using the
optional Filler or Backguard:
25
*Wall to front of
closed door handle
on model JSP34.
28" on models
JSP26/JSS26/16.
Note: Range may be placed with 0" clearance (flush) at the back wall and side walls
below countertop if the range side trims above the countertop extend beyond the cabinet
fronts at least 1/4". (Self-clean models only.) Maintain at least 6" distance from nearest
combustible surface.
30
30-3/4
You must use the rear filler strip kit shipped with the
range or the optional accessory backguard (JXS31,
JXS32, JXS33, JXS34) when installing these ranges.
Note: Cabinets installed adjacent to slide-in ranges
must have an adhesion spec of at least 194°F
temperature rating.
Optional Kits for Slide-In Gas Ranges:
(Available at additional cost)
Lower/Side Trim Kits
JXS52BB—Lower Trim Kit (Black)
JXS53WW—Lower Trim Kit (White)
JXS55CC—Lower Trim Kit (Bisque)
Accessory Backguards
JXS31—White Accessory Backguard
JXS32— Brushed-Chrome Accessory Backguard
JXS34—Black Accessory Backguard
JXS35—Bisque Accessory Backguard
Endcap Kit
JXS40—Endcap kit to accommodate replacement
where countertop may already be notched.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.

TM
JGSP48SH – GE Profile™ 30" Slide-In Gas Range
Features and Benefits
• Self-clean oven – Conveniently cleans the oven cavity without the need for scrubbing.
• Precise simmer burner – Offers a low setting of 600 BTUs, ensuring more temperature
control for simmering.
• High output burner – Provides a powerful 11,000 BTU burner output for efficient
heat-up and sautéing.
• Super large oven capacity – Provides the impressively large oven interior for cooking
more dishes and large meals at one time.
• Electronic oven controls – One-touch electronic pads are easy-to-use and allow for
simple oven operation.
• Continuous grates – Interlocking grates provide a flat, sturdy surface allowing easy
movement of pans between burners.
• Ceramic glass cooktop – A smooth cooktop surface makes cleaning quick and easy.
• Certified Sabbath mode – Prepared foods can stay warm in accordance with Kosher law.
• Model JGSP48SHSS – Stainless steel
Specification Created 4/04
230126
I
H
8
6
4
2
L
O
L
O
2
4
6
8
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
I
H
8
6
4
2
L
O
2
4
6
8
JGSP48SH
