GE JBP62BM Manual

†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 4/07 321598
Dimension from wall to front of closed door handle is 27-3/4".
KW Rating
240V 10.5
208V 7.9
Breaker Size
40 Amps†
30
25
29-7/8
46-7/8
2-1/2
7-1/2
25-3/8
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_ge.eps
Dimension from wall to front of
closed oven door handle is 27-3/4.
JBP62BM
GE®30" Free-Standing CleanDesign™Electric Range

Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing
• Super-Large 5.2 Cu. Ft. Oven Capacity - Provides an impressively large oven interior
to cook more dishes or large meals at once
• QuickSet III Oven Controls - Feature an easy to use design that lets you set precise
cooking temperatures
• Ceramic Glass Cooktop - A smooth cooktop surface makes cleaning quick and easy
• ClearView™Window - Features a convenient viewing area to check the progress
of food
• Dual Element Bake - Alternates the upper broiling element and the lower baking
element for even heating and optimal baking results
• Ribbon Heating Elements - Provide powerful heat beneath a smooth glass surface
to ensure even heat and fast warm-up times
• Model JBP62BMWH – White (black door/control panel and white patterned cooktop)
JBP62BM
BROIL SELF
CLEAN
OVEN
LIGHT
CLOCK
TIMECONTROLS
OVENCONTROLS
ONOFF
KITCHEN
LIGHT
ONOFF
BAKESTART
ON
CLEAR
OFF
Specification Created 4/07 321598
JBP62BM
GE®30" Free-Standing CleanDesign™Electric Range
