GE JBP89BLBB Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
JBP89TL/BL
GE® 30" Free-Standing Double Oven Range
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Revised 8/06 321575
KW Rating
240V 14.2
208V 10.7
Breaker Size
40 Amps†
30
25
A*
B*
2-1/2
7-1/2
25-3/8*
47-5/8
2-1/2
Acceptable electrical
outlet area
30_install_fse_drawer.eps
7
14-1/2
On models with baking or warming
drawers, electrical outlet must not
be in this area.
*Dimension from wall to front of closed
oven door handle is 27-3/8 on models
JB968/910/900 and 27-3/4 on models
JBP89/84/81.
*A is 29-7/8 on models JB968/910/900
and JBP89/84/81
*B is 46-7/8 on models JBP89/84/81
and 46-1/2 on models JB968/910/900
†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.

JBP89TL/BL
GE® 30" Free-Standing Double Oven Range
Specification Revised 8/06 321575
Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing
• Super-Large 5.3 Cu. Ft. Oven Capacity - Provides an impressively large oven interior to
cook more dishes and large meals at once
• Hidden Bake Oven Interior - Hides previously exposed bottom element to deliver a clean
interior appearance
• Lower Oven - Offers an additional 1.2 cu. ft. of capacity for convenient baking from 140
degrees to 450 degrees
• Dual Size Ribbon Element - Offers a convenient choice of using a 9" or 12" heating
element, depending on the size of the pan
• Bridge Element - Combines three cooktop elements into one large cooking area, ideal for
oversized cooking pans
• Warming Zone - Provides low heat capability for foods, making meal coordination simple
• QuickSet IV Oven Controls - Feature an easy to use design which allows you to set precise
cooking temperatures
• Big Hearth Window - Features an enhanced shape to add an elegant appearance and
make viewing trouble-free
• TrueTemp™System - Delivers even heat distribution and maximum oven control
• Self-Clean Heavy-Duty Oven Racks - Double coated porcelain-enameled racks no longer
require hand cleaning
• Model JBP89TLWW – True white (white glass door and true white cooktop)
• Model JBP89BLBB - Black on black (black glass door and black patterned cooktop)
JBP89TL/BL
SMALL
BURNER
LARGE
BURNER
FRONT
BURNER
BRIDGE
BURNER
BROIL SELF
CLEAN
OVEN
LIGHT
CLOCK
OVENCONTROLS TrueTemp
ON
TEMP
NORMAL
HILO
OFF
KITCHEN
TIMER
ONOFF
BAKESTART
ON
CLEAR
OFF
TIMECONTROLS
COOKING
TIME
ONOFF
AUTOMATICOVEN
START
TIME
ONOFF
WARMINGZONE
MED
LOWEROVEN
HEATING
WM
200
250
300 350400
450
