GE JGSP42SETSS Manual

All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
R
Listed by
Underwriters
Laboratories
JGSP42SET
GE®30" Slide-In Gas Range
Dimensions and Installation Information (in inches)
Specification Revised 9/11
330233
Rear filler strip or backguard are available for
these ranges
Note: Door handle protrudes 3" from door face.
Cabinets and drawers on adjacent 45° and 90°
walls should be placed to avoid interference with
the handle.
Note: Cabinets installed adjacent to slide-in
ranges must have an adhesion spec of at least
194° temperature rating.
Optional Kits for Slide-In Gas Ranges:
(Available at additional cost)
Lower Trim Kits
JXS56BB - Lower Trim Kit (Black)
Accessory Backguards
JXS32SS - Brushed-Chrome Accessory Backguard
JXS37BB - Black Glass Accessory Backguard
Rear Filler Strip
WB07T10680 - Black Filler Strip Assembly
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000. Dimension and installation information are shown in inches.
If you are NOT using the
optional Filler or Backguard:
23-3/16
30
If you are using the optional
Filler or Backguard:
25
30
Counter Cutout Dimensions (in inches)
12
ʺ
23-3/16
ʺ
7
ʺ
Acceptable
Gas Line &
Electrical
Outlet Area
30ʺMin.
30
ʺ
Min.
from
cooking
surface to bottom
of overhead
cabinets
Shave Raised Edge
To Clear 31-1/8
ʺ
Wide Control Panel
9-1/2
ʺ
Min.
From Walls
13
ʺ
Max.
depth
For Optimum
Installation These
Surfaces Must
Be Flat & Level
Follow instructions
packaged with
alternate appliance
Countertop
Depth 25
ʺ
(typical)
35-3/4
ʺ
to 36-1/2
ʺ
from floor to
countertop
18
ʺ
Min. vertical
distance from the
bottom of the adjacent
overhead cabinets
1-1/4
ʺ
Min. Counter top
to top of drawer
Drawer
cord, plug,
receptacle box
3.5
ʺ
to prevent
interference
& gas hookup
Max. depth of
with drawer
9/16
ʺ
29-15/16
ʺ
Min.
30-1/16
ʺ
Max.
3
ʺ
15
ʺ
12
ʺ
23-3/16
ʺ
7
ʺ
Acceptable
Gas Line &
Electrical
Outlet Area
30ʺMin.
30
ʺ
Min.
from
cooking
surface to bottom
of overhead
cabinets
Shave Raised Edge
To Clear 31-1/8
ʺ
Wide Control Panel
9-1/2
ʺ
Min.
From Walls
13
ʺ
Max.
depth
For Optimum
Installation These
Surfaces Must
Be Flat & Level
Follow instructions
packaged with
alternate appliance
Countertop
Depth 25
ʺ
(typical)
35-3/4
ʺ
to 36-1/2
ʺ
from floor to
countertop
18
ʺ
Min. vertical
distance from the
bottom of the adjacent
overhead cabinets
1-1/4
ʺ
Min. Counter top
to top of drawer
Drawer
cord, plug,
receptacle box
3.5
ʺ
to prevent
interference
& gas hookup
Max. depth of
with drawer
9/16
ʺ
29-15/16
ʺ
Min.
30-1/16
ʺ
Max.
3
ʺ
15
ʺ

JGSP42SET
GE®30" Slide-In Gas Range
Specification Revised 9/11
330233
Features and Benefits
• Deep-recessedcooktop-Deep-recessedcooktopcontainsspillsinoneareathat’s
easy to wipe clean
• Self-cleanoven-Self-cleanallowsyoutospareyourselffromthetroubleandeffort
it takes to scrub the oven interior
• PowerBoil™Burner - Delivers 15,000 BTUs of forceful heat for rapid boiling
• PreciseSimmerburner-Allowsforlow,evenheatdistributionthatisidealfor
delicate foods and sauces
• Heavydutyknobs-Adddurabilityandbrushedchromeforenhancedstyleand
performance
• Extra-largeovencapacity-Idealforspecialoccasionsandbigmeals,theextralarge
oven interior allows more to cook at once
• Continuousgrates-Connectedcooktopgratesprovideastudy,uninterrupted
surface that allows pots and pans to move easily
• Dishwasher-safegrates-Gratesaresafeforthedishwashersocleaningisaseasy
as ever
• Twoovenracks-Includestwoovenracksthataresturdyandreliable
•  T r u e T e m p ™oven system - This feature helps ensure the temperature you set is the
temperature you get to give you the baking and broiling performance you desire
• ModelJGSP42SETSS-Stainlesssteel
