GE Monogram ZGP484NGRSS Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
130564
Specification Created 12/10
Listed by
Underwriters
Laboratories
ZGP484NGRSS (Natural Gas)
ZGP484LGRSS (Liquid Propane)
GE Monogram® 48" All-Gas Professional Range with 4 Burners, Grill
and Griddle
Dimensions and Installation Information (in inches)
Professional ranges offer a number of choices in size and
cooktop configurations.
All Professional Ranges are factory set for natural or liquid
propane gas. The correct model should be ordered for the
installation situation.
Note: Conversion kits are included with the range if the wrong
gas type was ordered. High Altitude kit, WB28K10553 for
operation above 6,000 feet (for Natural and LP gas models), is
also available. The kits must be installed by a qualified service
technician at additional cost.
Installation Information
Before installing, consult installation instructions packed
with product or online at Monogram.com for current
dimensional data.
A suitable 48" or wider vent hood is required for installation
over ranges with a grill and recommended for all other
ranges.
Advance Planning
Refer to dimensional drawings
for appropriate placement and
necessary clearances when
planning the installation.
• Working areas adjacent to the
range should have 18" minimum
clearance between countertop and
cabinet bottom.
• Clearance between range and side
wall or combustible material must
be at least 12" on each side.
• Installation must conform with
local codes. In the absence of local
codes, the range must comply with
the National Fuel Gas Code, ANSI
Z223.1-1990.
3-1/4”
to 4-3/4”
Toekick/
Leg Height
Countertop
to Cooking
Surface
Depth
to Front
of Door
28-1/4”
1-1/2”
47-7/8”
Width
35-1/4”
to
36-3/4”
Height

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
130564
Specification Created 12/10
Listed by
Underwriters
Laboratories
ZGP484NGRSS (Natural Gas)
ZGP484LGRSS (Liquid Propane)
GE Monogram® 48" All-Gas Professional Range with 4 Burners, Grill
and Griddle
Dimensions and Installation Information (in inches)
Electrical Requirements
Ranges must be hooked up to a 120V, 60Hz properly
grounded dedicated circuit protected by a 15-amp circuit
breaker or time-delay fuse.
Optional Backsplash Accessories
The range requires a 12" minimum clearance to a vertical
combustible surface at the rear. A backsplash is required
for installations with less than 12" clearance. The following
backsplash accessories are available, or a custom, non-
combustible backsplash can be used.
Order one with a 48"-wide range backsplash
ZX12B48PSS–12" backsplash
ZXADJB48PSS– 30"-36" adjustable-height backsplash with
warming shelf
Side View with a Backsplash
Locate gas and
electric as shown
Universal Utility Locations
8”
23”
48”
6”
2”
3”
6-1/2” Gas/
Electric
Gas/
Electric
10-1/2”
1-1/2”
12”
28-1/4” to
Beveled
Edge of Control
Panel Bullnose
27-1/2” to
Beveled Edge
- Maximum
Adjacent
Cabinet Depth
for
Flush
Installation
13/16”
30-36”
3-3/16”
Control Panel
Depth
28-1/4”
to Front of
Door
48-1/4”
with Oven Door
Open
31-1/16”
to Front of
Handle
35-1/4”
to
36-3/4”
7” Control
Panel Height
28-7/8”
to Front
Edge
Optional
Backsplash
Accessories
Gas Supply
• The natural gas models are designed to
operate at 5" water column pressure.
For proper operation, the pressure of
the natural gas supplied to the regulator
must be between 7" and 13" water
column.
• The LP models are designed to operate
at 10" water column pressure. For
proper operation, the pressure of the LP
gas supplied to the regulator must be
between 11" and 13" water column.
Universal Utility Locations

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
130564
Specification Created 12/10
ZGP484NGRSS (Natural Gas)
ZGP484LGRSS (Liquid Propane)
GE Monogram® 48" All-Gas Professional Range with 4 Burners, Grill
and Griddle
Features and Benefits
• Authentic Professional appearance - With
premium-grade, 304 stainless steel with smoothly
finished edges, large electronic control knobs and
heavy duty handles
• Sealed, dual-ame stacked burners - Deliver a full
spectrum of heat settings, from an ultra-low 140°
F simmer to an intense 18,000 BTU
• Largest all-gas professional oven capacity
• Monogram Professional dual-burner bake system -
Combines Reverse-Air convection technology with
an infrared broil and gas burner to provide superb
baking results, with fast preheating
• Infrared broil burner - Produces intense heat
needed to sear meats to lock in juices and
is thermostatically controlled to provide top
browning when baking or convection baking
• Heavy-duty oven racks - Glide smoothly in and out
on stainless steel ball bearings for easy access,
and are designed to remain in the oven during the
self-clean cycle
• LED task lights - Below the bullnose, provide a
functional and theatrical touch
• Stainless steel and aluminum-clad griddle - Offers
18,000 BTUs* of cooking power, allowing fast and
consistent heating across the entire cooking surface
• Ceramic-infrared grill - has 15,000 BTUs* of
adjustable heat; The cooking grate is grooved on
one side to create sear marks and rounded on the
other for delicate foods
• Model ZGP484NGRSS - Natural Gas*
• Model ZGP484LGRSS - Liquid Propane
BACK FRONTGRILL GRIDDLE BACK FRONT
TIMER TIMER
PUSH TO
SELECT
O
F
F
B
A
K
E
B
R
O
I
L
P
R
O
O
F
R
O
A
S
T
B
R
O
I
L
B
A
K
E
C
O
N
V
.
C
O
N
V
.
C
O
N
V
.
O
F
F
B
R
O
I
L
P
R
O
O
F
C
L
E
A
N
R
O
A
S
T
B
R
O
I
L
B
A
K
E
C
O
N
V
.
C
O
N
V
.
C
O
N
V
.
ZDP484
