†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
JBP27WL/CL/BL
GE®30" Free-Standing QuickClean™Electric Range
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 9/06 322016
KW Rating
240V 11.7
208V 8.8
Breaker Size
40 Amps†
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
*Dimension from wall to front of closed door handle is 27-3/4".
30" FS Elec. Range ABC Dim.
25-3/8*
47-5/8
29-7/8
*Dimension from wall to front
of closed door without handle
46-7/8
1/4
†
The range may be placed with a 0"
clearance (flush) at the back wall and
side walls if the range side trims extend
beyond the cabinet fronts at least 1/4".
Self-clean models only.
†

JBP27WL/CL/BL
GE®30" Free-Standing QuickClean™Electric Range
Specification Created 9/06 322016
Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing
• Super-Large 5.0 Cu. Ft. Oven Capacity - Provides an impressively large oven interior
for cooking more dishes and large meals at one time
• TrueTemp™System - Delivers even heat distribution and maximum oven control
• QuickSet IV Oven Controls - Feature an easy to use design which allows you to set
precise cooking temperatures
• Coil Heating Elements - Provides consistent and even heat on the cooktop with a
plug-in element that is removable for easy cleaning
• Dual Element Bake - Alternates the upper broiling element and the lower baking
element for even heating and optimal baking results
• Big Hearth Window - Features an enhanced shape to add an elegant appearance
and make viewing trouble-free
• CleanWell™Cooktop System - Ensures spills are properly contained, while providing
convenient cleaning access
• Six Rack Positions - Provides flexibility and allows consumers to make the most of
available oven capacity
• Model JBP27WLWW – White on white (white door and white cooktop)
• Model JBP27CLCC – Bisque on bisque (bisque door and bisque cooktop)
• Model JBP27BLBB – Black on black (black door and black cooktop)
JBP27WK/CK/BK
BROIL SELF
CLEAN
OVEN
LIGHT
CLOCK
TIMECONTROLS
OVENCONTROLS
ONOFF
KITCHEN
LIGHT
ONOFF
BAKESTART
ON
CLEAR
OFF
COOKING
TIME
ONOFF
AUTOMATICOVEN
START
TIME
ONOFF
