GE GE Profile Arctica CustomStyle PSW23PSR User instructions

PSW23PSR – GE Profile Arctica CustomStyle™ ENERGY STAR® 22.6 Cu. Ft. Stainless-Wrapped
Side-By-Side Refrigerator with Dispenser
TM
Specification Revised 7/04
210265
Dimensions (in inches)
"94 SxS Refer
A
Front View
Top View
G
D
C
F
B
E
H
*Width including top caps is 36-3/16".
† Water hook-up fits in back air clearance when calculating installation depth.
If installed against a wall, allow clearance of 13-15/16" on freezer side to
remove ice bin.
To remove fresh food pans, remove door bins.
Clearance required to remove fresh food full-size pan without disassembling:
18-5/8".
Plus, allow additional space for any necessary leveling adjustments.
Overall
Dimensions
Height to top of hinge (in.) A 69-1/4*
Height to top of case (in.) B68-3/4
Case depth without door (in.) C†23-7/8
Case depth less door handle (in.) D†26-3/4
Case depth with door handle (in.) E†29-3/16
Depth with fresh food door open 90° (in.) F†45-9/16
Width (in.) G35-3/4*
Width with door open 90° with door handle (in.) H38-3/16
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1/2
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
R
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.

PSW23PSR – GE Profile Arctica CustomStyle™ ENERGY STAR® 22.6 Cu. Ft. Stainless-Wrapped
Side-By-Side Refrigerator with Dispenser
TM
Specification Revised 7/04
210265
Water Line Coupler
1.
366-15A
Hinge Screws
Wire Harness
Toekick Screw
4.
3.
2.
To Remove Top Cap and Doors on PSW23PSR
Step 1: Locate and remove two Phillips head screws on the top of
the refrigerator. Remove two screws, one on each side at the
rear of the top cap. Lift off and remove top cap.
Step 2: Open both doors. Remove one screw on each side of the
toekick. Pull forward to remove toekick.
Step 3: On the freezer door, disconnect water line coupler by
pushing against the collar on the left side. Disconnect
wire harness.
Step 4: Use a Torx T-20 screwdriver to remove 2 screws holding the
top hinge. Carefully remove hinge while supporting door.
Lift door up and off bottom hinge. Remove fresh food door in
the same manner. Note: Do not remove bottom hinges! Door
alignment will be difficult if bottom hinges
are removed.
Step 5: Place refrigerator onto a hand truck, upright and against one
side. Move refrigerator to the installation location.
Reinstall Doors, Top Cap
Step 6: Carefully lower doors onto bottom hinges. Be sure to route
the tubing and electrical connector through the bottom
hinge. Reinstall top hinges.
Step 7: Place cap over the top of the refrigerator. Reinstall the
original screws in the top and back of the cap.
Step 8: Reconnect the wiring harness and waterline.
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
R
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.

PSW23PSR – GE Profile Arctica CustomStyle™ ENERGY STAR® 22.6 Cu. Ft. Stainless-Wrapped
Side-By-Side Refrigerator with Dispenser
TM
Specification Revised 7/04
210265
Features and Benefits
• CustomStyle™ configuration – Offers a built-in look without the built-in expense
•
Full-wrap stainless design – Features stainless steel doors, side panels and top for a truly dramatic look
• ClimateKeeper2™ System – Keeps food fresher longer, while protecting ice from odor transfer, with its
unique dual-evaporator system
• CustomCool™ Technology With Full Extension Slides – Chills in minutes, thaws in hours and keeps
foods fresher, longer
• Upfront Electronic Digital Display – Clearly displays exact temperatures for the fresh food and
freezer compartments
• Integrated Ice™ System – Frees up valuable freezer space. It tilts down, providing easy access to cubed ice
• LightTouch! tall dispenser with child lock and door alarm – Delivers chilled water, cubed ice or crushed ice
at the slightest touch
• Full-Width Slide ’N Store Freezer Basket – Offers tremendous storage flexibility and keeps contents
perfectly in place
• Model PSW23PSRSS – Stainless steel
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
