Monogram.
™
Specification Revised 8/02
ZICS360NM – GE Monogram 36" Built-In Stainless Steel Bottom Freezer
Refrigerator with Automatic Icemaker
The Installation Space
Water and Electrical Locations
Electrical and water supply must be located as shown.
The cutout depth must be 24"
Designed for industry standard flush installation. The refrigerator will project
forward, slightly beyond adjacent cabinetry, depending on your installation.
Cutout depth beneath a soffit
When installed beneath a soffit, the soffit cannot exceed the 24" installation
depth shown.The top case trim overlaps the bottom of the soffit.
Frameless Cabinets
The case trim overlaps cabinets at the top and sides. Therefore, frameless
cabinets may require filter strips to prevent interference with cabinet door
swing. The opening must allow for filter strips.
Additional Specifications
• A 115 volt 60Hz., 15 or 20 amp power supply is required. An individual
properly grounded branch circuit or circuit breaker is recommended.
Install a properly grounded 3-prong electrical receptacle recessed into
the back wall. Electrical must be located on rear wall as shown.
Note: GFI (grounded fault interrupter) is not recommended.
•Water line can enter the opening through the floor or back wall. The water
line should be 1/4" O.D. copper tubing between the cold water line and
water connection location, long enough to extend to the front of the
refrigerator. Installation of an easily accessible shut off valve in the
water line is recommended.
Optional Custom Trim Kits:
•ZUGSS2: Unified Stainless Steel Grille Kit
Product Clearances
These refrigerators are equipped with a 2 position door stop. The factory set
130°door swing can be adjusted to 90°if clearance to adjacent cabinets or
walls is restricted.
Allow 25" minimum clearance for a full 130°door swing. Allow 15" for pan removal.
4" minimum clearance is required when door swing is adjusted to 90°. If the
90°door stop position is used, pan access is maintained, but pan removal
is restricted.
7"
Wall View
Electrical
Area
84-1/2" max
83-1/2" min
Finished
Opening
74-1/2" From
Floor to
Bottom
of Electrical
10"
5"
3 1/2"
5"
3 1/2"
Water Supply
24" Cutout Depth
35-1/2"
Finished Width
2-5/16"
For answers to your Monogram,
® GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
The finished cabinet width must be 35-1/2".
36"
Frame to Frame
Width
*84" From
Floor to
Top Frame
35"
Case Width
*83-1/2"
at
Rear
23-7/8"
Behind
Frame
36-3/4"
4" Minimum
to Wall
90°Door Swing
90°
25"
Minimum
to Wall
130°Door Swing
130°
Dimensions and Clearances
* Shipping height. The refrigerator
can be adjusted to fit into a
cutout that is 83-1/2" min. to
84-1/2" max. height. Note that
the top case trim at the front
is 1/2" higher and will overlap
upper cabinetry or soffit. Use
leveling legs and wheels for
height adjustment.

Monogram.
™
ZICS360NM –GE Monogram 36" Built-In Stainless Steel Bottom Freezer
Refrigerator with Automatic Icemaker
ZUGSS2 Unified Grille Panel Kit
•For side by side installation of two stainless steel wrapped
bottom-freezer refrigerators. This kit provides a unified stainless
steel grille panel to span the width of two units.
•If you are installing two refrigerators, side by side, the
installation space must be 71-1/2" wide.
Note: Additional cutout width may be required when side panels are
used. Add side panel thickness to the finished cutout to calculate
rough-in width.
•The water and electrical locations for each product must be located
as shown.
•A separate 115V, 60Hz., 15 or 20 amp power supply is recommended
for each product.
2-5/16"
74-1/2" From
Floor to Bottom
of Electrical
84-1/2" max
83-1/2" min
Finished
Opening
71-1/2" Finished Width
Electrical
5"
3-1/2"
24" Cutout
Depth
Water Supply
Wall View
24-3/16"
26"
7"
10"
7"
10"
Water Supply
26"
5"
3-1/2"
SIDE PANELS
Side panels must be used whenever the sides of the refrigerator
will be exposed. The 1/4" side panels will slip into the side case
trim. Order the side panels from the cabinet manufacturer.
*84"
2-9/16"
24"
*3" to 4"
* Depending on installation height.
Specification Revised 8/02
For answers to your Monogram,
®GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories

Monogram.
™
Specification Revised 8/02
ZICS360NM –GE Monogram 36" Built-In Stainless Steel Bottom Freezer
Refrigerator with Automatic Icemaker
Features and Benefits
•20.6 Cu. Ft. Capacity (Fresh Food
14.5 Cu. Ft./Freezer 6.1 Cu. Ft.)
•Equipped with Factory Installed Automatic
Icemaker with Removable Ice Storage Bin
•Upfront Dual Electronic Controls
•Multi-Shelf Air Management Tower
•2 Sealed, Adjustable Humidity
Produce Pans with Easy Access Lids
and Full Extension Slides
•2 Sealed Slide-Out Deli Pans
•Adjustable Spill-Proof Glass Shelves
•6 Adj. Fresh Food Door Bins
•Gallon Door Storage
•2 Sealed Dairy Compartments with
Glass-Covered Butter Dish
•Egg Bin
•Wine Caddy
•Freezer Drawer on Full Extension Slides
•Independent Utility Basket on
Full Extension Slides
•GE SmartWater Filtration System
•Model ZICS360NMRH –Right-handed
door swing (Stainless steel wrap)
•Model ZICS360NMLH –Left-handed
door swing (Stainless steel wrap)
