GE Monogram® 36" Built-In French-Door
Refrigerator
Technical Service Guide
August 2016
GE Appliances
31-9259
GE Appliances
Louisville, Kentucky 40225

– 2 –
Safety Information
IMPORTANT SAFETY NOTICE
The information in this service guide is intended for use by
individuals possessing adequate backgrounds of electrical,
electronic, and mechanical experience. Any attempt to repair a
major appliance may result in personal injury and property
damage. The manufacturer or seller cannot be responsible for the
interpretation of this information, nor can it assume any liability in
connection with its use.
WARNING
To avoid personal injury, disconnect power before servicing
this product. If electrical power is required for diagnosis or test
purposes, disconnect the power immediately after performing the
necessary checks.
RECONNECT ALL GROUNDING DEVICES
If grounding wires, screws, straps, clips, nuts, or washers used to
complete a path to ground are removed for service, they must be
returned to their original position and properly fastened.
GE Appliances
Technical Service Guide
Copyright © 2016
All rights reserved. This service guide may not be reproduced in whole or in part
in any form without written permission from GE Appliances.

– 3 – (Continued next page)
Table of Contents
Safety Information..........................................................................................................................................................................2
Table of Contents.............................................................................................................................................................................3
Safety Requirements.....................................................................................................................................................................6
Nomenclature...................................................................................................................................................................................7
Introduction.......................................................................................................................................................................................8
Technical Data..................................................................................................................................................................................9
Operating Instructions .................................................................................................................................................................10
Temperature Controls.........................................................................................................................................................10
Changing Display Temperatures from °F to °C Installation.............................................................................10
Door Alarm...............................................................................................................................................................................10
Sabbath Mode........................................................................................................................................................................10
Installation .........................................................................................................................................................................................11
Water Line................................................................................................................................................................................11
Anti-Tip Device.......................................................................................................................................................................12
Secure Refrigerator to Cabinetry...................................................................................................................................12
Level Refrigerator.................................................................................................................................................................13
Connect Water Supply.......................................................................................................................................................13
Fresh Food Doors............................................................................................................................................................................14
Door Alignment......................................................................................................................................................................14
Adjust Door Swing................................................................................................................................................................14
Door Bins...................................................................................................................................................................................15
Fresh Food Doors..................................................................................................................................................................15
Vertical Mullion.......................................................................................................................................................................16
Freezer Drawer.................................................................................................................................................................................18
Drawer Closer.........................................................................................................................................................................18
Main Drawer Slides..............................................................................................................................................................19
Upper Drawer Slides............................................................................................................................................................19
Fresh Food..........................................................................................................................................................................................20
Shelves and Bins...................................................................................................................................................................21
Fresh Food................................................................................................................................................................................22

– 4 –
Damper......................................................................................................................................................................................23
HMI (User Interface).............................................................................................................................................................24
Freezer..................................................................................................................................................................................................25
Freezer Interior Component Locator...........................................................................................................................25
Freezer Baskets......................................................................................................................................................................26
Freezer Lighting.....................................................................................................................................................................26
Icemaker...................................................................................................................................................................................27
Evaporator Component Locator....................................................................................................................................30
Defrost Heater........................................................................................................................................................................31
Safety Thermostat................................................................................................................................................................31
Defrost System.................................................................................................................................................................................32
Adaptive Defrost....................................................................................................................................................................32
Adaptive Defrost (Cooling Operation)..........................................................................................................................32
Adaptive Defrost (Pre-Chill Operation)........................................................................................................................32
Defrost Heater Operation.................................................................................................................................................32
Dwell Period.............................................................................................................................................................................32
Cabinet Bottom................................................................................................................................................................................33
Cabinet Bottom Component Locator..........................................................................................................................33
Toe Kick Installation.............................................................................................................................................................33
$LUÀRZDQG)DQV ..............................................................................................................................................................................34
$LUÀRZ ........................................................................................................................................................................................34
Fresh Food Fan......................................................................................................................................................................34
Freezer Fan..............................................................................................................................................................................35
Condenser Fan.......................................................................................................................................................................36
Drain Pan Fan.........................................................................................................................................................................37
Thermistors and Sensors.............................................................................................................................................................39
Thermistors..............................................................................................................................................................................39
Humidity Sensor....................................................................................................................................................................41
Cooling System.................................................................................................................................................................................42
Machine Compartment................................................................................................................................................................43
Cabinet Top Component Locator..................................................................................................................................43
Water System.........................................................................................................................................................................43
Water Filter Cartridge.........................................................................................................................................................44

– 5 –
Water Valve Assembly........................................................................................................................................................45
Inverter Compressor............................................................................................................................................................46
Inverter......................................................................................................................................................................................46
Main Board...............................................................................................................................................................................47
Main Board Connector Locations..................................................................................................................................48
Diagnostic Mode..............................................................................................................................................................................50
Schematic Diagram.......................................................................................................................................................................51
Monogram Refrigerator Warranty..........................................................................................................................................52
Index......................................................................................................................................................................................................53

– 6 –
Prior to disassembly of the refrigerator to access components, GE
Factory Service technicians are REQUIRED to follow the Lockout /
Tagout (LOTO) 6 Step Process:
Safety Requirements
GE Factory Service Employees are required to use safety glasses with side shields, safety gloves and
steel toe shoes for all repairs.
Steel Toed Work Boot Electrically Rated Glove and
Dyneema® Cut Resistant
Glove Keeper Dyneema®Cut Resistant
Glove
Plano Type Safety Glasses
Prescription Safety Glasses
Safety Glasses must be ANSI
Z87.1-2003 compliant
Brazing Glasses
Cut Resistant Sleeve(s)
Step 1
Plan and Prepare Step 4 Apply LOTO device and lock
Step 2
Shut down the appliance Step 5 Control (discharge) stored energy
Step 3
Isolate the appliance Step 6 “Try It” verify that the appliance is
locked out

– 7 –
Nomenclature
The nomenclature breaks down and explains what the letters and numbers mean in the model number.
Serial Number
7KH¿UVWWZRFKDUDFWHUVRIWKHVHULDOQXPEHULGHQWLI\WKHPRQWKDQG\HDURIPDQXIDFWXUH7KHOHWWHU
designating the year repeats every 12 years.
Example: LA123456S = June, 2013
A – JAN
D – FEB
F – MAR
G – APR
H – MAY
L – JUN
M – JUL
R – AUG
S – SEP
T – OCT
V – NOV
Z – DEC
2024 – Z
2023 – V
2022 – T
2021 – S
2020 – R
2019 – M
2018 – L
2017 – H
2016 – G
2015 – F
2014 – D
2013 – A
Brand
Z - Monogram
Z I P P 3 6 0 N H A S S
Configuration
P - French Door Bottom Freezer
Engineering Digit
0 - 99
Model Year
2014
Handle Options
SS - Stainless case/handle
Door Panel
P - Professional
S - Stainless wrap panel or European
*No designation - custom panel*
Installation
I - Built-in
Width
36”
Dispenser
D - Ice and water dispenser
N - No dispenser
Flush or Integrated
0 - Flush-inset, 3/4” overlay or 1/4” framed
The Mini Manual is located in
the machine compartment
to the left of the main board
enclosure.
The Model Serial ID Tag is located under
the full width drawer on the right side of
WKHIUHVKIRRGÀRRU

– 8 –
Monogram introduces 36" Built In Freezer French Door Refrigerators. The refrigerators are available in three
styles: European, Professional, and custom panel.
All LED lighting illuminates the fresh food and freezer sections with crisp clear lighting throughout the interior.
The French door design gives wide-open access to bins, shelves and drawers. The aluminum-trimmed glass
bins and shelves allows convenient visible access to contents in the fresh food section. Deli and produce
drawers are soft closing for smooth and quiet operation.
The freezer features a factory installed LFHPDNHU:LWKWKHXVHRI*(ZDWHU¿OWUDWLRQWKHicemaker produces
¿OWHUHGLFHFXEHV7ZREDVNHWVSURYLGHDPSOHVWRUDJHIRUIUR]HQJRRGV7KHWRSEDVNHWLVLQGHSHQGHQWIURP
the lower basket, and is able to fully extend.
Cooling is achieved through the use of a variable speed compressor and a single evaporator. A fresh food
IDQDQGHOHFWULFDOGDPSHUUHJXODWHWKHDLUÀRZLQWRWKHIUHVKIRRGVHFWLRQ8SIURQWHOHFWURQLFFRQWUROVZLWKD
GLJLWDOUHDGRXWRȺHUDUDQJHRIWHPSHUDWXUHVHWWLQJVIRUERWKFRPSDUWPHQWV
Approximate Dimensions (H x D x W): 84 inches x 25 13/16 inches x 36 inches
Additional Features
• Filter change indicator
• Sabbath mode
• Hidden door hinges
• 90 or 130 degree door stops
• Master Light control switch
• 6WDLQOHVVVWHHO¿QLVK
• Stainless steel handles
• Made In America
NOTE: Features may vary by model.
Introduction

– 9 –
Technical Data
NO LOAD PERFORMANCE
CONTROL POSITION 37-0°F and
AMBIENT TEMPERATURE OF 65°F 90°F
Fresh Food, °F 36-38 36-38
Frozen Food, °F (-1) - (1) (-1) - (1)
Percent Running Time 36-44 61-69
ELECTRICAL SPECIFICATIONS
Max Defrost Control
w/No Door Openings 96 hrs @ 40 min
Evap Defrost Thermodisc 140-110°F
Electrical Rating: 115V AC 60 Hz 7.0 amp
Maximum Current Leakage 0.75 mA
Maximum Ground Path Resistance 0.14 ohms
MONOGRAM - ZIP360NHA, ZIPP360NHASS, ZIPS360NHASS
REFRIGERATION DIAGNOSIS
To access the low pressure side of the system,
install a WJ56X61 valve only on the process tube
extending from the compressor case.
REFRIGERATION SYSTEM
Compressor 833 BTU/hr
Minimum Compressor Capacity
Vacuum 22 inches
Minimum Equalized Pressure
@ 70°F 62/68 PSIG
@ 90°F 87/91 PSIG
R134a Refrig. Chg 9.25 oz
Electrical Shock Hazard
Death or serious injury can result from failure to
follow these instructions.
• 6HUYLFHE\DTXDOL¿HGVHUYLFHWHFKQLFLDQRQO\
• Disconnect power before servicing this product.
• Reconnect all grounding devices after service.
• Replace all parts and panels before operating.
WARNING
To avoid personal injury when servicing the
condensing unit, stand on a ladder which will give
enough support to allow removal of the top panel
and safely allow access to service the unit.
CAUTION
To Cabinet
Wiring
Orange
Black Green/Yellow
Ground
Compressor
Black
Red
White
Red
White
Communication
Signal
Green/Yellow
Inverter
Ground
*Approximate
location of inverter
Condenser
Dryer
Discharge
Inverter*
Compressor
Suction Tube
Capillary
Evaporator
Condenser
Loop
Process
Tube
Suction Line
Muffler
Suction Line
0XȼHU
Process
Tube Condenser
Dryer
0XȼHU
Discharge
Capillary
Inverter*
Compressor
Suction Tube
Evaporator
Condenser Loop
*Approximate location of
inverter

– 10 –
Operating Instructions
The temperature display shows the actual
temperature of the freezer and fresh food
compartments. The actual temperature will vary
from the set temperature based on factors such as
frequency of door opening, amount of food, defrost
cycling and room temperature.
NOTE: Frequent door openings or a door left open
for periods of time may increase the internal
temperature of the freezer and fresh food
compartments temporarily.
7RWXUQRȹWKHFRROLQJV\VWHP in both the freezer
and fresh food compartments, press either "+" pad
until both displays show OFF.
To turn the cooling system on, press either "–" pad.
The preset temperatures of 0°F and 37°F will appear
in the displays.
To check the current temperature setting for the
fresh food or freezer compartment, press the "+" or
"–" pad once. After 5 seconds, the display will return
to the actual temperature.
To change the temperature settings, press the "+"
or "–" pads to the desired temperature set point for
fresh food and freezer separately. Allow 24 hours for
the refrigerator to reach the temperature that has
been set.
NOTE: Setting the controls to OFF stops cooling, but
GRHVQRWVKXWRȺHOHFWULFDOSRZHUWRWKHUHIULJHUDWRU
34°F
1°C
–6°F
–21°C
41°F
5°C
6°F
–14°C
Fresh Food
Freezer
Low High
Temperature Range
To change the temperature display between
Fahrenheit and Celsius, press Temp °C/°F.
To turn the Door Alarm feature on, press the pad
RQFH7KH$&7,9(OLJKWZLOOFRPHRQ7RWXUQLWRȺ
press the pad again.
:KHQWKHGRRUDODUPLVDFWLYHWKHDODUPZLOOÀDVK
and beep if the door is kept open for more than two
minutes.
Temperature Controls Changing Display Temperatures from °F to
°C Installation
Door Alarm
To set Sabbath Mode, press and hold the
refrigerator "+" pad and the Temp C°/F° pad at the
same time and hold for 5 seconds. The temperature
display will show "SA" for 5 seconds, and then the
GLVSOD\DQGOLJKWVWXUQRȺ7KHOLJKWVDQGGLVSOD\ZLOO
EHRȺXQWLO6DEEDWK0RGHLVWXUQHGRȺ7RWXUQRȺ
Sabbath Mode, press and hold the refrigerator "+"
pad and the Temp C°/F° pad at the same time for
¿YHVHFRQGV
DISPLAYS, ALARMS and LIGHTS: The main
temperature control, door alarms and lights will be
disabled.
ICEMAKER: The icemaker will be disabled in Sabbath
Mode.
Sabbath Mode

– 11 –
NOTE6DGGOHW\SHVKXWRȺYDOYHVDUHLQFOXGHGLQ
many water supply kits, but are not recommended
for this application.
If the water supply to the refrigerator is from
a Reverse Osmosis Water System, use the
UHIULJHUDWRU·V¿OWHUE\SDVVSOXJ8VLQJWKH
UHIULJHUDWRU·VZDWHU¿OWUDWLRQFDUWULGJHZLWKWKH52
¿OWHUFDQUHVXOWLQKROORZLFHFXEHV
Installation
A cold water supply is required for automatic
icemaker operation. The water pressure must be
between 40 psi and 120 psi.
Route 1/4 in. OD copper or GE SmartConnect™
plastic tubing between the house cold water line
and the water connection location.
The tubing should be long enough to extend to the
front of the refrigerator. Allow enough tubing to
accommodate the bend leading into the water line
connection.
NOTE: The only GE-approved plastic tubing is
supplied in the GE SmartConnect™ Refrigerator
Tubing kits. Do not use any other plastic water
supply line, because the line is under pressure at all
times. Other types of plastic may crack or rupture
with age and cause water damage to the home.
GE SmartConnect™ Refrigerator Tubing Kits are
available in the following lengths:
• 2 Feet (.6 m): (Part #: WX08X10002)
• 8 Feet (2.4 m): (Part #: WX08X10006)
• 15 Feet (4.6 m): (Part #: WX08X10015)
• 25 Feet (7.6 m): (Part #: WX08X10025)
ATTENTION: Commonwealth of Massachusetts
Plumbing Code 248CMR shall be adhered to.
Saddle valves are illegal and use is not permitted
in Massachusetts. Consult with a licensed plumber.
Water Line

– 12 –
These refrigerators are top heavy, especially with
any doors open, and must be secured to prevent
tipping forward which could result in death or
serious injury.
IMPORTANT: When the refrigerator is installed
XQGHUDVRȻWRULIWKHUHLVQRWHQRXJKKHLJKW
for this method of security using the anti-tip wall
bracket, proceed to the Level Refrigerator section
for leveling instructions, and then to the Secure
Refrigerator To Cabinetry section to secure the
refrigerator to the cabinets.
The refrigerator MUST be secured to prevent tipping.
Anti-Tip Device
WARNING Tip Over Hazard!
1. The “L” rod can be found in the upper left corner
of the unit in the access compartment. Look
through the access compartment to make sure
the rod lines up with the anti-tip bracket.
2. There are two washers and a hair pin cotter with
the rod. Remove the washers and hair pin cotter
from the end of the rod.
3. Rotate and move the “L” rod into the slot in the
anti-tip bracket tab. Once it is in the slot, rotate
the “L” rod so the hook portion is pointing down.
The holes at the front end of the rod should be in
a vertical position.
4. Pull out on the end of the rod to make sure it is
secure in the bracket.
5. Locate the hole on the rod that is closest to the
unit. A hair pin cotter will be put through this
hole to secure the rod. If this hole appears to be
WRRIDUDZD\IRUDVQXJ¿WDJDLQVWWKHXQLWDGG
WKHZDVKHUVRQHDWDWLPHXQWLOWKHSLQZLOO¿W
tightly into the hole.
6. Align the straight section of the pin with the hole
from the underside of the rod. Push the pin up
until it snaps into position. Pliers may be used.
NOTE: The hair pin cotter must be vertical when
this step is completed to ensure the “L” rod is
engaged in the bracket.
7. Check the rod for tightness by pulling forward. If
the rod moves, remove the hair pin cotter and
place another washer on the rod. Reinsert the
pin.
'L' Rod Pointing Down
Engaged in Bracket
Washer
'L' Rod Pointing Down
Engaged in Bracket
Hair Pin Cotter
is Vertical
Washer
Whenever possible, perform these steps in addition
to the Anti-Tip Device procedures for anti-tip
security. The refrigerator must be secured to
prevent tipping.
1. Raise the grille panel to access the case trim.
2. Drill a hole in the trim and drive a screw through
the trim into the adjacent cabinet.
3. Follow the same procedure on the opposite side.
Secure Refrigerator to Cabinetry
Drive Screws Through Case Trip and Into Adjacent
Cabinets

– 13 –
All models have 4-point leveling. The front is
supported by leveling legs, the rear is supported
by adjustable wheels. Both are accessible from the
front of the refrigerator.
• To level the back of the refrigerator, turn the
7/16 in. hex nut located above the front wheels.
Turn clockwise to raise, or counter-clockwise to
lower the refrigerator.
• For front leveling, use a 1-1/4 in. open-end
wrench.
• Adjust the height of refrigerator to match
installation cutout opening 83-1/2 inches to 84-
1/2 inches. The refrigerator should be level and
plumb with the cabinetry.
The rear leveling wheels and front leveling legs are
limited to a maximum height adjustment of 1 inch.
If the installation requires more than 84-1/2 inch
height, the installer should elevate the refrigerator
on a sheet of plywood or runners. Cabinetry trim
could also be added across the top of the opening
to shorten the opening. Any attempt to raise the
refrigerator more than 1 inch will damage the front
leveling legs and the rear leveling wheels.
CAUTION
Level Refrigerator
Hex Nut Adjusts
Rear Wheels
Leveling
Leg
1. Locate and bring tubing to the front of the
cabinet.
2. 7XUQWKHZDWHURQWRÀXVKDQ\GHEULVIURPWKH
line. Run about a quart of water through the
WXELQJLQWRDEXFNHWWKHQVKXWRȺWKHZDWHU
Copper Tubing:
3. Slip a 1/4 in. nut and ferrule (provided) over both
ends of the copper tubing. Insert tube into the
XQLRQ¿WWLQJRQWKHXQLWDQGWLJKWHQWKHQXWWR
the union.
4. Turn on the water to check for leaks.
GE SmartConnect™ Tubing:
3. Insert the molded end of the tubing into
the refrigerator connection. Tighten the
compression nut until it is just hand-tight.
4. Tighten one additional turn with a wrench.
Overtightening can cause leaks!
5. Turn on the water to check for leaks.
NOTE:Make sure any excess tubing length does
not interfere with drawer closing or the toe kick
installation.
Connect Water Supply
House Water
Supply Refrigeration
Water Supply

– 14 –
NOTE: This refrigerator has a 2-position door stop.
When space does not allow the door to swing open
fully to 130 degrees, change the door swing to a 90
degree opening. Skip this step if the door opening is
satisfactory for the installation situation.
1. Lift the grille panel to access the wire cover trim.
2. Remove the screws on both sides of the wire
FRYHUWULPDQGURWDWHRȺ
3. Use pliers to unscrew the door stop and reinstall
into the 90 degree position.
4. Reinstall the wire cover trim.
Adjust Door Swing
Remove Wire Cover
Trim Screws
Pin Location for
90 deg Door
Swing Pin Location
as Shipped
130 deg Door
Swing
Stand away from the refrigerator to inspect the door
alignment.
Installation or the addition of heavy door panels
may have caused the doors to move slightly out of
alignment. Check to be sure the top of the doors
are evenly aligned with each other. If necessary, the
doors may be adjusted up or down to align.
Add or remove shims as shown to adjust the right
door only. More shims are located in the machine
compartment on the left side in the bag with the
¿OWHUE\SDVVSOXJDQGPLQLPDQXDO
To Raise Right-Hand Door
1. Lift the right-hand door up so there is a gap
below the bottom hinge bushing.
2. Snap a shim onto the hinge pin below the
bushing.
3. Lower the door and re-check the alignment.
4. Repeat as necessary.
To Lower Right-Hand Door
1. Lift the right-hand door up so there is a gap
below the bottom hinge bushing.
2. 5HPRYHDVKLPE\SXVKLQJWKHVKLPRȺRIWKH
hinge pin.
3. Lower the door and re-check the alignment.
4. Repeat as necessary.
Door Alignment
Bag
Location
Shim
Fresh Food Doors

– 15 –
Some door bins are adjustable and can be moved
up and down to meet storage needs.
NOTE: The deeper door bins must be placed at the
bottom of the door only.
To remove: Lift the bin up and pull it outward.
Door Bins
Fresh Food Door Removal
1. Remove the switch cover.
2. Using clamp plyers, remove the closure spring
from the actuator arm.
3. Using a 3/16 in. Allen wrench, remove the bolt
mounting the actuator arm to the door.
4. Remove the actuator arm.
5. Remove four T25 Torx screws to remove the
actuator and hinge.
6. The left door will need to have the pins extracted
from the two pin connector to allow the door
harness to be pulled though the hinge. For door
or hinge replacement, the connector will need
to be reused.
Fresh Food Doors

– 16 –
Mullion Removal
1. Remove two T15 Torx screws at the top of the
door securing the wire cover, then remove the
cover.
2. Disconnect the mullion connector.
NOTE: If removing the mullion to replace the door,
proceed to step 4.
3. Remove the wires from the connector. The
connector will need to be reused for the
replacement mullion.
4. Remove two T15 Torx screws from the top hinge.
NOTE: If removing the mullion to replace the door,
proceed to step 6.
5. Slide the KLQJHRȺRIWKHZLULQJ
6. /LIWWKHPXOOLRQRȺRIWKHERWWRPhinge.
Diagnosing
The heater can be checked at the main board or
at the mullion connector. The mullion heater has a
resistance of 21.5 ohms.
Main board check
• J4 pin 2 (brown) - J2 pin 7 (violet) = 13 VDC
Mullion connector check
• Red and black wires under the wire cover.
NOTE: If no voltage is found at the main board or
the connector, it may be necessary to disconnect
the humidity sensor for 20 minutes to ensure the
main board is supplying voltage to the circuit.
The vertical mullion is located on the left fresh
food door. The mullion contains a heater which is
supplied with 13 VDC from the main board. Heater
operation is regulated by the humidity sensor
reading.
The vertical mullion heater is controlled by the
main board software logic. The main control
board takes into account the percentage of room
humidity, room temperature, and either freezer
or fresh food temperatures. As the room humidity
increases, the amount of voltage supplied to the
heaters is increased to keep the mullion surfaces
from sweating. At lowest humidity, the articulating
GRRUPXOOLRQPD\WXUQRȺFRPSOHWHO\7KHKHDWHU
is controlled automatically by the board based on
thermistor and humidity sensor input.
Every 20 minutes, the main control board utilizes
a duty cycle to monitor and react to the condition
of the humidity sensor. Control board corrections,
LIQHHGHGDUHPDGHDWDVSHFL¿FWLPHSHULRG
during the duty cycle. If the control detects a failed
humidity sensor the mullion heater will be operated
at 100%.
Vertical Mullion

– 17 –
Mullion Reinstallation
When reinstalling the mullion, ensure the mullion
spring is seated in the recess of the door, as shown
in the image below.

– 18 –
The freezer drawer closer is mounted to the right
front of the freezer liner, just below the main freezer
drawer slide assembly. It is mounted with two
Phillips screws. The mounting holes in the bracket
are slotted for adjustability.
Freezer Drawer Front Removal
1. Remove the lower freezer basket.
2. Loosen 1/4 to 1/2 inch, but do not remove
the eight #3 Phillips screws (four per bracket),
holding the 'L' brackets to the front drawer
panel.
3. The holes in the 'L' bracket are key hole shaped.
Pick up on the drawer front to allow the screw
heads to align with the larger opening of the
bracket holes, then pull drawer outward.
Freezer Drawer
Tabs Fit Into Slots
on Side Brackets
• Lift straight up until the tabs on the sides
disengage from the slots on the slide
brackets.
• Rotate the front of the basket about 90° and
pull up and out.
Drawer Closer
Freezer Drawer Front Panel

– 19 –
The main freezer drawer slide assemblies are
attached to the drawer front, and are mounted to
the sides of the freezer interior with three T20 Torx
screws per side. The slide must be extended to
expose the front screw. The center and rear holes
are slotted for adjustment to obtain proper sealing
of the drawer gasket to the cabinet frame. It is
not necessary to remove the slides to remove the
evaporator cover.
The upper freezer drawer slide assemblies are
mounted just above the main slides to the sides
of the freezer interior with three Phillips screws per
side. The slide must be extended to expose the front
and middle screws. It is not necessary to remove the
slides to remove the evaporator cover.
Main Drawer Slides
Upper Drawer Slides

– 20 –
Fresh Food
1. Fresh food door switches
2. Top mullion striker
3. Inlet air passages
4. HMI assembly
5. Vegetable pan slides
6. Deli pan slides
7. Return air passage
8. Lower LED lighting
9. Upper LED lighting
10. Fresh food thermistors
12
3
4
55
66
7 8
9
10
3
