Dimensions and Installation Information (in inches)
Overall
Dimensions
Height to top of hinge (in.) A 69-1/4
Height to top of case (in.) B 68-3/4
Case depth without door (in.) C†23-7/8
Case depth less door handle (in.) D†26-3/4
Case depth with door handle (in.) E†29-3/16
Depth with fresh food door open 90° (in.) F†45-9/16
Width (in.) G 35-3/4
Width with door open 90° inc. door handle (in.) H 41
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1/2
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
PSC23MST
GE Profile CustomStyle™22.6 Cu. Ft. Stainless Side-by-Side Refrigerator with Dispenser
Specification Revised 10/06 210205
Listed by
Underwriters
Laboratories

Rough-In Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Installation Tips to Maximize the Built-In Look
• All wall/floor molding should be removed prior to installation.
• Water recess on rear wall recommended to prevent water
line damage. 48" minimum length, 1/4" diameter water
line tubing recommended.
• When possible, recess both copper water line and electrical
outlet. (See local codes)
• Front and rear leveling legs are adjustable for the built-in look.
(See owner’s manual)
25"
Counter
Top
ElectricalWater
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
ElectricalWater
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
25"
Counter
Top
Electrical Water
Trim
3/4" Airspace
(1/2" Gap + 1/4"
Wall Plates)
24"
Cabinet
FOR 21 CUBIC FOOT MODELS
FOR 24 CUBIC FOOT MODELS
Fig 2A eps
8' Ceiling
13" to 14"
Cabinet
12"
Soffit
36-1/8"
24-1/2"
*The rough-in dimensions of 70-1/4"/72-1/4" are minimum and measured from
the finished floor to top of opening (or the underside of the overhead cabinets).
For Models with Trim Kit: If frameless style cabinets are planned for above the
refrigerator, you may need to consider adding a maximum of 1/4" (70-1/2") to
height of opening for 23 cu. ft. models and 1/8" (72-3/8") for 25 cu. ft. models
to allow additional clearance between cabinet doors and top of refrigerator trim
when cabinet doors are in open position.
Collar Trim In. w/ceiling
70-1/4"*
23 cu. ft. models
72-1/4"*
25 cu. ft. models
PSC23MST
GE Profile CustomStyle™22.6 Cu. Ft. Stainless Side-by-Side Refrigerator with Dispenser
Specification Revised 10/06 210205
Listed by
Underwriters
Laboratories
*The rough-in dimensions of 70-1/4”/72-1/4” are minimum and measured from the finished
floor to top of opening (or the underside of the overhead cabinets) For Models with Trim Kit:
If frameless style cabinets are planned for above the refrigerator, you may need to consider
adding a maximum of 1/4” (70-1/2”) to height of opening for 23 cu. ft. models and
1/8” (72-3/8”) for 25 cu. ft. models to allow additional clearance between cabinet doors
and top of refrigerator trim when cabinet doors are in open position.

PSS23MSTSS
PSS26MSTSS
WATER
LOCK
Hold3seconds
CRUSHED
DOOR
ALARM
CUBED
LIGHT
Hold3seconds to Reset
QUICKICE
RSET
FILTER
PSC23MST
GE Profile CustomStyle™22.6 Cu. Ft. Stainless Side-by-Side Refrigerator with Dispenser
Features and Benefits
• Stainless Steel Exterior - Convey a look of utmost polish and sophistication
• CustomStyle™Configuration - Offers a built-in look without the built-in expense
• ClimateKeeper™System - Best Temperature Management System You Can Buy!
• ExpressChill with 3 settings - Chills beverages quickly. Select 15, 30 or 45 minute with easy
one button selection
• Electronic Controls with Actual Temperature Display - Eliminates guesswork in setting
refrigerator temperatures
• Tall LightTouch! Dispenser with Child Lock - Delivers chilled water, cubed ice or crushed ice at
the slightest touch. A child lockout option keeps the dispenser off limits to little hands
• Slide ‘n Store™Full-Extension Freezer Baskets - Extends 12” to 16” beyond the cabinet,
providing easy loading and unloading
• Quick Ice™Option - Makes ice up to 50% faster than normal settings-ideal for entertaining
• TurboCool™Setting - “Revs up” the refrigerator, cooling it quickly after frequent door openings
• Integrated Ice™System - Frees up valuable freezer space. It tilts down, providing easy access
to bulk ice
• Tilt-Out Freezer Door Bins - Move forward for convenient access
• Integrated Shelf Support System - Provides strong, yet flexible support
• Model PSC23MSTSS - Stainless steel
