GE TBM18JAC WW User manual

Refrigerators
Models
TBM18JAC AA
TBM18JAC WW
TBM18GAD WW
Owner’s Manual
Top-mount no-frost
Part No. 162D9640P002 Pub. No. 49-60082 2-00 JR
PEPSI PEPSI PEPSI
PEPSI
FullDay's
FullDay's
Supplyof
Supplyof
FullDay's
FullDay's
Supplyof
Supplyof
015
MR
GE Appliances
Read me to get the most from
this appliance!

Safety Information
Safety Precautions . . . . . . . . . . . . . 3
Proper Disposal . . . . . . . . . . . . . . . . 3
Use of Extension Cords . . . . . . . . . . 3
How to Connect Electricity . . . . . . . 4
Use of Adapter Plugs . . . . . . . . . . . 4
Operating Instructions
Controls . . . . . . . . . . . . . . . . . . . . . 5
Features . . . . . . . . . . . . . . . . . . . . 6–9
Automatic Icemaker . . . . . . . . . . . 10
Ice and Water Dispenser . . . . . . . 11
Care and Cleaning . . . . . . . . . . 12, 13
Replacing the Light Bulbs . . . . . . . 13
Installation Instructions
Preparing to
Install the Refrigerator . . . . . . . . . 14
Troubleshooting Tips
Normal Operating Sounds . . . . . . 15
Before You
Call For Service . . . . . . . . . . . . 15–17
2
FOR YOUR RECORDS
Write the model and serial numbers here:
#
#
You can find them on a label on the left side, near the top of
the fresh food compartment.
Inside you will find many helpful hints on how to use and
maintain your refrigerator properly. Just a little preventive care
on your part can save you a great deal of time and money over
the life of your refrigerator.
You’ll find many answers to common problems in the
Before You Call For Service section. If you review our chart
of Troubleshooting Tips first, you may not need to call for
service at all.
READ THIS MANUAL
Customer Service
Specifications . . . . . . . . . . . . . . . . 18
Service . . . . . . . . . . . . . . . . . . . . . . 19
Warranty . . . . . . . . . . . . . Back Cover

3
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
■This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used.
■Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
■Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.
■Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
■In refrigerators with automatic icemakers,
avoid contact with the moving parts of the
ejector mechanism, or with the heating
element that releases the cubes. Do not place
fingers or hands on the automatic icemaking
mechanism while the refrigerator is plugged in.
■Keep fingers out of the “pinch point” areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
■Unplug the refrigerator before cleaning and
making repairs.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
■Turning the control to the OFF position does
not remove power to the light circuit.
■Do not refreeze frozen foods which have
thawed completely.
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators are still dangerous…even if they
will sit for “just a few days.” If you are getting
rid of your old refrigerator, please follow the
instructions below to help prevent accidents.
Before You Throw Away Your Old
Refrigerator or Freezer:
■Take off the doors.
■Leave the shelves in place so that children
may not easily climb inside.
USE OF EXTENSION CORDS
Because of potential safety hazards under
certain conditions, we strongly recommend
against the use of an extension cord.
However, if you must use an extension cord, it is
absolutely necessary that it be an approved 3-wire
grounding type appliance extension cord having
a grounding type plug and outlet and that meets
local regulations and standards. The electrical
rating of the cord must be 15 amperes (minimum)
and 120 volts.
DANGER! RISK OF CHILD ENTRAPMENT

4
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For
personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
If the outlet is a standard 2-prong outlet, it is
your personal responsibility and obligation to
have it replaced with a properly grounded
3-prong wall outlet.
The refrigerator should always be plugged into
its own individual electrical outlet which has a
voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull
straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
USE OF ADAPTER PLUGS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an adapter plug.
However, if you must use an adapter, where local
codes permit, a temporary connection may be made
to a properly grounded 2-prong wall outlet by use
of an approved adapter that meets local
regulations and standards.
The larger slot in the adapter must be aligned with
the larger slot in the wall outlet to provide proper
polarity in the connection of the power cord.
When disconnecting the power cord from the
adapter, always hold the adapter in place with
one hand while pulling the power cord plug with
the other hand. If this is not done, the adapter
ground terminal is very likely to break with
repeated use.
If the adapter ground terminal breaks, DO NOT
USE the refrigerator until a proper ground has
been established.
Attaching the adapter ground terminal to a wall outlet
cover screw does not ground the appliance unless the
cover screw is metal, and not insulated, and the wall
outlet is grounded through the house wiring. You should
have the circuit checked by a qualified electrician to make
sure the outlet is properly grounded.
Read and follow this Safety Information carefully.
SAVE THESE INSTRUCTIONS

5
About the controls on the refrigerator.
Control Settings
Fresh Food Control
The fresh food control maintains the temperatures throughout the refrigerator.
Moving the fresh food control to OFF stops cooling in both areas—fresh food and freezer—but does
not shut off power to the refrigerator.
Freezer Control
The freezer control moves a damper to change the amount of cold air that moves from the freezer
to the fresh food compartment.
How To Test Temperatures
Use the milk test for the fresh food compartment. Place a container of milk on the top shelf and check
it a day later. If the milk is too warm or too cold, adjust the temperature controls.
Use the ice cream test for the freezer compartment. Place a container of ice cream in the center of the
freezer and check it after a day. If it’s too hard or too soft, adjust the temperature controls.
After changing the controls, allow 24 hours for the refrigerator to reach the temperature you have set.
Power Saver Switch
Push switch to the POWER SAVER setting to reduce the amount of electricity required to operate
your refrigerator.
With this switch turned to the POWER SAVER setting, moisture may form on the outside of the
refrigerator, especially when the weather is humid.
Over time, moisture that forms on the surface may cause rust.
To prevent moisture on the outside, move the power saver switch from the POWER SAVER setting.
Cost? About the same as it costs to use 2 night lights.
The temperature controls on your refrigerator have letters and
numbers. Initially set the fresh food control at 5and the freezer
control at C.
If you want colder or warmer temperatures, adjust the fresh
food temperature first. When satisfied with that setting, adjust
the freezer temperature.
1
3
5
7
OFF
9
5INITIAL SETTING
9COLDEST
FRESH FOOD
E
D
C
B
A
INITIAL SETTING C
COLDEST E
FREEZER A
CE
Cold air
from freezer
compartment
(Warmest
setting)
Damper
(Coldest
setting)
Damper
Side View

6
About the refrigerator shelves, dishes and bins.
Not all features are on all models.
Quick Serve™ System
CAUTION: Dishes and lids are not
designed for use on the range top, broiler
or in the regular oven. Such use can be
hazardous.
Quick Serve™ dishes fit into a rack that
hangs on the fresh food or freezer door.
The rack can be moved in the same manner
as the door bins.
Dishes and lids are safe for use in microwave
ovens, refrigerators and freezers.
Do not use when cooking high-fat foods, such as
bacon, and high-sugar foods, such as candy and
syrup. The high temperatures of the fat and sugar
can cause bubbles to form on the inside of the dish.
Quick Store Bin
To avoid damaging the refrigerator, make
sure the bin is closed and latched before
closing the refrigerator door.
This bin can be placed on the fresh food or
freezer door.
To remove the bin, lift up and out of the
bin housing.
To move, lift the bin housing up and out of
the supports on the door. You do not have
to remove the bin from the housing when
moving it.
QUICK S
Pull forward
2
To open:
Bin Housing
Push up
1
Quick Store Bin
Rearranging the Shelves
Shelves in the fresh food and freezer compartments are adjustable.
To Remove To Replace
Lift up and out
2
Insert
top hook
1
Lower to
lock in place
2
Tilt up
1

7
About the storage drawers.
Not all features are on all models.
Fruit and Vegetable Drawers
Excess water that may accumulate in the
bottom of the drawers should be emptied
and the drawers wiped dry.
Adjustable Humidity Drawers
Slide the control all the way to the HIGH
setting to provide high humidity
recommended for most vegetables.
Slide the control all the way to the LOW
setting to provide lower humidity levels
recommended for most fruits.
Snacks Drawer
The snacks drawer can be moved to the most
useful location for your family’s needs.
Adjustable Temperature Meat Drawer
When the drawer is placed in the top 6 slots
on the left side and the lever is set at
COLDEST, air from the freezer is forced
around the drawer to keep it very cold.
You can move the drawer to any location if
you don’t want the extra cold storage.
The settings can be adjusted anywhere
between COLD and COLDEST.
When set at COLD, the drawer will stay at the
normal refrigerator temperature.
The COLDEST setting provides the coldest
storage area.

8
About storage drawer and cover removal.
Not all features are on all models.
Storage Drawers
To Remove:
These drawers can be removed easily by
lifting up slightly while pulling the drawers
past the stop location.
When the door cannot be opened enough
to pull the drawer straight out, slide the
drawer toward the middle and remove it.
Remove the glass, then the frame. When
replacing the glass, push the rear edge
firmly into the frame.
2
4
3
1
Step 1
About the additional features.
Not all features are on all models.
Snuggers
Place a finger on either side of the snugger
near the front to move the snugger back
and forth to fit your needs.
Step 2
2
4
3
11
Step 3

9
Condiment Caddy
The condiment caddy keeps frequently
used condiments together. It fits in your
refrigerator door shelf. A convenient
handle allows condiments to be easily
carried to the table.
Beverage Rack
Slide-out beverage rack holds twelve
cans of soda or two wine/water bottles
(lengthwise). Can be removed for cleaning.
Two-Position Freezer Shelf
For models without an icemaker, the shelf
can be placed in either position.
For models with an icemaker, the shelf
must be placed in the lower position.
Extra Freezer Shelf
Bins on the Doors
Baking Soda Holder

10
Automatic Icemaker (on some models)
The icemaker will produce eight cubes
per cycle—approximately 100 cubes in
a 24-hour period, depending on freezer
compartment temperature, room
temperature, number of door openings
and other use conditions.
If the refrigerator is operated before
the water connection is made to the
icemaker, keep the feeler arm in the
STOP (up) position.
When the refrigerator has been connected
to the water supply, move the feeler arm to
the ON (down) position.
The icemaker will fill with water when
it cools to freezing. A newly-installed
refrigerator may take 8 to 12 hours to
begin making ice cubes.
Throw away the first few batches of ice to
allow the water line to clear.
Be sure nothing interferes with the swing of
the feeler arm.
It is normal for several cubes to be
joined together.
If ice is not used frequently, old ice cubes
will become cloudy and taste stale.
About the automatic icemaker.
A newly-installed refrigerator may take 8 to 12 hours to begin making ice.
Icemaker
Ice Storage Bin
Feeler arm
in the STOP
(up) position
Feeler arm
in the ON
(down) position
Icemaker Accessory Kit
If your refrigerator did not already come
equipped with an automatic icemaker,
an icemaker accessory kit is available at
extra cost.
Check the back of the refrigerator for
the specific icemaker kit needed for
your model.
Feeler arm in the
STOP (up) position
Feeler arm on the dispenser model.

To Use the Dispenser
Press the rim of the glass gently against the
dispenser pad.
Select ICE CUBES, CRUSHED ICE or WATER
(on some models).
The spill shelf is not self-draining. To
reduce water spotting, the shelf and its
grille should be cleaned regularly.
If no water is dispensed when the refrigerator is
first installed, there may be air in the water line
system. Press the dispenser pad for at least two
minutes to remove trapped air from the water line
and to fill the water system. To flush out impurities
in the water line, throw away the first six glassfuls
of water.
CAUTION: Never put fingers or any other
objects into the ice crusher discharge opening.
About the ice dispenser.
On some models
Ice Storage Bin
To remove:
Lift the front of the bin and pull the bin
straight out while supporting it at front
and rear.
To replace:
Slide it back on the ice bin shelf. If the bin
does not go all the way back, remove it and
rotate the drive mechanism 1/4 turn. Then
push the bin back again.
Rotate
Drive
Mechanism
Important Facts About Your Dispenser
■Add ice before filling the glass with a
beverage. This will prevent splashing,
which could cause the ice selector switch
to stick or bind.
■Do not add ice from trays or bags to
the storage bin. It may not crush or
dispense well.
■Avoid overfilling glass with ice and use of
narrow or extra-tall glasses. Backed-up ice
can jam the chute or cause the door in the
chute to freeze shut. If ice is blocking the
chute, poke it through with a wooden spoon.
■Beverages and foods should not be quick-
chilled in the ice storage bin. Cans, bottles
or food packages in the storage bin may
cause the icemaker or auger to jam.
■Some crushed ice may be dispensed even
though you selected ICE CUBES. This
happens occasionally when a few cubes
accidentally get directed to the crusher.
■After crushed ice is dispensed, some
water may drip from the chute.
■Sometimes a mound of snow will form on
the door in the ice chute. This condition
is normal and usually occurs when you
have dispensed crushed ice repeatedly.
The snow will eventually evaporate.
■Dispensed water is not ice cold. For colder
water, add crushed ice or cubes before
dispensing water.
Water Filter Accessory
The water filter is an option at extra cost
and is available from your dealer. Specify
WR97X0214. It has complete installation
instructions and installs on 1/4″O.D.
copper water line.
Spill Shelf
11

12
Care and cleaning of the refrigerator.
Cleaning the Outside
The dispenser well (on some models),
beneath the grille, should be wiped dry.
Water left in the well may leave deposits.
Remove the deposits by adding undiluted
vinegar to the well. Soak until the deposits
disappear or become loose enough to
rinse away.
The dispenser pad (on some models). Clean
with warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda
to a quart (1 l) of water. Rinse thoroughly
and wipe dry.
HINT: Open the freezer door part way to prevent
dispensing of ice when cleaning.
The door handles and trim (on some
models). Clean with a cloth dampened
with soapy water. Dry with a soft cloth.
The soft door handles (on some models) are
easy to keep clean if they are waxed every
few months. Use a household wax such as
Pledge brand or Jubilee brand to coat the
handles. Clean with soapy water or a non-
abrasive, all-purpose cleaner.
Keep the outside clean. Wipe with a clean
cloth lightly dampened with kitchen
appliance wax or mild liquid dish
detergent. Dry and polish with a clean,
soft cloth.
Do not wipe the refrigerator with a soiled dish
cloth or wet towel. These may leave a residue
that can erode the paint. Do not use scouring
pads, powdered cleaners, bleach or cleaners
containing bleach because these products can
scratch and weaken the paint finish.
Press here to
remove grille.
Cleaning the Inside
To help prevent odors, leave an open box of
baking soda in the fresh food and freezer
compartments.
Unplug the refrigerator before cleaning. If this
is not practical, wring excess moisture out
of sponge or cloth when cleaning around
switches, lights or controls.
Use an appliance wax polish on the inside
surface between the doors.
Use warm water and baking soda solution—
about a tablespoon (15 ml) of baking soda
to a quart (1 l) of water. This both cleans
and neutralizes odors. Rinse and wipe dry.
After cleaning the door gaskets, apply a
thin layer of petroleum jelly to the door
gaskets at the hinge side. This helps keep
the gaskets from sticking and bending out
of shape.
Avoid cleaning cold glass shelves (on some
models) with hot water because the extreme
temperature difference may cause them to
break. Handle glass shelves carefully. Bumping
tempered glass can cause it to shatter.
Do not wash any plastic refrigerator parts in
the dishwasher except Quick Serve dishes
and lids.
Under the Refrigerator
For most efficient operation, keep the area
under the refrigerator clean. Remove the
base grille and sweep away or vacuum
up dust.
For best results, use a brush specially
designed for this purpose. It is available
at most appliance parts stores.
Clean the condenser coils at least
once a year.

13
Behind the Refrigerator
Be careful when moving the refrigerator away
from the wall. All types of floor coverings can
be damaged, particularly cushioned coverings
and those with embossed surfaces.
Pull the refrigerator straight out and return it
to position by pushing it straight in. Moving the
refrigerator in a side direction may result in
damage to the floor covering or refrigerator.
When pushing the refrigerator back, make
sure you don’t roll over the power cord or
icemaker supply line.
Preparing for Vacation
For long vacations or absences, remove
food and unplug the refrigerator. Move the
freezer control to the OFF position, and
clean the interior with a baking soda
solution of one tablespoon (15 ml) of
baking soda to one quart (1 l) of water.
Leave the doors open.
Move the icemaker feeler arm to the STOP
(up) position and shut off the water supply
to the refrigerator.
If the temperature can drop below freezing,
have a qualified servicer drain the water
supply system to prevent serious property
damage due to flooding.
Light Bulb Replacement
To replace a burned-out bulb, unplug
the refrigerator from its electrical outlet,
remove the light shield, unscrew the bulb
when cool and replace it with an appliance
bulb of the same or lower wattage.
Turning the control to the OFF position does not
remove power to the light circuit.
Preparing to Move
If the doors need to be removed, see the
Removing the doors section.
Secure all loose items such as grille, shelves
and drawers by taping them securely in
place to prevent damage.
Be sure the refrigerator stays in an upright
position during moving.

14
Preparing to install the refrigerator.
Read these instructions completely and carefully.
Water Supply to the Icemaker (on some models)
If the refrigerator has an icemaker, it will have to be
connected to a cold water line.
A water supply kit (containing copper tubing,
shutoff valve, fittings and instructions) is available
at extra cost from your dealer.
Refrigerator Location
Do not install the refrigerator where the
temperature will go below 60°F (16°C)
because it will not run often enough to
maintain proper temperatures.
Install it on a floor strong enough to support it
fully loaded.
Clearances
Allow the following clearances for ease of
installation, proper air circulation and
plumbing and electrical connections:
Sides ..............................3/4″(19 mm)
Top................................1″(25 mm)
Back ..............................1″(25 mm)
If a 19′, 22′or 25′model is to be installed next to
a wall on the hinge side, allow 11⁄2″ (38 mm) for
door clearance.
Rollers (on some models)
The rollers have 3 purposes:
Rollers adjust so the door closes easily when
opened about halfway. [Raise the front about
3/4″(19 mm) from the floor.]
Rollers adjust so the refrigerator is firmly
positioned on the floor and does not wobble.
Rollers allow you to move the refrigerator away
from the wall for cleaning.
To adjust the rollers:
Remove the base grille
by pulling out at the
bottom.
Turn the two front
roller adjusting screws
clockwise to raise the
refrigerator, counter-
clockwise to lower it.
Replace the base grille
by pushing forward
until it snaps into place.
3
2
1

15
Normal operating sounds.
Depending on the placement of the refrigerator in your kitchen, you may want to place a piece of
rubber-backed carpet under the refrigerator to reduce noise.
Icemaker (on some models). Occasionally you will hear ice cubes dropping
into the ice bin. If this is your first icemaker, you’ll hear occasional sounds that
may be unfamiliar. They are normal icemaking sounds and are not a cause
for concern.
Evaporator Fan. You may hear air being forced through the cabinet by the fan.
Evaporator. The flow of refrigerant through the evaporator may create a boiling
or gurgling sound.
Defrost Heater. During defrost cycles, water dripping onto the heater may cause
a hissing or sizzling sound. After defrosting, a popping sound may occur and
the evaporator may create a boiling or gurgling sound.
Cold Control & Defrost Timer. These parts can produce a snapping sound when
turning the refrigerator on or off. The timer also produces a sound similar to
an electric clock.
Plastic Liner. Cracking or popping sounds due to expansion of the plastic liner.
Water Valve (on models equipped with an automatic icemaker). When the
icemaker fills with water, a buzzing sound and running water will be heard.
Water Pan. Water may be heard running into the drain pan during the
defrost cycle.
Compressor. Modern, high efficiency compressors operate much faster
than older models. The compressor may have a high pitched hum or
pulsating sound.
Condenser Fan. You may hear air being forced over the condenser by the fan.
9
8
7
6
5
4
3
2
1
10
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Problem Possible Causes What To Do
Refrigerator does not Refrigerator in defrost cycle. •Wait about 30 minutes for defrost cycle to end.
operate
Fresh food control in OFF •Move the fresh food control to a temperature setting.
position.
Refrigerator is unplugged. •Push the plug completely into the outlet.
The fuse is blown/circuit •Replace fuse or reset the breaker.
breaker is tripped.
Vibration or rattling Rollers need adjusting. •See Rollers.
(slight vibration
is normal)
These sounds are normal
and are due mostly to highly
efficient operation.
12
3
4
5
6
7
8
9
10
(continued on next page)

16
Before you call for service…
Problem Possible Causes What To Do
Motor operates for Normal when refrigerator •Wait 24 hours for the refrigerator to completely
long periods or cycles is first plugged in. cool down.
on and off frequently.
Often occurs when large •This is normal.
(Modern refrigerators
amounts of food are
with more storage
placed in refrigerator.
space and a larger
Door left open. •Check to see if package is holding door open.
freezer require more
Hot weather or frequent •This is normal.
operating time. They
door openings.
start and stop often
Temperature controls •See About the controls.
to maintain even
set at the coldest setting.
temperatures.)
Grille and condenser •See Care and cleaning.
need cleaning.
Fresh food or freezer Temperature control not set •See About the controls.
compartment too warm cold enough.
Warm weather or frequent •Set the temperature control one step colder.
door openings. See About the controls.
Door left open. •Check to see if package is holding door open.
Package blocking air duct in •Check to see if package is blocking air duct in freezer
freezer compartment. compartment.
Frost or ice crystals Door left open. •Check to see if package is holding door open.
on frozen food
Too frequent or too long
(frost within package
door openings.
is normal)
Automatic icemaker Icemaker feeler arm in •Move the feeler arm to the ON (down) position.
does not work
the STOP (up) position. •Cubes may have fused to the side of the mold. Move
(on some models)
the feeler arm to the STOP (up) position then remove
the cubes.
Water supply turned off or
not connected.
Freezer compartment •Wait 24 hours for the refrigerator to completely
too warm. cool down.
Piled up cubes in the storage •Level cubes by hand.
bin cause the icemaker
to shut off.
Cubes too small Water shutoff valve connecting •Call the plumber to clear the valve.
refrigerator to water line may
be clogged.
Slow ice cube freezing Door left open. •Check to see if package is holding door open.
Temperature control not set •See About the controls.
cold enough.
Ice cubes have Ice storage bin needs cleaning. •Empty and wash bin. Discard old cubes.
odor/taste
Food transmitting odor/taste •Wrap foods well.
to ice cubes.
Interior of refrigerator •See Care and cleaning.
needs cleaning.

17
Problem Possible Causes What To Do
Moisture forms on Not unusual during •Wipe surface dry and make sure the power saver switch
cabinet surface periods of high humidity. is not set at the POWER SAVER setting.
between the doors
Moisture collects inside Too frequent or too
(in humid weather, air long door openings.
carries moisture into
refrigerator when doors
are opened)
Food freezing in Food too close to air vent. •Move the food away from the air vent (near the controls).
the refrigerator
Fresh food control is set •Move the fresh food control to a warmer
too cold. temperature.
Door does not close Rollers need adjusting. •See Rollers.
by itself
Cube dispenser does not Icemaker turned off or •Turn on icemaker or water supply.
work (on some models) water supply turned off.
Ice cubes are frozen to •Remove cubes and move the feeler arm to the
icemaker feeler arm. ON (down) position.
Irregular ice clumps in •Break up with fingertip pressure and discard
storage container. remaining clumps.
•Freezer may be too warm. Adjust the freezer control
to a colder setting, one position at a time, until
clumps do not form.
Refrigerator has odor Foods transmitting •Foods with strong odors should be tightly wrapped.
odor to refrigerator. •Keep an open box of baking soda in the refrigerator;
replace every three months.
Interior needs cleaning. •See Care and cleaning.
Hot air from bottom Normal air flow cooling •Your floor covering supplier should be consulted if
of refrigerator motor. In the refrigeration you object to this discoloration.
process, it is normal that
heat be expelled in the
area under the refrigerator.
Some floor coverings will
discolor at these normal
and safe temperatures.
Orange glow in the Defrost heater is on. •This is normal.
freezer

18
Specifications
General specifications of your refrigerator per model.
MANUFACTURER:
General Electric Co.
Appliance Park.
Louisville, Kentucky.
U.S.A. 40225
IMPORTER:
Mabe México S. de R. L. de C.V.
Insurgentes Sur 617-3er. piso, Col. Nápoles,
México, D.F. 03810
Tel. [phone]
015
MR
Model Nominal tension
(Volts)
Nominal frequency
(Hertz)
Nominal current
(Amperes)
Consumption
Kilowatt hour/year
TBM18JAC AA 127 V ~ ±10% 60 Hz 7.0 A 663.88
TBM18JAC WW
TBM18GAD WW

19
Service
UNICO SERVICIO DIRECTO DE FABRICAS
SERVIPLUS
MEXICO
Prol. Ings. Militares #156
Col. San Lorenzo Tlaltenango
C.P. 11210 México, D.F.
Tel: [phone]
Fax: [phone]
GUADALAJARA
Av. Las palmas #130-A
Col. San Carlos, Sec. Reforma
C.P. 44460 Guadalajara,
Jal. Tel. [phone] al 28
SAN LUIS POTOSI
Av. Nicolás Zapata #656,
Fracc. Tequisquiapan,
C.P. 78250
San Luis Potosí, S.L.P.,
Tel: [phone], y 06
TIJUANA
Calle 17 #217, Col. Libertad,
Parte Alta, C.P. 78250
Tijuana, B.C.,
Tel. [phone]
TOLUCA
Prol. Ings. Militares #156
Col. San Lorenzo Tlaltenango
C.P. 11210, Méx. D.F.
Tel: [phone]
VILLAHERMOSA
Av. Adolfo Ruíz Cortines Km.3
Local 1 C.P. 86100
Villahermosa, Tab.
Tel: [phone], 26 y 35
LEON
Prol. Juárez #2830-B, Col. Río
Escondido. C.P. 37450
León, Gto.
Tel. [phone] y 07.
SALTILLO
Av. Periférico Luis E. #386
Col. República Nte.
C.P. 25280, Saltillo, Coah.
Tel. [phone] y 8536
ENSENADA
Av. México #482
Fracc. California C.P. 22890
Ensenada B.C.N.
Tel: [phone]
NUEVO LAREDO
Calle Gutiérrez #4416
Col. Hidalgo.
Nuevo Laredo Tamps.
Tel: [phone]
MERIDA
Calle 27 #99 po la 16,
Col. Chichenitzá, C.P. 97170
Mérida, Yuc.
Tel. [phone] y 24,
(91-800) 03653
HERMOSILLO
García Morales #138
entre Morelia y Mty.
Col. Centro C.P. 83000.
Hermosillo, Sonora.
Tel. [phone] y 9977
CHIHUAHUA
Ocampo #4605 Col. Santa
Rosa C.P. 31050 Chihuahua,
Chih. Tel: [phone],
3725 y 1611
MATAMOROS
Porfirio Muñoz Ledo #22 Col.
Magisterial CEBETIS
Matamoros, Tamps.
Tel. [phone]
VERACRUZ
Barragán #65 Col. Ricardo
Flores Magón C.P. 91900
Veracruz, Ver.
Tel. [phone] y 34-44.
CULIACAN
Blvd. Emiliano Zapata #1585
Pte. Fracc. Los Pinos C.P.
80120 Culiacán, Sin.
Tel: [phone] y 04-58
TAMPICO
Jalisco #201 Pte. Col. Primero
de Mayo,
Cd. Madero Tamaulipas
Tel: [phone], 4666, y 1521
REYNOSA
Blvd. M. Hidalgo #530 Pte.
Col. Bellavista C.P. 88660
Reynosa, Tamaulipas
Tel: [phone] y 0571
PUEBLA
Calle 3 Pte. #916 Col. Centro
C.P. 72000 Puebla, Pue.
Tel. [phone] y 74
MONTERREY
Carretera Miguel Alemán
km 5 C.P. 67110
Cd. Guadalupe, N.L.
Tel: [phone]
CD. JUAREZ
Chimeneas s/n
Col. Parque Industrial Juárez
Cd. Juárez Chih.
Tel: [phone], 0801, y 0762
CD. OBREGON
Querétaro #720 C.P. 85140
Cd. Obregón, Sonora.
Tel: [phone]
ACAPULCO
Av. López Mateos #8
Fracc. Las Playas C.P. 39390
Acapulco, Gro.
Tel. [phone], 45, y 46.
TORREON
Simón Bolívar #832 Pte. esq.
Juan Terrazas.
Col. Amplición Los Angeles.
Torreón, Coah.
Tel: [phone], 43, y 49
MEXICALI
Circuito de Las Misiones #161
Parque Industrial
Las Californias C.P. 21600
Mexicali, B.C.N.
Tel: [phone]
QUERETARO
Av. 5 de Febrero #1325 Zona
Industrial Benito Juárez C.P.
76120 Querétaro, Qro.
Tel: [phone]
VENEZUELA
Caracas: [phone]
Maracaibo: (5861) 22-0131
Guacará: (58) 71-4198
COLOMBIA
Bogotá: [phone]
PERU
Lima: (14) 447-7122 y 0514
COSTA RICA
San José [phone]
ECUADOR
Guayaquil: (5934) 25-3494 y
25-1100
GUATEMALA
Guatemala: (5022) 69-2901
ONLY DIRECT SERVICE FROM THE FACTORY

2020
Warranty
✄
Mabe México S. de R.L. de C.V., offers you the following warranty under the following points:
■To make this warranty effective, no major requisites will be required other than the presentation of the
product and the corresponding warranty in the place where it was acquired or in any service center
indicated on the reverse, in which you will be able to obtain the repairs and parts for your product.
■Mabe México S. de R.L. de C.V. is obligated to repair or to replace the product if it cannot be repaired,
and also to replace any defective part or component without additional cost to the consumer,
including labor and transportation expenses derived from its obligation within its service net.
■The repair time in no case will be more than 30 days counted from the time the product is received in
any place where this can be done.
CONCEPTS COVERED BY THE WARRANTY
AND LIMITATIONS AND EXCEPTIONS THAT MAY EXIST
DURATION
WE WILL REPAIR THE PRODUCT WITHOUT
ADDITIONAL COST ACCORDING TO THE
FOLLOWING CONCEPTS
WE WILL NOT MAKE THE WARRANTY EFFECTIVE
IN THE FOLLOWING CASES
1 YEAR Replacing any defective part or
component and labor
■When the product has been used in conditions different to
the normal conditions (bumps or malfunctions caused by
mishandling or carelessness with the product).
■When the product has not been operated in accordance
with the operating instructions provided with it.
■When the product has been altered or repaired by NON
authorized people.
NOTE: In the same manner the consumer will be able to solicit that the warranty be made effective in the very same
commercial establishment where he acquired the product, in case Mabe México S. de R.L. de C.V. does not have a network
of service shops in that location.
THIS WARRANTY COVERS:
Product: Two Door Refrigerator Brand: General Electric Models: TBM18JAC AA,
TBM18JAC WW, TBM18GAD WW
TO BE FILLED OUT BY THE DISTRIBUTOR
Serial No. of the product ____________________________ Distributor_______________________
Street: ___________________________ No. __________ City Section _____________________
Zip Code ____ City ____________________ State _____________ Telephones _____________
DISTRIBUTOR
Seal and Delivery Date
IMPORTER:
MABE MEXICO S. DE R.L. DE C.V.
Ave. Insurgentes Sur 617 3er Piso Col. Nápoles
México D.F. C.P. 03810 Tel.: [phone]
015
MR
In case the warranty is lost, the consumer may go to the product provider in order to obtain another warranty policy, upon
previous presentation of the corresponding sales receipt or bill of sales which you must keep.
