TruVision Dome Installation Sheet
Description
© 2009 GE Security, Inc.
1 of 2
P/N 1069136 • REV 1.0 • ISS 27OCT09
The TruVision Dome is a high-resolution dome camera that that
can be used in retail, commercial, and residential environments.
The TruVision Dome uses a varifocal lens and offers custom
configurability.
Safety precautions
Read this installation sheet in its entirety before using the camera.
To avoid dangerous electrical shock or damage to the equipment,
do not try to disassemble the camera or any of its components.
Do not attempt to service this camera by yourself unless you are
authorized to do so. Opening the cover may expose you to
dangerous electrical shock or other hazards. Only a service
technician should perform this procedure.
Never point the camera at the sun and do not expose the lens
directly to the sun or strong light as this may damage the camera.
Handle the camera with care. The camera contains sensitive
components, avoid any shock or impact to the camera. Improper
handling can damage the camera.
The camera is designed for indoor use. Do not use the camera
when the temperature is lower than −10°C (14°F) or higher than
+50°C (122°F). For safe camera usage, the maximum humidity
should not exceed 85%. If the camera is placed in an extremely
dusty location, special housing may be needed to protect the
camera and lens.
Installation
Before installing the TruVision Dome, make sure that the location
is mechanically sound, protects the camera, and affords the
required views. Once the camera is securely mounted, follow the
procedure below to connect the camera. For power and video
connections see Figure 1 below. For camera dimensions see
Figure 2 and Figure 3 on page 2.
Figure 1: TruVision Dome camera power and video connections
To install the camera:
1. Fasten the camera to a wall or ceiling (or another solid
surface). The camera must be stable when connected.
2. Connect the 75 Ωcoaxial cable to the video output.
3. Connect the power cable to the camera.
4. Adjust the camera position and angle as required.
Camera dimensions
Figure 2: TruVision Dome dimensions - base attachment
All manuals and user guides at all-guides.com

Figure 3: TruVision dimensions - camera orientation
Maintenance
To clean inside and outside the camera, do not use any organic or
corrosive cleaning solutions. When cleaning the camera, turn off
the power, and use a clean cloth with some water.
Specifications
Pickup device 1/3 in. interline transfer CCD
Total pixels NTSC: 811 (H) x 508 (V)
PAL: 795 (H) x 596 (V)
Effective pixels NTSC: 768 (H) x 494 (V)
PAL: 752 (H) x 582 (V)
Resolution 500 TV lines
Synchronization system Internal synchronization
Scanning system NTSC: 525 lines / 60 fields
PAL: 625 lines / 50 fields
S/N ratio >48 dB
Electronic shutter Auto 1/60 (1/50)
Minimum illumination 0.2 lux at F2.0
Video output 1.0 Vp-p, 75 Ω
White balance Automatic
Lens type Board lens / DC varifocal lens
DC power source 12 VDC, 500 mA /24 VAC,185 mA
Power consumption <2.2 W max.
Operating temperature −10 to 50°C (14 to 122°F)
FCC information
Cautions
This device complies with Part 15 FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received including
interference that may cause undesired operation.
Compliance
This Equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the service technician is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Manufacturer GE Security, Inc., 8985 Town Center Parkway,
Bradenton, FL 34202, USA
Year of
manufacture
The first two digits of the product serial number
(located on the product identification label) are the
year of manufacture.
Certification
North American
standards
FCC Part 15, Subpart J, Class B
European Union
directives
2002/96/EC (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For
more information see: www.recyclethis.info.
2004/108/EC (EMC directive): Non-European
manufacturers must designate an authorized
representative in the Community. Our authorized
manufacturing representative is:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands.
Contact information
For contact information see our Web site: www.gesecurity.com.
