GE Appliances
Louisville, Kentucky 40225 31-9254
Technical Service Guide
May 2016
GE Appliances
GE 27" Top Load Washer
HTW200ASK_WW
MTW200AMK_WW
GTW220ACK_WW
HTW240ASK_WW
GTW330ASK_WW
GTW460ASJ_WW
GTW485ASJ_WW
GTW485ASJ_WS
GTW490ACJ_WW
GTW490ACJ_WS
GTW680BSJ_WS

– 2 –
Safety Information
IMPORTANT SAFETY NOTICE
The information in this service guide is intended for use by
individuals possessing adequate backgrounds of electrical,
electronic, and mechanical experience. Any attempt to repair a
major appliance may result in personal injury and property
damage. The manufacturer or seller cannot be responsible for the
interpretation of this information, nor can it assume any liability in
connection with its use.
WARNING
To avoid personal injury, disconnect power before servicing
this product. If electrical power is required for diagnosis or test
purposes, disconnect the power immediately after performing the
necessary checks.
RECONNECT ALL GROUNDING DEVICES
If grounding wires, screws, straps, clips, nuts, or washers used to
complete a path to ground are removed for service, they must be
returned to their original position and properly fastened.
GE Appliances
Technical Service Guide
Copyright © 2016
All rights reserved. This service guide may not be reproduced in whole or in part
in any form without written permission from GE Appliances.

– 3 –
Table of Contents
Safety Information..........................................................................................................................................................................2
Table of Contents............................................................................................................................................................................3
Safety Requirements......................................................................................................................................................................6
Nomenclature...................................................................................................................................................................................7
Introduction........................................................................................................................................................................................8
Control Features.............................................................................................................................................................................9
Operating Instructions..................................................................................................................................................................17
Consumer Help Indicator.............................................................................................................................................................21
3URGXFW6SHFL¿FDWLRQV ..................................................................................................................................................................22
Water Levels............................................................................................................................................................................22
Tools Needed..........................................................................................................................................................................23
Component Locator Views..........................................................................................................................................................24
Underside Top Cover 680 Model....................................................................................................................................24
Underside Top Cover 200, 220, 240, 330, 460, 485, 490 Models....................................................................25
Tub Assembly 680 Model..................................................................................................................................................26
Tub Assembly 680 Model.............................................................................................................................................................26
Tub Assembly 460 485 and 490 Models....................................................................................................................27
Dryer Components..........................................................................................................................................................................27
Tub Assembly 200, 220, 240, and 330 Models.......................................................................................................28
Backsplash Assembly Electronic 680 Model............................................................................................................29
Backsplash Assembly Analog Models.........................................................................................................................29
Control Board Electronic 680 Models..........................................................................................................................30
Control Board Analog Knob Models.............................................................................................................................30
Bottom View ...........................................................................................................................................................................31
Diagnostics.........................................................................................................................................................................................32
Consumer Error Mode (CEM)............................................................................................................................................32
Field Service Mode...............................................................................................................................................................32
Understanding The Binary Chart...................................................................................................................................33
Binary Chart Service Mode Tests...................................................................................................................................34
Service Mode Tests..............................................................................................................................................................35

– 4 –
Fault Codes..............................................................................................................................................................................39
Personality ID..........................................................................................................................................................................44
Cabinet and Structure...................................................................................................................................................................45
Backsplash ..............................................................................................................................................................................45
Lid ................................................................................................................................................................................................46
Lid Latch ...................................................................................................................................................................................46
Lid Switch/Lock Assembly................................................................................................................................................47
Lid Hinge...................................................................................................................................................................................48
Agitators....................................................................................................................................................................................48
Impeller .....................................................................................................................................................................................48
Dual Action Agitator............................................................................................................................................................49
Single Action Agitator.........................................................................................................................................................50
Top Cover..................................................................................................................................................................................51
Basket Assembly...................................................................................................................................................................51
Cabinet/Apron Assembly...................................................................................................................................................52
Leveling Legs..........................................................................................................................................................................52
Fill System...........................................................................................................................................................................................53
Water Valves...........................................................................................................................................................................53
Thermistor................................................................................................................................................................................54
Dispensers................................................................................................................................................................................55
Bleach Funnel ........................................................................................................................................................................55
Water Levels............................................................................................................................................................................56
Pressure Sensor.....................................................................................................................................................................56
Option Selector Switches..................................................................................................................................................56
Wash System.....................................................................................................................................................................................58
Recirculation Pump..............................................................................................................................................................58
Drain System.....................................................................................................................................................................................59
Drain Pump..............................................................................................................................................................................59
Drain Hose External.............................................................................................................................................................60
Drain Hose Internal..............................................................................................................................................................60
Drive System......................................................................................................................................................................................61
Drive Belt...................................................................................................................................................................................61
Drive/Transmission Pulleys..............................................................................................................................................61

– 5 –
Speed/Hall Sensor................................................................................................................................................................62
Drive Motor..............................................................................................................................................................................63
Mode Shifter............................................................................................................................................................................63
Platform/Transmission Assembly..................................................................................................................................65
Main Harness Assembly....................................................................................................................................................66
Schematics / Wiring Diagrams.................................................................................................................................................67
Schematics / Wiring Diagrams Cont...........................................................................................................................68
Schematics / Wiring Diagrams Cont...........................................................................................................................69
Warranty.............................................................................................................................................................................................70
Index......................................................................................................................................................................................................71

– 6 –
Prior to disassembly of the washer to access components, GE Factory
Service technicians are REQUIRED to follow the Lockout / Tagout
(LOTO) 6 Step Process:
Safety Requirements
GE Factory Service Employees are required to use safety glasses with side shields, safety gloves and
steel toe shoes for all repairs.
Steel Toed Work Boot Electrically Rated Glove and
Dyneema® Cut Resistant
Glove Keeper Dyneema®Cut Resistant
Glove
Plano Type Safety Glasses
Prescription Safety Glasses
Safety Glasses must be ANSI
Z87.1-2003 compliant
Brazing Glasses
Cut Resistant Sleeve(s)
Step 1
Plan and Prepare Step 4 Apply LOTO device and lock
Step 2
Shut down the appliance Step 5 Control (discharge) stored energy
Step 3
Isolate the appliance Step 6 “Try It” verify that the appliance is
locked out

– 7 –
Nomenclature
The nomenclature breaks down and explains what the letters and numbers mean in the model number.
Serial Number
7KH¿UVWWZRFKDUDFWHUVRIWKHVHULDOQXPEHULGHQWLI\WKHPRQWKDQG\HDURIPDQXIDFWXUH
Example: LA123456S = June, 2013. The letter designating the year repeats every 12 years.
A – JAN 2024 – Z
D – FEB 2023 – V
F – MAR 2022 – T
G – APR 2021 – S
H – MAY 2020 – R
L – JUN 2019 – M
M – JUL 2018 – L
R – AUG 2017 – H
S – SEP 2016 – G
T – OCT 2015 – F
V – NOV 2014 – D
Z – DEC 2013 – A
The model tag is located at the right bottom edge of the lid.
The mini manual is in a storage bag on the inside bottom left of the cabinet.
Mini (Maxi) Manual
Model ID Tag
Brand
G: General Electric
H: Hot Point
M: Moffatt
G T W 6 8 0 B S J 0 W S
Configuration
F: Front Load
T: Top Load - Rear Control
N: Top Load - Front Control
U: Unitized
Engineering Digit
0 - 99
Product Type
R: Riser
A: 2” Cover Top Load
B: 4” Cover Top Load
S: Standard/Stationary
P: Portable
Model Year
J - 2015
Specific Color
W: White
WS: Silver Backguard
MC: Metallic Carbon
Fuel Type Dryer
E: Electric
G: Gas
P: Propane
Partner Type
P: Premium Cost (Color)
H: Home Depot
L: Lowes
S: Standard
C: Contract (Hoses)
M: Mabe
Platform
W: Washer
D: Vented Dryer - Std
V: Vented Dryer - Long
C: Condenser Dryer
H: Heat Pump
Z: Flat Back Dryer - Long
X: Flat Back Dryer - Std
Series 1: 1 - 9
Series 2: 1 - 9
4: 24” Unitized
7: 27” Unitized
Series 3: 1 - 9 Washer Only

– 8 –
GE Top Load Washer Features
GE's 27" Top Load Washer has features the consumer has asked for. Between the cycles and options
selected, the consumer will be happy with the washability of this product.
Features include:
• Deep Fill: Option to add more water for larger loads.
• Deep Rinse: Removes any leftover soap residue.
• Warm Rinse: Option to select between a warm or cold rinse.
• Auto Soak: Loosens stains by soaking up to 2 hours.
• Agitator or Impeller Models: Provides gentle wash action with great turnover for great washability.
• Load Size: Automatically measures load size, and adjusts settings and water levels accordingly. Settings
are customizable, so you always get the wash you want.
• Stain Removal Guide: Assists removing tough stains with preprogrammed selectable settings that
modify your cycle to treat the four most common stains.
• Sanitize with Oxi: Removes 99.9 % of bacteria with a dedicated cycle that uses an Oxi additive to boost
your detergents cleaning power, while keeping fabrics looking their best.
Introduction

– 9 –
Throughout this manual, features and appearance may vary by model.
Control Features
(Continued next page)
APower
Press to “wake up” the display. If the display is active, press to put the washer into idle mode.
NOTE: Pressing Power does not disconnect the appliance from the power supply.
BStart/Pause
Press Start to begin the cycle. NOTE: The lid must be closed for the washer to start the cycle. If the lid is open, “Lid” will
scroll across the display. If the lid is closed, the lid will lock, the Lid Lock light will illuminate, and “SEnSing” will scroll
across the display.
Pressing Pause will unlock the lid (if locked at that time), pause the cycle and the Start indicator light will blink.
To continue the cycle, press Start again. If the machine is paused more than 24 hours, the cycle will be cancelled. If
water remains in the machine, select theDrain & Spin cycle to drain basket and spin water out of the washer basket.
CDisplay and Status Lights
Display: The display shows the approximate time remaining until the end of the cycle. NOTE7KHF\FOHWLPHLVDȺHFWHG
E\KRZORQJLWWDNHVWKHZDVKHUWR¿OO7KLVGHSHQGVRQWKHZDWHUSUHVVXUHLQWKHKRPH7KHVL]HRIWKHORDGEHLQJ
ZDVKHGDOVRVLJQL¿FDQWO\LPSDFWVF\FOHWLPHZLWKODUJHUORDGVWDNLQJORQJHU
In addition, this display will, “scroll” the washer status:
• bALAnCINg Start of rebalancing cycle to redistribute clothes. Stops after rebalancing is complete.
• dELAY When Delay Wash is initiated. Replaced with estimated time when cycle starts.
• End End of current cycle.
• FILL )RUWKH¿UVWVHFRQGVRID¿OOWKHHVWLPDWHGHQGRIF\FOHWLPHLVGLVSOD\HG)RUWKHUHVWRIWKH¿OO
WLPH´),//µLVVFUROOHGXQWLOWKH¿OOFRPSOHWHV
• H2O SUPPLY &DQQRWVHQVHZDWHUOHYHOYDOYHVSRVVLEO\WXUQHGRȺ
• LId Cycle stopped because lid is open. Close the lid.
• SEnSIng 6HQVLQJORDGVL]HDQGW\SHEHIRUHDQGGXULQJ¿OOQRUPDO
• PAUSE Cycle paused because theStart/Pause button was pressed and the washer was set toPause.
Press the Start button again to restart the cycle.
Cycle status lights: Shows whether the washer is in the Delay, Fill, Soak, Wash, Rinse or Spin portion of the cycle.
If an out-of-balance condition is detected by the washer, the Spin light will blink during the remaining portion of the
cycle and will stay illuminated for a short time after cycle completion. When this occurs, the washer is taking actions to
correct the out-of-balance condition and complete the cycle normally. In some cases, the washer may not be able to
balance the load and spin up to full speed. If the load is more wet than normal at the end of the cycle, redistribute the
load evenly in the wash basket and run a Drain & Spin cycle.
Feature status lights indicate (see sections Fand Gfor more details):
Pause Will display when washer is paused between cycles.
Controls The washer is locked - will blink once if any button is pressed or the cycle knob is turned.
Lid Lock The lid is locked. See the Control Lock description.
Spin Stop Indicates wash basket is coasting to a stop following spin. Lid will not unlock until basket has fully
come to a stop.
GTW680 Models

– 10 –
Items to Wash Cycle Wash
Temp Soil Level Spin Selection Options Available Cycle Details
Heavily to
lightly soiled
colorfast cottons,
household linens,
work and play
clothes.
Colors Hot
Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
This is the normal cycle which is
recommended for normally soiled
cotton and linen items. Choose
the Heavy or Extra Heavy soil level
selection and Warm or Hot water
temperature selection as appropriate
for the clothes load for a higher degree
of cleaning.
Casual clothes,
lightly soiled
RȻFHZHDU
Casuals Hot
Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Wash cycle tailored to care for casual
FORWKHVDQGRȻFHZHDULWHPV
Lingerie and
special care
fabrics with light
to normal soil.
Delicates Hot
Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Utilizes a unique "tri-pulse" extra gentle
DJLWDWHSUR¿OHWRSURYLGHVSHFLDOFDUH
to delicate fabrics. It is recommended
to place small or ultra-delicate items in
mesh bags before washing.
Medium to lightly
soiled athletic
wear items.
Active
Wear Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Warm Rinse
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle designed for care of medium to
lightly soiled active wear, athletic wear,
and technical fabrics. Incorporates a
dual stage wash period with soak to
HȺHFWLYHO\WUHDWERG\VRLOVDQGRGRUV
Use the Heavy Duty cycle for heavily
soiled sports clothing constructed of
sturdy fabric.
Dark colored
cottons, linens,
and mixed loads.
Cold
Wash Hot Warm
Colors
Cool
Cold
Tap Cold
Ex. Heavy
Heavy
Normal
Light
Max
More
Normal
No Spin
Stain Removal Guide
Deep Fill
Auto Soak
Deep Rinse
Delay Wash
Extra Rinse
Cycle combines multiple wash agitation
periods with soak periods to provide
enhanced cleaning performance and
HQHUJ\HȻFLHQF\ZLWKFROGHUZDWHU
temperatures.
(Continued Next Page)
DWash Cycles-Cycle Selector Knob
The wash cycle controls the type of washing process. The cycle selector knob can be turned in
either direction. Turning the knob after starting a cycle will stop the washer and change the cycle
options to the new selection. Press Start to begin the new cycle selection.
The chart below will help match the items to be washed with the best wash cycle settings. For
optimal performance, select the cycle that most closely matches the items being washed.
Selections and options shown in bold are default settings for that cycle.
Some cycles and options may not be available on some models.
