MTR12 models
Owner’s Manual and
Installation Instructions
Top-Freezer
Refrigerators
350A4502P469Printed in China
Safety Information..........................2 - 3
Operating Instructions..........................4
Installation Instructions...................5 - 8
Warranty................................................9
Consumer Support..............................10

WARNING!
READALLINSTRUCTIONSBEFOREUSING.
DANGER! RISK OF CHILD ENTRAPMENT
tr
opp
u
Sre
m
u
sn
oC spiTgnito
o
hselbuorT sno
i
tcurtsnI
n
o
it
allatsnI snoitc
u
rtsnI
g
nit
a
repO snoi
t
cur
t
snIytefaS
2
IMPORTANT SAFETY INFORMATION.
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed,
including the following:
This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used.
Do not allow children to climb, stand or hang
on the shelves in the refrigerator. They could
damage the refrigerator and seriously injure
themselves.
Do not touch the cold surfaces in the freezer
compartment, paticularly when hands are
damp or wet. Skin may stick to these extremely
cold surfaces
Do not store gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance.
Keep fingers out of the “pinch point” areas;
clearance between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
Unplug the refrigerator before cleaning and
making repairs.
NOTE: We strongly recommend that any
servicing be performed by a qualified
individual.
Do not refreeze frozen foods which have
thawed completely.
PROPER DISPOSAL OF THE REFRIGERATOR
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators are still dangerous... even if they
will sit for “just a few days.” If you are getting
rid of your old refrigerator, please follow the
instructions below to help prevent accidents.
1. Take off the doors.
2. Leave the shelves in place so that children
may not easily climb inside.
USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend
against the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed
or a CSA-listed, 3-wire grounding type appliance extension cord having a grounding type plug
and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.

WARNING!
tr
o
p
pu
S
re
m
u
sn
o
C
s
p
i
T
g
n
i
t
o
o
h
s
e
l
b
u
o
r
T
s
n
o
i
t
c
u
r
t
s
n
I
n
o
i
t
a
l
l
a
t
s
n
I
s
n
o
i
t
c
u
r
t
s
nI
g
n
i
t
a
r
e
p
O
s
n
o
i
t
c
u
r
t
s
n
I
y
t
e
f
a
S
SAVETHESEINSTRUCTIONS
www.GEAppliances.ca
3
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the
power cord. For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
The refrigerator should always be plugged into
its own individual electrical outlet which has a
voltage rating that matches the rating plate.
This provides the best performance and
also prevents overloading house wiring
circuits which could cause a fire hazard
from overheated wires.
Never unplug your refrigerator by pulling on
the power cord. Always grip the plug firmly
and pull straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
USE OF ADAPTER PLUGS
ADAPTER PLUGS ARE NOT PERMITTED IN CANADA.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

About the control on the refrigerator.
The temperature control on your refrigerator
regulates the temperature in the fresh food and
freezer compartment. Initially, set the control to the
mid-setting, as shown.
If you want colder or warmer temperatures, adjust
the temperature control slightly, and allow 12 hours
after each adjustment for the refrigerator to reach
the temperature you set.
tro
pp
uS r
e
musnoC spiT gnit
o
ohselbuorT snoitcurtsnI
no
ita
ll
atsn
Isn
oi
t
c
u
rt
s
nI gnitarepO snoitc
u
r
t
snI ytefaS
MAXMIN
Setting the control furthest to the right, MAX, is the coldest. Setting the control furthest
to the left, MIN, is the warmest.
Control settings will vary based on personal preferences, usage and
operating conditions and may require more than one adjustment.
4

Installation
Instructions
Refrigerator
Model 12
If you have questions, call 1-800-361-3400 or visit our Website at www.GEAppliances.ca
BEFORE YOU BEGIN CLEARANCES
LEVELING LEGS
REFRIGERATOR LOCATION
5
Read these instructions completely and carefully.
IMPORTANT - Save these instructions for
local inspector’s use.
IMPORTANT - Observe all governing codes
and ordinances.
Note to Installer - Be sure to leave these
instructions with the Customer.
Note to Customer - Keep these instructions
for future reference.
Skill level - Installation of this particular
appliance requires basic mechanical skills.
Completion time: - Refrigerator installation
15 minutes
- Reversing door swing
1 hour
Proper installation is the responsibility of the
installer.
Product failure due to improper installation is
not covered under the Warranty.
Do not install the refrigerator where the
temperature will go below 13°C because it will
not run often enough to maintain proper
temperatures.
Install it on a floor strong enough to support it
fully loaded.
Do not install it closer than 5” (13 cm) next to a
range.
Allow for the following clearances for ease of
installation, proper air circulation and plumbing
and electrical connections:
- Sides 1” (2.5 cm)
- Top 2” (5.1 cm)
- Back 2” (5.1 cm) from the rear cabinet
surface to the wall.
To raise the refrigerator
Adjustable legs at the front corners of the
refrigerator should be set so the refrigerator is
firmly positioned on the floor and the front is
raised just enough that the door closes easily
when opened about halfway.
To adjust the leveling legs, turn the legs
clockwise to raise the refrigerator, counter-
clockwise to lower it.

Installation Instructions
REVERSING THE DOOR SWING
IMPORTANT NOTES REMOVE THE FREEZER DOOR
1
TOOLS YOU WILL NEED
6
Once you begin, do not move the cabinet
until door-swing reversal is completed. These
instructions are for changing the hinges from
the right side to the left side - if you ever want
to change the hinges back to the right side,
follow these same instructions and reverse all
references to left and right.
Unplug the refrigerator from its electrical
outlet. Empty all door shelves.
socket driver
Phillips screwdriver thin-blade screwdriver
Tape the door shut with masking tape. Remove
the hinge cover, top hinge, and screws.
Set the door on a non-scratching surface with
the outside up.
CAUTION: Do not let door drop to the floor.
To do so could damage the door stop.

2
Installation Instructions
TRANSFER TOP HINGE TO
THE LEFT
3TRANSFER BOTTOM HINGE
TO THE LEFT
REVERSING THE DOOR SWING (CONT.)
TRANSFER CENTER HINGE
TO THE LEFT
4
7
plug buttons
Remove the plug buttons carefully with a thin-
blade screwdriver.
Reinstall the plug buttons on the right side by
inserting them into the holes vacated by the top
hinge screws.
Reassemble the top hinge on the left side,
turning the screws just enough to hold the
hinge in place.
Remove the supporting leg from the bottom of
the refrigerator and the screws that hold the
bottom hinge.
Reassemble the hinge on the left side of the
cabinet in the same manner, reversing the hinge
180° so that it holds the door in the correct
position with the notch on the hinge facing
inwards.
ATTENTION: The screws must be properly
tightened. Turn the screws until snug. Then
tighten the screws a minimum of one full turn
using both hands.
Remove the two plug buttons on the opposite
side.
Remove the centre hinge and screws.
Rotate the hinge 180° so the pin is on the left
side then mount the hinge on the left.
CAUTION: When assembled correctly, the hinge
is tight against the cabinet.
ATTENTION: The screws must be properly
tightened. Turn the screws until snug. Then
tighten the screws a minimum of 1/2 turn using
both hands.

Installation Instructions
5REHANG THE FRESH
FOOD DOOR
6REHANG THE FREEZER DOOR
7 ALIGN THE DOORS
8
Place the fresh food door on the bottom
hinge and position it under the centre hinge.
Place the freezer door on the centre hinge over
the pin. Raise the top hinge by hand and insert
the pivot pin into the hole in the door. Then
swing the door shut.
Align the freezer door with the fresh food door so
that the gap between the doors is even.
Tighten the top hinge screws by turning them
until snug. Then turn the screws a minimum of
1/2 turn using both hands.

This warranty applies only for single family
domestic use in Canada when the
Refrigerator has been properly installed
according to the instructions supplied by
Camco and is connected to an adequate
and proper utility service.
Damage due to abuse, accident, commercial
use, and alteration or defacing of the serial
plate cancels all obligations of this warranty.
Service during this warranty must be
performed by an Authorized Camco
Service Agent.
Neither Camco nor the Dealer is liable for
any claims or damages resulting from any
failure of the Refrigerator or from service
delays beyond their reasonable control.
To obtain warranty service, purchaser must
present the original bill of sale. Components
repaired or replaced are warranted through the
remainder of the original warranty period only.
This warranty is in addition to any statutory
warranty.
• Service trips to your home to teach you
how to use the product.
• Damage to finish after delivery.
• Improper installation—proper installation
includes adequate air circulation to the
refrigeration system, adequate electrical,
plumbing and other connecting facilities.
• Replacement of house fuses or resetting
of circuit breakers.
• Replacement of light bulbs.
• Damage to product caused by accident,
fire, floods or acts of God.
• Loss of food due to spoilage.
• Proper use and care of product as listed
in the owner’s manual, proper setting of
controls.
• WARRANTOR IS NOT RESPONSIBLE
FOR CONSEQUENTIAL DAMAGES.
In Home Warranty Service will be provided in
areas where it is available and deemed
reasonable by Camco to provide.
Keep this warranty and your bill of sale as proof of original purchase and purchase date.
Camco Service is available coast to coast.
If further help is needed concerning this
warranty, contact:
Manager, Consumer Relations
Camco Inc.
Suite 310,
1 Factory Lane
Moncton, N.B.
E1C 9M3
Your refrigerator is warranted to be free of defects in material and workmanship.
What is covered
All Parts
How Long Warranted
(From Date of Sale)
One (1) Year
Parts
Repair or Replace
at Camco’s Option
Labour
CONSUMER WARRANTY
One (1) Year One (1) Year
Full parts and labour covered for the period of
one year from the date of the original purchase
TERMS AND CONDITIONS WHAT IS NOT COVERED
IMPORTANT
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
Consumer Support: To schedule service, call 1.800.361.3400
www.geappliances.ca
9

Consumer Support.
GE Appliances Website GEAppliances.ca
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™” your questions,
and so much more...
Schedule Service 1.800.361.3400 or GEAppliances.ca
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your
convenience 24 hours any day of the year! Call 1.800.361.3400 during normal business hours.
Real Life Design Studio
GE supports the Universal Design concept---products, services and environments that can be used by people of all
ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and
impairments. For details of GE’s Universal Design applications, including kitchen design ideas for people with
disabilities, check out our Website today.
In Canada, contact: Manager, Consumer Relations, Camco, Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Extended Warranties 1.888.261.2133 or GEAppliances.ca
Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still
in effect. You can purchase it on-line anytime, or call 1.888.261.2133 during normal business hours. GE Consumer
Home Services will still be there after your warranty expires.
Parts and Accessories 1.800.661.1616 or GEAppliances.ca
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at
1.800.661.1616 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should be
referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to:
Director, Consumer Relations, Camco, Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
Register Your Appliance GEAppliances.ca
Register your new appliance on-line----at your convenience! Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.
GEAppliances.ca
10

OWNERSHIP REGISTRATION
P.O. BOX 1780
MISSISSAUGA, ONTARIO
L4Y 4G1
(FOR CANADIAN CONSUMERS ONLY)
Please place in envelope and mail to:
Veuillez mettre dans une enveloppe et envoyez à :

RAC NRUTER DNA ENIL SIHT GNOLA TUC D SKNAHT—
For Canadian
Customers
Pour les
Consommateurs
Canadiens
OWNERSHIP REGISTRATION CERTIFICATE – FICHE D’INSCRIPTION DU PROPRIÉTAIRE
Please register your product to enable us to contact you in
the remote event a safety notice is issued for this product
and to allow for efficient communication under the terms of
your warranty, should the need arise.
Veuillez enregistrer votre produit afin de nous permettre de
communiquer avec vous si jamais un avis de sécurité concernant
ce produit était émis et de communiquer facilement avec vous en
vertu de votre garantie, si le besoin s’en fait sentir.
REGISTER ON-LINE: www.geappliances.ca
ENREGISTREMENT SUR INTERNET À : www.electromenagersge.ca
MAIL TO: P.O. BOX 1780, MISSISSAUGA
POSTER À : ONTARIO, L4Y 4G1
MR. / M MRS. / MME.
MISS/MLLE. MS.
FIRST NAME / PRÉNOM
LAST NAME / NOM
STREET NO / NO RUE
STREET NAME / RUE
APT.NO/APP./RR#
CITY / VILLE
PROVINCE
POSTAL CODE POSTAL
AREA CODE/
IND. RÉG.
TELEPHONE
E-MAIL
DID YOU PURCHASE A SERVICE CONTRACT FOR THIS APPLIANCE?
AVEZ-VOUS ACHETÉ UN CONTRAT DE SERVICE POUR CET APPAREIL ?
YES/OUI
NO/NON
IF YES/SI OUI : EXPIRATION
Y/A M D/J
NAME OF SELLING DEALER / NOM DU MARCHAND
INSTALLATION DATE / DATE D’INSTALLATION
Y/A M D/J
CORRESPONDENCE ENGLISH
CORRESPONDANCE FRANÇAIS
I do not wish to receive any promotional offers regarding this product.
Je ne désire pas recevoir d’offres promotionnelles concernant ce produit.
MODEL / MODÈLE
SERIAL / SÉRIE
