GEERFAB AUDIO D.BOB User manual

GeerFabAudio.com
Designed in Milwaukee | Manufactured in China
D.BOB (Digital Breakout Box)
Hi-Res Audio Disc Digital Extractor
DSD64 and up to 24/192 PCM from HDMI Input
S/PDIF Coax & Toslink Optical Stereo Outputs
VER 1.0
D.BOB (Digital Breakout Box)
Hi-Res Audio Disc Digital Extractor
DSD64 and up to 24/192 PCM from HDMI Input
S/PDIF Coax & Toslink Optical Stereo Outputs

Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electr-ical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
IMPORTANT – POWER ON THE D.BOB FIRST
Power On Sequence in an Audio System:
Power amplifiers have a specific power on sequence and so does the D.BOB.
Because of the complicated nature of the data extraction and routing the
D.BOB is required to perform, for every audio system power on sequence,
the D.BOB should always be the first component to be turned on. If this rule
is not followed, sometimes the DAC screen may read NO LOCK. Should this
occur, turn off the D.BOB, the disc player and the DAC and re-power on the
D.BOB first.
Table of Contents
1. Introduction...........................................................................................
2. Features.................................................................................................
3. Package Contents................................................................................
4. Specifications.......................................................................................
5. Operation Controls and Functions......................................................
5.1. Front Panel....................................................................................
5.2. Rear Panel....................................................................................
6. Application Example............................................................................
7. FAQ.........................................................................................................
1
1
1
2
3
3
3
4
4
2

1. Introduction
2. Features
HDMI 1.4b, HDCP1.4 and DVI 1.0 compliant
Inputs: 1 HDMI
Outputs: 1 HDMI, 1 S/PDIF coax and 1 S/PDIF Toslink optical
1 mini-USB input for firmware upgrades
Video resolution up to 4K60Hz YCbCr 4:2:0
HDMI bandwidth up to 10.2Gbps
HDMI audio format: PCM 2.0 and DSD64 2.0
Audio sample rates up to PCM 24/192KHz and DS64
Supports 10bits HDR (High Dynamic Range) pass through
Compact design for easy and flexible installation
3. Package Contents
D.BOB Digital Breakout Box
12V/1A DC Locking Power Adapter
100 ~ 240V AC 50/60Hz Power Cable
International Power Cable Adapters
User Manual
3
This high performance product supports one HDMI input to one HDMI output
(for TV or monitor – for Blu-ray menus) and separate S/PDIF
coax and Toslink optical audio outputs. It extracts from the HDMI data stream
digital audio formats of PCM up to 24/192 coax and 24/176.4 Toslink optical
and DSD64 via the DOP protocol over both coax and optical. It also supports
video resolution up to 4K60Hz YCbCr 4:2:0. It includes two power supplies –
internal AC and a DC power port, both controlled by a back panel switch.
HDMI bandwidth is 10.2Gbps. Mini-USB input for firmware upgrades.
1. Introduction
2. Features
삺HDMI 1.4b, HDCP1.4 and DVI 1.0 compliant
삺
Supports 1 HDMI input and 1 HDMI output
삺
Video resolution up to 4K60Hz YCbCr 4:2:0
삺
Supports bandwidth up to 10.2Gbps
삺
Supports HDMI audio format including PCM 2.0/2.1/5.1/6.1/7.1 and DSD
삺
Supports digital audio format including PCM 2.0 and DSD
삺
Supports extract HDMI IN port audio to separate coax and optical audio
output
삺
Audio sample rates up to 192KHz
삺
Supports 10bits HDR (High Dynamic Range) pass through
삺Compact design for easy and flexible installation
3. Package Contents
샼1×10.2Gbps HDMI with Coax/Optical Audio Extract
샽1× 12V/1A DC Locking Power Adapter
샾1× 100 ~ 240V AC 50/60Hz Power Cable
샿1× User Manual
1/4
This high performance product supports one HDMI input to one HDMI output,
and simultaneously it can extract HDMI IN audio to separate coax and optical
audio output. It supports digital audio format including PCM and DSD (DSD
adopts DOP protocol). The product supports resolution up to 4K60Hz YCbCr
4:2:0. It provides double power supply (including an AC and DC power port)
with switch control. With its 10.2Gbps bandwidth and the additional features
with the latest HDMI standards.
1. Introduction
2. Features
삺HDMI 1.4b, HDCP1.4 and DVI 1.0 compliant
삺Supports 1 HDMI input and 1 HDMI output
삺Video resolution up to 4K60Hz YCbCr 4:2:0
삺Supports bandwidth up to 10.2Gbps
삺Supports HDMI audio format including PCM 2.0/2.1/5.1/6.1/7.1 and DSD
삺Supports digital audio format including PCM 2.0 and DSD
삺Supports extract HDMI IN port audio to separate coax and optical audio
output
삺Audio sample rates up to 192KHz
삺Supports 10bits HDR (High Dynamic Range) pass through
삺Compact design for easy and flexible installation
3. Package Contents
샼1×10.2Gbps HDMI with Coax/Optical Audio Extract
샽
1× 12V/1A DC Locking Power Adapter
샾
1× 100 ~ 240V AC 50/60Hz Power Cable
샿
1× User Manual
1/4
This high performance product supports one HDMI input to one HDMI output,
and simultaneously it can extract HDMI IN audio to separate coax and optical
audio output. It supports digital audio format including PCM and DSD (DSD
adopts DOP protocol). The product supports resolution up to 4K60Hz YCbCr
4:2:0. It provides double power supply (including an AC and DC power port)
with switch control. With its 10.2Gbps bandwidth and the additional features
with the latest HDMI standards.
1. Introduction
2. Features
삺HDMI 1.4b, HDCP1.4 and DVI 1.0 compliant
삺Supports 1 HDMI input and 1 HDMI output
삺Video resolution up to 4K60Hz YCbCr 4:2:0
삺Supports bandwidth up to 10.2Gbps
삺Supports HDMI audio format including PCM 2.0/2.1/5.1/6.1/7.1 and DSD
삺Supports digital audio format including PCM 2.0 and DSD
삺Supports extract HDMI IN port audio to separate coax and optical audio
output
삺Audio sample rates up to 192KHz
삺Supports 10bits HDR (High Dynamic Range) pass through
삺Compact design for easy and flexible installation
3. Package Contents
샼1×10.2Gbps HDMI with Coax/Optical Audio Extract
샽1× 12V/1A DC Locking Power Adapter
샾1× 100 ~ 240V AC 50/60Hz Power Cable
샿1× User Manual
1/4
This high performance product supports one HDMI input to one HDMI output,
and simultaneously it can extract HDMI IN audio to separate coax and optical
audio output. It supports digital audio format including PCM and DSD (DSD
adopts DOP protocol). The product supports resolution up to 4K60Hz YCbCr
4:2:0. It provides double power supply (including an AC and DC power port)
with switch control. With its 10.2Gbps bandwidth and the additional features
with the latest HDMI standards.
5

4. Specifications
Technical
HDMI Compliance HDMI 1.4b
HDCP Compliance HDCP 1.4
Video Resolution
Color Space RGB/YCbCr 4:2:0, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 8/10/12-bit (1080P60Hz)
8-bit (4K60Hz, 4K24Hz)
Input ports HDMI Type A [19-pin female]
Mini-USB (firmware updates)
Output ports HDMI Type A [19-pin female]
S/PDIF Coaxial Audio [RCA]
S/PDIF Optical Audio [Toslink]
1 kg (2.2 lbs)
Input: AC100~240V 50/60Hz
Output: DC 12V/1A(US standards, CE/FCC/UL certified)
100 ~ 240V AC 50/60Hz
0.84W
0°C ~ 40°C / 32°F ~ 104°F
-20°C ~ 60°C / -4°F ~ 140°F
ESD Protection Human-body Model:
±8kV (Air-gap discharge) , ±4kV (Contact discharge)
Power Supply
Dimensions
Weight
Metal
Operating
Temperature
Storage Temperature
Relative Humidity
20~90% RH (non-condensing)
Power Consumption
Color
Black, Light Grey Lettering
218mm(W)×120mm(D)×45.5mm(H)
8.5 in (W) x 4.75 in (D) x 1.75 in (H) (2.00 in w/feet)
Housing
Video Bandwidth 10.2Gbps
Coax / Optical Audio
Formats PCM 2.0, DSD64 2.0
Connections
Mechanical
Up to 4K60Hz YCbCr 4:2:0
4
HDMI Audio Formats PCM 2.0 16/20/24-bit, DSD64

5. Operation Controls and Functions
Number Function description
1 Power LED
Name
5.2 Rear Panel
The blue LED will illuminate when the product is
connected to power via the AC or DC power inputs and
the power switch is turned on.
Connect with HDMI cable to HDMI display device such as
TV or monitor
5.1 Front Panel
5
1
1 2 3 4 56
7
Number Function description
1 HDMI IN
Name
Connect with HDMI cable to HDMI output source device
such as universal disc player
2 HDMI OUT
3 COAX OUT Connect to external DAC with 75 ohm coaxial cable
4OPTICAL OUT Connect to external DAC with Toslink optical cable

TV or Monitor
Universal Disc (recommended)
SACD or Blu-ray Player
Premium High Speed HDMI and Premium Coax and Toslink cables are highly recommended.
6
Number Function descriptionName
5MINI-USB PORT For firmware updates
6
DC 12V IN Connect 12V/1A adapter to AC wall outlet for power supply
or connect to 12V batteries
Connect AC power with AC power cable.
AC POWER IN
7Power switch Turn on/off the power supply.
6. Application Example
Power Supply
**both cables could connect
to same DAC
External DAC
(Digital to Analog Converter)
Recommended player settings (may vary by manufacturer):
Since the D.BOB has an HDMI out for a TV, it can provide stereo hi-res DAC conversion for Blu-ray movies.
SACD Priority Stereo
HDMI Audio Auto
Coax/Optical Output Bitstream
SACD Output Auto
