Gefei MMIO EMB-HDSDI-2AES User manual

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Audio Embedder
User manual V1.0
www.gefei-tech.com
[Gefei Tech.Co.,Ltd]

Table of Content
I. Description.......................................................................................................................................................1
II.Features............................................................................................................................................................1
III. Interface Description...............................................................................................................................2
3.1 Overview...............................................................................................................................................2
3.2 Right panel..........................................................................................................................................2
3.3 Left panel..............................................................................................................................................3
3.4 Front panel..........................................................................................................................................3
ⅣInstallation Guide..........................................................................................................................................5
IV. Technical specification...........................................................................................................................7
V.Contact..............................................................................................................................................................9

Copyright
Copyright © 2009 Gefei Tech. Co., Ltd All rights reserved. This document may not be
copied in whole or in part.
Trademarks
Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or
trademarks of Gefei Tech. Co., Ltd in China and/or other countries. Other trademarks
used in this document are either registered trademarks or trademarks of the
manufacturers or vendors of the associated products.
Disclaimer
Product options and specifications subject can be changed without notice. The
information in this manual is furnished for informational use only, is subject to change
without notice, and should not be construed as a commitment by Gefei Tech. Co., Ltd.
Gefei Tech. Co., Ltd assumes no responsibility or liability for any errors or inaccuracies
that may appear in this publication.
Revision Status
Rev Date
Description
Dec. 26, 2013
Initial release of the MMIO EMB-HDSDI-2AES User Manual
Firmware V1.0

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
1 / 9
MMIO EMB-HDSDI-2AES
I. Description
MMIO EMB-HDSDI-2AES is a kind of embedder based on Mini-Box chassis. It can
embed two AES digital audio signal into a single serial digital signal, and output one
serial digital signals with embedded audio. It supports SD-SDI, 1.5 Gbps HD-SDI and
3.0 Gbps HD-SDI for inputs and outputs. It can also be applied to digital signal with
embedded audio for input signal.
MMIO EMB-HDSDI-2AES supplies real-time input signal status indicator and
power indicator which make it convenient to monitor. The embedded audio channel can
be selected though DIP Switch.
MMIO EMB-HDSDI-2AES is easy to install, and can be widely used in
broadcasting system, studios and other professional audio fields.
II. Features
2 AES digital audio signals embedded into a single serial digital signal
Inputs and outputs for SD-SDI, 1.5Gb/s HD-SDI and 3.0Gb/s HD-SDI
Support self-definition embedded audio channel via DIP Switch
All audio interfaces adopt 3-PIN connector, balanced input
Supply real-time input signal status indicator and power indicator
Support bypass function with power on

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
2 / 9
III. Interface Description
3.1 Overview
3.2 Right panel
SDI INLOOP
DC IN：12V 1A
PWR：Power indicator, when the power works normally, the indicator shows green.
IN：Input signal indicator, when the input signal is correct, the indicator shows green.
SDI IN：BNC interface, digital signal input with embedded or non-embedded audio, support

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
3 / 9
the SD-SDI, HD-SDI, and 3G-SDI.
SD: 525i 60, 625i 50
HD: 720p 50Hz/59.94Hz/60Hz
1080i 50Hz/59.94Hz/60Hz
1080p 23.97Hz/24Hz/25Hz/29.97Hz/30Hz
1080p 50 Hz/59.94Hz/60 Hz
LOOP：BNC interface, it support loop function with power on.
3.3 Left panel
AES2 INAES1 INSDI OUT
SDI OUT：BNC interface, one serial digital signal output with embedded audio.
AES1 IN & AES2 IN：3pin interface, 2 AES digital audio signals input.
3.4 Front panel
MODE SET: DIP switch, users can set DIP position to achieve more functions, the DIP
specific meaning as following:

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
4 / 9
DIP Switch
1
2
3
4
5
6
7
8
9
0
Select
embedded
audio
channel
Silence
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
G1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
G2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
G3
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
G4
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
AUTO
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
Note: Power switch UP=OFF DOWN=ON
When two AES digital audio signals are embedded to eight certain channels of
HD/SD-SDI signal, the other eight audio channels will have no audio any more. For
instance, when embedding two AES digital audio to G1, and then G2 will have no
audio any more.

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
5 / 9
ⅣInstallation Guide
The unit is equipped with mini mounting bracket. And there are several screw holes on
the bottom of unit for installing the mini bracket. Please see the pictures below.
Mini bracket:
61.5mm
24mm
Bottom of unit:
There are several ways to fix this bracket to case. According the direction of connection,
you can choose one appropriate way to fix it.
Fix the bracket vertically like this:
Use these two screw holes
to fix bracket to case.
Fix the bracket horizontally like thiSs:
MIO
Mini Converter
Audio to SDI
Use screw hole to fix unit
to rack or back of monitor.
MIO
Mini Converter
Audio to SDI
A
B

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
6 / 9
Use these two screw holes
to fix bracket to case.
MIO
Mini Converter
Audio to SDI
Use screw hole to fix unit to
rack or back of monitor.
MIO
MiniConverter
AudiotoSDI
A
B

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
7 / 9
IV.Technical specification
Digital video input:
Input interface: 1*HD/SD-SDI, BNC connection
Impedance: 75Ω
Format: SD: 525i 60, 625i 50
HD: 720p 50Hz/59.94Hz/60Hz
1080i 50Hz/59.94Hz/60Hz
1080p 23.97Hz/24Hz/25Hz/29.97Hz/30Hz
1080p 50 Hz/59.94Hz/60 Hz
SMPTE-259M-C；270Mb/s
SMPTE-292M；1.485Gps
SMPTE-425M；2.970Gps
Analog audio Input:
Input interface: 2*3pin
Impedance: 110Ω
Digital video output:
Output interface: 1*HD/SD-SDI, BNC connection
1*HD/SD-SDI LOOP, BNC connection
Impedance: 75Ω
Format: SMPTE 259M-C；270Mb/s
SMPTE-292M；1.485Gps
SMPTE-425M；2.970Gps
Level: 800mV±10%

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
8 / 9
Rise time/Fall time: ≤270PS（20%-80%）(HD)
750~1500PS（20%-80%）(SD)
Jitter: <0.2UI (100 kHz)
Status indicator:
Input signal status indicator
Power indicator
(Indicate by shining or extinguishing of the green LED)
Power consumption:
Power: 12VDC 1A

MMIO EMB-HDSDI-2AES 3G/HD/SD Signal & AES Digital Audio Embedder
9 / 9
