Gefen AUD-148 User manual

1x8 HDTV DA
USER MANUAL
www.gefen.com

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday.
Write To:
Gefen Inc.
C/O Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
The 1x8 Audio DA is a trademark of Gefen Inc.
Macintosh is a trademark of Apple Computer Inc.
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE

TABLE OF CONTENTS
Introduction
Box Contents
How it works
Operation Notes
1x8 Audio DA Front Panel Layout
1x8 Audio DA Back Panel Functions
Link Cable - Wiring Diagram
System Specifications
Warranty
1
2
3
4
5
6
7
8
9

Thank you for purchasing the new ex•tend•it 1x8 Audio DA series.
The ex•tend•it 1x8 Audio Distribution DA allows 8 audio locations from the same audio
source. The 1x8Audio Distribution DAalso extends the distributed audio to 8 locations up
to a 1000 feet away with CAT5.
INTRODUCTION
1

The 1x8 Audio DA system consists of:
(1) 1x8 Audio DA
(1) 5 VDC power supply
(1) Audio cable (6 FT)
(1) User's Manual
BOX CONTENTS
2

HOW IT WORKS
3
The ex•tend•it 1x8 Audio Distribution unit sits next to your audio source. Stereo cables
supplied with the 1x8 Audio Distribution package connects your audio source to the
1x8 Audio Distribution sender. TheAudio Extender receiver unit connects to your
speakers or audio output device. One CAT-5 cable per channel connects the 1x8 Audio
Distribution unit and the Audio Extender receive unit to each of the distributed locations
- up to 1000 feet away.
1X8 Audio DA
1X8 Audio DA

READ THESE NOTES BEFORE INSTALLING
OR OPERATING THE 1X8 AUDIO DA SYSTEM
* Industry standard Category-5 (CAT-5) cables are used to link the 1x8 Audio DA and
receiver boxes together.
* The 1x8 Audio DA units are housed in a metal box for better RF shielding.
OPERATION NOTES
4

Front Panel Function Descriptions
POWER ON INDICATOR - Indicates that the unit is plugged in and powered on
1x8 AUDIO DA FRONT PANEL LAYOUT
5
1
1

12
POWER - 5 VDC external power supply
AUDIO - Audio mini Jack input from source
Audio Out - RJ-45 connector connects to Audio Extender Receiver units.
1x8 AUDIO DA BACK PANEL FUNCTIONS
6
1
2
3
3

LINK CABLE - WIRING DIAGRAM
7
White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
RJ-45 Jack RJ-45 Jack
2 3 4 5
6
7 8 1
2 3 4 5
6
7 8 1
1818
