Gefen HDMI-1410 User manual

1:10 HDMI DA
USER MANUAL
www.gefen.com

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff Street
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
1:10 HDMI DA is a trademark of Gefen Inc.
HDMI is a trademark of hdmi.org
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE

TABLE OF CONTENTS
Introduction
Features
Panel Descriptions
Connecting and Operating the 1:10 HDMI DA
Specications
Warranty
1
2
3
4
5
6

Congratulations on your purchase of the ex•tend•it 1:10 HDMI Distribution
Amplier. Your complete satisfaction is very important to us.
The 1:10 HDMI™ Distribution Amplier is the perfect solution for anyone
who needs to send one source of digital high denition video to multiple
displays at the same time. It supports all HDMI™ equipment, such as DVD
players and satellite set top boxes and all HDMI displays. HDMI (High-
Denition Multimedia Interface) is a digital point to point interface for audio
and video signals. In operation, the digital video source is connected to
the distribution amplier on one side. On the other side, ten HDMI outputs
are available to be used in part or in full. Once the unit is connected and
powered, your source is routed to up to ten digital displays at the same time.
For home theater applications, the unit is HDCP (high bandwidth digital
content protection) compliant, making it effective for use with all HDMI
displays. HDCP is a standard “key” encoded into the HDMI signal to
prevent video data from being pirated. HDCP was strongly endorsed by the
entertainment industry. If a source device is HDCP coded and is connected
to a HDMI display or projector via HDMI without the proper HDCP decoding
mechanism, the picture is relegated to “snow” or in some cases, a very low
(480P) resolution. In order to see protected content, the source, the display
and any device in between must be equipped with HDMI connections that
can enable HDCP using “software key” decoding.
Our Commitment
Gefen will always offer the nest quality product at the best possible price.
Included in that price is a lifetime support from a team of outstanding
engineers.
The ex•tend•it 1:10 HDMI DA allows one HDTV HDMI device to be
distributed easily in to eight HDTV HDMI compatible monitors or projectors.
Simply connect your HDTV displays to the DA’s display outputs. The 1:10
HDMI DA can also be placed at the end of a long HDMI cable to regenerate
the HDMI signal.
How It Works
Simply connect your HDMI™ video source to the 1:10 HDMI Distribution
Amplier’s input using the supplied HDMI cable. Then connect up to
ten HDMI displays to the unit’s ten HDMI outputs. Once connected and
powered, your source will be seen on all ten displays at the same time.
INTRODUCTION
1

FEATURES
Features
• Connects up to ten HDMI™/DVI displays at the same time to one video
source
• Allows simultaneous display
• Maintains high resolution video - beautiful, sharp HDTV resolutions up to
1080p, 2k,
and computer resolutions up to 1920 x 1200 are easily achieved
• HDMI™ compliant
• HDCP compliant
• Includes rack ears
Includes:
(1) 1:10 HDMI Distribution Amplier
(1) 6 foot HDMI cable
(1) 24V External Power Supply
(1) Set of Rack Ears
(1) User’s Manual
2

PANEL DESCRIPTIONS
3
Connects to
24VDC power
supply
HDMI
Input
HDMI Output
1-10
Power LED
&
Act. LED
Reset
EDID
Switch

CONNECTING AND OPERATING THE 1:10 HDMI DA
Connect the supplied cable from the HDTV HDMI source into the 1:10
HDMI DA input.
Connect the cables from your displays (monitor or projector) into the
HDMI outs of the 1:10 HDMI DA.
Plug the 24VDC power supply into the 1:10 HDMI DA.
4
1.
2.
3.
How to Connect the 1:10 HDMI DA to your devices
EDID SWITCH
The HDMI 1:10 has an EDID Switch which will determine if you are going to
use the EDID from the display attached to output 1 or use an onboard EDID.
If you want to use the EDID from the display attached to output 1, make
sure the switch is selected to "EXT".
If you want to use the onboard EDID, make sure the switch is selected to
"INT" which will give you a generic EDID of 1080i.

SPECIFICATIONS
5
Video Amplier Bandwidth...............................................................1.65 Gbps
Input Video Signal........................................................................1.2 volts p-p
Input DDC Signal...................................................................5 volts p-p (TTL)
Single Link Range.............................................................1080p/1920 x 1200
HDMI Connector..............................................................type A 19 pin female
Power Supply.......................................................................................24V DC
Power Consumption.................................................................60 watts (max)
Dimensions...................................................................17”W x 1.75”H x 5.5”D
Rackmountable.........................................................................1U rack space
Shipping Weight......................................................................................8 lbs.
