INTRODUCTION
Congratulations on your purchase of the USB-400FO. Your complete satisfaction
is very important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
Gefen’s reliable, plug-and-play products supplement cross-platform computer
systems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to implement and simple to operate.
The Gefen USB-400FO
The USB-400 FO Extender supports all USB 2.0 devices, extending to 1640 feet
(500 meters) away from the USB source. The receiver end is also a four USB
2.0 hub.
By using fiber optic cables, the USB-400FO extends a long distance from the
location of a computer. It provides an EMI-free solution for using USB at remote
locations.
How It Works
The USB-400FO sender unit is connected to the source using the supplied USB
short cable. The USB peripheral(s) are connected to the receiver unit at the
remote end. Two LC-terminated multi-mode fiber optic cables are used to link the
sender to the receiver. The Receiver unit must be powered by a 5V DC power
supply. The Sender unit is powered by the USB bus.
Applications
The USB-400FO is invaluable for applications where complete control of devices
is necessary when using USB when placing in restricted areas, such as medical
facilities and oil rigs. The USB-400FO will connect with any USB-compliant
peripheral in all operating systems supporting USB 2.0.

READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE USB-400FO
This equipment is a new version replacing the existing part number,
EXT-USB-400FO, and can provide outstanding extension facilities for any device
or USB application that requires a peripheral connection over a distance, such as
a USB camera or USB hard drive, keyboard and mouse.
The USB-400FO works like a USB hub with extension capabilities over a distance of
up to 1,640 feet. This means, for example, that a remote USB sensor can be placed
at a safe distance from the sender unit in situations that demand this type of security.
The USB-400FO signal controls the keyboard, mouse, trackball and other USB
peripherals using send and receive units. The USB signal is extended by using
multimode fiber optic cabling.
The USB-400FO uses dual multi-mode LC fiber optic cables to connect the sender
and receiver units.
FCC Radio Frequency Interference Statement Warning
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and (2) this device must
accept any interference received including interference that may cause undesired
operation.
Requirements:
To complete the installation, you will also require the following items that are not
included with the product:
• USB 1.1 or 2.0 Compatible computer (host computer) with a USB compliant
operating system
• USB 1.1 or 2.0 Compatible device
• 2-strand fiber optic cable with Duplex LC connectors (if using surface
cabling) OR, 2-strand fiber optic cabling with two information outlets and two
2-strand fiber optic patch cords with Duplex LC connectors (if using premise
cabling) .
The Sender Unit and Receiver Unit are interconnected by up to 500 meters of
fiber optic cabling. Two strands of 50/125m (500m) MMF or 62.5/125m (275m)
MMF cabling are required. The cabling subsystem must provide a duplex
connection with crossover, and must be terminated with Duplex LC connectors
at both ends.
OPERATION NOTES
2

3
FEATURES
Features
• “Extreme USB” technology is used to extend the range of USB 2.0 devices
up to 1640 feet (500 meters) using fiber-optic cables
• Receiver unit is also a USB 2.0 four-port hub
• Provides support for both low-speed and high-speed USB devices
• Fully backward-compliant with USB 1.1 and USB 2.0 specifications as
certified by the USB Implementation.
• Number of USB devices can be expanded using standard USB hubs
• Supports all operating systems including Windows®, Mac OS®, and Linux®
• Supports other USB peripherals and are used in devices such as PlayStation
and Wii.
• A very secure method of USB control in areas where environmental
conditions prohibit access by people
• Metal box for better RF-sheidling.
• Ideal as optical isolation from over-voltage and static electricity
• Supports High Speed devices up to 480Mbs
Package Includes
(1) Gefen USB-400FO Sender Unit
(1) Gefen USB-400FO Receiver Unit
(1) 6 ft. USB Cable (A-B)
(1) 5V DC Power Supply
(1) User Manual

4
SENDER UNIT PANEL LAYOUT
Front Panel
Back Panel
1234
65 7

5
SENDER UNIT PANEL DESCRIPTIONS
1 Power Indicator
LED turns bright blue when power is supplied.
2 Link Indicator
This LED turns bright green when a valid ExtremeUSB® link is established
between the Sender Unit and Receiver Unit.
3 Host Indicator
This LED turns bright green when the USB-400FO system is properly
enumerated on the host PC. The LED blinks when in Suspend Mode.
4 Activity Indicator
This LED turns bright amber, indicating that data transmission is active between
the Sender Unit and Receiver Unit. The LED blinks intermittently with or without
a USB device plugged in. When the Sender Unit and Receiver Unit are in a
Suspend Mode, the LED is off.
5 Power port
An optional 5V power supply can be connected to the Sender unit to provide
power if the USB port on the host PC is not capable of delivering 500mA to the
unit.
6 USB Port
Used to connect the Sender unit to the host computer.
7 Link Port
Extension link Duplex LC fiber optic transceiver port.

6
RECEIVER UNIT PANEL LAYOUT
Front Panel
Back Panel
3456
8
7
12

7
RECEIVER UNIT PANEL DESCRIPTIONS
1 USB Port (1-4)
USB device input ports.
2 USB Indicator (1-4)
This LED indicates when a USB device is connected to the Device Port. Solid
green when device is plugged in and active. Off when device is in a suspend
mode or Receiver unit is powered off. Orange when the Receiver unit detects an
overcurrent condition, or if the attached USB device attempts to draw more than
the 500mA current.
3 Power Indicator
This LED turns bright blue when power is supplied.
4 Link Indicator
This LED turns bright green when a valid ExtremeUSB® link is established
between the Sender Unit and Receiver Unit.
5 Host Indicator
This LED turns bright green when the USB-400FO system is properly
enumerated on the host PC. The LED blinks when in Suspend Mode.
6 Activity Indicator
This LED turns bright amber, indicating that data transmission is active between
the Sender and Receiver. The LED blinks intermittently with or without a USB
device plugged in. When the Sender Unit and Receiver Unit are in a Suspend
Mode, the LED is off.
7 Power port
Connects to the 5V DC power supply.
8 Link Port
Connect one end of a duplex LC fiber optic cable to this port.

8
CONNECTING AND OPERATING THE USB-400FO EXTENDER
Connecting the USB-400FO Extender
1. Connect the included USB cable between USB port on the host computer
and the Sender Unit.
2. Connect two (2) LC-fiber cables between the Sender Unit and the Receiver
Unit.
3. Connect the USB devices to the Receiver Unit.
IMPORTANT: The Sender Unit must be powered before the Receiver Unit.
4. Connect the power supply to the Sender Unit and connect the power cord to
an available electrical outlet.
5. Connect the power supply to the Receiver Unit and connect the power cord
to an available electrical outlet.
Wiring Diagram for the USB-400FO Extender
EXT-USB-400FON
Sender
Computer
Receiver
USB Peripheral
e
n
de
r
R
eceive
r
USB Peripheral
USB Peripheral
USB Peripheral
(Up to 1640 ft.)
FIBER OPTIC LC-LC CABLE
USB CABLE

9
TROUBLESHOOTING
Verifying Installation on PC or Macintosh Computers
1. For Windows users (2000, XP, Vista, Windows 7), open the Device Manager
to confirm that the USB-400FO has installed correctly. Expand the entry for
Universal Serial Bus controllers by clicking the + sign. If the USB-400FO has
been installed correctly, you should find it listed as a “Generic USB Hub”.
2. For Mac OS X users, open the System Profiler to confirm that the USB-400FO
has installed correctly. In the left hand column under Hardware, select “USB” and
inspect the right hand panel. If the USB-400FO has been installed correctly, you
should find it listed as a “Hub” under the USB high-Speed Bus/USB Bus.
The following table provides additional troubleshooting tips. The topics are
arranged in the order in which they should be executed in most situations. If
you are unable to resolve the problem after following these instructions, please
contact technical support for further assistance.
PROBLEM CAUSE SOLUTION
All LEDs on
Sender unit are
off.
The Sender unit is not
receiving power from the
USB port or the optional)
Sender 5VDC power supply.
1. Ensure that the USB
connection between the
Sender and host computer is
properly installed.
2. Move the USB connector to
another USB port on the host
computer.
All LEDs on
Receiver unit
are off.
The Receiver unit is not
receiving power from the
5VDC power supply.
1. Ensure that the 5VDC
power supply is properly
connected to the Receiver
unit.
2. Check that the 5VDC
power supply is connected
to a live source of electrical
power. Check that the
Receiver power LED is
illuminated.

10
TROUBLESHOOTING THE USB-400FO EXTENDER
PROBLEM CAUSE SOLUTION
Link LEDs on
Sender unit
and Receiver
unit are off.
There is no connection
between the Sender unit
and Receiver unit.
1. Ensure that a multimode
fiber optic cable with
crossover is connected
between the Sender and
Receiver units.
2. Connect a fiber optic
crossover patch cord between
the Sender and Receiver
units. Recheck operation of
the system.
Link LED
on Sender /
Receiver
units are on,
Host LED
on Sender/
Receiver units
are off.
The host computer is not
powered on.
The Sender unit is not
connected to the computer
(when used with the
optional Sender 5VDC
power supply).
The computer does not
support USB hubs.
The USB-400FO is
malfunctioning.
1. Disconnect all USB devices
from the Receiver unit.
2. Disconnect the Sender unit
from the computer.
3. Disconnect the Receiver
unit from the 5VDC power
supply.
4. Reconnect the Sender unit
to the computer.
5. Reconnect the Receiver
unit to the 5VDC power
supply.
6. In the Universal Serial Bus
controllers section of Device
Manager, check that the USB-
400FO is recognized as a
“Generic USB Hub”.

11
TROUBLESHOOTING THE USB-400FO EXTENDER
PROBLEM CAUSE SOLUTION
USB-400FO units
were working,
but the Host
LED on Sender/
Receiver units
are suddenly
blinking
The Receiver unit is
in suspend mode. The
operating system may
put the USB-400FO in
suspend mode when the
computer is put into a
Suspend/Standby state or
when no USB devices are
attached.
1. Recover/Resume the
operating system from
Suspend/Standby mode
(see your operating system’s
documentation).
2. Attach a USB device to the
USB-400FO.
All LEDs on both
the Sender unit
and Receiver
unit are on but
the USB device
does not operate
correctly, or is
detected as
an “Unknown
Device” in the
operating system.
The USB device is
malfunctioning.
The computer does
not recognize the USB
device.
The application software
for the device is not
operating.
1. Disconnect the USB-
400FO from the computer.
2. Connect the USB device
directly to the USB port on the
computer.
3. If the device does not
operate properly, consult the
user documentation for the
device.
4. Update your system
BIOS, chipset, or USB
Host controller drivers from
your System/Mother board
manufacturer’s website.
5. If the device operates
properly when directly
connected to the computer,
connect another device (of
a different type) to the USB-
400FO. Connect the USB-
400FO to the computer.

12
TROUBLESHOOTING THE USB-400FO EXTENDER
PROBLEM CAUSE SOLUTION
All LEDs on both
the Sender unit
and Receiver
unit are on but
the USB device
does not operate
correctly, or is
detected as
an “Unknown
Device” in the
operating system.
(continued)
The USB-400FO is
malfunctioning.
The computer does
not recognize the USB
device.
The application software
for the device is not
operating.
6. If the second device does
not operate, the USB-400FO
may be malfunctioning.
Contact technical support for
assistance.
7. If the second device does
operate properly, the first
device may not be compatible
with the USB-400FO.
USB device
is attached to
Receiver USB
port but Receiver
device LED is off
A USB device must have
the appropriate driver
installed on the computer
operating system
1. Install the required
USB device driver on the
computer operating system
prior to attaching the USB
device to the Receiver unit.
Please see your USB device
manufacturer’s website for
details.
2. Consult your USB device
documentation and power
your USB device with the
additional, USB device
manufacturer supplied, power
supply (if available).

13
TROUBLESHOOTING THE USB-400FO EXTENDER
PROBLEM CAUSE SOLUTION
Device LED is
orange and units
are no longer
functioning.
Overcurrent condition has
occurred because USB
device draws more power
than can be supplied
per USB specification
(500mA).
1. Power cycle Receiver.
LED Host and
LINK LEDs on
Sender/Receiver
units blink
intermittently.
Firmware mismatch
between the Sender and
Receiver.
1. Use a different Sender/
Receiver pair which have the
same firmware revision.
2. Upgrade the Sender/
Receiver firmware, contact
technical support for
assistance.

14
SPECIFICATIONS
USB 2.0 device support.............................................................................480Mbps
USB Input Connector....................................................................................Type B
USB Output Connector..................................................................................Type A
Link Connector..................................................................................Fiber, Type LC
Power Supply.................................................................................................5V DC
Dimensions (Sender)..............................................................4” W x 3” D x 1.25” H
Dimensions (Receiver)...........................................................4” W x 3” D x 1.25” H
Shipping Weight...............................................................................................2 lbs
Operating temperature range.....................................................................0 - 50 °C
Range.........................1640ft (500m) over 50/125m Multi-Mode Fiber optic cable

15
WARRANTY
Gefen warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen is notified within two (2)
years from the date of shipment, Gefen will, at its option, repair or replace the
equipment, provided that the equipment has not been subjected to mechanical,
electrical, or other abuse or modifications. Equipment that fails under conditions
other than those covered will be repaired at the current price of parts and labor in
effect at the time of repair. Such repairs are warranted for ninety (90) days from
the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including
without limitation, any implied warranty or merchantability or fitness for any
particular purpose, all of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from
Gefen.
3. Copper cables are limited to a 30 day warranty and cables must be in their
original condition.
The information in this manual has been carefully checked and is believed to
be accurate. However, Gefen assumes no responsibility for any inaccuracies
that may be contained in this manual. In no event will Gefen be liable for
direct, indirect, special, incidental, or consequential damages resulting from
any defect or omission in this manual, even if advised of the possibility of such
damages. The technical information contained herein regarding the features and
specifications is subject to change without notice.
For the latest warranty coverage information, please visit Gefen’s Warranty web
page at http://www.gefen.com/kvm/aboutus/warranty.jsp
PRODUCT REGISTRATION
Please register your product online by visiting Gefen’s web site at
http://www.gefen.com/kvm/Registry/Registration.jsp

*ma-USB-400FON*
20600 Nordhoff St., Chatsworth CA 91311
1-800-545-6900 818-772-9100 fax: [phone]
www.gefen.com [email protected]
Rev A5
Pb
